- Page 1 Users Guide and Installation Handbook 60cm Built-In Oven NW 602F NW 602FP NW 602MF...
-
Page 2: Table Of Contents
Contents 1.Before You Start................1 2.Oven Overview ................3 3.How to use your oven ..............4 4.Cooking Tips ..................8 5.Cooking Table ..................9 6.Cleaning Your Oven.................9 7.Troubleshooting ................13 8.Installation ..................15 9.Circuit Diagram ................20 10.Warranty/After Sales Service ............24... -
Page 3: Before You Start
1.Before You Start... Thank you for buying a NEW WORLD oven. It should give you many years trouble-free cooking if installed and operated correctly. It is important that you read this section before you start, particularly if you have not used an electric oven before. - Page 4 a hot surface. Never operate the oven with wet hands. Do not use a towel or other bulky cloth in place of a glove – it might catch fire if it touches a hot surface. Always keep combustible wall coverings or curtains, etc., a safe distance away from your oven, and never wear loose-fitting or hanging clothes while using the appliance.
-
Page 5: Oven Overview
The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product. -
Page 6: How To Use Your Oven
FEATURES A. Control Panel B. Cooking mode selection knob C. Cooking temperature selection knob D. Electronic programmer-Allows you to program the desired cooking by selecting the cooking time and the end cooking time. It can also be used as a timer (only available on certain models). For models with just a minute minder this is just an End Cooking Time Knob E. -
Page 7: Convection Mode
onlywhen grilling food or when using the rotisserie (only available on certain models). For all other types of cooking, never use the bottom shelf and never place anything on the bottom of the oven when it is in operation because this could damage the enamel. - Page 8 Fan Assisted Grill Position of thermostat knob “C”:Between 60 ℃ and 250 ℃ . The top central heating elements and the fan come on. This combination of features increases the effectiveness of the unidirectional thermal radiation of the heating elements through forced circulation of the air throughout the oven.
- Page 9 start automatically or you can press the function button to make it work. Automatic setting (set the time of full automatic starting and ending) 1.Press button, set cooking time; 2.Press button, set cooking finish time; 3.Set temperatures and cooking modes by turning the thermostat knob and selector knob.
-
Page 10: Cooking Tips
time is shown on the screen. After the setting, the correct time (hour:minute) and the button will show on the screen. When the button is pressed the time displaced will be seen. When the set time is reached, disappears and the alarm will ring again. To stop the alarm, press the button. -
Page 11: Cooking Table
necessary, otherwise the knobs may get very hot. Always leave a ‘‘finger’s width’’ between dishes on the same shelf. This allows the heat to circulate freely around them. To reduce fat splashing when you add vegetables to hot fat around a roast, dry them thoroughly or brush lightly with cooking oil. -
Page 12: Cleaning Your Oven
6.Cleaning Your Oven Essential Information Allow the oven to cool and isolate the electricity supply before carrying out any thorough cleaning and maintenance. Never use paint solvents, washing soda, caustic cleaners, biological powders, bleach, chlorine based bleach cleaners, coarse abrasives or salt. Do not mix different cleaning products –... -
Page 13: Control Panel And Doors
panel markings. Stainless steel can be effectively cleaned by simply using a dilute solution of water and mild detergent and drying to a shine with clean cloth. All parts of the oven can be cleaned with hot soapy water, take care that no surplus water seeps into the appliance. - Page 15 Removing the Oven Shelf Runners for Cleaning ??? (Need to add instructions on how to do this) Do not use steam cleaners to clean your appliance. Removing the glass from the door 1.Follow the procedure to remove the door. 2.Place the door on a soft and clean surface. With both hands hold the door and push the buttons on either side of the oven door (Fig.
-
Page 16: Troubleshooting
The glass door panels are made of toughened glass. This ensures in the unlikely event that a panel breaks, it does so into small fragments to minimize the risk of injury. Oven DO NOT use steel wool, oven cleaning pads, or any other materials that will scratch the surface. - Page 17 pushed fully back to stop? The knobs get hot when I use the oven or the grill. Can I avoid this? Yes, this is caused by heat rising from the oven or the grill and heating them up. Do not leave the oven door open. Make sure that the grill pan is pushed right back to the ‘back stop’...
-
Page 18: Installation
8.Installation Dear Installer Before you start your installation, please complete the details BELOW. Installer’s Name Installer’s Company Installer’s Telephone Number Appliance Serial Number If your customer has a problem relating to your installation they will be able to contact you easily. You must be aware of the following safety requirements &... - Page 19 protective gloves during installation This appliance should not be installed in a boat or caravan. The oven must be installed in accordance with the relevant Building regulations and IET regulations. You will need the following tools and equipment to complete the oven installation satisfactorily: 1.Electric drill 2.Steel tape measure...
- Page 20 DOUBLE POLE SWITCHED Fig. 9.2 FUSE SPUR OUTLET FUSE Fig. 9.3 220V - 240V ArtNo.130-0006 - Electrical connections BI oven (60) The oven can be installed under a worktop (Fig. 9.1) or at high level in a tall kitchen unit and depending on the type of installation it is designed to fit into a standard 560 mm or 600 mm wide oven housing.
-
Page 21: Provision For Ventilation
performance of the hob. Ensure that air can flow freely around the housing area, ideally remove the false back to the cabinet. If the oven is being installed into a fully enclosed built-under oven housing unit it may be necessary to cut a small slot in the top of the plinth fitted under the unit. -
Page 22: Customer Care
via a double pole switched fused spur outlet, protected by a 13A fuse (Fig. 9.2). We recommend that the appliance is connected by a qualified electrician, who is a member of the N.I.C.E.I.C. and who will comply with the I.E.T. and local regulations. -
Page 23: Circuit Diagram
SERVICE RECORD Date of purchase Installed by Installation Date Place of purchase: Date Part(s) replaced Engineer’s name 9.Circuit Diagram... - Page 26 NW602MF...
-
Page 27: Warranty/After Sales Service
10.Warranty/After Sales Service New World Customer Care Please keep this handbook in a safe place. Please fill in the model number and serial number in the spaces provided below as they will assist us should you need to call. 0344 815 3747 When you dial this number you will hear a recorded message and be given a number of options.
