  • Page 1 SAILOR XTR GX-R2 Installation manual...
  • Page 2 1. Connect a PC to the front LAN connector of the Below Deck Unit (BDU). 2. Open an Internet Browser and type the default IP address of the SAILOR XTR GX-R2: https://192.168.0.1. 3. Bypass the admin password by pressing the left arrow key on the BDU for 5 seconds.
  • Page 3 SAILOR XTR GX-R2 4.5W/9W Installation manual SAILOR 1000 XTR GX-R2 and SAILOR 600 XTR GX-R2 Document number: 98-175666-C Release date: 17 May 2022...
  • Page 4 SW Technology/GPL Compliance, Cobham SATCOM (Thrane & Thrane A/S), Lundtoftegaardsvej 93D 2800 Lyngby DENMARK Write "source for product SAILOR XTR GX-R2" in the memo line of your payment. This offer is valid to anyone in receipt of this information. https://www.cobhamsatcom.com/legal/free-and-open-source-software-foss/ 98-175666-C...
  • Page 5 Safety summary The following general safety precautions must be observed during all phases of operation, service and repair of this equipment. Failure to comply with these precautions or with specific warnings elsewhere in this manual violates safety standards of design, manufacture and intended use of the equipment.
  • Page 6 User access to the interior of the BDU is prohibited. Only a technician authorized by Cobham SATCOM may perform service - failure to comply with this rule will void the warranty. Access to the interior of the Above Deck Unit is allowed. Replacement of certain...
  • Page 7 Cobham SATCOM. Grounding, cables and connections To minimize shock hazard and to protect against lightning, the equipment chassis and cabinet must be connected to an electrical ground. The BDU must be grounded to the ship.
  • Page 8 About this manual Intended readers This is an installation manual for the SAILOR XTR GX-R2 system intended for installers of the system and service personnel. Personnel installing or servicing the system must be properly trained and authorized by Cobham SATCOM. It is important that you observe all safety requirements listed in the beginning of this manual, and install the system according to the guidelines in this manual.
  • Page 9 Some materials can be dangerous. CAUTION! Do not use materials that are not equivalent to materials specified by Cobham SATCOM. Materials that are not equivalent can cause damage to the equipment. CAUTION! The system contains items that are electrostatic discharge sensitive.

  • Page 10: Table Of Contents

    Table of contents Chapter 1 Introduction SAILOR XTR GX-R2 system ................1-1 Part numbers and options ................ 1-10 Chapter 2 Installation What’s in the box ..................2-1 Site considerations ..................2-2 Installation of the ADU (S1000 antenna) ..........2-17 Installation of the ADU (S600 antenna) ........... 2-21 Installation of the BDU ................
  • Page 11 Table of contents Specifications SAILOR 1000 XTR GX-R2 ............. A-2 Specifications SAILOR 600 XTR GX-R2 ............A-3 Patents ......................A-4 Outline drawings ..................A-5 Appendix B Dual antenna solution Introduction ....................B-1 Installation of the dual antenna solution ..........B-1 Configuration of the dual antenna solution ..........

  • Page 12: Chapter 1 Introduction

    • Part numbers and options 1.1 SAILOR XTR GX-R2 system The SAILOR XTR GX-R2 is a unique stabilized maritime GX antenna system operating in the Ka-band (17.7 to 30 GHz). It is used with the Global Xpress service from Inmarsat, delivering consistent high-performance download speeds of up to 50 Mbps and 5 Mbps over the uplink.
  • Page 13 SAILOR XTR GX-R2 system Above Deck Unit (ADU) Below Deck Unit (BDU) GX Modem Unit (GMU) Figure 1-2: ADU, BDU and GMU System features Single 50 Ohm coax cable for the ADU  One Touch Commissioning  GX-R2 support, wideband and dual polarisation.
  • Page 14 BDU. 1.1.1 Above Deck Unit (ADU) The SAILOR XTR GX-R2 ADU is a 103cm or 65 cm VSAT stabilized tracking antenna, consisting of a suspended antenna with a standard global RF configuration. It is stabilized by heavy-duty vibration dampers in 3-axis and can be used in environments with elevations of -20°...
  • Page 15 SAILOR XTR GX-R2 system Modules in the ADU (SAILOR 1000 XTR GX-R2) Figure 1-3: SAILOR 1000 XTR GX-R2 ADU modules 1/2 1. GNSS module (GPS, GLONASS, BEIDOU). 2. XTR Antenna Control Module (ACM). 3. ADU power on/off. 4. Cross elevation motor.
  • Page 16 SAILOR XTR GX-R2 system Figure 1-4: SAILOR 1000 XTR GX-R2: ADU modules 2/2 8. Azimuth motor. 9. Azimuth zero reference module. 10. Rotary joint. 11. Feed horn. 98-175666-C Chapter 1: Introduction...
  • Page 17 SAILOR XTR GX-R2 system Modules in the ADU (SAILOR 600 XTR GX-R2) Figure 1-5: SAILOR 600 XTR GX-R2)ADU modules 1/2 1. GNSS module (GPS, GLONASS, BEIDOU). 2. XTR Antenna Control Module (ACM). 3. ADU power on/off. 4. Cross elevation motor.
  • Page 18 SAILOR XTR GX-R2 system Figure 1-6: SAILOR 600 XTR GX-R2: ADU modules 2/2 8. Azimuth motor. 9. Azimuth zero reference module. 10. Rotary joint. 11. Feed horn. 12. Azimuth motor driver. 1.1.2 Below Deck Unit (BDU) The BDU contains all user interfaces and manages all communication between the ADU and the connected VSAT modem, a connected PC and an optional FleetBroadband service communication line.
  • Page 19 SAILOR XTR GX-R2 system BDU connector ID Type Function NMEA0183 RJ-45 Vessel gyro input GPIO RJ-45 General Purpose I/O LAN 1 RJ-45 VSAT modem LAN 2 RJ-45 User LAN LAN 3 RJ-45 User LAN LAN 4 RJ-45 User LAN RS-232...
  • Page 20 For a list of satellite type approvals see the SAILOR XTR GX-R2 product page at www.cobhamsatcom.com. 1.1.5 Service activation Before you can start using the SAILOR XTR GX-R2, you need to activate the system for VSAT service. Contact your service provider for activation. 98-175666-C...

  • Page 21: Part Numbers And Options

    Part numbers and options 1.2 Part numbers and options 1.2.1 Applicable model and part numbers The following model and part numbers are available for the SAILOR XTR GX-R2 system: Part number Model number Description 407509C-00540 7509C SAILOR 1000 XTR GX-R2 4.5W ADU...

  • Page 22: Chapter 2 Installation

    Chapter 2 Installation This chapter has the following sections: • What’s in the box • Site considerations • Installation of the ADU (S1000 antenna) • Installation of the ADU (S600 antenna) • Installation of the BDU • Installation of the modem •...

