Newworld NW60 Users Manual & Installation Handbook

60cm electric oven/grill
Hide thumbs
Table of Contents

Advertisement

Quick Links

Users Guide & Installation
Handbook
NW60
60cm conventional electric oven/grill
NW60F
60cm fanned electric oven/grill
NW60FP
60cm fanned electric oven/grill
NW60MF
60cm multifunction electric oven/grill
NW64FP
60cm fanned electric oven/grill
Please read carefully and retain for future reference
www.newworldappliances.co.uk

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NW60 and is the answer not in the manual?

Questions and answers

Related Manuals for Newworld NW60

Summary of Contents for Newworld NW60

  • Page 1 Users Guide & Installation Handbook NW60 60cm conventional electric oven/grill NW60F 60cm fanned electric oven/grill NW60FP 60cm fanned electric oven/grill NW60MF 60cm multifunction electric oven/grill NW64FP 60cm fanned electric oven/grill Please read carefully and retain for future reference www.newworldappliances.co.uk...
  • Page 2 IMPORTANT NOTICE Please note the cooling fan fitted to this appliance is an integral part of its safety and functionality. When the appliance is installed care must be taken that the cooling fans perfor- mance is not impeded by any objects coming into contact with it. (Installation pipes, leads etc) Care must also be taken that there is sufficient air flow at the rear of the appliance for the cooling fan to run at its optimum efficiency.

  • Page 3: Table Of Contents

    Contents User’s Section ........2 - 22 Introduction .

  • Page 4: User's Section

    Introduction Thank you for choosing a New World This appliance is designed to fit into a appliance standard 600mm wide housing unit with a minimum internal height of 580mm. We hope that the following information will help you to familiarise yourself with the features of the appliance, and Electrical connection to use it successfully and safely.
  • Page 5 Introduction Cooling fan To replace an oven light bulb (if fitted) The cooling fan helps to keep the exterior cool during normal use. aution: Switch off the electricity When an element is operated, you supply to the appliance, to avoid the should hear the cooling fan switch on risk of electric shock.

  • Page 6: Be Safe - Not Sorry

    Be Safe - Not Sorry G Using aluminium foil to cover the When you are cooking, keep children away from the vicinity grill pan, or putting items wrapped of appliance. in foil under the grill creates a fire hazard. The high reflectivity can This product is designed as a domestic also damage the element.

  • Page 7: Grill Introduction

    Grill Introduction aution: Accessible parts may Detachable grill pan handle trivet be hot when the grill is used, young children should be kept away. The grill is a single circuit fully variable grill. It can be used for conventional grilling, or as a fanned grill. Grill pan To switch on the grill Handle...

  • Page 8: Using The Grill

    Using the Grill Conventional grill The door must be open when the Grilling conventional grill function is used - The temperature of the grill is variable, either fully open or using the door stop and can be adjusted by turning the position - open the door about 30˚...

  • Page 9: Oven Functions Introduction

    Oven Functions Introduction Oven functions are detailed below with suggested uses. Note: Please be aware that not all appliances have all func- tions. Oven Function Recommended Uses Used to finish off the bases of food following cooking using the con- Base Heat Only ventional or fanned modes.

  • Page 10: Fanned Oven (Selected Models)

    Fanned Oven (Selected Models) When you are cooking, keep Aluminium foil children away from the vicinity Use aluminium foil only to cover food of the oven. or cooking dishes. Do not foil to cover the shelves or oven base, as this creates a fire hazard.
  • Page 11 Fanned Oven Continued..Cooking with a fan oven To help the air circulate freely; G Position the shelves evenly within If you are used to cooking with a conventional oven you will find a the oven and maintain a clearance number of differences to cooking with from the oven roof and base.

  • Page 12: Conventional Oven

    Conventional Oven Introduction aution: Accessible parts may Aluminium foil be hot when the oven is used, Use foil only to cover food or young children should be kept cooking dishes - do not use foil to away. cover the shelf or oven base, as this creates a fire hazard.
  • Page 13 Conventional Oven Continued..Using a conventional oven Zones of heat The oven is heated by elements at the The temperature at the centre of the top of the oven, and underneath the oven corresponds with the selected floor of the oven. temperature - it is slightly higher towards the top of the oven and Conventional oven cooking is ideal for...

  • Page 14: Slow Cooking

    Slow Cooking & Frozen/chilled foods Slow cooking (if fitted) Cooking frozen & chilled foods G For roasting joints of meat or G Always preheat the oven before use. G When cooking frozen or chilled poultry and for pot roasts preheat the oven to 190˚C - 200˚C and foods, please follow the food cook for 30 minutes, then adjust...

  • Page 15: Defrosting And Cooling

    Defrosting Defrosting times Defrosting and cooling (if fitted) Small or thin pieces of frozen fish or To defrost frozen foods, turn the meat eg; fish fillets, prawns and mince oven control to the defrost position, will take approximately 1 - 2 hours. place the food in the centre of the oven Placing the food in a single layer will and close the door.

  • Page 16: Baking Guide

    Baking Guide (Fanned Oven) Fanned oven baking guide The cooking times are only approximate because the size and type of cooking Because a fan oven has an even dish will influence cooking time as will temperature throughout the oven, no personal preferences.
  • Page 17 Baking Guide (Conventional Oven) Conventional oven baking Note: When cooking 2 trays or items guide in a conventional oven (when using 2 shelves), remove the top item when it is The temperature settings and times given cooked and raise the lower item to the in this baking guide are based on dishes higher shelf to finish cooking, or where made with block margarine.

  • Page 18: Traditional Fruit Cakes

    Using the Oven Traditional fruit cakes Roast turkey It should be remembered that ovens Roasting turkey perfectly involves can vary over time, therefore cooking cooking two different types of meat - times can vary, making it difficult to be the delicate light breast meat, which precise when baking fruit cakes.

