HANDLING:

Care must be taken to avoid damage to any component parts of electrical connectors
during installation and use. Although there are normally no sharp edges, care must be
taken when handling certain components to avoid injury to fingers.

CHARACTERISTICS

Current rating
Voltage rating
Dielectric strength
Micro-switch operating voltage
Micro-switch current rating
Operating temperature
Environmental protection
PowerLock Box weight
Flammability rating
Endurance
MAINTAINENCE
1. Periodic greasing of the O ring seals on the connector ports with Molykote® 3451 is
recommended
2. The PowerLock Box should regularly be inspected for damage, including a visual
inspection of the contacts on PS (Power Source) versions
3. Periodic retention testing of PS (Power Source) contacts using ITT Veam tool T4907 is
recommended to confirm that contact life has not been exceeded

DISPOSAL

After use, the device should be disposed of in accordance with national or local authority
guidelines

MANUFACTURE INFORMATION

ITT Interconnect Solutions
Jays Close,
Viables Estate
Basingstoke
Hampshire
RG22 4BA, UK
Telephone +44 (0)1256 311200
www.ittcannon.com
400 amp or 660 amp (check label for rating)
1000V AC / 1500 DC
9.5Kv dc
125Vac max.
5 amp
-30ºC to +85ºC
IP65 – Environmental protection applies to the 'power connector
ports' only when connectors are mated or the lid is closed and
locked.
Unit with lid – 3.75Kg. approx
Unit without lid – 3.25Kg. approx
UL94-V0
500 connection cycles
Note – Molykote® is a registered trade name of Dow Corning Corporation