  • Page 23: Site Considerations

    Site considerations WARNING! To avoid electric shock, do not apply power to the system if there is any sign of shipping damage to any part of the front or rear panel or the outer cover. Read the safety summary at the front of this manual before installing or operating the system.
  • Page 24 For optimum system performance, follow the guidelines on where to install or mount the different units of the SAILOR XTR GX-R2 system. You do not have to align the ADU with the bow-to-stern line of the ship. When configuring the SAILOR XTR GX-R2 system, the azimuth calibration provides the correct azimuth of the ADU.
  • Page 25 Site considerations Ship motion and offset from the shipʼs motion centre When installing the ADU you must consider the mounting height carefully. The higher up the ADU is mounted, the higher is the linear g force applied to the ADU. The g force also depends on the roll period of the ship, see Table 2-2.
  • Page 26 Site considerations 3. Elevate the ADU by mounting it on a mast or on a mounting pedestal on a deck or deck house top to avoid obstruction. Figure 2-2: Signal degradation because of obstructing objects, look angle -18° to 118° Blocking zones –...
  • Page 27 Site considerations Figure 2-4: Blocking zone with no-transmit zones, elevation angle (example) 2.2.3 ADU mast flange and mast length The system is designed for harsh environmental conditions at sea, both in regards to vibration amplitude and speed. The antenna system performs optimally when mounted on a properly designed foundation.
  • Page 28 Site considerations ADU mast flange (S1000 antenna) For best performance, do as follows: 1. Provide a mast flange with a minimum of four gusset plates. 2. Fit the top of the ADU mast with a flange with clearance holes matching the bushings in the radome and with minimum 4 gusset plates.
  • Page 29 Site considerations Figure 2-7: ADU, bottom view (S1000) ADU mast flange (S600 antenna) For best performance, do as follows: 1. Provide a mast flange with a minimum of four gusset plates. 2. Fit the top of the ADU mast with a flange with clearance holes matching the bushings in the radome and with minimum 4 gusset plates.
  • Page 30 Site considerations 3. Make sure that the flatness on the mast mount plateau is below 3,0 mm. Figure 2-9: ADU mast flange, recommended flatness on the mast mount plateau 4. Use the dimensions in the following figure to prepare the mast flange for mounting of the ADU.
  • Page 31 Mast length (S1000 antenna) The below tables show the minimum dimensions for a SAILOR XTR GX-R2 ADU (S1000 ) mast with and without stays/braces. Note that the values are only guidelines - always consider the environment and characteristics of the ship before deciding on the mast dimensions.
  • Page 32 Site considerations Max. free Outer Wall Outer Thickness Mast with 3 braces mast length Diameter Thickness Diameter for for brace (steel), (m) (mm) (mm) brace (mm) (mm) 30-40° Table 2-4: Mast dimensions with 3 braces (S1000) Mast length (S600 antenna) Outer Max.
  • Page 33 Site considerations consider the environment and characteristics of the ship before deciding on the mast dimensions. Mast Outer Wall Max. free mast Weight without Diameter Thickness length (steel), (m) (kg/m) braces (mm) (mm) 10.8 13.9 17.0 20.2 23.3 26.4 Table 2-6: Mast dimensions without braces (S600 antenna) Brace Outer Thicknes...
  • Page 34 Site considerations 2.2.4 Interference from radar, GPS/GNSS, L-band and other transmitters Do not place the antenna close to interfering signal sources or receivers. For Note allowed distances to other transmitters see Figure 2-13. It is recommended to test the total system by operating all equipment simultaneously and verifying that there is no interference.
  • Page 35 Even at distances greater than “d min.” in the previous section the radar might still be able to degrade the performance of the SAILOR XTR GX-R2 system. The presence of one or more S or X-band radars within a radius up to 100 m may cause a minor degradation of the Ka band connection.
  • Page 36 If L-band antennas are installed on the same vessel, keep a minimum distance of 3 meters from the SAILOR XTR GX-R2 ADU to the L-band antenna. The following figure shows the minimum recommended distance to other transmitters in the frequency range below 1000 MHz.
  • Page 37 Site considerations 2.2.6 Alternative ADU cable The allowed RF loss in the antenna cable is determined by the attenuators of the antenna. The electronic design guarantees that minimum 20 dB RF loss @ 1700 MHz (S1000) and 20 dB RF loss @ 1950 MHz (S600) and maximum 35 dB RF loss @4450 MHz in the antenna cable will work, but typically an RF loss of about 25 dB will be within the limits of the cable calibration.

  • Page 38: Installation Of The Adu (S1000 Antenna)

    Installation of the ADU (S1000 antenna) 2.3 Installation of the ADU (S1000 antenna) The following sections describe the installation and grounding of the ADU. The ADU is shipped fully assembled. Install it on the mast and attach the ADU cable. WARNING! Use a strong webbed sling with a belt to lift the ADU without damaging the radome.
  • Page 39 Figure 2-16: Free space for access to the service hatch You do not need to align the ADU with the bow-to-stern line of the ship. When configuring the SAILOR XTR GX-R2 you make an automated azimuth calibration to obtain the correct azimuth of the ADU.
  • Page 40 Installation of the ADU (S1000 antenna) 6. With a crane lift the ADU off the wooden platform and move it on top of the ADU mast. 7. Install the ADU on the mast flange with 4 M12 bolts and washers. Tightening torque value: 30 Nm.
  • Page 41 Installation of the ADU (S1000 antenna) To open the service hatch Do as follows to open the service hatch: 1. With a Torx TX30 screw driver, loosen the 8 screws that keep the hatch in place. 2. Lower the service hatch and let it hang in the 2 strips. Figure 2-20: Opening the service hatch 2.3.2 To ground the ADU...

  • Page 42: Installation Of The Adu (S600 Antenna)

    Use the lifting harness only to lift the antenna. Do not lift other objects or persons with the harness. The lifting harness (Cobham SATCOM part number TT 48-149056) is designed, tested and conforms to the requirements for lifting equipment in DIRECTIVE 2006/42/EC OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 17 May 2006 on machinery, and amending Directive 95/16/EC (recast).
  • Page 43 • Always use all 4 bolts when installing the ADU. You do not need to align the ADU with the bow-to-stern line of the ship. When configuring the SAILOR XTR GX-R2 you make an automated azimuth calibration to obtain the correct azimuth of the ADU.
  • Page 44 Installation of the ADU (S600 antenna) 7. Install the ADU on the mast flange with 4 M10 bolts and washers. Tightening torque value: 30 Nm. 8. Read carefully and follow instructions given in the next section on grounding. 9. Remove the harness as shown in the following figure: Figure 2-24: Removal of the harness 10.
  • Page 45 Installation of the ADU (S600 antenna) 2.4.2 To ground the ADU The ADU must be grounded using one of the mounting bolts. To ground the ADU do as follows: 1. Clean the metal underneath the head of at least one bolt of insulating protective coating and use a serrated washer to obtain a good ground connection.

