Escape Character Translation

In many IBM host environments, the programmer cannot send an ESC character (ASCII
hex 1B) to the printer from within the application. Your Secure MICR Printer allows you to
define the ESC character as a printable character or a combination of two printable
characters. You can select combinations of 1 or 2 characters which are translated to a Hex
1B when they are sent to the printer.
The command &%STYxxyy$ is used to select the character or character combination. The
pair xx represents the first characters' ASCII hex value, yy represents the second
characters hex value.
Example: The symbols @@ should be translated into the escape character:
&%STY4040$
After this is sent to the printer, anytime an @ @ is received in exact sequence, the pair is
translated into the ESC character (Hex 1B). A single @ would print normally.
If yy is equal to 00, only the first character is used for the escape character.
Example: The symbol @ should translate into the escape character:
&%STY4000$
After this is sent to the printer, anytime an @ is received it is translated into the ESC character.
This means that the printer will never print the @ character. The only invalid single characters
are the & (HEX 26) and a null (00).
Example: &%STY2300$
The printer would translate the number sign (Hex 23) to the ESC character and it would act
on the sequence Esc&l8D which will set line spacing to 8 lines per inch.
If you want to reset the ESC character translation from the previous settings then you can send
the &%STY Command to deactivate the translation.
Example:
Secure MICR Printer User's Guide
July 2003
#&l8D
&%STY0000$
Section 7: IBM Host Programming Features and Examples
Page 33
©
