Assembly Instructions
& User's Manual
Model No: JS-OFT-Z02A,JS-OFT-Z02B
Model No ：WH-T28
FOR OUTDOOR USE ONLY.
KEEP THE INSTRUCTIONS FOR FUTURE REFERENCE.
If you have any question , pls email us at service@joysidefurniture.com.
If you have any question, pls call our customer service telephone: (888) 680-2849.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Legacy Heating JS-OFT-Z02A
Summary of Contents for Legacy Heating JS-OFT-Z02A
- Page 1 Assembly Instructions & User’s Manual Model No: JS-OFT-Z02A,JS-OFT-Z02B Model No ：WH-T28 FOR OUTDOOR USE ONLY. KEEP THE INSTRUCTIONS FOR FUTURE REFERENCE. If you have any question , pls email us at service@joysidefurniture.com. If you have any question, pls call our customer service telephone: (888) 680-2849.
- Page 2 SAFETY INFORMATION DANGER CARBON MONOXIDE HAZARD • This appliance can produce carbon monoxide which has no odor. • Using it in an enclosed space can kill you. • Never use this appliance in an enclosed space such as a camper, tent, car or home. Page 2 of 23...
- Page 3 SAFETY INFORMATION DANGER FLAMMABLE GAS UNDER PRESSURE. LEAKING LP-GAS MAY CAUSE A FIRE OR EXPLOSION IF IGNITED CAUSI NG SERIOUS BODILY INJURY OR DEATH. CONTACT LP GAS SUPPLIER FOR REPAIRS, OR DISPOSAL OF THIS CYLINDER OR UNUSED LP-GAS. WARNING FOR OUTDOOR USE ONLY.* DO NOT USE OR STORE CYLINDER IN A BUILDING, GARAGE OR ENCLOSED AREA.
-
Page 4: Table Of Contents
Table of Contents Warnings …………. Hardware and To Parts ...................10 11-13 Assembly Instructions Installing Instructions..………………………………………..14-15 Operating Instructions Lighting..............Cleaning and Care 18-19 Troubleshooting …. 20-21 Care and Maintenance........Warranty Information..........WARNING: Improper installation, adjustment, alteration, service and maintenance can cause injury or property damage. Read all the installation, operating and maintenance instructions thoroughly before installing or servicing this equipment. -
Page 5: Warnings
Warnings WARNING FOR YOUR SAFETY Read these instructions before using this appliance. The appliance must be installed in accordance with the instructions and local regulations. The use of this appliance in enclosed areas can be dangerous and is PROHIBITED. Do the leak test after each changing of cylinder. Never check for leaks with a match or open flame. - Page 6 Warnings DANGER WARNING DANGER indicates an imminently WARNING indicates an imminently hazardous situation which, if not hazardous situation which, if not avoided, will result in death or avoided, could result in death or serious injury. serious injury. CAUTION DANGER CAUTION indicates an imminently hazardous situation which, if not avoided, may result in minor or Do not store or use gasoline or...
- Page 7 Warnings DANGER Solid fuels shall not be burned in this appliance DANGER The maximum inlet gas supply pressure: Max . 250PSI . Min 5PSI DANGER “Do not use this appliance if any part has been under water. Immediately call a qualified service technician to inspect the appliance and to replace any part of the control system and any gas control that has been under water.”...
- Page 8 Warnings You must provide propane gas and propane cylinder. Use a standard 20 lb. propane cylinder only. The hose assembly must be replaced prior to the appliance being put into operation if there is evidence of excessive abrasion or wear, or if the hose is damaged. The replacement hose assembly shall be that specified by the manufacturer.
- Page 9 Hardware Door handle 1 set Wing nut 1 set PREPARATION --Select an area where you will assemble this product. To protect components, choose a smooth non abrasive surface that's free of cracks or openings. --Spread out all parts. --Tighten all hardware connections by hand first. Before completing each step, go back and fully tighten all hardware.
