- Page 1 TECHNICAL MANUAL INSTRUCTIONS FOR INSTALLATION AND USE OF ELECTRIC WATER HEATERS AND ENAMELLED HEATER TANKS FROM 300 to 3000L Document ref.: 428016 03...
- Page 2 Document ref.: 428016 03...
-
Page 3: Document Ref.: 428016
DATASHEET Name of supplier Model LCA P 300 LCA P 500 LCA P 750 LCA P 1000 LCA P 1500 LCA P 2000 LCA P 2500 LCA P 3000 ErP class Standing [W/H] 93,23 112,09 145,57 168,2 205,92 246,25 277,52 302,05 losses Storage... - Page 4 DATASHEET Name of supplier LCA 300 LCA 500 LCA 750 LCA 1000 LCA 1500 LCA 2000 LCA 2500 LCA 3000 Model 2CO hh 2CO hh 2CO hh 2CO hh 2CO hh 2CO hh 2CO hh 2CO hh ErP Class Standing [W/H] 98,94 118,96...
-
Page 5: Table Of Contents
CONTENTS 1. RECOMMENDATIONS 2. INSTALLATION 3. HYDRAULIC CONNECTION 4. HYDRAULIC TESTS 5. ELECTRICAL CONNECTION 6. INSTALLATION OF HEATING COMPONENTS 7. ELECTRICAL SPECIFICATIONS AND CABLING DIAGRAMS 8. PUFFER RANGE 9. DOMESTIC HOT WATER STORAGE RANGE 10. SINGLE COIL RANGE 11. HEAT PUMP COIL RANGE 12. - Page 6 Document ref.: 428016 03...
-
Page 7: Recommendations
1. RECOMMENDATIONS essential to comply with all prescriptions relating to 1-1 General recommendations domestic hot water tanks, as well as the instructions 1. This very important manual is an indispensable part of supplied by the manufacturer. the appliance. To prevent burns, use suitable mixing devices to avoid The manual must be kept in a safe place and must be exceeding a temperature of 50°C at the catchment passed onto any subsequent owners or users of the... - Page 8 Contact with live conductors can cause electrical arcing. inhaling dust, being hit, or cuts, pricks, abrasions, noise Explosions, fires or poisoning in the event of gas leaking or vibrations. from a damaged duct. The utmost care must be taken during operations Damage to existing installations.
- Page 9 TRANSPORT, STORAGE RECYCLING INSTRUCTIONS The appliance must be transported in accordance with the pictograms hereunder on the packaging. The appliance must be transported and stored in dry conditions and freezing conditions must be avoided. EU directive 2002/96/EC requires selective collection and recycling of used electrical and electronic devices.
-
Page 10: Installation
INSTALLATION IMPORTANT The appliance must be installed in accordance with professional good practice and in compliance with the national regulations in force for hydraulic and electrical connections, under the entire responsibility of the installer. This appliance must be installed in covered premises, sheltered from frost and having sufficient upper and lower ventilation. -
Page 11: Hydraulic Connection
RECOMMENDATIONS The appliance must be as close as possible to the supply stations. For operations of maintenance or replacement of heating components, easy access must be provided. (Fig 1) Figure 2 0.30 m Figure 1 Electrical cover Capot électrique 1.20m Sleeves de raccordement Connecting sleeves... - Page 12 DIAGRAM OF PRINCIPLE WITH TWO WATER HEATERS CONNECTED IN SERIES/PARALLEL IMPORTANT: In the event of installation of battery appliances, it is imperative to install a safety valve specific to each appliance. Safety units for the whole of the range (as option) to be installed on each appliance. These valves must be calibrated at 7 bar maximum and comply with NF.
-
Page 13: Hydraulic Tests
To enable the expansion of the water in the water heater, the safety valve must be fitted with a pipe which will allow this expansion to overflow into a funnel connected to the drain. Under no circumstances must you reduce its diameter or close this pipe with a plug or a stop valve. -
Page 14: Electrical Connection
ELECTRICAL CONNECTION Before connecting the appliance, check that the power is off, that the appliance is full of water and that it is watertight. Recommendations for installation: The electrical installation must comply with national regulations in force in the country of installation. -
Page 15: Installation Of Heating Components
INSTALLATION OF HEATING COMPONENTS A) Single resistance platinum shielded (9Kw - 15Kw - 30Kw) ASSEMBLY DIAGRAM Recommended order of assembly Assembly of the flange with tightening to 3dN Duct for Installation of M10Pins thermostat Installation of the seal centre Installation of the resistance (NB loop downwards for 15 &... - Page 16 C – Multi-resistance steatite ASSEMBLY DIAGRAM Recommended order of assembly Assembly of the flange with tightening to 3dN Duct for Installation of seals, abutting thermostat the head of the sheaths sensor The sheaths must be assembled by hand, using a tube giving counterweight to facilitate the engagement of the thread of the sheath into...
-
Page 17: Electrical Specifications And Cabling Diagrams
E - Coil with flange 1m² or 3m² ASSEMBLY DIAGRAM Recommended order of assembly Duct for Installation of joint on the thermostat flange. sensor Assembly of the flange fitted with its coil on the tank and tighten the bolts at 3dN. Installation of cap. - Page 18 6h59mn 3h29mn 2h41mm 1h45mm 14h56mm 9h20mm 4h39mn 2000 3h27mm 2h21mm 18h42mm 11h40mm 5h49mn 2500 4h25mm 2h57mm 22h25mm 14h00mm 7h00mn 3000 5h15mm 3h28mm ELECTRIC DIAGRAM Supplied by installer Supplied with the kit Document ref.: 428016 03...
