COBHAM EXPLORER 540 User & Integrator's Manual page 88

The SIM PIN must be enabled before you can use this feature. See To enable or
Note
disable the use of a SIM PIN on page 79.
To set up the Auto SIM PIN validation feature, do as follows:
1. Under Advanced, select SIM.
2. Select Auto SIM PIN validation.
3. Select Automatically validate SIM PIN on startup.
4. Type in the PIN.
5. Click Save.
If the SIM PIN is changed either using the web interface or AT commands, the Auto
Note
SIM PIN validation feature is disabled and must be reenabled manually.
If the SIM card is replaced without disabling the Auto SIM PIN validation feature, and
Note
the first verification of the SIM PIN fails, the Auto SIM PIN validation feature will
disable itself to avoid locking the SIM card.
SIM lock
The SIM lock feature can be used by suppliers to lock your SIM card to a specific provider or
distribution partner. For further information, contact your supplier.
SIM PIN for cellular network
See Optional: To set up cellular network for data on page 93.
To save or load a configuration
If you need to reuse a configuration in other terminals of the same type, you can save your
current configuration to a file, which can then be loaded into the other terminal(s).
Be aware that if the terminals have different software versions, some of the settings
Note
may be different than expected. If possible, use the same software version in the
terminals.
To save a configuration to a file
To save the current configuration of your EXPLORER 540 to a file on your computer, do as
follows:
1. In the Advanced page, click Load/save configuration.
2. Click Save configuration.
The configuration file is saved in the EXPLORER 540.
98-148232-E
Chapter 4: Configuration with web interface
Advanced settings 80