  • Page 46: Installation Of The Bdu

    Installation of the BDU 2.5 Installation of the BDU The following sections describe the installation and grounding of the BDU. 2.5.1 To install the BDU To install the BDU, do as follows: 1. Slide the BDU into a 1U space in a 19” rack. 2.

  • Page 47: To Connect The Adu, Bdu And Modem

    To connect the ADU, BDU and modem Figure 2-27: Ground stud, GMU 2.7 To connect the ADU, BDU and modem The following sections show how to connect the ADU, BDU and the modem. AC power AC power Figure 2-28: Connection between ADU, BDU and modem 1.
  • Page 48 Integration of a 3rd party IP device 2.8.1 Power connector The power output options are 12 VDC / 2A and 5 VDC / 2A. The physical interface is a Molex 105308 4-pin nano-fit connector on the XTR Antenna Control Module (ACM). Figure 2-29: ADU power on off (left) and ACM 4-pin nano-fit connector 2.8.2 Communication The ACM has four Ethernet LAN ports.
  • Page 49 Integration of a 3rd party IP device Fasten the mounting bracket with 4.5 Nm Figure 2-32: Mounting pattern, measures 2.8.4 Example of a 3rd party device integration The nano-fit connector supplies 12 VDC to power the LTE modem, which interconnects to the antenna system on one of the LAN ports on the ACM.

  • Page 50: Power And Startup

    • Tracking This may take some time (up to a couple of minutes). 4. The SAILOR XTR GX-R2 is ready to be calibrated (for first time power up) or receive data from the VSAT modem (when in normal operation). The LEDs Power and Fail/Pass are steady green, the LED Logon is off.

  • Page 51: Chapter 3 Interfaces

    Chapter 3 Interfaces 3.1 Connector panel of the BDU Figure 3-1: BDU: connector panel 3.1.1 AC input connector Connect the power cable to the AC power connector. Outline (on the BDU) Voltage range 100–240 VAC Earth Table 3-1: AC power connector 3.1.2 ADU connector There is just one cable from the BDU to the ADU.
  • Page 52 Connector panel of the BDU 3.1.3 Rx/Tx connectors for modem Connect the Rx and Tx channels of the modem to the Rx and Tx connectors of the BDU with the 2 supplied Rx/Tx cables (75 Ohm coax, F-F, 1 m). Outline Pin function (on the BDU)
  • Page 53 Connector panel of the BDU To accommodate the gyro cable use the terminal block (DIN Rail Adapter 31-208142- 000). The pin numbers on the adapter are the same as on the RJ-45 plug. Figure 3-2: Gyro input, terminal block NMEA 0183 The NMEA 0183 connection supports IEC 61162-1 and IEC 61162-2.
  • Page 54 Connector panel of the BDU 3.1.5 GPIO RJ-45 connector Outline on BDU I/O Signal Pin function GPIO1 Tx mute (active high) 12 VDC / 500 mA Power output GPIO2 Rx lock (open drain) N/A GPIO3 Future use Ground 12 VDC / 500 mA Power output N/A GPIO4 Future use...
  • Page 55 Connector panel of the BDU 3.1.7 RS-422 RJ-45 connector Use the following connector to connect the BDU to the VSAT modem Outline Signal Pin function Line A RXD (+) Receive data (non- inverting) Line A RXD (-) Receive data (inverting) Line B TXD (+) Transmit data (non- inverting)

  • Page 56: Interfaces Of The Modem

    Interfaces of the modem 3.1.8 LAN connectors The BDU has four Ethernet connectors (type RJ-45), located at the back of the unit, for PC/laptops, routers, wireless access points. LAN port 5 is for service access at the front. Depending on the VSAT modem, one LAN connector may be used for modem control. The maximum cable length per connection is 100 m.
  • Page 57 Interfaces of the modem Outline Pin function (on the BDU) number Inner conductor: 50 MHz clock, Rx/Tx Outer conductor: GND (Shield) Table 3-9: F connector, Rx and Tx, outline and pin assignment 3.2.3 RS-232 and RS-422 connectors The modem has two RS-232 and one RS-422 connector for control information to and from the BDU.
  • Page 58 Interfaces of the modem Outline (on the Pin function modem) Key-line P Reset P Not connected Key-line N Reset N Not connected Table 3-11: RS-422 connector, male, outline and pin assignment, modem 3.2.4 LAN connectors (8 + 2) The modem has 8 Ethernet connectors (type RJ45). Port 1 connects to the BDU and is used for modem control.
  • Page 59 Interfaces of the modem 3.2.6 GMU cables (RS-232 and RS-422) Figure 3-5: GMU cable (RS-422) 98-175666-C Chapter 3: Interfaces...
  • Page 60 Interfaces of the modem Figure 3-6: GMU cable (RS-232) 98-175666-C Chapter 3: Interfaces 3-10...

  • Page 61: Chapter 4 Setup Of The Antenna

    Internet. It must be connected behind a dedicated network security device such as a firewall. If any ports of the SAILOR XTR GX-R2 are exposed to the Internet you must use a strong password as anyone with access and malicious intent...

  • Page 62: Introduction To The Web Interface

    Introduction to the web interface 4.1 Introduction to the web interface Use the built-in web interface of the BDU to set up the SAILOR XTR GX-R2. Use a standard Internet browser. The menus are grouped in three sections: Dashboard, Settings and Service.
  • Page 63 4. Open an Internet browser and enter the IP address of the BDU. The default IP address is http://192.168.0.1. When the login screen is displayed you have verified that the connection to the SAILOR XTR GX-R2 can be established. Figure 4-4: Login There is an admin and a guest login.
  • Page 64 Introduction to the web interface Parameter Description RX RF frequency Receiving transponder frequency LNB LO frequency Block-down Local Oscillator, auto-selected by the modem TX RF frequency Modem transmit frequency BUC LO frequency Block-Down Local Oscillator, depending on antenna hardware Tracking RF Antenna tracking frequency frequency MODEM...
  • Page 65 Introduction to the web interface Parameter Description Azimuth (Relative) Current antenna pointing for relative azimuth Elevation (Relative) Current antenna pointing for relative elevation Polarization skew LNB skew angle to the current satellite SYSTEM INFO BDU part name BDU model BDU serial number BDU serial number, used for service cases Antenna part name ADU model...