-
Page 10: Parts
Parts List S/N Description Quantity S/N Description Quantity Leg with Tab Leg with Magnet Igniter Housing* Door Handle Regulator/Hose Assembly* Base Side Panel Fire Pit Cover Page 10 of 23... - Page 11 Assembly Step 1: door handle Remove the screws and washer from the door handle ( c ). Attach the door handle ( c ) to door ( 12 ), then tighten the handle. Attach door (12) to leg (10) using M6X25 (b) - 2PC Note：...
-
Page 12: Assembly Instructions
Assembly Instructions Step 3: Attach side panels (8) and side panel ( 11) with M6X12 (a) -12 pcs. Step 4: Note ：the base's direction Note ：the base's direction Attach the wing nut ( d ) to base (16). Attach base (16) by rotating to vertical position and lowering it into the center of the side panels. Rotate base (16) to horizontal position and attach with M6x25 (b) screws –... - Page 13 Assembly Instructions Step 5 Turn unit upright. lace lava rocks. CAUTION: Do Not dump lava rocks out of package. Carefully place lava rocks by hand so that dust will not clog burner. CAUTION: Do Not cover pilot hosing. Note: Lava rocks should be 0.8-2.0 in. (2-5 cm long). Approx. 4.4 lbs (2 kgs) of lava rocks are needed (included).
- Page 14 Installing LP Gas Tank To operate, you will need one precision-filled standard LP grill gas tank with external valve threads. The LP-Gas supply cylinder to be used must be: Constructed and marked in accordance with D.O.T. Specifications for LP-gas cylinders as applicable. Provided with a listed overfilling prevention device.
- Page 15 Installing LP Gas Tank Connection LP gas tank 1. Before connecting, be sure there is no debris caught in the head of the LP gas tank, head of the regulator valve or in the head of the burner or burner ports. 2.
-
Page 16: Operating Instructions
Operating Instructions Checking for leaks *WARNING: Before using this outdoor fireplace, make sure you have read , understand and are following all information provided in the “Warnings” section. Failure to follow those instructions can cause death, serious injury or property damage. Burner connections 1. -
Page 17: Lighting
Lighting CAUTION:Keep outdoor gas appliance area clear and free from combustible material, gasoline and other flammable vapors and liquid. CAUTION:Do NOT obstruct the flow of combustion and ventilation air. CAUTION:Check and clean burner/ venturi tubes for insects and insect nests. A clogged tube can lead to a fire. -
Page 18: Cleaning And Care
Cleaning and Care CAUTION: 1. All cleaning and maintenance should be done when outdoor fireplace is cool and with the fuel supply disconnected. 2. Do Not clean any outdoor fireplace part in a self-cleaning oven. The extreme heat will damage the finish. 3. - Page 19 Cleaning and Care Cleaning surface 1. Wipe surface clean with mild dishwashing detergent or baking soda mixed with water. 2. For stubborn stains, use a citrus-based cleaner and nylon scrubbing brush. 3. Rinse clean with water. 4. Allow to air dry. Before Storing 1.
-
Page 20: Troubleshooting
TROUBLESHOOTING Problem Possible Cause Prevention/Cure Make sure regulator is securely attached to the LP gas LP gas tank valve is closed tank per " Installing LP Gas Tank" section, then turn LP gas tank valve to "ON" Check if LP gas tank is empty. A.If empty exchange, No gas flow refill or replace B.If LP gas tank is not empty, refer to "Sudden drop in gas flow or reduced flame height"... - Page 21 TROUBLESHOOTING Problem Possible Cause Prevention/Cure New burner may have residual Burn outdoor fire pit for 15 minutes and manufacturing oils inspect. Spider webs or inset nest in Flame is yellow or orange Clean burner/venturi tube burner/venturi tube Poor alignment of valve to Ensure/burner/venturi tube is properly burner/venturi...
-
Page 22: Care And Maintenance
CARE AND MAINTAINCE Service: Repair gas passages and associated components should be done only by a qualified service person. Caution: Always allow heater to cool before attempting service. Warranty Information This product has a 1 year guar antee against defects in material and/or workmanship. - Page 23 PACKAGE CONTENTS S/N Description Quantity Description Quantity Leg with Tab Leg with Magnet Igniter Housing* Door Handle Regulator/Hose Assembly* Base Side Panel Fire Pit Cover Page 23 of 23...
