Comfort manual _Comfort 55 9/8/14 10:29 AM Page 1
Comfort
WARNING
IMPORT NT
Date Revised 06/20/14
Indirect Fired Water Heater
Technical Specifications
Installation and Maintenance Guide
•
Before proceeding with installation and operation, read entire manual care-
fully. Failure to do so can cause injury or property damage.
•
When receiving COMFORT Water Heaters, any claims for damage or
shortage in shipment must be filed immediately against the transporta-
tion company by the consignee.
•
Warranty Registration Card must be filled out by the customer and mailed
within thirty (30) days of installation in order to gain warranty coverage.
•
Retain and affix this manual near the water heater for future reference
•
Installation and service should only be performed by a qualified installer or
service technician.
2013-32 COMFORT IWH Manual
661A0100 rev C
Advertisement
Table of Contents
Related Manuals for ACV COMFORT 45
Summary of Contents for ACV COMFORT 45
- Page 1 Comfort manual _Comfort 55 9/8/14 10:29 AM Page 1 Comfort Indirect Fired Water Heater Technical Specifications Installation and Maintenance Guide • Before proceeding with installation and operation, read entire manual care- WARNING fully. Failure to do so can cause injury or property damage. •...
-
Page 2: Table Of Contents
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 2 Table of Contents Product & Safety Information ........1 Pre-Installation . -
Page 3: Product & Safety Information
CAUTION To prevent damage to the inner tank, the NOTI E Installer must: ACV-Triangle Tube reserves the right to • Always fill inner tank prior to outer tank modify the technical specifications and and always drain outer tank prior to inner components of its products without prior tank. -
Page 4: Pre-Installation
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 4 Pre-Installation Codes Compliance Codes Restrictions Water heater installation must conform with the Single wall heat exchanger in the COMFORT instructions in this manual and where applicable: water heater complies with National Standard Plumbing Code, provided that: •... - Page 5 Comfort manual _Comfort 55 9/8/14 10:29 AM Page 5 Pre-Installation Operating Restrictions NOTI E • Maximum boiler water temperature is 194ºF. Any water conditioning system must be installed and maintained in accordance with • Maximum working pressure for inner manufacturer’s specifications. (domestic water) tank is 125 psig.
-
Page 6: Pre-Installation
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 6 Pre-Installation Locating Water Heater Recommended Clearances • This water heater is not intended for out- • Water heater should be installed to allow door installations. adequate clearance for servicing. • Zero clearance is permissible to any side of •... -
Page 7: Installation - Piping
- directly connected to a drain. Terminate local codes: discharge piping within 6” from drain. - COMFORT 45 and 55: 3/4”NPT with an Refer to local codes. AGA Rating of 100,000 BTU/hr and a - plugged, reduced or restricted. -
Page 8: Drain Valve
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 8 Installation - Piping Drain Valve Water Hammer Drain valve and fittings are supplied by others. Dishwashers, clothes washers and fast-closing pos- Standard Installation itive shut-off valves incorporated in the system all •... -
Page 9: General Piping
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 9 Installation - Piping General Piping Domestic Piping • For domestic water piping diagrams, see page 9. • Union on domestic hot water outlet should be piped at a higher elevation than domestic water •... -
Page 10: Thermostatic Mixing Valve
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 10 Installation - Piping Thermostatic Mixing Valve Boiler Piping • A mixing valve complying with ASSE 1017 • If plastic pipe is used for boiler water piping, it must be installed on the domestic hot water must have a maximum oxygen diffusion rate of outlet. - Page 11 Comfort manual _Comfort 55 9/8/14 10:29 AM Page 11 Installation - Piping 12" min. Heat Trap 12" min. Loop Heat Trap (Optional) Loop (Optional) Cold Water Inlet Fig. 1: Standard Installation Domestic Piping COMFORT Series Recirculating Loop Cold Water Inlet 12"...
- Page 12 Comfort manual _Comfort 55 9/8/14 10:29 AM Page 12 Installation -Piping 3- Port Priority Valve Cold water inlet Fig. 3: COMFORT System Piping with 3-Port Zone Valve (Domestic Priority) 2-Port Priority Valve (normally open) 2-Port Priority Valve (normally close) Cold water inlet Fig.
- Page 13 Comfort manual _Comfort 55 9/8/14 10:29 AM Page 13 Installation - Piping COMFORT System Piping with Zone Valves Fig. 5: (Non Domestic Priority) Fig. 6: COMFORT System Piping with Zone Circulators 1. Shut-off valves 5. Drain valve 2. Circulator 6. Feed valve 3.