  • Page 66: Settings

    Settings 4.2 Settings In this section you can define a VSAT profile, enter navigation input, set the blocking zones and define settings for added third-party equipment mounted in the antenna. You can also set passwords and user permissions. Furthermore you can access the installation wizard.
  • Page 67 Settings 4.2.2 Modem types The following modem types are supported: • SAILOR GX Modem (GMU) • Generic Modem SAILOR GX Modem (GMU) To set up the modem type GX Modem, do as follows: Figure 4-8: Setup of SAILOR GX Modem 1.
  • Page 68 Settings Generic Modem To set up the modem type Generic, do as follows: Figure 4-9: Setup of Generic Modem Use the generic modem profile with any type of single beam VSAT modem. 1. Select the BUC reference. The setting is: TX 50 MHz 2.
  • Page 69 Settings Elevation TX cutoff versus VSAT modem bandwidth and power 1. At Elevation TX cutoff enter the minimum elevation angle for the antenna to function in accordance with ETSI (ETSI EN 302 340) and FCC (FCC §25.205) regulations. • FCC (FCC §25.205): 5 degrees •...
  • Page 70 Settings Bandwidth Nominal modem power 8192 kHz 3° 3° 4° 4° 5° 6° 7° 8° 10° 16384 kHz 2° 2° 3° 3° 4° 5° 6° 7° 8° 32768 kHz 2° 2° 2° 3° 3° 4° 4° 5° 6° Table 4-4: SAILOR 1000 XTR GX-R2 9W: Elevation TX cutoff (in degrees) versus VSAT modem bandwidth and power (Continued) a.
  • Page 71 Settings 4.2.3 Network settings On this page you enter the host name and set up the network settings for the LAN ports of the BDU and the LAN ports of the ADU. Figure 4-10: Settings, Network page (example) Static IP or DHCP Client The default setting for LAN Port 3 is DHCP client.
  • Page 72 Settings Gateway setup If the BDU needs to communicate with network units outside the specified sub-nets, you must specify a default gateway (typically a router). The default gateway can be set as a static IP address. Then set the default gateway source to static and enter the IP address of the default gateway.
  • Page 73 Settings DHCP client Network parameters obtained via DHCP - VLAN 2 Modem User defined VLANS configured by GMU via SNMP controlled Table 4-7: BDU LAN port 2 (Continued) BDU LAN port 3 - mode LAN port 1 Modem: LAN Port 3 assigned to LAN Port 1 VLAN / IP-subnet. LAN port 5 Service: LAN Port 3 assigned to LAN Port 5 VLAN / IP-subnet.
  • Page 74 The VLAN table shows which VLANs are set up per physical Ethernet port on the BDU. U means Untagged, T means Tagged. VLAN 1 through 8 are used internally by the SAILOR XTR GX-R2 antenna Important system. Do not use them with external equipment connected to the LAN ports of the BDU/ACM.
  • Page 75 Settings User defined VLAN's (SNMP from the iDirect Core module / GMU) 12 User defined VLANs are supported. The IDs of the user defined VLANs must be outside the 1-8 range used internal by the SAILOR BDU/ACU switch. (System VLANs, see previous section).
  • Page 76 Settings 4.2.4 Navigation You must set the heading and position before you start the calibration procedure. If you change the heading settings from external to fixed or vice versa you Note must make a new azimuth calibration. 1. Click Settings > Navigation. 2.
  • Page 77 Settings 3. Click Apply. 4. Select the desired position mode. Position mode Description Mode Select one of the following: • GNSS (default) • Manual • External GNSS Select one of the following: • GPS (default) • BEIDOU • GPS + BEIDOU •...
  • Page 78 Settings Tracking for satellite elevation between 5 and 75 degrees When the system has found the satellite and is in pointing mode, the performance of a system with heading input and a system without heading input will be very similar. Note that this is only the case for a satellite elevation range from 5 to 75 degrees.
  • Page 79 Settings With heading input or fixed heading, Inclined Orbit Satellite 1. The antenna starts the acquisition, searches for 10 seconds at the expected position. If RX lock is detected the antenna goes to Tracking. 2. If no RX lock is detected, a box search pattern is started and the positions where RF power can be received are stored.
  • Page 80 Settings 4.2.7 Blocking zones You can define blocking zones, i.e. No TX and RX zones by entering azimuth and elevation angles for each blocking zone. The systemʼs blocking map is built up over some weeks and shows where the actual blocking zones are. This is useful if the antenna looses the signal frequently and you might want to check whether the blocking zones are set up correctly.
  • Page 81 Settings Blocking map for optimization of blocking zones The blocking map is intended as a tool to optimise the blocking zones in order to reduce the antennaʼs downtime. It shows the active blocking zones and an automatic evaluation of the antenna reception. Over time the antenna can determine where the signal is blocked by structures on the ship.
  • Page 82 Settings Figure 4-17: Settings, IoT & management (example) E-mail setup (secure e-mail) To send e-mails from the antenna you must set up some parameters. SMTP port numbers: • Insecure Simple Mail Transfer Protocol: SMTP port number 25. • SMTPS for secure Simple Mail Transfer Protocol: IP port 465. •...
  • Page 83 The SAILOR XTR GX-R2 supports SNMP v2 requests to retrieve configuration and present settings. SNMP is always enabled on all Ethernet interfaces. The SNMP community string is public. The SAILOR XTR GX-R2 offers via SNMP most of the data that are available from the DASHBOARD web pages. Detailed documentation about supported OIDs can be found in the MIB file.
  • Page 84 3. Click Apply. Statistics report This report contains historical information from the SAILOR XTR GX-R2 of up to 1 month. It is sent as a zipped attachment to an e-mail. The file format is a comma separated value file (csv). The report can then be processed in spreadsheet applications, e.g.
  • Page 85 Settings The following parameters are recorded in the statistics report: Parameter Description recorded Host name Host name, entered in the web interface on the page Settings > Network. BDU SN BDU serial number ADU SN ADU serial number SW ver. Software version System type SAILOR 1000 XTR GX-R2 4.5W...
  • Page 86 Settings Parameter recorded Description Carrier rf.rx (GHz) Rx frequency of carrier for this record. Carrier rf.tx (GHz) Tx frequency of carrier for this record. Pol.rx Current Rx and Tx polarization modes Pol.tx Rx Lock (%) Rx locked and logon time, in percent, for the Logon (%) sampling interval.
  • Page 87 It is not possible to connect to the IoT hub or the data stream from external systems. Once the subscription has been purchased from Cobham SATCOM a list of IoT Keys will be provided. Each IoT key is unique and will be bound to the antenna the first time it connects.
  • Page 88 5. Click the icon for saving. At the next login the new password is required. To set up permissions for guest user You can manage user access (guest) to certain functions of the SAILOR XTR GX-R2 system. You can select R/W, R/O or no access to a number of functions. This is useful if you want to protect the system against unintended changes or tampering of the system.
  • Page 89 Settings Figure 4-21: Permissions for guest users To set up the user permissions, do as follows: 1. From the left navigation pane, select Settings > User administration. 2. Click the pen icon for guest 3. For each item under Allow user to: select •...
  • Page 90 Settings 4.2.11 Installation wizard The installation wizard guides you through the necessary steps to set up the antenna. You start the installation wizard from the section Settings. Figure 4-22: Installation wizard 1. Enter the necessary data on each page and click Next. 2.

