- Page 1 Technical Manual CEILING EXPOSED SPLIT SYSTEMS ACM 30D/DR ACM / A5CM 40D/DR ACM / A5CM 50D/DR ACM / A5CM 62C/CR...
-
Page 2: Table Of Contents
TABLE OF CONTENTS 1. NOMENCLATURE ......................1 - PRODUCT LINE UP 2. FEATURES ........................7 3. APPLICATION INFORMATION ..................8 - OPERATING RANGE - REFRIGERANT CIRCUIT DIAGRAM - CONTROLLER - INSTALLATION 4. SOUND DATA ......................30 - NC CURVES 5. ENGINEERING AND PHYSICAL DATA ............... 34 - SPECIFICATIONS 6. -
Page 3: Nomenclature
R : Heatpump Omitted if Cooling Only Series C : C Series D : D Series Capacity 40 : 40,000 Btu/h Model Name CM : Ceiling Exposed Refrigerant 4 : R407C 5 : R410A Omitted if R22 Brand R : Acson... - Page 4 R : Heatpump Omitted if Cooling Only Series C : C series / D : D Series Capacity 20 : 20,000 Btu/h Model Name LC : Single Split Condensing Unit Refrigerant 5 : R410A Omitted if R22 Model Brand A : Acson...
- Page 5 R : Heatpump Omitted if Cooling Only Series B : B Series C : C Series Capacity 30 : 30,000 Btu/h Model Name LC : Single Split Condensing Unit Refrigerant 4 : R407C Omitted if R22 Brand A : Acson...
- Page 6 A C M A C M A 5 C M...
- Page 7 OUTDOOR UNIT ALC-C SERIES PRODUCT LINE UP Classification Safety Devices ACPOD ACPID ACPOD ACPID ACPOD ACPID ACPOA ACPIA AFGE AFGF AFGG FFGE FFGG AFGE AFGG AFGE AFGG FFGE FFGF FFGG FFGE FFGF FFGG FFFE FFFF FFFG ACPOD 18CR ACPID ACPOD 20CR ACPID ACPOD...
- Page 8 OUTDOOR UNIT A5LC-C SERIES PRODUCT LINE UP Classification Safety Devices A5LC M5LC ACPOA ACPIA FCPOA FCPIA ACCOA ACCIA FCCOA ACCOB FCCOB FCCOB FCCOB ACPOA ACPIA 28CR FCPOA FCPIA ACCOA ACCIA 35CR FCCOA FCCGA ACCOB 40CR FCCOB 50CR FCCOB 61CR FCCGA...
-
Page 9: Features
2. FEATURES ULTRA SLIM NEW STYLISH DESIGN PROFILE This unit is contemporary in design and match even the most up to date interior decor. The slim, round profile and compact design of this unit adds a touch of elegance to every decor. No indoor connection pipe and hanger bracket are visible. -
Page 10: Application Information
3. APPLICATION INFORMATION OPERATING RANGE Ensure the operating temperature is in allowable range. Cooling only High ambient Caution : unit The use of your air conditioner Standard outside the range of working point temperature and humidity can result in serious failure Low ambient kit Indoor temp. - Page 11 MODEL : ACM 30D – ALC 28C ACM 30D – ALC 30D MODEL : ACM 40D – ALC 35 / 40D ACM 50D – ALC 50D ACM 62C – ALC 61D...
- Page 12 MODEL :A5CM 40D – A5LC 35 / 40D A5CM 50D – A5LC 50D A5CM 62C – A5LC 61D...
- Page 13 MODEL :ACM 30DR - ALC 28CR MODEL :ACM 30DR - ALC 30DR ACM 40DR - ALC 40DR ACM 50DR - ALC 50DR...
- Page 14 A5CM 40DR – A5LC 35 / 40DR MODEL : A5CM 50DR – A5LC 50DR A5CM 62CR – A5LC 61DR MODEL : ACM 62CR – ALC 61DR...
-
Page 15: Controller
G8 Remote Controller 1. TRANSMISSION SOURCE • The source where the signal will be transmitted. • Set the desired off time by pressing the SET button 2. SIGNAL TRANSMISSION INDICATION continuosly. • Blink to confirm the last setting has been send to •... -
Page 16: Controller
SENSOR ON/OFF ON/OFF AUTO COOL HIGH TEMP MODE TEMP HEAT SWING SLEEP TIMER SWING SLEEP TIMER MODE AC-5300 (OPTIONAL) 1. “ON/OFF” SWITCH 6. “SLEEP” MODE • Press to start the air conditioner unit. • Press button to activate the sleep •... -
Page 17: Controller
OPERATING STATE AND FAULT TABLE WIRELESS REMOTE CONTROLLER - HANDSET COOLING: LED INDICATOR LIGHT DISPLAY HEATPUMP : LED INDICATOR LIGHT DISPLAY COOL COOL HEAT Self Diagnosis Table Operation / Faulty Indication COOL HEAT Cool Mode Dry Mode Fan Mode Heat Mode ◑... - Page 18 PHSAE SEQUENCER The unit with Scroll Compressor can only rotate in one direction. For this reason, a protective device (phase sequencer) is fitted to prevent incorrect wiring of the electrical phases. When the three phases are not connected correctly, the phase sequencer operates, and the unit will not start. This devise is located in the control box of the outdoor unit.
