INSTALLATION INSTRUCTIONS
MANROSE 125MM EXTRACT-A-LITE DIFFUSER
CLASSIC AND PRO SERIES
Thank you for selecting our Manrose 125mm Extract-a-Lite Diffuser.
Please read all instructions before commencing installation.
Please ensure the corrrect LED lamp and driver OR Halogen lamp and transformer are used for
replacements. The LED model MUST be replaced with an LED lamp and the Halogen model MUST be
replaced with a Halogen lamp. They are not interchangeable.

Light Specifications:

Clasic LED models: DCT3206 and DC3207
(including driver)
Pro Series LED models: DCT3213 and DCT3214
(including driver)
Driver Input: 220-240 VAC
Driver Output: 12VDC
Lamp MR16: 12V / 3W high power LED, 25
angle
Classic Halogen models: DCT2120 and
DCT2121 (excluding transformer)
Pro Series Halogen models: DCT1519 and
DCT1520 (excluding transformer)
Transformer Input: 220-240 VAC
Output: 12VAC
Lamp MR16: 12V / 50W Halogen, 60
Diagram 1
INSTALLATION
PUB0329 iss:03 10/13
PRO SERIES
DIMENSIONS
0 beam
165mm
0 beam angle
115mm
80mm
When screw is tightened fixing
clip fingers secure the fan
Fixing clip
Fan
chassis
Ceiling board
Screw
C L A S S I C S E R I E S
CLASSIC
DIMENSIONS
165mm
118mm
80mm