- Page 19 CABLING DIAGRAMS Fig N° 1 Fig N° 2 Star Cabling 9 kW (3x400 V) Triangle Cabling 9 kW (3x230 V) TYPE SECTION COLOUR TYPE SECTION COLOUR Control 1.5mm² Control 1.5mm² Power 10 mm² Black Power 10 mm² Black Earth 10 mm² Green/Yellow Earth 10 mm²...
- Page 20 Fig N° 5 Triangle Cabling 45 kW / 60 kW (3x400 V) Safety bulb Bulbe de sécurité Regulation bulb Bulbe de régulation Document ref.: 428016 03...
- Page 21 B - Multi steatite resistances Enamelled tank of 750 to 3000 litres Flange equipped with immersion steatite resistances (from 2 to 5 steatites depending on heating power) directed towards the bottom of the tank, thus avoiding cold zones and the proliferation of bacteria. ...
- Page 22 CABLING DIAGRAMS Fig N° 7 Fig N° 6 Triangle Cabling 9 – 18 kW (3x230 V) Star Cabling 9 – 18 kW (3x400 V) TYPE SECTION COLOUR TYPE SECTION COLOUR Control 1.5 mm² Control 1.5 mm² Power 10 mm² Black Power 10 mm²...
- Page 23 Fig N° 10 Fig N° 11 Star Cabling 15 – 30 kW (3x400 V) Triangle Cabling 15 – 30 kW (3x230 V) TYPE SECTION COLOUR TYPE SECTION COLOUR Control 1.5 mm² Control 1.5 mm² Power 10 mm² Black Power 10 mm² Black Earth 10 mm²...
-
Page 24: Puffer Range
PUFFER RANGE This is a carbon steel tank designed for the storage of water for primary network (Operating pressure max : 5bar). WEIGHT WITH ELEVATION (mm) Ø A LITRES INSULATION (mm) (kg) 1409 1145 2005 1752 1322 1906 1601 1246 1000 2259 1956... -
Page 25: Domestic Hot Water Storage Range
DOMESTIC HOT WATER STORAGE RANGE This is an enamelled tank designed for the storage of Domestic Hot Water (Operating pressure max : 7bar). WEIGHT ELEVATION (mm) WITH Ø A LITRES INSULATION (mm) 1386 1155 472 150 204 525 1983 1752 1494 1108 472 150... -
Page 26: Single Coil Range
SINGLE COIL RANGE This is an enamelled tank with single exchanger designed for the production of Domestic Hot Water from a heating application such as boiler or solar panels (Operating pressure max : 7bar). WEIGHT ELEVATION (mm) EXCHANGE Ø A WITH SURFACE (mm) -
Page 27: Heat Pump Coil Range
MISECE DE HEAT PUMP COIL RANGE This is an enamelled tank with single exchanger designed for the production of Domestic Hot Water from a heating application such as boiler, Heat Pump or solar panels (Operating pressure max : 7bar). EXCHANGE WEIGHT WITH ELEVATION (mm) SURFACE... -
Page 28: Double Coil Range
DOUBLE COIL RANGE This is an enamelled tank with double exchanger designed for the production of Domestic Hot Water from (Operating pressure max : 7bar). twin applications such as boiler, PAC and solar panels ELEVATION (mm) EXCHANGE SURFACE (m²) Ø A Weight Low. -
Page 29: Installation Of Hydraulic Accessories
INSTALLATION OF HYDRAULIC ACCESSORIES Installation of upper flange using 6 M10 bolts and seal. The Flange, Seal and Screws assembly is provided in a box inside the electrical kits or fixed to the pallet. The drain in the lower part is connected to the cold water (see diagram of hydraulic installation and dimensions). -
Page 30: Installation Of The Insulation
14. INSTALLATION OF THE INSULATION A – I M1 – E NSTALLATION OF SOFT INSULATION UROCLASS M0 – E B - I NSTALLATION OF SOFT INSULATION UROCLASS Unpack the shells, place them near the water heater. Install pannels A&B (or +) closed to the tank, rests on the upper bottom. Close latches C. -
Page 31: Commissioning
15. COMMISSIONING VERY IMPORTANT 15-1 CHECK THAT THE TANK IS FULL OF WATER Fill the water heater (by opening the water inlet valve and a hot water To do this: The water heater is full when the water flows normally at this tap. supply tap to evacuate the air from the tank). -
Page 32: User Recommendations
17. USER RECOMMENDATIONS With regard to the water temperature: The distribution temperature of 65 °C is the ideal temperature for most needs. However, in the event of hard water the water temperature must be below 60 °C to limit the scaling of the heating elements. In the event of boiling in a water heater and emission of steam jets at the supply taps, immediately switch off the power, open a hot water tap and notify your installer. -
Page 33: Maintenance And Cleaning
MAINTENANCE AND CLEANING SWITCH OFF THE ELECTRICAL SUPPLY BEFORE ANY WORK ON THE APPLIANCE The frequency of interventions depends on the quality of the water stored and the output. However, it is recommended to check the condition of the heating elements and the inside of the tank twice a year. -
Page 34: Troubleshooting
Annual operation (mandatory) Dissemble the flange and the heating elements (resistances and sheath) Check the inside of the tank; descale if necessary Change the seal Dismantle the heating elements (resistances and sheath) and clean them As this operation is tricky, you are strongly advised to use a specialised company. carefully of any deposit. -
Page 35: Warranty
Insufficient hot water the adjustment of the thermostat, and modify it if it is not in the stop position, Check successively: the correct tightening of the connections, the power of the resistances on the three phases and the type of current used, ... - Page 36 ACV International Oude Vijverweg 6 1653 DWORP BELGIUM Document ref.: 428016 03...