-
Page 19: Installation
Figure B. All Dimension in mm ACM 20D/DR ACM 25D/DR ACM 30D/DR ACM 40D/DR ACM 50D/DR Model 1214... - Page 20 ACM-D ACM 62C Figure B Please ensure that the following steps are taken : • Check the gradient for drainage flow as recommended in Figure B. • Provide clearance for easy servicing and optimal air flow as shown in Figure C. •...
- Page 21 ACM 62C Figure C • Provide the installation space as shown in Figure D. ACM-D ACM 62C Figure D...
- Page 22 INSTALLATION - CEILING EXPOSED TYPE STEP 1 Remove air intake grille, side panel, side close-up and hanger bracket from the unit; see Fig E Figure E STEP 2 Position the hanger rods as per Fig B and install the hanger bracket; see Fig F. Figure F STEP 3 Hanger up the unit and tighten the bolt, after completed the piping and drain pipe;...
- Page 23 INSTALLATION - FLOOR STANDING TYPE STEP 1 Remove air intake grille, side panel, side close-up and side panel from the unit; see Fig E. STEP 2 Position the support supply) as per Fig B. install the unit; see Fig I Figure I STEP 3 Two types of piping and drain pipe connection as Fig J.
-
Page 24: Model
(2) INSTALLATION OF OUTDOOR UNIT As condensing temperature rises, evaporating temperature rises and cooling capacity drops. In order to achieve maximum cooling capacity, the location selected for outdoor unit should fulfill the following requirements : • Install the condensing (outdoor) unit in a way such that hot air distributed by the outdoor condensing unit cannot be drawn in again (as in the case of short circuit of hot discharge air). - Page 26 4) WIRING ELECTRICAL CONNECTIONS Wiring regulations on wire diameters differ from country to country. Please refer to your LOCAL ELECTRICAL • CODES for field wiring rules. Be sure that installations comply with the rules and regulations. GENERAL PRECAUTIONS Ensure that the rated voltage of the unit corresponds to the name plate before carrying out proper wiring •...
-
Page 27: Model
(6) ADDITIONAL CHARGE The refrigerant charge has already charged into the outdoor unit. For the piping length of 7.6m, additional • refrigerant charge after vacuuming is not necessary. When the piping length is more than 7.6m, please use the table below (unit in gram). •... - Page 28 SPECIAL PRECAUTIONS WHEN DEALING WITH REFRIGERANT R410A UNIT 1) WHAT IS NEW REFRIGERANT R410A? R410A is a new HFC refrigerant which does not damage the ozone layer. The working pressure of this new refrigerant is 1.6 times higher than conventional refrigerant (R22), thus proper installation / servicing is essential.
- Page 29 d) When charging R410A, ensure that only liquid is being withdrawn from the cylinder or can. This is to ensure that only the original composition of R410A is being delivered into the system. The liquid composition can be different from the vapor composition. Dip-pipe Invert cylinder without dip-pipe...
- Page 30 (6) OVERALL CHECKING Ensure the following, in particular: • The unit is mounted solidly and rigid in position. Piping and connections are leak proof after charging. Proper wiring has been done. Drainage check – pour some water into drain pan. •...
