LACUS11xxx and LYCUS11xxx 1.5" ColorLogic lights can be used in Universal ColorLogic mode or
Omni Direct mode. For Omni Direct mode, the lights must be built after June 2018 and used with an
OmniLogic or OmniHub pool controller (page 10).

Setting Brightness

How to change brightness:
1. Turn light on and wait 15 seconds for show/color to launch.
2. Turn off light for between 11-15 seconds, then turn on.
3. Turn off light for between 11-15 seconds, then turn on.
4. Turn off light for between 11-15 seconds, then turn on.
5. The light should blink once or twice indicating which brightness setting is in use. Refer to the
table below:
6. If you would like to change the setting, turn lights off and on 4 times quickly. The new bright-
ness setting should be indicated.
7. When the desired brightness has been selected, remove power from the lights for at least one
minute.
8. The light will restart with the desired brightness the next time it is turned on.

Operating the ColorLogic

The ColorLogic light is controlled through power-cycling: a method of changing light programs which
requires no special controller or interface. To activate the light, simply turn on the switch. To deac-
tivate the light, turn off the switch. To advance to the next light program (fixed color or color show),
turn the switch off, then back on within 10 seconds.
When the light has been off for over 60 seconds, and is first turned on, it will come on to white for 15
seconds for quick clear view of your pool, then go to the last fixed color or color show it was running.

Light Synchronization

If your pool or spa has multiple Hayward ColorLogic LED lights, they may be operated independently,
or they can be easily synchronized so they will all display the same colors and shows at the same
time. For light synchronization, all lights must be wired to the same switch. Once installed, all lights
should be automatically synchronized, however, if they get out of sync, they can be re-synchronized
easily.
To re-synchronize your lights, start with the lights off and follow the steps below:
1. Turn lights on.
2. Turn off light for between 11-15 seconds,.
3. Turn lights on.
9
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

Operation

(LAWUS11xxx, LACUS11xxx and LACUN11xxx models only)
Mode
100% Brightness
50% Brightness
Indication
single blink red
double blink red
