Newworld 444444026 Operating And Installation Instructions

60edoc 60x60 electric double oven
Hide thumbs

Advertisement

Table of Contents

444444026
NW 60EDOC Whi
444444027
444444028
444444029
OPERATING AND INSTALLATION
INSTRUCTIONS OF
60x60 ELECTRIC DOUBLE OVEN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 444444026 and is the answer not in the manual?

Questions and answers

Related Manuals for Newworld 444444026

Summary of Contents for Newworld 444444026

  • Page 1 444444026 NW 60EDOC Whi 444444027 444444028 444444029 OPERATING AND INSTALLATION INSTRUCTIONS OF 60x60 ELECTRIC DOUBLE OVEN...
  • Page 2 Dear Customer, Thank you for purchasing this Cooking Appliance. The safety precautions and recommendations in these instructions are for your own safety and the safety of others. These instructions will also allow you to make full use of all the features offered by your appliance.
  • Page 3 CONTENS: LAYOUT OF YOUR COOKER SAFETY WARNINGS INSTALLATION AND PREPARATION FOR USE USING YOUR COOKER CLEANING AND MAINTENANCE SERVICE AND TRANSPORT...

  • Page 4: Part 1: Layout Of Your Cooker

    PART 1: LAYOUT OF YOUR COOKER Rack 2 Rack 1 Rack 5 Rack 4 Rack 3 List of Components Rack 2 Rack 1 1. Cooktop 2. Control panel 3. Top oven door 4. Oven door handle 5. Main oven door 6.

  • Page 5: Part 2: Safety Warnings

    PART 2: SAFETY WARNINGS READ THESE INSTRUCTIONS CAREFULLY AND COMPLETELY BEFORE USING YOUR APPLIANCE, AND KEEP IT IN A CONVENIENT PLACE FOR REFERENCE WHEN NECESSARY. THIS MANUAL IS PREPARED FOR MORE THAN ONE MODEL IN COMMON. YOUR APPLIANCE MAY NOT HAVE SOME OF THE FEATURES THAT ARE EXPLAINED IN THIS MANUAL. PAY ATTENTION TO THE EXPRESSIONS THAT HAVE FIGURES, WHILE YOU ARE READING THE OPERATING MANUAL.
  • Page 6 - WARNING: If the surface is cracked, switch off the appliance to avoid the possibility of electric shock. - For hobs incorporating a lid, any spillage should be removed from the lid before opening. And also the hob surface should be allowed to cool before closing the lid.
  • Page 7 - WARNING: Ensure that the appliance is switched off before replacing the lamp to avoid the possibility of electric shock. - CAUTION: Accessible parts may be hot when the cooking or grilling is in use. Young children should be kept away. •...
  • Page 8 During usage • When you first run your oven a certain smell will emanate from the insulation materials and the heater elements. For this reason, before using your oven, run it empty at maximum temperature for 45 minutes. At the same time you need to properly ventilate the environment in which the product is installed.

  • Page 9: Part 3: Installation And Preparation For Use

    PART 3: INSTALLATION AND PREPARATION FOR USE Manufactured with the best quality parts and materials, this modern, functional and practical cooker aims to meet all your cooking needs. Read the manual carefully to familiarise yourself with the functions of the appliance so that you know how to use it successfully and safely.

  • Page 10: Adjusting The Feet

    3.2 ADJUSTING THE FEET This cooker stands on 4 levelling legs. As the legs are initially on a lower position, you must adjust them to make sure the cooker is balanced before using it. If you need to balance the cooker, the legs can be adjusted by turning them clockwise. You can raise the cooker by a maximum of 15mm via the leveling legs.
  • Page 11 Connection diagram is given below. 3.4 GENERAL WARNING AND MEASURES Your product is manufactured in accordance with the related safety norms. Maintenance and repair works must be made only by authorized service technicians. It is dangerous to alter or modify the specifications of the appliance in any way.

  • Page 12: Part 4: Using Your Cooker

    PART 4: USING YOUR COOKER 4.1 TECHNICAL SPECIFICATIONS FOR TOP AND MAIN OVENS TOP OVEN OF 60x60 COOKER RATING Top Heating Element 700W Bottom Heating Element 700W Grill Heating Element 1600W MAIN OVEN OF 60x60 COOKER RATING Top Heating Element 1200W Bottom Heating Element 1100W...