-
Page 31: Sound Data
Overall Noise 1/1 Octave A-weighted und Pressure (dBA), ref 20μPa 125Hz 250Hz 500Hz 1kHz 2kHz 4kHz 8kHz A(dBA) Criteria ACM 30D/DR High Medium ACM / R5CM High 40D/DR Medium ACM / R5CM High 50D/DR Medium ACM / R5CM High 62C/CR... -
Page 32: Acm 20D/Dr
ACM 20D/DR NC CURVES ACM 25D/DR NC CURVES... -
Page 33: Acm / A5Cm 40D/Dr
ACM30D/DR NC CURVES ACM / A5CM 40D/DR NC CURVES... -
Page 34: Acm / A5Cm 50D/Dr
ACM / A5CM 50D/DR NC CURVES ACM / A5CM 62C/CR NC CURVES... -
Page 35: Engineering And Physical Data
5. ENGINEERING AND PHYSICAL DATA GENERAL DATA - COOLING ONLY (R22) ACM 30D INDOOR UNIT MODEL OUTDOOR UNIT ALC 28C ALC 30D Btu/h 26500 29000 / <29000> NOMINAL CAPACITY - 1Ø / <3Ø> 7766 8490 / <8490> NOMINAL TOTAL INPUT POWER - 1Ø / <3Ø>... -
Page 36: Model
GENERAL DATA - COOLING ONLY (R22) ACM 40D INDOOR UNIT MODEL OUTDOOR UNIT ALC 35D ALC 40D Btu/h 34000 39000 / <39000> NOMINAL CAPACITY - 1Ø / <3Ø> 9960 11420 / <11420> NOMINAL TOTAL INPUT POWER - 1Ø / <3Ø> 3120 3250 / <3220>... -
Page 37: Model
GENERAL DATA - COOLING ONLY (R22) INDOOR UNIT ACM 50D ACM 62C MODEL OUTDOOR UNIT ALC 50D ALC 61D Btu/h 49000 56000 / 55100* NOMINAL CAPACITY 14350 16410 / 16150* NOMINAL TOTAL INPUT POWER 4590 5593 / 6310* NOMINAL RUNNING CURRENT 9.4 / 9.9* POWER SOURCE V/Ph/Hz... -
Page 38: Model
GENERAL DATA - HEAT PUMP (R22) INDOOR UNIT ACM 30DR MODEL OUTDOOR UNIT ALC 28CR ALC 30DR Btu/h 26500 30000 / <30000> NOMINAL COOLING CAPACITY - 1Ø / <3Ø> 7766 8790 / <8790> Btu/h 27000 32000 / <32000> NOMINAL HEATING CAPACITY - 1Ø / <3Ø> 7910 9380 / <9380>... -
Page 39: Model
GENERAL DATA - HEAT PUMP (R22) ACM 40DR INDOOR UNIT MODEL OUTDOOR UNIT ALC 35DR ALC 40DR Btu/h 34000 39000 / <39000> NOMINAL COOLING CAPACITY - 1Ø / <3Ø> 9960 11420 / <11420> Btu/h 35000 41000 / <41000> NOMINAL HEATING CAPACITY - 1Ø / <3Ø> 10260 12020 / <12020>... -
Page 40: Model
GENERAL DATA - HEAT PUMP (R22) INDOOR UNIT ACM 50DR ACM 62CR MODEL OUTDOOR UNIT ALC 50DR ALC 61DR Btu/h 48000 56000 NOMINAL COOLING CAPACITY 14067 16410 Btu/h 48000 56000 NOMINAL HEATING CAPACITY 14067 16410 NOMINAL TOTAL INPUT POWER (COOLING) 4491 5593 NOMINAL TOTAL INPUT POWER (HEATING) -
Page 41: Model
GENERAL DATA - COOLING ONLY (R410A) INDOOR UNIT A5CM 40D MODEL OUTDOOR UNIT A5LC 35D A5LC 40D Btu/h 33000 / <33300> 38500 / <38500> NOMINAL COOLING CAPACITY - 1Ø / <3Ø> 9670 / <9670> 11280 / <11280> NOMINAL TOTAL INPUT POWER (COOLING) - 1Ø / <3Ø> 3148 / <3048>... -
Page 42: Model
GENERAL DATA - COOLING ONLY (R410A) INDOOR UNIT A5CM 50D A5CM 62C MODEL OUTDOOR UNIT A5LC 50D A5LC 61D Btu/h 43000 55000 NOMINAL COOLING CAPACITY 12600 16119 NOMINAL TOTAL INPUT POWER (COOLING) 4700 6414 NOMINAL RUNNING CURRENT (COOLING) POWER SOURCE V/Ph/Hz 380 - 415 / 3 / 50 380 - 415 / 3 / 50... -
Page 43: Model
GENERAL DATA - HEAT PUMP (R410A) A5CM 40DR INDOOR UNIT MODEL OUTDOOR UNIT A5LC 35DR A5LC 40DR Btu/h 33000 / <33000> 38500 / <38500> NOMINAL COOLING CAPACITY - 1Ø / <3Ø> 9670 / <9670> 11280 / <11280> Btu/h 33000 / <33000> 39000 / <39000>... -
Page 44: Model
GENERAL DATA - HEAT PUMP (R410A) INDOOR UNIT A5CM 50DR A5CM 62CR MODEL OUTDOOR UNIT A5LC 50DR A5LC 61DR Btu/h 43000 55000 NOMINAL COOLING CAPACITY 12600 16119 Btu/h 46000 55000 NOMINAL HEATING CAPACITY 13480 16119 NOMINAL TOTAL INPUT POWER (COOLING) 4700 6414 NOMINAL TOTAL INPUT POWER (HEATING) -
Page 45: Model
