Dear Beneteau Owner,
It is with great pleasure that we welcome you to the family of Beneteau boat
owners!
We sincerely hope that your new Beneteau will offer you, your family, and your
guests many hours of pleasant and safe sailing.
Your support of our product is greatly appreciated, and we are confident that your
new yacht will fulfill all your expectations of a finely crafted vessel.
Our dealer network, supported by our Customer Service Department, will gladly
attempt to answer any questions and they will provide advice and guidance on any
problems that you may have.
Once again, thank you, and we wish you as much pleasure sailing your boat as we
had in building her for you.
Sincerely,
Annette Roux
Chief Executive Officer
Chantiers Beneteau, S.A., France

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Oceanis 351 and is the answer not in the manual?

Questions and answers

Related Manuals for BENETEAU Oceanis 351

Summary of Contents for BENETEAU Oceanis 351

  • Page 1 Dear Beneteau Owner, It is with great pleasure that we welcome you to the family of Beneteau boat owners! We sincerely hope that your new Beneteau will offer you, your family, and your guests many hours of pleasant and safe sailing.
  • Page 2 These craft were built to last; like today's Beneteau's. At Beneteau the sea is at the roots of our family tree. This is a story of love, commitment and long-standing tradition. From my grandfather to his descendants who operate the company today, we have always been innovative.

  • Page 3: Table Of Contents

    6.4. SWIM LADDER WARNING LABEL ___________________________________________ 15 6.5. HIGH VOLTAGE WARNING LABEL __________________________________________ 15 6.6. TRANSOM DOOR WARNING LABEL _________________________________________ 16 6.7. STANDARD BATTERY SWITCH LABEL ______________________________________ 16 6.8. OPTIONAL BATTERY SWITCH LABEL _______________________________________ 16 6.9. SLING LOCATION ARROWS LABEL _________________________________________ 17 Oceanis 351 Rev. 00...
  • Page 4 11.6. INTERIOR WOOD__________________________________________________________ 29 11.7. ELECTRICAL SYSTEMS____________________________________________________ 29 11.7.1. Battery Maintenance ________________________________________________________________30 11.8. WATER SYSTEM __________________________________________________________ 30 11.9. MARINE HEAD____________________________________________________________ 31 11.10. ENGINE __________________________________________________________________ 31 11.11. SAILS ____________________________________________________________________ 32 12. WINTERIZING PROCEDURES ____________________________________________33 12.1. HAULING_________________________________________________________________ 33 Oceanis 351 Rev. 00...
  • Page 5 13.2.9. Stopping the Engine.________________________________________________________________43 13.3. FUELING __________________________________________________________________ 45 13.3.1. Before Fueling. ____________________________________________________________________45 13.3.2. Fueling __________________________________________________________________________45 13.3.3. After Fueling. _____________________________________________________________________46 13.3.4. Fuel Sanitation. ____________________________________________________________________46 13.3.5. Bacterial Contamination. ____________________________________________________________46 13.3.6. Fuel Additives. ____________________________________________________________________47 13.4. STEERING SYSTEM ________________________________________________________ 48 13.4.1. Wheel Steering.____________________________________________________________________48 Oceanis 351 Rev. 00...
  • Page 6 13.13.7. Optional 110V Inverter Schematic ___________________________________________________82 13.14. RIGGING_________________________________________________________________ 83 13.14.1. General Description _______________________________________________________________83 13.14.2. SPREADER TIP DETAIL __________________________________________________________84 13.14.3. MAST HEAD DETAIL ____________________________________________________________84 13.14.4. TUNING________________________________________________________________________85 13.14.5. ROLLER FURLING MAST DECK LAYOUT __________________________________________86 13.14.6. ROLLER FURLING MAST DRAWING ______________________________________________87 Oceanis 351 Rev. 00...
  • Page 7 11/6/2006 9:03 AM 13.14.7. ROLLER FURLING MAST_________________________________________________________88 13.14.8. CLASSIC MAST DECK LAYOUT ___________________________________________________90 13.14.9. CLASSIC MAST _________________________________________________________________91 13.14.10. GENOA FURLING SYSTEM ______________________________________________________92 13.14.11. RIGGING SPECIFICATIONS______________________________________________________92 APPENDIX A MODIFICATION UPDATES Oceanis 351 Rev. 00...