  • Page 13: Control Panel

    4.2. CONTROL PANEL 444444027 The control panel of the cooker is shown below. 444444028 444444029 Mode 4.3. USING THE COOKTOP BURNERS The hob part of the appliance is controlled via knobs with 7 positions on the control panel. Position ''0'' is the off position. The remaining 6 positions indicate the following types of use: :Heat maintenance position : Heating in low temperature position...

  • Page 14: Using The Oven

    WRONG WRONG WRONG CORRECT pot bottom is round pot buttom does not sit well pot buttom is small Figure 9 After using any hob, make sure that it is switched off. Never touch any heating element, even after it is turned off. The element will still hold heat for a certain time after use.
  • Page 15 Alarm Setup This function can be used to set up an alarm that will go off after a desired period of time. The ''Mode'' key must be pressed until the ‘ led indicator start to flash. ‘ Adjust the desired duration via the ''+'' and ''-'' keys. The desired time remains on screen after it was adjusted and the ‘...
  • Page 16 The cooking period is adjusted as described above. Then, press the ''Mode'' key until the ''End'' indicator flashes, and adjust the end time using the ''+'' and ''-'' has been keys. Once time adjusted, En d registered automatically within 5 seconds. The will be lit.
  • Page 17 Double Grilling Function This function is used for wider area grilling. In order to grill, please use the grill pan supplied with your product. Turn your top oven's switch until it shows the sign of this function. For cooking details, please refer to the cooking table. At the end of grilling, as in all other cooking processes;...
  • Page 18 4.4.4. Using the Main Oven The main oven switch allows you to select the various oven functions. Where the functions are the same as the top oven, these functions are explained in the previous pages. The detailed information for functions unique to the main oven ar explained in the following pages.
  • Page 19 4.5. USING THE GRILL PAN AND HANDLE SET Warning : Always use an oven glove to protect your hand when using the grill as the metal parts can become very hot! The grill pan has a detachable handle. Ensure when using the grill pan handle that it is centralized and secure as shown below.

  • Page 20: Cooking Recommendations

    4.6. COOKING RECOMMENDATIONS 4.6.1. Top oven cooking chart Food Cooking Temperature Time(min.) Rack position Small Cakes 160-185 20-25 1(From Bottom) Burgers Max position 20-25 2(From Bottom) Beef Max position 25-30 2(From Bottom) Toast Max position 5-10 2(From Bottom) Fruit Cake Sponge Cake Victoria Sandwich 4.6.2.

  • Page 21: Cleaning The Oven

    PART 5: CLEANING AND MAINTENANCE OF YOUR OVEN 5.1 GENERAL Before starting to clean your oven, be sure that all control knobs are off and your appliance has cooled off. Before using any cleaning materials, check whether they are appropriate and recommended for your oven.

  • Page 22: Cleaning The Ceramic Hob

    5.3. CLEANING THE CERAMIC HOB Make sure to unplug the oven before starting to clean it. Before starting cleaning wait for the ceramic cooker to cool down completely. Be sure that the cleaning material does not contain any particles which may scratch the glass.
  • Page 23 5.5 REMOVAL OF THE TOP OVEN DOOR In order to clean properly, you may remove the top oven door. To remove the door, please follow the instructions below. Open the door fully and release the saddle brackets situated either side. Please make sure that the saddle brackets are opened to their end positions (Fig.5-2).

  • Page 24: Maintenance

    · Close the door till it almost reaches the fullly closed position and remove it by pulling towards yourself. Note : To re- assemble the door follow the opposite rules of removal. Please pay attention to the reccessed forms on each hinge mechanism, they should be positioned properly on the hinge counterparts as shown above.
  • Page 25 Anti-tilting wire grid To locate the grid correctly in the cavity, put it up to any rack position and push the grid up to the end. The anti-tilting wire grid must be placed inside of the cavity. WARNING- Fit the grid correctly into any corresponding rack in the oven cavity and push it to the end.

  • Page 26: Part 6: Service And Transport

    PART 6: SERVICE AND TRANSPORT 6.1. CHECK BEFORE CONTACTING TO SERVICE If the oven does not operate : The oven may be plugged off; there has been a blow-out. On models fitted with a timer, the time may not be regulated. If the oven does not heat : The temperature may not have been selected on the heater control switch.
  • Page 27 The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