Components Data (R22) ACM 30D INDOOR UNIT MODEL OUTDOOR UNIT ALC 28C ALC 30D TYPE CROSS FLOW QUANTITY MATERIAL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 146 / 5.75 LENGTH mm/in 200 / 7.87 TYPE INDUCTION INDOOR FAN QUANTITY MOTOR INDEX OF PROTECTION (IP) -
Page 46: Model
COMPONENTS DATA (R22) ACM 40D INDOOR UNIT MODEL OUTDOOR UNIT ALC 35D ALC 40D TYPE CROSS FLOW QUANTITY MATERIAL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 146 / 5.75 LENGTH mm/in 200 / 7.87 TYPE INDUCTION INDOOR FAN QUANTITY MOTOR INDEX OF PROTECTION (IP) TYPE PROPELLER QUANTITY... -
Page 47: Model
COMPONENTS DATA (R22) INDOOR UNIT ACM 50D ACM 62C MODEL OUTDOOR UNIT ALC 50D ALC 61D TYPE CROSS FLOW QUANTITY MATERIAL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 146 / 5.75 160 / 6.30 LENGTH mm/in 200 / 7.87 202 / 7.95 TYPE INDUCTION INDOOR FAN... -
Page 48: Model
COMPONENTS DATA (R22) ACM 30DR INDOOR UNIT MODEL OUTDOOR UNIT ALC 28CR ALC 30DR TYPE CROSS FLOW QUANTITY MATERIAL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 146 / 5.75 LENGTH 200 / 7.87 mm/in TYPE INDUCTION INDOOR FAN QUANTITY MOTOR INDEX OF PROTECTION (IP) TYPE PROPELLER QUANTITY... -
Page 49: Model
COMPONENTS DATA (R22) ACM 40DR INDOOR UNIT MODEL OUTDOOR UNIT ALC 35DR ALC 40DR TYPE CROSS FLOW QUANTITY MATERIAL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 146 / 5.75 LENGTH mm/in 200 / 7.87 TYPE INDUCTION INDOOR FAN QUANTITY MOTOR INDEX OF PROTECTION (IP) TYPE PROPELLER QUANTITY... -
Page 50: Model
COMPONENTS DATA (R22) INDOOR UNIT ACM 50DR ACM 62CR MODEL OUTDOOR UNIT ALC 50DR ALC 61DR TYPE CROSS FLOW QUANTITY MATERIAL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 146 / 5.75 160 / 6.30 LENGTH mm/in 200 / 7.87 202 / 7.95 TYPE INDUCTION INDOOR FAN... -
Page 51: Model
COMPONENT DATA (R410A) A5CM 40D INDOOR UNIT MODEL OUTDOOR UNIT A5LC 035D A5LC 040D TYPE CROSS FLOW QUANTITY MATERIAL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 146 / 5.75 LENGTH mm/in 200 / 7.87 TYPE INDUCTION INDOOR FAN QUANTITY MOTOR INDEX OF PROTECTION (IP) TYPE PROPELLER QUANTITY... -
Page 52: Model
COMPONENT DATA (R410A) INDOOR UNIT A5CM 50D A5CM 62C MODEL OUTDOOR UNIT A5LC 50D A5LC 61D TYPE CROSS FLOW QUANTITY MATERIAL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 146 / 5.75 160 / 6.30 LENGTH mm/in 200 / 7.87 202 / 7.95 TYPE INDUCTION INDOOR FAN... -
Page 53: Model
COMPONENT DATA (R410A) A5CM 40DR INDOOR UNIT MODEL OUTDOOR UNIT A5LC 35DR A5LC 40DR TYPE CROSS FLOW QUANTITY MATERIAL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 146 / 5.75 LENGTH mm/in 200 / 7.87 TYPE INDUCTION INDOOR FAN QUANTITY MOTOR INDEX OF PROTECTION (IP) TYPE PROPELLER QUANTITY... -
Page 54: Model
COMPONENT DATA (R410A) INDOOR UNIT A5CM 50DR A5CM 62CR MODEL OUTDOOR UNIT A5LC 050DR A5LC 061DR TYPE CROSS FLOW QUANTITY MATERIAL INDOOR FAN DRIVE DIRECT DIAMETER mm/in 146 / 5.75 160 / 6.30 LENGTH mm/in 200 / 7.87 202 / 7.95 TYPE INDUCTION INDOOR FAN... -
Page 55: Model
SAFETY DEVICES INDOOR UNIT ACM 30D MODEL OUTDOOR UNIT ALC 28C ALC 30D TYPE HIGH PRESSURE SWITCH OPEN kPa / psi 2937 / 426 CLOSE kPa / psi 2413 / 350 TYPE SAFETY DEVICE LOW PRESSURE SWITCH OPEN kPa / psi... -
Page 56: Model
SAFETY DEVICES INDOOR UNIT ACM 50D ACM 62C MODEL OUTDOOR UNIT ALC 050D ALC 061D TYPE HIGH PRESSURE SWITCH OPEN kPa / psi 2937 / 426 2937 / 426 CLOSE kPa / psi 2413 / 350 2413 / 350 TYPE SAFETY DEVICE LOW PRESSURE SWITCH OPEN... -
Page 57: Model
SAFETY DEVICES INDOOR UNIT ACM 40DR MODEL OUTDOOR UNIT ALC 35DR ALC 40DR TYPE HIGH PRESSURE SWITCH OPEN kPa / psi 2937 / 426 2937 / 426 CLOSE kPa / psi 2413 / 350 2413 / 350 TYPE SAFETY DEVICE LOW PRESSURE SWITCH OPEN kPa / psi... -