  • Page 8: Introduction

    410 Mill Street, Suite 101 Marion, SC 29571 Charleston, SC 29464 Tel (843)-629-5320 Tel ( 843)-629-5394 Fax (843)-629-5329 (843)-881-1405 We would like to sincerely thank you for choosing a Beneteau and we wish you good sailing. 11/06/06 9:05 AM Rev. 05...
  • Page 9 The primary function of your Beneteau is to maximize yourboating pleasure. Your new Beneteau was made to last through weather and time. From the very beginning, great care has been taken in building you boat. Her molds have been designed and built to resist any deformation of her lines and meticulously maintained to guarantee a superior finish.
  • Page 10 BENETEAU USA's BOATS. Beneteau shall in no event be liable to the Owner or any other person or entity for damages of any kind, including but not limited to direct, indirect, special or consequential damages, arising from the sale or in connection with the use or inability to use the boat for any purpose whatsoever, irrespective of whether the claims or actions for such damages are based upon contract, tort, negligence, strict liability, warranty, or otherwise.

  • Page 11: Warranty/Registration Procedures

    WARRANTY/REGISTRATION PROCEDURES 3.1.1. Warranty Procedure All Beneteau boats carry a one year limited warranty, as well as an extended hull and deck structural warranty (see warranty form for details). As the first owner of your new Beneteau, your warranty only becomes valid upon receipt, by Beneteau, of the completed and signed warranty form.

  • Page 12: Hull Identification Numbers

    Checking of all systems on the boat for fit, proper function and to familiarize you with the usage of each system. • Sea trial of your new Beneteau with you as a final verification that all systems are in good order. •...

  • Page 13: Owner's/Operator's Responsibilities

    5.2. SAFETY AND MAINTENANCE For maximum enjoyment of your Beneteau, due respect should be given to proper safety and maintenance procedures. Be sure that your boat is operated according to the U.S. Coast Guard Regulations as outlined in the "Federal Requirements For Recreational Boats".

  • Page 14: Recommended Safety Equipment

    Compass - be sure that it is properly calibrated to give the correct magnetic reading. • A large capacity bilge pump. We recommend that you fully outfit your Beneteau with safety equipment that can be obtained through your dealer or marine supply outlets. These items should include but not be limited to: •...

  • Page 15: Anchoring

    5.6. ANCHORING Various sea and bottom conditions require different anchoring systems. Your dealer can help in choosing rode size and length, anchor chains, and working and storm anchors most appropriate for your boat and location. In general, a minimum of two anchors should be carried at all times and enough anchor rode and chain necessary for the depth of water to be navigated during storm conditions.

  • Page 16: Tool Kit

    5.9. TOOL KIT A basic kit should consist of: • Wrenches - adjustable, Metric and SAE open end, box, socket • Hammers - large and small • Knife - with marlinespike • Screwdrivers - large and small, standard and Phillips •...

  • Page 17: Safe Operation And Warning Labels

    Ensure that the boat operator is not under the influence of drugs and/or alcohol. Do not venture out in weather or sea conditions beyond the skill or experience of the operator. There are "Warning" and "Caution" statements affixed to your Beneteau. These are detailed below with location: 6.1.

  • Page 18: Propane Labels

    6.3. PROPANE LABELS • At the propane stove affixed to the bulkhead in the galley Beneteau Part #00001021 Beneteau Part #00001026 11/06/06 9:05 AM REV 04...
  • Page 19 • In the propane locker affixed under the propane locker lid Beneteau Part #00001024 • On or next to the LP Gas Line Beneteau Part #00001030 11/06/06 9:05 AM REV 04...

