Advantech PCM-9374 Startup Manual

PCM-9374 3.5'' SBC with VIA CPU, Audio, VGA/
LCD & 2 LAN
Startup Manual
Packing List
Before you begin installing your card, please make sure
that the following materials have been shipped:
• 1 PCM-9374 SBC
• 1 Startup manual
• 1 Utility CD
• 1 Mini jumper pack
• 1 Audio cable
• 1 IDE 44 pin
• 1 USB 2 port cable
• 1 Parallel port cable
• 1 Keyboard/Mouse cable
• 1 serial port cable
• 1 ATX power cable 20P-12P
cable
If any of these items are missing or damaged, contact your
distributor or sales representative immediately.
Note 1: For detailed contents of the PCM-9374, please
refer to the enclosed CD Disc or disk (in PDF for-
mat).
Note 2: Acrobat Reader is required to view any PDF file.
Acrobat Reader can be downloaded at:
http://www.adobe.com/products/acrobat/
readstep2.html (Acrobat is a trademark of Adobe.)
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/eplatform
For technical support and service, please visit our
support website at:
http://www.advantech.com/support
This manual is for the PCM-9374 Series Rev. A1.
Part No. 2006937401
1 PCM-9374 Startup Manual
Standard SBC Functions
• CPU: Embedded low power VIA Eden 400/667 MHz or
p/n: 9689000002 • System Memory: One 200 pin SODIMM socket, sup-
p/n: 1703100152
• 2nd Cache Memory: 64 KB on the Eden processor
p/n: 1701440351
• System Chipset: VIA CLE266 100/133MHz FSB
p/n: 1703100121
• BIOS: Award 2Mbit Flash BIOS
p/n: 1700260250
• Watchdog Timer: 1-62sec, 62 level timer intervals sys-
p/n: 1700060202
p/n: 1701140201
• Expansion Interface: PCI-104
p/n: 1700000265
• Battery: Lithium 3V/210 mA
• Power management: ACPI 1.0B
• Enhanced IDE interface: One channels supports up to
• Serial ports: Two serial RS-232 ports, COM1: RS-232,
• Parallel port: One parallel port, supports SPP/EPP/
• Keyboard/mouse connector: Supports one standard
• Audio: Support AC97 Audio stereo sound
• USB: Five USB 2.0 compliant universal serial bus ports
Solid State Disk
• Supports one 50-pin socket for CFC type I/II
VGA/LCD Interface
• Chipset: VIA CLE266 Twister chip with S3 Graphics
• Memory Size: 8/16/32/64 MB
• Resolution:
• LCD Interface: support 24-bit TTL interface for TFT
• LVDS: support 24-bit LVDS interface(optional BIOS
• Display Mode: CRT+LCD
Ethernet interface
• Chipset:
• Speed: 10/100 Mbps (optional)
• Interface: Two RJ45 connectors
• Standard: IEEE 802.3u 100 Base-T Fast Ethernet com-
2nd Edition
Sep. 2005.
Specifications
VIA C3-LP 1GHz Processor
VIA Eden 400MHz
VIA Eden 667MHz
VIA C3-LP 1GHz
port DDR 200/266 SDRAM
tem reset
two EIDE devices. BIOS auto-detect, PIO Mode 3 or
Mode 4, supports UDMA 33 mode
COM2: RS-232/422/485
ECPmode
PC/AT keyboard and a PS/2 mouse
UniChrome IGP 2D/3D/Video Accelerator
CRT Mode: 1400 x 1050@32bpp(85Hz)
LCD Mode: 1600 x 1200@32bpp(60Hz)
LCD
support)
10/100Mbps RealTek RTL8100
patible Build-in boot ROM in Flash BIOS
PCM-9374F-J0A1
PCM-9374F-M0A1
PCM-9374F-S1A1