Page 58: Model
SAFETY DEVICES A5CM 40D INDOOR UNIT MODEL OUTDOOR UNIT A5LC 35D A5LC 40D TYPE HIGH PRESSURE SWITCH OPEN kPa / psi 2937 / 426 2937 / 426 CLOSE kPa / psi 2413 / 350 2413 / 350 TYPE SAFETY DEVICE LOW PRESSURE SWITCH OPEN kPa / psi... -
Page 59: Performance Data
6. PERFORMANCE DATA Interpolation and Extrapolation method can be used to get the total capacity, TC and sensible capacity, SC at those temperatures which are not stated out in the table. EXAMPLE: Model: RCM 20D– ALC 18C Indoor Condition: 23°C DB, 15°C WB Outdoor Condition: 37°C DB Solution: Overall... - Page 60 Details: Step: To obtain the Total capacity and Sensible capacity for (a) Indoor Condition: 24°C DB, 15°C WB Outdoor Condition: 35°C DB Outdoor DB ° C Indoor DB Indoor WB ° C ° C TC (kW) SC (kW) 4.999 3.465 5.113 3.243 Total capacity, TC...
- Page 61 Step: To obtain the Total capacity and Sensible capacity for (a) Indoor Condition: 23°C DB, 15°C WB Outdoor Condition: 35°C DB Outdoor DB ° C Indoor DB Indoor WB ° C ° C TC (kW) SC (kW) 4.885 2.460 4.885 3.687 Total capacity, TC = 4.885kW (Same as Total capacity at 20°C Indoor DB / 15 °C Indoor WB &...
- Page 62 Step: To obtain the Total capacity and Sensible capacity for (a) Indoor Condition: 23°C DB, 15°C WB Outdoor Condition: 37°C DB Outdoor DB ° C Indoor DB Indoor WB ° C ° C TC (kW) SC (kW) TC (kW) SC (kW) TC (kW) SC (kW) 4.885...
-
Page 64: Model
R22 MODELS (COOLING ONLY) MODEL : ACM 30D / ALC 30D Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 8.391 5.170 8.022 4.879 7.653 4.587 7.284 4.295... -
Page 65: Model
R22 MODELS (COOLING ONLY) MODEL : ACM 40D / ALC 40D Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 11.844 7.117 11.211 6.638 10.578 6.159 9.945 5.680 9.107 4.908... -
Page 66: Model
R22 MODELS (COOLING ONLY) MODEL : ACM 62C / ALC 61D Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 17.094 10.283 16.118 9.482 15.142 8.680 14.166 7.878 13.190 7.077 12.019 6.115 17.848 9.526 16.791 8.802 15.734 8.078 14.677 7.354 13.620 6.630 12.351 5.761 17.848 12.600 16.791 11.876 15.734 11.152 14.677 10.428 13.620 9.704 12.351 8.835 18.601 11.843 17.463 11.196 16.325 10.550 15.187 9.903 14.049 9.257 12.684 8.481... -
Page 67: Model
R22 MODELS (HEATPUMP) MODEL : RCM 30DR / ALC 28CR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 9.047 6.110 8.447 5.509 7.846 4.907 7.245 4.305 6.644 3.704 5.923 2.982 9.053... -
Page 68: Model
R22 MODELS (HEATPUMP) MODEL : ACM 30DR / ALC 30DR COOLING MODE Outdoor DB°C ID DB°C D I W B°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 8.363 5.245 7.996 4.960 7.629 4.675 7.262... -
Page 69: Model
R22 MODELS (HEATPUMP) MODEL : ACM 40DR / ALC 35DR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 11.044 7.153 10.377 6.524 9.710 5.895 9.042 5.266 8.375 4.637 7.575 3.883 11.217 6.578 10.578 6.012... -
Page 70: Model
R22 MODELS (HEATPUMP) MODEL : ACM 40DR / ALC 40DR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 11.608 6.753 11.006 6.320 10.404 5.887 9.802 5.454 8.976... -
Page 71: Model
R22 MODELS (HEATPUMP) MODEL : ACM 50DR / ALC 50DR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 13.185 8.048 12.585 7.694 11.986 7.340 11.386 6.986 10.728 6.397 10.125 5.858 9.773 5.543... -
Page 72: Model
R22 MODELS (HEATPUMP) MODEL : ACM 62CR / ALC 61DR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 16.960 10.123 15.997 9.343 15.033 8.562 14.070 7.782 13.106 7.002 11.950 6.065 17.850... -