  • Page 91: Service

    Only qualified service personnel should make a software Note update. 1. Power up the SAILOR XTR GX-R2 system, i.e. switch on the BDU. Wait until the text INITIALISING has disappeared from the BDU display. 2. Connect a PC to he front LAN connector of the BDU.
  • Page 92 You can enter safe mode press left and right key on the BDU while power cycling. To import and export a system configuration If you need to reuse a configuration in another SAILOR XTR GX-R2, you can save the current configuration to a file, which can then be loaded into another SAILOR XTR GX- R2.
  • Page 93 3. At Load config from BDU click Load. 4.3.2 Calibration Before the SAILOR XTR GX-R2 can be used you must select a heading input in order to make an azimuth and cable calibration. The azimuth calibration is required in order to determine the offset of the ADU zero direction to the bow-to-stern line of the ship.
  • Page 94 Service on the calibration page. A cable calibration is required in order to record the cable characteristics of the antenna cable which is used in the fixed gain feature. You must log in as an administrator to do a calibration. Important Figure 4-24: Service - Calibration Azimuth calibration...
  • Page 95 Service 4. Select Enable in the section Azimuth calibration (active satellite profile). 5. Click Apply. 6. Switch on the modem. Azimuth calibration (user controlled) 1. On the page SERVICE > Calibration, in the section Azimuth calibration (user controlled), select User defined in the Satellite drop down list. If you do not want to enter the satellite data on the calibration page you can Note select a dedicated satellite service profile for calibration and select it.
  • Page 96 Service calibration has completed. In case of failure, see the table in the following section for a description of error codes during calibration. It is strongly recommended to verify the result of a calibration Important performed with user defined data. This can be done by making a new calibration on a different satellite and verify that the resulting Azimuth calibration value differs less than one degree.
  • Page 97 This indicates whether the antenna cable and connectors are in good condition and well crimped. The SAILOR XTR GX-R2 is calibrated now. If the calibration failed there will be a message.
  • Page 98 8. The web interface of the iDirect core module will indicate the modem in the network and the modem status is shown in the display in the menu MODEM of the SAILOR XTR GX-R2 web interface. 9. When commissioning is completed, test all subscribed services.
  • Page 99 Service 4.3.5 Line up The SAILOR XTR GX-R2 has been tested at the factory and online on a live satellite link to calibrate the TX polarization unit. You can fine-tune the TX polarization by doing a line up. Figure 4-27: Service - Line up The ship must not move during the line-up procedure.
  • Page 100 Service • Compatibility with the TX Power control feature When installing the SAILOR XTR GX-R2 you make a cable calibration. At that point every installation adjusts to the same average TX IF gain regardless of the ADU cable length. Additionally the SAILOR XTR GX-R2 system also compensates for variations of the cable characteristics or loss over frequency.

  • Page 101: Keypad And Menus Of The Bdu

    Signal strength Figure 4-30: Display (example) and keypad of the BDU 1. Current status of the SAILOR XTR GX-R2. 2. Current menu. 3. NAV: Navigational information First letter: G (Valid GPS signal received from the GPS module) or g (No valid GPS fix) Second letter: H (Valid ship heading data received from the shipʼs gyro) or h (No...
  • Page 102 Keypad and menus of the BDU 5. SAT: Longitude, satellite position of the currently active satellite profile. 6. RX: 1 (Rx Lock: - or 1), H (horizontal) or V (vertical) (RX polarization of currently active satellite profile). 7. RF tracking frequency in GHz and LNB LO Frequency. 8.
  • Page 103 Keypad and menus of the BDU Top-level Description NETWORK Shows the IP addresses and netmasks of the LAN connectors of the BDU and the management mask. SATELLITE Current satellite information. This information is entered using the web interface. EVENTS View system events. Active events are shown as: X ACTIVE EVENTS in the MAIN display.
  • Page 104 Keypad and menus of the BDU MODEM Description NET LED LED indication from modem. Steady or flashing green/amber/red, STAT LED TX LED RX1 LED RX2 LED PWR LED TEMP LED FAN LED Table 4-24: MODEM menu of the BDU (Continued) NETWORK Description HOST NAME...

  • Page 105: Startup Sequence

    Startup sequence SATELLITE Description POSITION Position of the current satellite. Right Hand Circular, Left Hand Circular, auto-selected by the RX POLARISATION VSAT modem TX POLARISATION X-polarization or Co-polarization, auto-selected by VSAT modem RX FREQUENCY Ka band receiving frequency of the active satellite, auto- selected by VSAT modem.

  • Page 106: Chapter 5 Installation Check Lists

    Chapter 5 Installation check lists Use the following sections to verify that the system is ready for customer delivery. 5.1 Installation check list: Antenna Step Task Further information Done Check that the antenna is free of See Obstructions (ADU shadowing) obstructions.

  • Page 107: Installation Check List: Bdu, Connectors And Wiring

    Installation check list: BDU, connectors and wiring Step Task Further information Done Make sure that the drain tube is open and See Condensation and water risk for water intrusion is at a minimum. intrusion on page 2-15. Check that the ADU is grounded correctly, See .

  • Page 108: Installation Check List: Functional Test In Harbor

    Installation check list: Functional test in harbor 5.3 Installation check list: Functional test in harbor Step Task Further information Done Check that the antenna is tracking the The logon LED in the BDU display satellite must be steady green and the display shows: TRACKING.

  • Page 109: Chapter 6 Service

    Chapter 6 Service This chapter has the following sections: • Built-in test and LEDs • Removal and replacement of the BDU • Removal and replacement of ADU modules • Troubleshooting basics • Returning units for repair 6.1 Built-in test and LEDs The ADU and the BDU have a Built-In Test Equipment (BITE) function in order to make fault diagnostics easy during service and installation.

  • Page 110: Removal And Replacement Of The Bdu

    Table 6-2: LEDs on the BDU 6.2 Removal and replacement of the BDU There are no parts in the BDU that you can remove or replace. Contact your Cobham SATCOM service partner for repair or replacement. 6.3 Removal and replacement of ADU modules All replacement of modules must be done by a Cobham SATCOM service partner.

  • Page 111: Troubleshooting Basics

    In case there is no RX lock on the connected VSAT modem you can activate a VSAT profile using the generic modem to verify that the transponder data used during calibration are received correctly. If the SAILOR XTR GX-R2 can go into tracking mode it is most likely not defective.

  • Page 112: Returning Units For Repair

    3. Go to DASHBOARD and monitor the system status. If the field ends up showing Tracking, the SAILOR XTR GX-R2 can track the satellite and is most likely not the reason why the VSAT modem is not in RX lock.