  • Page 20: Swim Ladder Warning Label

    6.4. SWIM LADDER WARNING LABEL • Located on the transom Beneteau Part # 00001022 6.5. HIGH VOLTAGE WARNING LABEL • Located beside the 110v electric panel. Beneteau Part #00001034 11/06/06 9:05 AM REV 04...

  • Page 21: Transom Door Warning Label

    6.6. TRANSOM DOOR WARNING LABEL • Located on or next to the helmsman’s seat. Beneteau Part #00001031 6.7. STANDARD BATTERY SWITCH LABEL • Located at the standard battery switches. Beneteau Part #00001032 6.8. OPTIONAL BATTERY SWITCH LABEL • Located at the optional battery switches...

  • Page 22: Sling Location Arrows Label

    6.9. SLING LOCATION ARROWS LABEL • Located at or near the hull to deck joint Beneteau Part #00001033 6.10. ANTI FREEZE CAUTION TAG • Tied to the breaker for the water Beneteau Part #00001038 ! CAUTION BOAT SHIPPED FROM FACTORY...

  • Page 23: Federal/State Regulations

    FEDERAL/STATE REGULATIONS 7.1. DISCHARGE OF OIL • Located: under the sail locker lid. Beneteau Part #00001007 11/06/06 9:05 AM Rev. 05...

  • Page 24: Solid Waste Disposal

    7.3. MARINE SANITATION Your Beneteau is equipped with an USCG approved marine head and holding tank. By law you must use a holding tank in all U.S. waters, Check with local authorities for regional laws governing your area before selecting the overboard discharge option.

  • Page 25: Accident Reporting

    ACCIDENT REPORTING Knowledge of accident reporting requirements. Please refer to the following list for a copy of the U.S. Coast Guard Boating Accident form. For further information on where to obtain more forms, please call the U.S. Coast Guard Boating Safety Hotline at (800) 368-5647 NATIONAL VESSEL DOCUMENTATION CENTER 2039 STONEWALL JACKSON DR.

  • Page 26: Rendering Assistance

    RENDERING ASSISTANCE United States Code, Title 46: "The owner or operator of a vessel is required by law to render assistance to any individual or vessel in distress, so long as his vessel is not endangered in the process." 11/06/06 9:05 AM Rev.

  • Page 27: Commissioning

    The first commissioning of a yacht is essentially the start of its life, and the importance of proper commissioning procedures at this time cannot be overstated. The commissioning procedure must be performed by Beneteau dealer personnel or those authorized by them. The owner also needs to concern himself with items such as safety equipment, which is considered to be his responsibility.

  • Page 28: Machinery Inspection

    10.2.2. Machinery Inspection • Make an overall inspection of the machinery spaces. Ensure that they are free of loose material that might interfere with machinery operation, and then check the following items: • Engine oil, transmission fluid, and coolant levels satisfactory. •...

  • Page 29: Post-Launch Checks

    3. Horn 4. Emergency signals such as flares 5. Fire extinguishers • ** Medical kit • ** Spare parts and tool kit 10.3. * POST-LAUNCH CHECKS 10.3.1. Hull Inspection • Make an overall inspection of the hull interior. Check bilge areas for evidence of major leaks near thru-hulls, and then make the following specific checks: •...

  • Page 30: Rigging And Sails

    The alignment must be checked again after the boat has been rigged and tuned. A marine mechanic should complete engine alignment. The basic procedure is to: 1. Loosen the transmission to shaft coupling bolts enough to slide a feeler gauge between the coupling plates.

  • Page 31: Fresh Water System

    10.3.5. Fresh Water System Check the following: 1. Water tanks full, no leaks at tank, fittings or vent hoses. 2. Pressure water system operational. 3. All faucets operational 4. Sinks and drains operational. 5. Hot water system operational. 6. All showers operational. 10.3.6.

