Summary of Contents for Newworld NW70DO
- Page 1 Users Guide & Installation Handbook NW70DO 70cm electric double oven and grill NW90DO 90cm electric double oven and grill Please read carefully and retain for future reference www.newworldappliances.co.uk...
- Page 2 IMPORTANT NOTICE Please note the cooling fan fitted to this appliance is an integral part of its safety and functionality. When the appliance is installed care must be taken that the cooling fans perfor- mance is not impeded by any objects coming into contact with it. (Installation pipes, leads etc) Care must also be taken that there is sufficient air flow at the rear of the appliance for the cooling fan to run at its optimum efficiency.
-
Page 3: Table Of Contents
Contents User’s Section ........2 - 23 Introduction . -
Page 4: User's Section
Introduction Thank you for choosing a New World Your electric oven is designed to be appliance installed underneath a worktop, either into a housing unit, or between base We hope that the following information units depending on the size of the will help you to familiarise yourself model - see installation section. - Page 5 Introduction Cooling fan Environmental Protection The cooling fan helps to keep the We are committed to protecting the exterior cool during normal use. environment operate When an element is operated, you Environmental Management System should hear the cooling fan switch on which complies with BS EN ISO automatically and be able to feel air 14001:1996.
-
Page 6: Be Safe - Not Sorry
Be Safe - Not Sorry G Using aluminium foil to cover the When you are cooking, keep children away from the vicinity grill pan, or putting items wrapped of the appliance. in foil under the grill creates a fire G This product is designed as a hazard. -
Page 7: Using The Grill
Using the Grill Caution: Accessible parts may Detachable grill pan handle be hot when the grill is used, grid young children should be kept away. To switch on the grill Open the top oven / grill door. Turn the grill control fully clockwise to select either the full grill setting or economy grill setting. - Page 8 Using the Grill Using the grill Aluminium foil The temperature of each grill setting is Using aluminium foil to cover the grill fixed. Grilling can be adjusted by pan, or putting items wrapped in foil selecting a higher or lower shelf under the grill creates a fire hazard, position, or by adjusting the trivet and the high reflectivity can damage...
-
Page 9: Using The Top Oven
Using the Top Oven Caution: Accessible parts may Notes: be hot when the oven is used, Caution: The top element gets young children should be kept extremely hot when in use, so take away. extra care to avoid touching it. Important: Never put items directly The top oven is a conventional electric on the base of the oven or cover the... -
Page 10: Top Oven Baking Guide
Using the Top Oven Top oven baking guide Cooking temperatures Because the top oven is more compact Cooking times it may be necessary to reduce the The cooking times given in the following cooking temperatures specified in guide are based on a preheated oven, if recipes by up to 20˚C. -
Page 11: Using The Main Oven
Using the Main Oven Caution: Accessible parts may To help the air to circulate freely G Position the shelves evenly within be hot when the oven is used, young children should be kept the oven and maintain a clearance away. from the oven roof and base. -
Page 12: Cooking With A Fan Oven
Using the Main Oven Cooking with a fan oven Defrosting and cooling If you are used to cooking with a To defrost frozen foods, turn the conventional oven, you will find a oven control to the defrost position, number of difference to cooking with a place the food in the centre of the oven fan oven, which will require a different and close the door. -
Page 13: Main Oven Baking Guide
Using the Main Oven Main oven baking guide Because a fan oven has an even temperature throughout the oven, no The cooking times given below are only shelf positions have been given, approximate, because the size and type and there is no need to interchange of cooking dish will influence cooking dishes onto different shelves part times, as will personal preference. -
Page 14: Oven Furniture
Using the Ovens Oven furniture Aluminium foil Use foil only to cover food or cooking dishes. Do not use foil to cover the Baking tray and roasting tins shelves or oven base, as this creates a For best cooked results and even fire hazard. -
Page 15: Traditional Fruit Cakes
Using the Ovens Traditional fruit cakes Roast turkey It should be remembered that ovens Roasting turkey perfectly involves can vary over time, therefore cooking cooking two different types of meat - times can vary, making it difficult to be the delicate light breast meat, which precise when baking fruit cakes. -
Page 16: Roasting Guide
Using the Ovens Roasting guide Notes; G When cooking stuffed meat or The times given in the roasting guide are only approximate, because the poultry, calculate the cooking time size and age of the bird will influence from the total weight of the meat cooking times as will the shape of a plus the stuffing. -
Page 17: Automatic Cooking In The Main Oven
Using the Ovens Automatic cooking in the main oven Do not G Warm food should never be The automatic cooking facility is controlled by the programmer (see placed in the oven if there is a ‘Programmer/ Clock’ section) and allows delay period. - Page 18 Using the Ovens Important: Food is more susceptible Hints for automatic cooking G Food is placed in a cold oven so to the growth of food poisoning organisms in warm conditions. If the you will need to add about 10 - weather is hot, either take care to 15 minutes onto the cooking time ensure that food is not left standing in...
-
Page 19: Programmer / Clock
PROGRAMMER / CLOCK The programmer buttons minus plus The ‘function’ button in the centre is used for setting the minute minder and Minute Minder symbol setting up the automatic cooking. See This Bell symbol appears when the below for details. Minute Minder function has been selected. - Page 20 PROGRAMMER / CLOCK To set the time of day Setting the minute minder Press the Plus and Minus buttons To set the Minute Minder, press the together for a few seconds, and Function button once. The bell symbol release. will appear and start flashing. The ‘G’...