  • Page 113: Appendix A Technical Specifications

    Appendix A Technical specifications This appendix has the following sections: • Specifications SAILOR 1000 XTR GX-R2 • Specifications SAILOR 600 XTR GX-R2 • Patents • Outline drawings 98-175666-C...

  • Page 114: Specifications Sailor 1000 Xtr Gx-R2

    Specifications SAILOR 1000 XTR GX-R2 A.1 Specifications SAILOR 1000 XTR GX-R2 SPECIFICATIONS SAILOR XTR BELOW-DECK UNIT (BDU) Dimensions 1U 19” Rack Mount Type approvals Inmarsat HxWxD: 4.4 x 48 x 33 cm / 1.75” x 19” x 13” Weight 3.6 kg / 8 lb System power supply range 100-240 VAC, 50-60 Hz Temperature (ambient)

  • Page 115: Specifications Sailor 600 Xtr Gx-R2

    Specifications SAILOR 600 XTR GX-R2 A.2 Specifications SAILOR 600 XTR GX-R2 SYSTEM SPECIFICATIONS BELOW DECK UNIT (BDU) Frequency band Ka-band (Inmarsat GX-R2) Dimensions 1U 19” rack mount HxWxD: 4.4 x 48 x 33 cm / 1.73” x 18.9” x 13” Type approvals Inmarsat Weight...

  • Page 116: Patents

    Patents A.3 Patents The patents listed below apply to SAILOR XTR Patent application number Description 11749202.5; 10-2013-7008607; An assembly comprising a movable and 13/819,621 brakable/dampable part and a method for braking a movable part PCT/EP2012/063849 Combined antennas without switch Table A-1: Patents 98-175666-C Appendix A: Technical specifications...

  • Page 117: Outline Drawings

    Outline drawings A.4 Outline drawings A.4.1 ADU SAILOR 1000 XTR GX-R2 Figure A-1: Outline drawing: ADU (S1000) 98-175666-C Appendix A: Technical specifications...
  • Page 118 Outline drawings A.4.2 ADU SAILOR 600 XTR GX-R2 Figure A-2: Outline drawing: ADU (S600) 98-175666-C Appendix A: Technical specifications...
  • Page 119 Outline drawings A.4.3 BDU Figure A-3: Outline drawing: BDU 98-175666-C Appendix A: Technical specifications...
  • Page 120 Outline drawings A.4.4 GX GMU Figure A-4: Outline drawing: BDU 98-175666-C Appendix A: Technical specifications...

  • Page 121: Introduction

    B.2 Installation of the dual antenna solution B.2.1 System overview You can use the SAILOR XTR GX-R2 in dual antenna mode with 2 ADUs, 2 BDUs and the dual-antenna accessories kit. The kit consists of two 75 Ohm RF cables, an RF splitter and an RF combiner plus a modem keyline splitter cable.
  • Page 122 Parts needed The following parts are needed for the SAILOR XTR GX-R2 Dual antenna solution: • 1 x SAILOR XTR GX-R2 System (Master System) • 1 x SAILOR XTR GX-R2 ADU (Slave Above Deck Unit) •...
  • Page 123 Installation of the dual antenna solution B.2.2 Installation To install the dual antennas, do as follows: 1. Install the master ADU, BDU, the RX combiner and the VSAT modem. 2. Install the slave ADU, BDU and the TX splitter. 3. Provide vessel heading input to the master BDU and slave BDU. 4.

  • Page 124: Configuration Of The Dual Antenna Solution

    Configuration of the dual antenna solution B.3 Configuration of the dual antenna solution B.3.1 Overview The master antenna VSAT profile is configured the same way as a single antenna system. The master is additionally enabled to be a dual antenna master system and will always listen for a slave connection.
  • Page 125 Configuration of the dual antenna solution • When signal strength drops 4 dB lower than the in-active antenna. B.3.2 To configure the Master BDU The configuration of the master BDU depends on which ports are used and how your network has been configured. Before you enable dual mode, set up the master and the slave to be on Important the same subnet but with different IP addresses.
  • Page 126 8. Click Activate to activate the VSAT profile ADU Slave. B.3.4 Blocking zone setup for dual antenna setup It is recommended to define the following 3 blocking zones in each SAILOR XTR GX-R2 system: 1. Actual blocking zones on the vessel (No TX) 2.
  • Page 127 Configuration of the dual antenna solution Figure B-7: Dual-antenna mode, blocking zones — azimuth and elevation B.3.5 Lineup and commissioning for dual antenna setup The master BDU and the slave BDU must be lined up and commissioned one by one. . Do as follows: 1.
  • Page 128 Configuration of the dual antenna solution 3. Go to Setting - Dual antenna page to set the antenna as master in dual configuration. Figure B-8: Dual-antenna mode B.3.6 To make an OTC for dual antenna systems Do not power up the GMU at this point in time. Important 1.

  • Page 129: Dual Antenna Software Upgrade Procedure

    Dual antenna software upgrade procedure B.4 Dual antenna software upgrade procedure When making a software upgrade of a dual antenna system, it must be done in the correct order to limit downtime of the VSAT service. It is recommended to do the upgrade at a location where both antennas have connection to the satellite and are outside blocking zones.

  • Page 130: Flow Chart For Installation Of The Dual Antenna Solution

    Flow chart for installation of the dual antenna solution B.5 Flow chart for installation of the dual antenna solution Figure B-9: Flow chart for dual antenna installation 98-175666-C Appendix B: Dual antenna solution B-10...

  • Page 131: Dual Antenna Splitter Cable

    Dual antenna splitter cable B.6 Dual antenna splitter cable Figure B-10: Splitter cable 98-175666-C Chapter B: Dual antenna solution B-11...

  • Page 132: Appendix C Miscellaneous

    Appendix C Miscellaneous C.1 Performance optimization for blockage C.1.1 Encountering blockage, configured with multiple satellites. Definition of blockage In most VSAT installations the VSAT antenna is installed in a position with areas of blockage. Blockage is often caused by the vessel's masts, stacks and other equipment installed on board.
  • Page 133 Performance optimization for blockage Minimum elevation angle One safe way of getting optimum performance under the current conditions is to switch to a satellite in view as fast as possible. This is done by having well defined satellite parameters in the VSAT modem configuration. It is the VSAT modem that has the task of selecting the correct satellite, and since the VSAT modem is only concerned about the satellite visibility at the current geographic position, it is very important to enter the minimum elevation of a satellite at which a stable link can be established.

