Advantech PCM-9370F Startup Manual

PCM-9370F Transmeta Crusoe
TM5400 CPU, 64 MB memory, VGA/LCD & Ethernet
Startup Manual
Packing List
Before you begin installing your board, please make
sure that the following materials have been shipped:
• 1 PCM-9370 all-in-one single board computer
• 1 startup manual
• 1 utility disk/CD driver, and manual (in PDF format)
• 1 2.5" IDE flat cable, 44-pin to 44-pin
(part no. 1700060202)
• 1 keyboard / PS2 mouse cable
(part no. 170100250)
• 1 secondary serial port cable
(part no. 1701140201)
• 1 parallel cable (part no. 1700260250)
• 1 floppy cable, for 3.5" FDD only
(part no. 1701340603)
• 1 USB cable (part no. 1703100260)
• 1 set of spare mini jumpers
• 1 set of spare screws for PC/104 module connect
If any of these items are missing or damaged, contact
your distributor or sales representative immediately.
Note 1: For detailed contents of the PCM-9370F
please refer to the enclosed CD-ROM or
disk (in PDF format).
Note 2: Acrobat Reader is required to view any PDF
file. Acrobat Reader can be downloaded at:
www.adobe.com/Prodindex/acrobat/
readstep.html
(Acrobat is a trademark of Adobe.)
Note 3: Windows 98 will not display "It is now safe
to turn off your computer" when users are
using an AT power supply and have the
ACPI function enabled. It is safe to turn off
the computer at this time.
For more information on this and other Advantech
products, please visit our website at:
http://www.advantech.com
http://www.advantech.com/epc
For technical support and service, please visit our support
website at:
http://support.advantech.com
This manual is for the PCM-9370F Rev. A101 or higher.
Part No.2006937011
Printed in Taiwan
®
Specifications
Standard SBC Functions
• CPU: Embedded Transmeta
processor
• BIOS: AWARD 256 KB Flash memory
• System memory: 64 MB system memory on 1
16 MB used for Crusoe chip. 2
MB SDRAM
• Enhanced IDE interface: Supports up to two EIDE
devices. BIOS auto-detect, PIO Mode 3 or Mode 4
transfer, Ultra DMA33 mode (ATA-4) up to 33 MB/sec
• FDD interface: Supports up to two FDDs
• Serial ports: One serial RS-232 port, one serial
RS-232/422/485 port
• Parallel port: One parallel port, supports
SPP/EPP/ECP mode
• Infrared port: Shared with COM2. Transfer rate up to
115 kbps
• Keyboard/mouse connector: Mini-DIN connector
supports standard PC/AT keyboard and PS/2 mouse
• USB interface: Two USB ports, USB 1.1 compliant
• Power management: Supports power saving modes
including Normal/Standby/Suspend. APM 1.1
compliant
• Watchdog timer: 255 level timer intervals from 12 -
510 seconds.
• Expansion: PC/104 plus connector for ISA and PCI
control board.
VGA/LCD Interface
• Chipset: SMI Lynx 721 4 MB on chip option 8 MB
VGA memory
• Interface: PCI interface, 128-bit engine
• Display mode: Flat panel displays up to 800 x 600 @
24 bpp, 1024 x 786 @ 24 bpp. CRT monitors up to
1024 x 768 @ 24 bpp, 1280 x 1024 @ 24 bpp
• Supports 18/24/36/48 bit TFT LCD, STN and Mono LCD
• Dual display: Supports dual 18/24 bit TFT LCD or CRT
and LCD Display under Windows
Audio Function (optional)
• Chipset: VIA 82C868A
• Audio controller: AC97 version 2.0 compliant
interface
2nd Edition
• Audio interface: Supports Microphone in, Line in,
May 2001
Line out and CD Audio in via optional PCM-231AV
SBC with
®
Crusoe TM5400-500
nd SODIMM socket accepts up to 256
®
PCM-9370F Startup Manual
st
SODIMM with
98/NT/2000.
1