Page 73: Model
R410A MODELS (COOLING ONLY) MODEL : A5CM 40D / A5LC 35D Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 10.630 6.784 9.801 5.955 8.988 5.141 8.175 4.327 7.361 3.512 6.385 2.536 10.892 6.263 10.085 5.512 9.286... -
Page 74: Model
R410A MODELS (COOLING ONLY) MODEL : A5CM 50D / A5LC 50D Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 12.928 8.452 12.323 7.851 11.623 7.352 10.923 6.853 10.223 6.354 9.383 5.756 13.441 8.003 12.782 7.488 12.077 7.025 11.371 6.562 10.666 6.098 9.819... -
Page 75: Model
R410A MODELS (HEATPUMP) MODEL : A5CM 40DR / A5LC 35DR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 10.630 6.784 9.801 5.955 8.988 5.141 8.175 4.327 7.361 3.512 6.385 2.536 10.892 6.263 10.085 5.512... -
Page 76: Model
R410A MODELS (HEATPUMP) MODEL : A5CM 40DR / A5LC 40DR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 10.874 6.936 10.294 6.356 9.796 5.858 9.298 5.360 8.800 4.862 8.202 4.265 11.376 6.545 10.802 6.038 10.268 5.571... -
Page 77: Model
R410A MODELS (HEATPUMP) MODEL : A5CM 50DR / A5LC 50DR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 11.841 7.739 11.269 7.168 10.606 6.686 9.943 6.205 9.281 5.723 8.485 5.145 12.386... -
Page 78: Model
R410A MODELS (HEATPUMP) MODEL : A5CM 62CR / A5LC 61DR COOLING MODE Outdoor DB°C ID DB°C ID WB°C TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) TC(kW) SC(kW) 14.970 9.688 14.484 9.102 13.941 8.675 13.398 8.247 12.855 7.819 12.204 7.306 15.690... -
Page 80: Model
MODEL : CM 62C/CR All Dimension in mm A(GRILL) 1750 1930 1830 1880... - Page 81 ALC 30/35/40/50/61D/DR A5LC 35/40/50/61D/DR...
-
Page 82: Electrical Data
8. ELECTRICAL DATA ELECTRICAL DATA - COOLING ONLY (R22) INDOOR UNIT CM 30D MODEL OUTDOOR UNIT ALC 28C ALC 30D INSULATION GRADE CLASS E POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 RATED INPUT POWER INDOOR MOTOR 0.49 RATED RUNNING CURRENT MOTOR OUTPUT POLES... -
Page 83: Model
ELECTRICAL DATA - COOLING ONLY (R22) INDOOR UNIT CM 50D CM 62C MODEL OUTDOOR UNIT ALC 50D ALC 61D INSULATION GRADE CLASS E 220 - 240 / 1 / 50 POWER SOURCE V/Ph/Hz RATED INPUT POWER INDOOR MOTOR RATED RUNNING CURRENT 0.76 MOTOR OUTPUT 80 x 2... -
Page 84: Model
ELECTRICAL DATA - HEAT PUMP (R22) INDOOR UNIT CM 20DR MODEL OUTDOOR UNIT ALC 18CR ALC 20CR INSULATION GRADE CLASS E POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 RATED INPUT POWER INDOOR MOTOR RATED RUNNING CURRENT 0.38 MOTOR OUTPUT POLES INSULATION GRADE... -
Page 85: Model
ELECTRICAL DATA - HEAT PUMP (R22) INDOOR UNIT CM 30DR MODEL OUTDOOR UNIT ALC 28CR ALC 30DR INSULATION GRADE CLASS E POWER SOURCE V/Ph/Hz 220 - 240 / 1 / 50 RATED INPUT POWER INDOOR MOTOR RATED RUNNING CURRENT 0.49 MOTOR OUTPUT POLES INSULATION GRADE... -
Page 86: Model
ELECTRICAL DATA - HEAT PUMP (R22) INDOOR UNIT CM 50DR CM 62CR MODEL OUTDOOR UNIT ALC 50DR ALC 61DR INSULATION GRADE CLASS E 220 - 240 / 1 / 50 POWER SOURCE V/Ph/Hz RATED INPUT POWER INDOOR MOTOR RATED RUNNING CURRENT 0.76 MOTOR OUTPUT 80 x 2... -
Page 87: Model
ELECTRICAL DATA - COOLING ONLY (R410A) INDOOR UNIT 5CM 40D MODEL OUTDOOR UNIT A5LC 35D A5LC 40D INSULATION GRADE CLASS E 220 - 240 / 1 / 50 POWER SOURCE V/Ph/Hz RATED INPUT POWER INDOOR MOTOR 0.68 RATED RUNNING CURRENT MOTOR OUTPUT POLES INSULATION GRADE... -
Page 88: Model
ELECTRICAL DATA - HEAT PUMP (R410A) INDOOR UNIT 5CM 40DR MODEL OUTDOOR UNIT A5LC 35DR A5LC 40DR INSULATION GRADE CLASS E 220 - 240 / 1 / 50 POWER SOURCE V/Ph/Hz RATED INPUT POWER INDOOR MOTOR RATED RUNNING CURRENT 0.68 MOTOR OUTPUT POLES INSULATION GRADE... -