  • Page 134: Appendix D Command Line Interface

    Appendix D Command line interface D.1 Connection modes After you have done the initial configuration and connected the SAILOR XTR to your network, you can use SSH to configure the SAILOR XTR. You can also set up VSAT modem parameters. Note that the following sections cover the command line interface for all SAILOR XTR antennas.
  • Page 135 List of commands • status • system • test • iothub D.2.1 antenna_data Command Description antenna_data Shows detailed information of this specific command. Shows current antenna type. Example output: antenna_data type UCLI:/$ antenna_data type System: 7509D Type: 2 Oem: inmarsat sub type: 0 lnb type: 1 buc type: 4...
  • Page 136 • active • inactive Table D-5: UCLI command: dual_antenna D.2.6 exit Command Description exit Exits the connection to the SAILOR XTR GX-R2. Table D-6: UCLI command: exit D.2.7 help Command Description help Shows detailed information of this specific command. help status Shows the sub commands and description for the command status.
  • Page 137 Command Description status Shows detailed information of this specific command. status system Shows the current status of the SAILOR XTR GX-R2. status track_all Shows the current values for all tracking parameters: • vessel heading • azimuth relative • elevation relative •...
  • Page 138 List of commands D.2.10 system Command Description system Shows detailed information of this specific command. system restart Sends a command to the BDU to restart the system instantaneously. It makes a power-on self test and then points to the last used satellite. system info Shows the software version, part names and serial numbers of the SAILOR 1000 XTR GX-R2 4.5W.
  • Page 139 List of commands Command Description iothub_schedule set Sets iothub scheduler configuration <group> [parameter] parameters. <value> iothub_schedule read Reads iothub scheduler configuration <group> [parameter] parameters. <value> Table D-12: UCLI command: iothub (Continued) 98-175666-C Appendix D: Command line interface...

  • Page 140: Appendix E Grounding And Rf Protection

    Grounding and RF protection E.1 Introduction E.1.1 Reasons for grounding Grounding the SAILOR XTR GX-R2 system is required for at least two reasons: • Safety: Lightning protection of persons and equipment. • Protection: ESD (Electro Static Discharge) protection of equipment.

  • Page 141: Grounding Recommendations

    Grounding Recommendations E.2 Grounding Recommendations E.2.1 To ground the BDU The BDU should be grounded to the ship/hull. For this purpose you may use a short ADU cable and a grounding kit. Further, the BDU must be grounded at its grounding stud in order to ensure proper grounding if the short ADU cable is disconnected.
  • Page 142 Grounding Recommendations electrical contact to the hull. Use serrated washers when securing the mounting bolts and seal the joint with protective coating to avoid corrosion. Antenna bottom Mounting base M12 bolt Serrated washer (stainless steel) (stainless steel) Figure E-2: Grounding the ADU For optimum grounding use the mounting bolt located Note closest to the ADU cable plate, see .
  • Page 143 Grounding Recommendations To ground the ADU For optimum grounding use the mounting bolt located Note closest to the ADU cable plate, see . To ground the ADU on page 2-20. Terminal grounded at the hull (recommended) In this case the ADU is grounded to the ship via one (or more) of its mounting bolts. Make sure to remove painting, dirt, grease etc.
  • Page 144 The BDU should preferably be grounded with the short ADU cable and a grounding kit (available from Cobham SATCOM). Further, the BDU must be grounded at its grounding stud in order to ensure a proper grounding if the short ADU cable is disconnected.
  • Page 145 Grounding Recommendations The ground connection must be established at a dedicated RF ground (either capacitive or electrical coupled). Bear in mind that the ADU ground connection is to Important be made at the same electrical ground potential as the BDU (see To ground the ADU). To ground the ADU If the mounting base of the ADU is electrically connected to any other ground potential than the BDU (e.g.
  • Page 146 Grounding Recommendations illustration below. The crimp terminals must be a marine approved type e.g. the DuraSeal series from Raychem. Antenna: M12 Insulated Ring Terminal (Raychem, DuraSeal Series ) Terminal: Appropriate size Insulated Ring Terminal (Raychem, DuraSeal Series ) Figure E-6: Separate ground cable Ground cable - connection Mount the ground cable close to and parallel to the shielded coax cable thus minimizing ground loop problems.
  • Page 147 Grounding Recommendations isolation has to be implemented on all four mounting bolts (including the bolt securing the ground cable). Isolating washer Plain washer (stainless steel) Spring washer (stainless steel) Isolating shoulder bush Figure E-7: Isolation of the ADU from the mounting base The ground cable must be connected at one of the mounting/grounding bolts on the ADU as illustrated below.

  • Page 148: Jumper Cable For Grounding

    Jumper cable for grounding E.3 Jumper cable for grounding Figure E-9: Jumper cable for grounding (specifications) 98-175666-C Appendix E: Grounding and RF protection...

  • Page 149: Appendix F Event Messages

    • CM (Continuous Monitoring) – automatically performed while the system is in operation. When the SAILOR XTR GX-R2 detects an event that requires your action, it issues an event message and the red Fail/Pass LED in the LED panel of the BDU is lit. As long as an event is active, it is shown in the BDU display and the web interface (in Service >...