  • Page 32: Maintenance Of Your Boat

    MAINTENANCE OF YOUR BOAT Your boat represents a sizable capital investment that needs special and regular care Safeguarding your investment and looking after your own safety should persuade you of the importance of careful and regular upkeep of your boat. The maintenance suggestions in the following sections will help you with the basics.

  • Page 33: Minor Gel Coat Repairs

    11.2. MINOR GEL COAT REPAIRS To fill in a scratch or small dent, order a Beneteau Gel coat Repair Kit with instructions for use, from your dealer or obtain a small quantity of gel coat and catalyst.

  • Page 34: Interior Wood

    Your dealer will be able to order Beneteau varnish. When this is dry, rub it down with a very fine wet-and- dry sandpaper (grade 800 or 1000) and finish off with polish (or a silicone spray) or wax.

  • Page 35: Water System

    WARNING! THE ELECTROLYTE IN A BATTERY IS A SOLUTION OF SULFURIC ACID. IF ANY SHOULD ENTER THE EYES, RINSE IMMEDIATELY WITH LARGE AMOUNTS OF FRESH WATER, AND SEEK MEDICAL ATTENTION. ELECTROLYTE SPILLED ON SKIN SHOULD BE RINSED WELL WITH FRESH WATER. EVEN SMALL AMOUNTS OF ELECTROLYTE SPILLED ON CLOTHING WILL DESTROY THE CLOTHING.

  • Page 36: Engine

    Water temperature, salinity, the presence of neighboring boats, the nature of the bottom and the materials in the dock will all affect the life of your boat's anodes. Order your spare anodes thru your dealer or from Beneteau Customer Service. 11/06/06 9:05 AM Rev.

  • Page 37: Sails

    CALIFORNIA Proposition 65 Warning Diesel engine exhaust and some of its constituents are known to the State of California to cause cancer, birth defects, and other reproductive harm. 11.10. SAILS Check the sails regularly, as the slightest wear in the stitching or at a reinforced part can very quickly have dramatic consequences.

  • Page 38: Winterizing Procedures

    12.1. HAULING Your Beneteau should be hauled for inspection and maintenance at least once a year; the frequency of haul-outs may vary due to your local conditions and marine growth. A good boatyard is seasoned in hauling and maneuvering boats on land, you may verify this by checking to see that the weight of the hull is resting firmly on the bottom of the keel and that even contact exists along the bottom of keel.

  • Page 39: Freshwater System

    12.5. FRESHWATER SYSTEM This system is best winterized with one of the non-toxic antifreezes available for use in boat and recreational freshwater systems. It is an easy method, which replaces fresh water with a non-toxic antifreeze mixture. Caution! Be sure to use correct non-toxic antifreeze. 1.

  • Page 40: Fuel System

    Consult the Engine Owner's Manual for your specific engine's guidelines for winterizing. Follow the instructions carefully to ensure the engine is adequately protected. The general procedure is to replace raw seawater with an antifreeze solution mixed to protect the engine in your local area and to check the heat exchanger side to ensure that it contains an adequate antifreeze solution as well.

  • Page 41: Stove

    Remove any remaining food from the icebox and wash down thoroughly with warm water and detergent solution. Odors can be removed with a baking soda and water solution, and an open box of baking soda left in the icebox will continue to remove odors throughout storage. Completely pump out any water from the bottom of the icebox and make sure pump is completely dry of any water.

  • Page 42: Supplier Information List

    Lubricate if necessary. SUPPLIER INFORMATION LIST The following page lists our key suppliers in the United States. If you need information from a supplier not listed you may contact Beneteau’s Customer Service Department in Marion, South Carolina at 1-843-423-6459. 11/06/06 9:05 AM Rev.
  • Page 44 Your Beneteau dealer can advise you on the availability of boating courses and professional instruction in your area.

  • Page 45: Oceanis 352 Systems

    40. Water Tank Vent 13. Companionway Handrail 28. Opening Transom Seat 41. Genoa Tracks 14. Stb Line Stoppers 29. Propane Locker 42. Shroud Chainplates 15. Stb Cabin Top Winch 30. Engine Air Vent 43. Single Stanchion Oceanis 351 Rev. 00...