  • Page 19: Roasting Guide

    Roasting Guide Roasting guide Notes; G When cooking stuffed meat or The times given in the roasting guide are only approximate, because the poultry, calculate the cooking time size and age of the bird will influence from the total weight of the meat cooking times as will the shape of a plus the stuffing.

  • Page 20: Automatic Cooking Introduction (Selected Models)

    Automatic Cooking Introduction (Selected Models) Automatic cooking Do not: G Warm food should never be The automatic cooking facility is controlled by the programmer (see placed in the oven if there is a ‘Programmer/ Clock’ section) and delay period. Stews prepared by allows complete meals, or individual frying the meat and vegetables dishes to be cooked while you are out...
  • Page 21 Automatic Cooking Continued..Important: Food is more susceptible Hints for automatic cooking G Food is placed in a cold oven so to the growth of food poisoning organisms in warm conditions. If the you will need to add about 10 - weather is hot, either take care to 15 minutes onto the cooking time ensure that food is not left standing in...

  • Page 22: Programmer/Clock (Selected Models)

    Programmer/Clock (Selected Models) The programmer buttons minus plus The ‘Function’ button in the centre is Minute Minder Symbol used for setting the minute minder and setting up the automatic cooking. See This Bell symbol appears when the below for details. Minute Minder function has been selected.
  • Page 23 Programmer/Clock Continued..To set the time of day Setting the minute minder Press the ‘Plus’ and ‘Minus’ buttons together for a few seconds, and To set the Minute Minder, press the release. ‘Function’ button once. The bell sym- The ‘G’ in between the numbers on bol will appear and start flashing.
  • Page 24 Programmer/Clock Continued..Semi-automatic cooking For the instructions on how to use both of these functions, please see the fol- There are two types of semi automatic lowing page. cooking available on this appliance. Fully automatic cooking The oven must be switched on, and in This function incorporates both a dura- use to use either of these functions tion and an end time and is meant to be...
  • Page 25 Using the Programmer/Clock 1. The ‘Duration’ method Semi-automatic cooking (example) The ‘Duration’ method Press the ‘Function’ button twice,(1) which will skip past the Minute Minder. The LED display will flash the word ‘dur’, (2) and the ‘A’ will flash on the left hand side of the display.
  • Page 26 Using the Programmer/Clock Continued..Fully automatic cooking (example) This programming method is best suit- ed for when a delayed start time is required. Unlike the semi automatic methods this requires both the dura- tion and the end time to be entered. The timer will work out the start time and begin cooking.

  • Page 27: Mechanical Minute Minder (Selected Models)

    Mechanical Minute Minder (Selected Models) Please note: Not all appliances have mechanical minute minders. Mechanical minute minder The timer can be set up to 60 minutes. Turn the minute minder control knob fully clockwise to the maximum 60 minute setting (ie; return to the G “off” position) before turning anticlockwise to the desired setting.

  • Page 28: Cleaning

    Cleaning aution: Any cleaning agent Vitreous enamel parts used incorrectly may damage GRILL PAN OVEN COMPARTMENT FLOOR the appliance. Use a mild cream cleaner - eg; “Cif”. Always let the oven cool before Stubborn marks may be removed with cleaning. a moistened “Brillo”...
  • Page 29 Cleaning Continued..Glass parts Important: if the inner door glass panel is removed for cleaning, it must & FASCIA PANEL DOOR PANELS be replaced the right way up as Use a mild cream cleaner - eg; “Cif”. shown, and pushed fully in to the Rinse thoroughly and dry with a soft stop position.
  • Page 30 Cleaning Continued..Stainless steel surfaces (stainless steel finish models only) FASCIA PANEL HANDLES Only use a clean cloth wrung out in hot soapy water, and dry with a soft cloth. Stubborn marks can be removed using “Luneta”. We recommend that you clean the whole of the stainless steel area to maintain a uniform finish.

  • Page 31: Installation Instructions

    Installation Instructions Step 1: Prepare installation Do not lift the oven by the Note: When removing the appliance door handle. from the base tray packaging care should be taken not to damage the Whilst every care is taken to eliminate appliance.

  • Page 32: Installation Instructions

    Installation Instructions Installing appliance under a The appliance is designed to fit into a standard 600mm wide housing unit, worktop with minimum internal dimensions Where the appliance is installed under as shown. a worktop, with a hob installed above Note: 590mm is to the underside of it, the installation instructions for the the worktop when the appliance is hob must be read in conjunction with...

  • Page 33: Step 2: Connect To Electricity Supply

    Installation Instructions Step 2: Connect to the electricity supply We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.E. and local regulations. Important: Ensure that you route all mains electrical cables well clear of any adjacent heat source, such as an oven or grill.

  • Page 34: Step 3: Check Edging Strip

    Installation Instructions Step 3: Check edging strip Step 4: Secure appliance into housing unit The edging strip is factory fitted to the front side edges of the appliance Insert appliance into cabinet. front frame. This strip provides the To secure the appliance to the housing cabinetry with extra protection from unit, open the oven door and screw 4 any escape of heat.

  • Page 35: Technical Data

    Technical Data Power supply Multifunction Oven: 220 - 240V ~ 50Hz Element ratings (given at 240V) Grill 1800W Warning: This appliance must be Fan oven element 2000W earthed. Conventional oven 2090W Stir fan Conventional Oven: Light Element ratings (given at 240V) Cooling fan Grill 1800W...

  • Page 36: New World Customer Care

    New World Customer Care In case of difficulty within the UK and Northern Ireland, please call the New World Customer Care Centre Helpline on 0871 22 22 504 When you dial this number you will hear a recorded message and be given a number of options.
