Hayward Universal ColorLogic Installation And Operation Manual

Led light fixtures

Hide thumbs Also See for Universal ColorLogic:

Replacement manual (2 pages)

Quick reference manual (2 pages)

Owner's manual (16 pages)

Quick Links

ColorLogic

Installation and Operation Manual

Universal

and CrystaLogic

LED Light Fixtures

LPCUS11xxx, LPCUN11xxx

LSCUS11xxx, LSCUN11xxx

LPLUS11xxx, LSLUS11xxx

LPWUS11xxx

Pour obtenir le manuel de l'usager

en Francais consultez www.hayward-pool.ca.

Hayward Pool Products

620 Division Street, Elizabeth NJ 07207

www.hayward.com

USE ONLY HAYWARD GENUINE REPLACEMENT PARTS

Contents

Safety Instructions..........2

Introduction....................3

Installation.....................4

Replacement Parts.........11

Operation......................12

Troubleshooting............13

Warranty........................14

Registration Card...........15

092467 RevA

Need help?

Do you have a question about the Universal ColorLogic and is the answer not in the manual?

Questions and answers

Summary of Contents for Hayward Universal ColorLogic

Page 1: Table Of Contents
Replacement Parts..11 Operation......12 Troubleshooting....13 Warranty......14 Registration Card...15 LPCUS11xxx, LPCUN11xxx LSCUS11xxx, LSCUN11xxx LPLUS11xxx, LSLUS11xxx LPWUS11xxx Pour obtenir le manuel de l’usager en Francais consultez www.hayward-pool.ca. Hayward Pool Products 620 Division Street, Elizabeth NJ 07207 www.hayward.com USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 2: Safety Instructions
The luminaire is firmly secured to the niche and cannot be removed without the use of a tool.  The niche is properly bonded UNLESS a Hayward Universal ColorLogic Niche is used.  The luminaire has been installed by qualified personnel in compliance with the National Electrical Code (NEC) or Canadian Electric Code (CE Code) and any applicable local codes and/or regulations.
Page 3: Introduction
5. Offers spectacular brilliant light with low power consumption. Uses up to 86% less energy than a typical incandescent pool light. The 12 volt Hayward Universal ColorLogic and CrystaLogic LED (light-emitting diode) underwater lighting fixtures you have purchased are UL Listed to be installed in all Hayward or any other manufacturer’s light fixture housing (niche).
Page 4: Installation
Install Niche (new installations) NOTE: For installation of Hayward niches, see installation instructions provided with the unit. The light fixture must be installed in or on a wall of the pool or spa with the top of the lens not less than 4 inches (10 cm) below the normal water level of the pool except when the fixture is installed in an area of the swimming pool that is not used for swimming.
Page 5 When using a wallmount low voltage transformer, a junction box should be installed to make the connection to the pool/spa light. If using more than one light, an adequate amount of junction boxes must be installed. Alternatively, Hayward low voltage junction box transformer kits (LTBUY11H65) can be used when in-line transformers are desired.
Page 6 Twist the light fixture clockwise until it firmly locks. The mounting hole should now be at the 12 o’clock position (Figure 2). Install the trim ring by positioning the HAYWARD logo at the 11 o’clock position onto the light fixture. Twist the trim ring clockwise until it firmly locks.
Page 7 Hayward website for the very latest compatibility information. In the interest of improving our products, if you find a niche that we have not listed or if you find that our list is inaccurate, please contact Hayward and provide feedback. We will send you a small gift in exchange for you time.
Page 8 For some installations into Pentair niches, the plastic spacer must be used. ® For some installations into Sta-Rite and SwimQuip niches, the bottom tab may need to be removed. ® ® USE ONLY HAYWARD GENUINE REPLACEMENT PARTS...
Page 9 Install Wiring using a Wallmount Transformer A suitable transformer must be installed which is agency listed for low-voltage swimming pool and spa lights (Hayward LTBUY11300, Intermatic model ® PX100/PX300, or equivalent). The transformer must be rated at or above the total wattage used by all attached light fixtures. Up to four Universal Col- orLogic/CrystaLogic LED lights (three pool lights max.) can be connected to a single Hayward LTBUY11300 transformer.
Page 10 Install Wiring using a Hayward Junction Box Transformer Hayward offers pool/spa light transformers designed to fit into various manufacturer’s junction boxes. Refer to the table on this page to determine which model transformer will fit you type of junction box. These transformers are designed to power a single Hayward ColorLogic/CrystaLogic LED light.
Page 11: Replacement Parts
Pro Logic Controller. When using network control, custom colors and custom light shows can be programmed for each or all lights. An LKBUN1000 is required for each transformer in use and is designed to install into the Hayward LTBUY11300 300 Watt and Hayward Junction Box transformers. Refer to the LKBUN1000 installation manual for mounting and wiring instructions.
Page 12: Operation
“seen” as another ColorLogic 4.0 light and will operate in the same manner as the others. ColorLogic 2.5 & earlier mode: Use this mode when installing your new light in systems with ColorLogic 2.5 & below lights. The Universal ColorLogic/ CrystaLogic light will be “seen”...
Page 13: Troubleshooting
SOLUTION: Be sure that you power-cycle the light for less than 10 seconds. PROBLEM: Multiple lights are not correctly synchronized. SOLUTION: Verify that the Universal ColorLogic/CrystaLogic light is in the proper mode (page 12). Follow the steps in these instructions to re-synchronize the lights.
Page 14 The express limited warranty above constitutes the entire warranty of Hayward Pool Products with respect to its’ pool products and is in lieu of all other warranties expressed or implied, including warranties of merchantability or fitness for a particular purpose. In no event shall Hayward Pool products be responsible for any consequential, special or incidental damages of any nature.
Page 15: Warranty
 Please include me on all e-mail communications regarding Hayward Equipment or promotions. Please include me on all e-mail communications regarding Hayward Equipment or promotions. Mail to: Hayward Pool Products, 620 Division Street, Elizabeth, NJ 07207 Attn: Warranty Dept or REGISTER YOUR WARRANTY ONLINE AT WWW.HAYWARD.COM...
Page 16 Hayward is a registered trademark and ColorLogic and CrystaLogic are trademarks of Hayward Industries, Inc. © 2012 Hayward Industries, Inc. All other trademarks not owned by Hayward are the property of their respective owners. Hayward is not in any way affiliated with or endorsed by those third parties.
