Assembly Instructions

Step 3:
Attach side panels (8) and
Step 4:
Note ：the base's direction
16
Attach the wing nut ( d ) to base (16).
Attach base (16) by rotating to vertical position and lowering it into the center of the side panels.
Rotate base (16) to horizontal position and attach with M6x25 (b) screws – 4pc.
Attach the control knob (6). Please be mindful of the direction of the knob ( 6 ) when you install it.
Finally tighten all screws from step 1 to step 4 .
8
side panel (
16
Page 9 of 20
11) with M6X12 (a) -12 pcs.
Note ：the base's direction
8
11
6
b