- Page 21 PROGRAMMER / CLOCK Semi-automatic cooking For the instructions on how to use both of these functions, please see the fol- There are two types of semi automatic lowing page. cooking available on this appliance. Fully automatic cooking The oven must be switched on, and in This function incorporates both a dura- use to use either of these functions tion and an end time and is meant to be...
- Page 22 PROGRAMMER / CLOCK 1. The Duration method Semi-automatic cooking The Duration method Press the Function button twice,(1) which will skip past the Minute Minder. The LED display will flash the word ‘dur’, (2) and the ‘A’ will flash on the left hand side of the display.
- Page 23 PROGRAMMER / CLOCK Fully automatic cooking (example) This programming method is best suit- ed for when a delayed start time is required. Unlike the semi automatic methods this requires both the dura- tion and the end time to be entered. The timer will work out the start time and begin cooking.
-
Page 24: Cleaning
Cleaning Caution: Any cleaning agent Vitreous enamel parts used incorrectly may damage GRILL PAN MAIN OVEN BASE TOP OVEN the appliance. GRILL COMPARTMENT Always let the appliance cool Use a mild cream cleaner - eg; “Cif”. before cleaning. Stubborn marks may be removed with Some cooking operations generate a a moistened “Brillo”... - Page 25 Cleaning Stainless steel surfaces (stainless steel finish models only) FACIA PANEL HANDLES Only use a clean cloth wrung out in hot soapy water, and dry with a soft cloth. Stubborn marks can be removed using “Luneta”. We recommend that you clean the whole of the stainless steel area to maintain a uniform finish.
- Page 26 Cleaning Glass parts Important: if the inner door glass panel is removed for cleaning, it must & FACIA PANEL DOOR PANELS be replaced the right way up as Use a mild cream cleaner - eg; “Cif”. shown, and pushed fully in to the Rinse thoroughly and dry with a soft stop position.
-
Page 27: Maintenance
Maintenance Maintenance All models with side lights. All models with rear lights To replace a light bulb Fan Assisted Ovens (if fitted) To replace an oven light bulb Warning: Switch off the electricity (If fitted) supply to the cooker at the socket, to Warning: Switch off the electricity avoid the risk of electric shock. -
Page 28: Installation
NW70DO Installation Instructions Before you start - please read the If this appliance is to be installed near to a instructions carefully - planning your corner where the adjacent cabinets run at installation will save you time and effort. right angles forward of the appliance,... - Page 29 NW70DO Installation Instructions Method 1: Without housing unit 1. Take the 6 No 8 x 12mm (silver) (between 2 base units) self tapping screws from the polythene bag, and use them to fit Before installing the appliance, check one runner to each side of the the internal dimensions as shown.
- Page 30 Installation Instructions Method 1: Without housing unit (between 2 base units) Shown with fixing kit min 550mm 598 - 602mm 710mm sidetrim runners 50mm...
- Page 31 Installation Instructions Method 1: Without housing unit (between 2 base units) Shown without fixing kit min 550mm 598 - 602mm sidetrim...
- Page 32 NW70DO Installation Instructions Method 2: To fix the runners (if required) Housing unit with internal height less than 710mm. 1. Take the side trims, hold it against Note: You will not need the 2 side the side of the base unit, and use...
- Page 33 Installation Instructions Method 2: Housing unit with internal height less than 710mm Shown with fixing kit min 550mm 560 - 570mm 710mm runners 50mm...
- Page 34 Installation Instructions Method 2: Housing unit with internal height less than 710mm Shown without fixing kit min 550mm 560 - 570mm...
- Page 35 NW70DO Installation Instructions Method 3: Housing unit with Remove any fixings that may prevent internal height of 710mm or more. entry of the oven into the housing. The cabinetry should be kept structurally Note: You will not need the 4 runners...
- Page 36 NW70DO Installation Instructions Important Note: For connecting to the electricity supply, and fitting the edging strip - see page 37. These steps must be completed before securing the appliance.
- Page 37 NW90DO Installation Instructions Prepare installation 1. Remove the fixing screws from the polythene bag on the top of the Do not lift the oven by the door appliance, but leave the appliance handle. in the base tray packaging until Whilst every care is taken to eliminate you are ready to install it.
- Page 38 NW90DO Installation Instructions 3. The appliance is designed to fit Please note that all sizes are nominal - into a standard 600mm wide some variation is to be expected. housing unit, with minimum internal dimensions as shown. 560mm 547mm 550mm 20mm 885mm 30 - 80mm...
- Page 39 NW90DO Installation Instructions Connect to the electricity supply on the outer edges of the front frame, before positioning and securing the Warning: This appliance must be appliance to the cabinet. earthed. 1. The appliance must be installed front frame seal by a competent electrician using a double pole...
- Page 40 General Installation Instructions Insert appliance into cabinet. Secure appliance into housing unit 70cm models Note: The unit housing the appliance must be appropriately fixed. Method 1: Care must be taken to Note: Ensure that the appliance is ensure the appliance runners are centrally located.
-
Page 41: Technical Data
Technical Data Installing a hob above the Electrical supply appliance 70cm models 220 - 240V ~ 50Hz Where the appliance is installed under a worktop, with a hob installed above Element ratings at 230V it, the installation instructions for the Dual grill 1.6 - 2.57kW hob must be read in conjunction with... -
Page 42: New World Customer Care
New world Customer Care Please keep this handbook in a safe place as the information inside may be of use should you sell, or pass on the appliance. Please fill in the model number and serial number in the spaces provided below as they will assist us should you need to call.