Page 89: Wiring Diagrams
9. WIRING DIAGRAMS COOLING ONLY INDOOR UNIT MODEL : CM 20 / 25D OUTDOOR UNIT MODEL : ALC 18 / 20 / 25C... -
Page 90: Model
INDOOR UNIT MODEL : CM 30D OUTDOOR UNIT MODEL : ALC 28C... -
Page 91: Model
INDOOR UNIT MODEL : CM 30D ALC 30D INDOOR UNIT MODEL : ALC 30C... -
Page 92: Model
INDOOR UNIT MODEL : CM 40D ALC 30/40D OUTDOOR UNIT MODEL : ALC 35 / 40C (1 PHASE) -
Page 93: Model
INDOOR UNIT MODEL : CM / 5CM 40D, CM 50CD ALC/A5LC 40D, A5LC 35D, ALC 50D OUTDOOR UNIT MODEL : ALC / A5LC 40C, A5LC 35C , ALC 50C (3 PHASE) -
Page 94: Model
INDOOR UNIT MODEL : 5CM 40D OUTDOOR UNIT A5LC 35/40D MODEL : A5LC 35C (1 PHASE) -
Page 95: Model
INDOOR UNIT MODEL : 5CM 50C A5LC 50D OUTDOOR UNIT MODEL : A5LC 50C... -
Page 96: Model
INDOOR UNIT MODEL : CM 62C ALC 61D OUTDOOR UNIT MODEL : ALC / A5LC 061C *Please refer to Appendix 1 for wiring diagram of 5CM 62C / A5LC 61D *For wiring diagram of ALC 61DR-xxYxx, please refer to Appendix 2. -
Page 97: Model
HEATPUMP INDOOR UNIT MODEL : CM 20 / 25DR OUTDOOR UNIT MODEL : ALC 18 / 20 / 25CR... -
Page 98: Model
INDOOR UNIT MODEL : CM 30DR OUTDOOR UNIT MODEL : ALC 28CR... -
Page 99: Model
INDOOR UNIT MODEL : CM 30 / 40DR ALC 30/35/40DR OUTDOOR UNIT MODEL : ALC 30 / 35/ 40CR (1 PHASE) -
Page 100: Model
INDOOR UNIT MODEL : CM 30 / 40/ 50DR ALC 30/40/50DR OUTDOOR UNIT MODEL : ALC 30/ 40/ 50CR (3 PHASE) -
Page 101: Model
INDOOR UNIT MODEL : CM / 5CM 40DR OUTDOOR UNIT A5LC 35DR MODEL : A5LC 35CR (1 PHASE) -
Page 102: Model
INDOOR UNIT MODEL : 5CM 40DR A5LC 40DR OUTDOOR UNIT MODEL : A5LC 40CR (1 PHASE) -
Page 103: Model
INDOOR UNIT MODEL : 5CM 40DR A5LC 35/40DR OUTDOOR UNIT MODEL : A5LC 35 / 40CR (3 PHASE) -
Page 104: Model
INDOOR UNIT MODEL : 5CM 50DR OUTDOOR UNIT MODEL : A5LC 50CR A5LC 50DR... -
Page 105: Model
INDOOR UNIT MODEL : CM 62CR OUTDOOR UNIT ALC 61DR MODEL : ALC 61CR... -
Page 106: Model
INDOOR UNIT MODEL : 5CM 62CR OUTDOOR UNIT MODEL : A5LC 61CR A5LC 61DR... -
Page 107: Servicing And Maintenance
10. SERVICING AND MAINTENANCE Warning: Disconnect from main supply before servicing the air conditioner. The unit is designed to give long life operation with minimum maintenance required. However, it should be regularly checked and the following items should be given due attention. Components Maintenance Procedure Recommended Schedule... -
Page 108: Model
FOR ALC OUTDOOR MODELS The design of the ALC outdoor series allows servicing to be carried out readily and easily. The removal of the top side, front and back panel make almost every part accessible. Under normal circumstances, these outdoor units only require a check and cleaning of air intake coil surface once quarterly. -
Page 109: Troubleshooting
11. TROUBLESHOOTING When a malfunction of the air conditioner unit is detected, immediately switch off the main power supply before proceeding with the following troubleshooting procedures. The following are common fault conditions and simple troubleshooting tips. If any other fault conditions which are not listed occur, contact your nearest local dealer. - Page 110 DIAGNOSTIC GUIDELINES By means of pressure readings: Data Pressure Probable cause Circuit High side • 1. Overcharged with refrigerant. Low side 2. Non-condensable gases in refrigerant circuit (e.g. air) • 3. Obstructed air-intake / discharge. 4. Hot air short circuiting in outdoor unit. High side •...
