Solimotion FTR20

Reference operating

conditions

Influence of ambient

temperature

Influences on bulk flow

detection

Endress+Hauser

Performance characteristics

Every application is different in terms of its shapee (such as influential reflexion edges), medium as

well as the properties of the medium (such as attenuation and moisture levels) and therefore always

requires an individual basic setup of the flow indicator.

The ambient temperature has no direct influence on the measuring system (FTR20 is temperature-

compensated internally)�

Distance of FTR20 from the medium

The measuring signal is influenced by the distance between the device and the medium. With

significantly deviating distances, the device should be installed, if possible, such that the distance

is as constant as possible. If this is not possible, the flow indicator must be adjusted under the least

favourable conditions in this case too�

Vibration resistance – continuous load with sliding frequency in accordance with EN 60068-2-6:

• -40 to +80 °C (-40 to +176 °F)

• Excitation: Sine

• Frequency range: 10 to 55 Hz

• Amplitude: 0�75 mm

• Throughput speed: 1 octave per minute

• Test axes: Three directions (X, Y, Z)

• Number of frequency cycles: 20 per axis

• Test duration: Approx� 1 h 38 min per axis

• Test temperature: Room temperature