  • Page 150: List Of Events

    List of events F.2 List of events (170322) Module Type Description Explanation 08061-0 WARNING VMU linux shell The specified password (root) for the satellite password modem is not accepted by the modem. (!T,!G,!S) 08062-0 WARNING VMU debug shell The specified password (user) for the satellite password modem is not accepted by the modem.
  • Page 151 List of events Module Type Description Explanation 08076-0 WARNING Dual mode The system is configured as a dual antenna configuration system, but the master and slave systems are not identical. The dual mode function may not work properly or performance could be degraded.
  • Page 152 List of events Module Type Description Explanation 0807F-0 WARNING Local Local administration mode is currently enabled. administration This allows login without providing the admin enabled password. Will be disabled after 1 hour or next reboot. 08081-0 WARNING BUC Missing communication between VMU and BUC. communication Info: 0x00000001: From VMU to BUC Info: 0x00000002: From BUC to VMU (!T,!V,!S)
  • Page 153 List of events Module Type Description Explanation 08111-0 ERROR Presence of EBUS Present EBUS devices matches antenna type. devices The info code shows the sum of all missing or unexpected modules, see below: 0x00000001: Azimuth IFDM 0x00000002: Cross Elevation IFDM 0x00000004: Elevation IFDM 0x00000008: ISCM 0x00000010: Polarisation IFDM 08112-0 ERROR...
  • Page 154 List of events Module Type Description Explanation 08534-0 WARNING BDU The communication link between BDU and communication antenna is not working. 08537-0 INFO GNSS Lost connection to the GNSS device. communication 08538-0 INFO GNSS data range Received information from the GNSS device which is out of range.
  • Page 155 List of events Module Type Description Explanation 08841-0 ERROR Tuner lock The internal tuner PLL was unable to lock. (!V,!T) 08842-0 WARNING GSC demodulator The GSC demodulator has reported an error. (!V,!T) 08843-0 WARNING DVBS demodulator The DVBS demodulator cannot be initialised and loaded correctly.
  • Page 156 List of events Module Type Description Explanation 08A03-0 ADM WARNING GX Core Module The Power Good signal from the Core Module is power low. The issue can either be: - Internal Core Module or internal cable failure - Temperature of Core Module is too high and it has been turned off (*) - GMU has been manually switched off on the front panel (*) (*) = Only on systems with GMU.
  • Page 157 List of events Module Type Description Explanation 0A101-0 Antenn ERROR ISCM Internal communication error on ISCM. Accelerometer communication 0A102-0 Antenn ERROR ISCM Internal communication error on ISCM. Magnetometer communication 0A103-0 Antenn ERROR ISCM IMU Internal communication error on ISCM. communication 0A104-0 Antenn WARNING ISCM OMT analog No analog communication to OMT.
  • Page 158 List of events Module Type Description Explanation 0A284-0 Antenn ERROR Azi Motor Over Motor temperature too high. Motor shut down. temperature fault 0A285-0 Antenn INFO Azi Motor Over Over current protected activated. Check free current fault movement of antenna. 0A286-0 Antenn ERROR Azi Motor No No communication with motor.
  • Page 159 List of events Module Type Description Explanation 0A483-0 Antenn WARNING Ele Motor Over Motor temperature too high. temperature warning 0A484-0 Antenn ERROR Ele Motor Over Motor temperature too high. Motor shut down. temperature fault 0A485-0 Antenn INFO Ele Motor Over Over current protected activated.
  • Page 160 List of events Module Type Description Explanation 0B063-0 APSM ERROR APSM AUX Temperature too high. AUX shut down. (!T,!S) temperature failure 0B064-0 APSM WARNING APSM EBUS Temperature too high. (!T,!S) temperature warning 0B065-0 APSM ERROR APSM EBUS Temperature too high. EBUS shut down. (!T,!S) temperature failure 0B066-0 APSM WARNING APSM LNB...
  • Page 161 List of events Module Type Description Explanation 0B084-0 APSM INFO APSM Main Over Too high current. APSM shut down. (!T,!S) current protection 0B090-0 APSM INFO APSM AUX Over Voltage too high. (!T,!S) voltage protection 0B092-0 APSM INFO APSM EBUS Over Voltage too high.
  • Page 162 List of events Module Type Description Explanation 0F002-0 BIMO ERROR BIM-O voltage Voltage measured at BIM-O is not within range expected range 0F003-0 BIMO ERROR BIM-O cal data BIM-O calibration data is invalid 0F004-0 BIMO WARNING VMU reference There is no VMU Rx or Tx reference signal. signal Whether this is Rx or Tx reference depends on the user's selection on the modem profile page...

  • Page 163: Appendix G Inmarsat Gx Satellites

    Appendix G Inmarsat GX satellites This appendix contains examples of satellite data for azimuth calibration. The following figure shows the coverage map of the GX service. Global Xpress network available Extendable Global Xpress over at least 99% of this area coverage via steerable beams 90°...

  • Page 164: Ce (Red

    Appendix H Approvals H.1 CE (RED) 98-175666-C...

  • Page 165: Inmarsat Type Approval (Sailor 1000 Xtr Gx-R2

    Inmarsat type approval (SAILOR 1000 XTR GX-R2) H.2 Inmarsat type approval (SAILOR 1000 XTR GX-R2) 98-175666-C Chapter H: Approvals...

  • Page 166: Inmarsat Type Approval (Sailor 600 Xtr Gx-R2

    Inmarsat type approval (SAILOR 600 XTR GX-R2) H.3 Inmarsat type approval (SAILOR 600 XTR GX-R2) 98-175666-C Chapter H: Approvals...
  • Page 167 Glossary Glossary Antenna Control Unit ACU Digital Module. A main processor board in the ACU. Antenna Diversity Solution AIMO Antenna Interface Module APSM Antenna Power Supply Module BDCM BDU Control Module Below Deck Unit BEIDOU Chinese satellite navigation system BITE Built-In Test Equipment Block Up Converter Continuous Monitoring...
  • Page 168 Glossary Global Positioning System HeaDing True, NMEA sentence. International Electrotechnical Commission Internet of Things Internet Protocol Inertial Sensor Module Keyboard and Display Module of the BDU Local Area Network Light Emitting Diode LGPL Lesser General Public License Left Hand Circular LHCP Left Hand Circular Polarization Long-Term Evolution (also called 4G)
  • Page 169 Radio Frequency Interference. A non-desired radio signal which creates noise or dropouts in the wireless system or noise in a sound system. RHCP Right Hand Circular Polarization ROSS Roaming Oceanic Satellite Server SNMP Simple Network Management Protocol. An Internet-standard protocol for managing devices on IP networks.
  • Page 170 Index Index connector panel, overview 3-1 access description 1-3 limit 4-28 grounding 2-25 ACMAntenna Control Module 4-12 LED 6-1 acquisition LEDs, display and keypad 3-1 gyro-free 4-19 BDU display search pattern 4-18 description 4-41 search pattern, inclined orbit 4-19 BDU rack version time 4-19 installing 2-25 administrator...
  • Page 171 Index command line interface D-1 display config D-2 BDU, description 4-41 demo D-3 distance dual antenna D-3 antenna to radar 2-13 exit D-3 DNS setup 4-11 modem D-4 drainage of antenna 2-15 status D-4 drawing supported commands D-1 ACU rack version A-7 system D-5 ADU A-5 track D-5...
  • Page 172 Index elevation angle 4-9 import configuration 4-32 4-33 Features 1-2 inclined orbit fiberglass hulls search pattern for acquisition 4-19 grounding E-5 inclined orbit satellites 4-17 fire wall 4-1 installation fixed heading 4-16 4-17 BDU 2-25 fixed TX gain 4-39 Interfaces 3-1 flange thickness 2-7 interference 2-13 flatness 2-7...
  • Page 173 Index mast 2 braces 2-11 obstructions 3 braces 2-11 2-12 distance and size 2-4 design 2-6 one touch commissioning 4-37 flange thickness 2-7 opening antenna 2-20 flatness 2-7 order numbers 1-10 foundation 2-6 OTC 4-37 gusset plates 2-7 dual antenna B-8 height 2-6 outline drawing steel type 2-6...
  • Page 174 Index roll period software update limitations 2-4 automatic rollback 4-32 mounting height 2-4 recover 4-32 ship 2-4 software version rollback verify 4-32 software upload 4-32 specifications A-1 RS-232 spreadsheet connector 3-4 statistics report 4-26 RS-422 static IP 4-3 connector 3-4 static IP address 4-11 Rx-Tx statistics...
  • Page 175 Index user CLI D-1 user permissions 4-29 setup 4-28 verification tracking mode 6-3 VLAN 4-14 user defined, example 4-15 VMU connector 3-6 VSAT profiles 4-6 warning messages F-1 warranty 6-4 web interface connect 4-3 LAN connector 3-6 modem 4-38 web mmi LAN connector 3-6 weight mast 2-12...
  • Page 176 98-175666-C www.cobhamsatcom.com...

Table of Contents
