Dialog
Value
Description (continued)
item
V 7.X
Lev0...
Programming lock:
Lev2
Version display with current input level:
0:
only display of operating parameters, no changes possible
1:
only switching points can be set and "max" and "min" memories
2:
release user level (all operating parameters for customer)
LITH
20... 100
Change display brightness 20... 100% (only for units with dot-matrix display)
AOZS
0... 9999
Scale the analog output - start value (e. g. 0 bar = 4 mA)
(only
V 7.X)
AOFS
0... 9999
Scale the analog output - end value (e. g. 400 bar = 20 mA)
((output signal start value always corresponds to the display initial value,
e. g. 0 bar = 4 mA), max. turn-down 4: 1, i. e. at values below 25 % of the
measuring
range the analog output is switched off
Code
000... 999
Enter the code level:
Lev1:
471
Lev2:
740
Lev0:
999
OPT
-----
Display of the unit options stored by the manufacturer Barksdale.
(only
V 7.X)
12
Changes:
(up + down 5 seconds) Lev1 - Lev0
(up + down + M 5 seconds) Lev2 - Lev0
Operating Instructions
Dual Pressure Switch UDS 7
Dual Temperature Switch UTS 7
1
Intended Applications ................................................................................................. 2
2
Safety Instructions ...................................................................................................... 2
3
Standards ..................................................................................................................... 3
4
Warranty/Guaranty ...................................................................................................... 3
5
Installation/Commissioning ........................................................................................ 4
6
Maintenance/Cleaning ................................................................................................. 5
7
Technical Data ............................................................................................................. 6
8
Operation ..................................................................................................................... 8
9
Programming ............................................................................................................... 9
10
User Level Dialog ...................................................................................................... 10
Barksdale GmbH
Dorn-Assenheimer Straße 27
D-61203 Reichelsheim
Phone:
+49 (6035) 949-0
Fax:
+49 (6035) 949-111 and 949-113
email:
info@barksdale.de
Internet: www.barksdale.de
Art. no. 923-1724
Index E, 19.08.2009
Software version: from V 1.X
Specifications are subject to changes
without notice!
1
Advertisement
Table of Contents
Related Manuals for Barksdale UDS 7
Summary of Contents for Barksdale UDS 7
- Page 1 Lev2: (up + down + M 5 seconds) Lev2 - Lev0 Lev0: Intended Applications ....................2 ----- Display of the unit options stored by the manufacturer Barksdale. Safety Instructions ...................... 2 (only Standards ........................3 V 7.X) Warranty/Guaranty ...................... 3 Installation/Commissioning ..................
-
Page 2: Intended Applications
Intended Applications Disposal The dual pressure switch monitors system pressures and has up to two switching outputs and one The sensor must be disposed of correctly in accordance with the local regulations for analog output. electric/electronic equipment. The dual temperature switch monitors the temperature of the medium into which the probe is The switch must not be disposed of with the household garbage! immersed and has up to two switching outputs and one analog output. -
Page 3: Maintenance & Cleaning
Installation/Commissioning Maintenance/Cleaning Maintenance DANGER The pressure/temperature switch requires no maintenance. Only install or uninstall the switch when deenergized (electrically and hydraulically/pneumatically). Cleaning Pressure connection and electrical connection must be carried out by trained or instructed personnel according to state-of-the-art standards. CAUTION The switch must only be installed in systems where the maximum pressure P or the maximum... -
Page 4: Technical Data
Operating and display elements/Dimensions Dimensions in mm Technical Data Dual pressure switch UDS7 UDS 7 UTS 7 Measuring element Piezoresistive pressure sensor with Pt100 (class B) according to approx internal stainless steel diaphragm DIN IEC 751 LEDs (1) Measuring ranges 0…... -
Page 5: Operation
Operation Programming authorized persons. Do not use any hard objects for The switch may be installed and operated only by After switching on with change to the first dialog item. making entries. Change dialog item In case of first commissioning a self-test is performed. The device is menu-operated via three Select the desired dialog item with membrane keys, which must not be touched with any hard objects. - Page 6 Dialog Value Description (continued) 10 User Level Dialog item (xxxx = 125% v. f. s.) ON-2 -1... xxxx Switch-on point for SP2 Dialog Value Description NOTE: if the ON-value is set smaller than the OFF-value you receive a item decreasing switch point evaluation. MENU -1...