-
Page 14: Installation - Wiring
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 14 Installation - Wiring Wiring Requirements 4. An optional service switch may be installed in water heater electrical circuit. This switch would only shut off the water heater, not the WARNING home heating system. Do not shut off water heater if there is a chance of freezing. -
Page 15: Installation - Wiring Drawings
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 15 Installation - Wiring P and 1 Connections Fig. 7: Optima Zone Panel SZC5 with Zone Pumps Wiring... - Page 16 Comfort manual _Comfort 55 9/8/14 10:29 AM Page 16 Installation - Wiring P and 1 Connections Fig. 8: Optima Zone Panel SCZ5 with Zone Valves Wiring...
- Page 17 Comfort manual _Comfort 55 9/8/14 10:29 AM Page 17 Installation - Wiring Typical 4-wire Zone Valve Zoning, Fig. 10: Typical 3-wire Zone Valve Zoning, Fig. 9: with Domestic Priority with Domestic Priority V.A.C. High Voltage V.A.C. High Voltage Transformer Transformer (Power) (Power) V.A.C.
- Page 18 Comfort manual _Comfort 55 9/8/14 10:29 AM Page 18 Installation - Wiring Fig. 11: Typical 4-wire Zone Valve Zoning, Fig. 12: Typical 3-wire Zone Valve Zoning, without Domestic Priority without Domestic Priority V.A.C. High Voltage V.A.C. High Voltage Transformer Transformer (Power) (Power) V.A.C.
- Page 19 Comfort manual _Comfort 55 9/8/14 10:29 AM Page 19 Installation - Wiring Fig. 13: Typical Circulator Zoning Fig. 14: Typical Circulator Zoning with Domestic Priority without Domestic Priority Thermostat Honeywell Thermostat zone 1 Honeywell R845A zone 1 R845A Relay Relay Circulator Zone 1 Circulator...
- Page 20 Comfort manual _Comfort 55 9/8/14 10:29 AM Page 20 Installation - Wiring Fig. 15: Priority Zone Circulator Wiring Thermostat Honeywell zone 1 R845A Circulator Relay Note: Maximum of 4 total circulator zone when wiring 1 zone for priority. Circulator Zone 1 Thermostat zone 2 Low Voltage...
-
Page 21: Water Heater Start-Up
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 21 Water Heater Start-Up Filling the Inner (Domestic Water) Tank Filling the Outer (Boiler Water) Tank CAUTION CAUTION • Never use water heater unless inner and Never use water heater unless inner and •... -
Page 22: General Notes
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 22 Water Heater Start-Up General Notes DANGER • Household water usage patterns will affect water temperature at any faucet or shower. HOT WATER CAN SCALD! Occasionally check temperature at each point • Water temperatures over 125ºF can cause of use, then adjust thermostat accordingly. -
Page 23: Adjusting The Water Heater Thermostat
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 23 Water Heater Start-Up Adjusting the Water Heater Thermostat Water heater thermostat is factory set to its lowest temperature. This may or may not be suitable for your needs. Turn thermostat knob clockwise toward 5 increase water temperature. -
Page 24: Water Heater Maintenance
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 24 Water Heater Maintenance Maintenance Schedule Review homeowner’s maintenance responsi- bilities and their frequencies, including any Annual service by qualified service technician not listed in the following section. should include the following: Homeowner monthly maintenance to include: Any procedure required by local codes. -
Page 25: Draining Inner (Domestic Water) Tank
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 25 Water Heater Maintenance NOTI E WARNING Do not use automotive, ethylene glycol or Prior to draining the inner tank, ensure the petroleum-based antifreeze. Do not use following is completed: any undiluted antifreeze. This can cause 1. -
Page 26: Draining Outer (Boiler Water) Tank
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 26 Water Heater Maintenance Draining Outer (Boiler Water) Tank 6. When draining is complete, remove the air hose and fittings needed to connect the air 1. Disconnect wiring connection at water heater. hose. -
Page 27: Replacement Parts List
Comfort manual _Comfort 55 9/8/14 10:29 AM Page 27 Replacement Parts COMFORT Aquastat Assembly... - Page 28 Comfort Item Part # Models Description P3KITAV02 Air vent, manual Aquastat Assembly ( Knob, Cover & P3KITTH04 Aquastat - 160ºF) P3KITBTM05 Bottom cap P3KITTOP05 Top cap P3DW06 Drywell (Not Shown) P3WKITDT01 COMFORT 45 Dip tube P3WKITDT02 COMFORT 55 P3KNB02 Knob...
-
Page 29: Water Heater Specifications
Thermostat & Cover Cold Water Air Vent Inlet Hot Water Outlet Boiler Supply Top View Left Side View MODEL COMFORT 45 COMFORT 55 Capacity Gal. Domestic Boiler Heating surface Sq. Ft. Head loss boiler side 1-1/4 Piping connections Inches ø... - Page 30 Comfort manual _Comfort 55 9/8/14 10:29 AM Page 30 riangle Tube Additional quality water heating equipment available from: ACV-T Prestige Condensing Wall Mounted Boiler 95% AFUE - Energy Star Fully modulating Natural gas or propane Stainless Steel Construction Direct vent PVC, CPVC, PP and SS...
