Devatec AC4 Instructions For Use

Table of Contents

Download this manual

Description:

The centrifugal AC4 humidifier is operating with adiabatic

effect : it transforms water into a very fine mist which is

immediately absorbed by the air. This method allows to

humidify and cool at the same time.

It can be easily installed on a level surface.

All these features, with simple and robust construction, make

this humidifier ideal for a variety of applications.

Dimension

Weight

Power supply

Power consumption

Humidity capacity

Coverage

Colour

310x310x480 mm

7Kg

230V/50Hz

70W

Up to 4.5l/h

100-150m²

White

Table of Contents

Do you have a question about the AC4 and is the answer not in the manual?

Page 1 Description: The centrifugal AC4 humidifier is operating with adiabatic effect : it transforms water into a very fine mist which is immediately absorbed by the air. This method allows to humidify and cool at the same time. It can be easily installed on a level surface.
Page 2: Water Connection
Plug the unit directly into an electrical outlet for evaluation. Listen for a smooth, quiet operation. Motor shaft should be centered and vertical. Make any necessary adjustments. After evaluation, connect AC4 to desired control device as you see options below;...
Page 3: Troubleshooting
**Operation** WARNING : designed for atomizing water only !!! Don’t use in any case flammable, toxic or corrosive liquids. Operating the unit with the fogging head will provide directionnal fogging output and a drier fog. For a maximum fogging and circulation, operate unit without the lower housing as well as upper housing and fogging head.
Page 4 +33 (0)2 35 83 06 44 ou +33 (0)2 35 83 03 86 tel. 02 35 04 61 41- fax. +33 (0)2 35 85 36 72 fax. +33 (0)2 35 85 36 72 Email: france@devatec.com - www.devatec.com Email: export@devatec.com - www.devatec.com...