- Page 111 BY MEANS OF DIAGNOSTIC FLOW CHART : Generally, there are two kinds of problems, i.e. starting failure and insufficient cooling/heating. “Starting failure” is caused by electrical defect while improper application or defects in refrigerant circuit causes “Insufficient cooling / heating”. i) Diagnosis of Electric Circuit The most common causes of air conditioner failure to “start”...
- Page 112 ii ) Diagnosis of Refrigerant Circuit / Application There might be some causes where the unit starts running but does not perform satisfactorily, i.e. insufficient cooling. Judgement could be made by measuring temperature difference of indoor unit’s intake and discharge air as well as running current.
- Page 113 Insufficient heating Indoor / outdoor coil dirty Clean the coil Restricted (clogged) circulation Indoor air filter dirty Clean the filter Fan motor malfunction Change or repair the motor Obstruction at air inlet / outlet of indoor / outdoor Remove the obstruction unit High heating Windows / doors wide...
-
Page 114: Exploded View And Part List
12. EXPLODED VIEW AND PARTS LIST MODEL : CM 30 D/DR Description Part No. Description Part No. 1 Bracket Hanger, Left R01014032844 16 Drain Hose Assy. R50124025113 2 Control Box Cover R01014022491 17 Grille, Air Intake R50124032385 3 L2 Control Module 18 Assy, Filter Frame Left/Right R50124022130 RCM 30D... -
Page 115: Model
MODEL : CM / 5CM 40 / 50 D/DR Description Part No. Description Part No. 1 Bracket Hanger, Left R01014032844 17 Air Intake Grille Frame Holder Assy. R50124026115 2 Control Box Cover R01014022491 18 Bottom Panel R01015024889 3 L2 Control Module 19 Drain Pan Assy. -
Page 116: Model
MODEL : CM / 5CM 62 C/CR Description Part No. Description Part No. 1 Top Back Panel R50015039175 15 Terminal Box R01014021961 2 Coil Holder Left R01014037090 16 Front Frame R12014053120 3 Coil Assy. 17 Front Frame (With LED Indicators) R12014053119 RCM 62C R50024039514... -
Page 117: Model
MODEL : ALC 25 / 28C Description Part No Description Part No 1 Assy. Base Pan R50014073884 13 Terminal Cover Panel A01014070838 2 Assy. Outdoor Coil 14 Assy. Control Panel ALC 25C R50024089206 ALC 25C R50044086076 ALC 28C A50024070959 ALC 28C R50044086137 3 Motor Bracket R01014070948... -
Page 118: Model
MODEL : ALC 25 / 28CR Description Part No Description Part No 1 Assy. Base Pan R50014073884 14 Assy. Control Panel 2 Assy. Outdoor Coil ALC 25CR R50044086136 ALC 25CR R50024088731 ALC 28CR R50044086139 ALC 28CR A50024082133 15 Top Panel R01014070596 3 Motor Bracket R01014070948... -
Page 119: Model
ALC 30/35/40/50/61D MODEL: ALC 30 / 40C/CR Description Part No Description Part No 1 Assy. Base Pan R50014053238 11 Bracket, Fan Motor R01014053232 2 Assy. Flare Valve 3/8" 12 Side Panel, Left R01010029899 ALC 30/40C/CR R50059000221 13 Fan Motor R03039004046 3 Assy. -
Page 120: Model
ALC 30/35/40/50/61DR MODEL: A5LC 35 / 40C/CR A5LC 30/35/40/50D/DR Description Part No Description Part No 1 Assy. Base Pan R50014053238 13 Fan Motor R03039004046 2 Assy. Flare Valve 3/8" R50059017536 14 Fan Blade R03013028160 3 Assy. Flare Valve 5/8" R50059020805 15 Assy. -
Page 121: Model
MODEL : ALC 50 / 61CR A5LC 61DR Description Part No Description Part No 1 Assy. Base Pan R50014053238 11 Bracket, Fan Motor 2 ALC 50C/CR ALC 50C/CR R01014053232 Assy. Flare Valve 3/8" R50059000221 ALC 61C/CR R01014051775 ALC 61C/CR 12 Side Panel, Left R01010029899 Assy. - Page 122 Sarawak : +6082-344 128 Products manufactured in an ISO certified facility. Johor : +607-3551 599 Sabah : +6088-420 205 This document contains the most current product information as of this printing. For the most up-to-date product information, please logon to www.acson.com.my www.acson.com.my TM-A(5)CM-D/C(R)