  • Page 46: Diesel Engine

    13.2. DIESEL ENGINE 13.2.1. General Description The power system installed on your Beneteau is a diesel engine. Detailed descriptions of the features of this engine, along with complete operating and maintenance procedures, are provided in the engine manual supplied with your boat.

  • Page 47: Engine Panel

    11/6/2006 8:54 AM 13.2.3 Engine Panel Oceanis 351 Rev. 00...
  • Page 48 11/6/2006 8:54 AM Oceanis 351 Rev. 00...

  • Page 49: Stuffing Box

    Check the coolant level if the engine is fitted with a closed heat exchanger cooling system. Check the oil in the sump and gearbox (this should be repeated after a few hours running). Check the tension of the alternator drive belt. Oceanis 351 Rev. 00...

  • Page 50: Starting The Engine

    Shifting should be performed with RPM reduced to idle. Keep a regular watch to make sure that the coolant water is circulating properly. 13.2.9. Stopping the Engine. To stop the engine: Place throttle/transmission lever in the idle/neutral position. Oceanis 351 Rev. 00...
  • Page 51 CAUTION! IF YOU CLOSE THE FUEL AND SEA WATER VALVES AFTER STOPPING THE ENGINE, BE SURE TO RE-OPEN THEM BEFORE RESTARTING. FAILURE TO DO SO COULD CAUSE ENGINE TO OVER-HEAT AND CAUSE DAMAGE TO THE PUMP IMPELLER OR CAUSE FUEL LINES TO BECOME AIR LOCKED. Oceanis 351 Rev. 00...

  • Page 52: Fueling

    (due to condensation in the tank), and to prevent the injector pump running dry and needing repriming. 13.3.3. After Fueling. Replace cover, clean up any spilled fuel. If any rags, etc. were used for this purpose, dispose of them ashore. Oceanis 351 Rev. 00...

  • Page 53: Fuel Sanitation

    Oceanis 351 Rev. 00...

  • Page 54: Fuel Additives

    Various brands of this product are available at marine supply stores. As with all products of this nature, the directions on the container should be carefully followed. Oceanis 351 Rev. 00...

  • Page 55: Steering System

    NOTE: When backing under auxiliary power in reverse gear, it is necessary to maintain a hold on the steering wheel the entire time. The rudder and steering Oceanis 351 Rev. 00...

  • Page 56: Emergency Tiller

    13.4.4. Emergency Tiller. As a safety precaution on your Beneteau, an emergency tiller has been provided as a backup to the wheel steering system. Remove the deck plate with a winch handle and slip emergency tiller into top of rudder post.

  • Page 57: Fresh Water System

    The water is drawn from the tanks via an electric pump and distributed to the hot and cold water systems thru tank selector switches and a manifold. Take care not to run an electric pump with an empty tank, as this will ruin it beyond repair. Oceanis 351 Rev. 00...

  • Page 58: Operation

    3. Fwd Water Tank Supply Line 9. Head Sink & Shower 4. Aft Water Tank 10. Head Supply Lines 5. Aft Water Tank Supply Line 11. Transom Shower Supply Line 6. Hot Water Heater 12. Transom Shower Valve 13. Transom Shower Oceanis 351 Rev. 00...
  • Page 59 01 1 CB 0 12 0 13 0 13 0 12 01 4 CS...
  • Page 60 11/6/2006 8:54 AM 13.5.3.2. Pump House Layout The pump house for the fresh water system and electric bilge pump is located under the aft inboard settee in the main saloon. Revision Hull # 205 onwards Oceanis 351 Rev. 00...
  • Page 61 0 2 2 0 0 4 0 2 4 0 2 2 0 0 4 0 0 5 0 0 8 0 0 9 0 1 0 0 0 4 0 0 2 0 1 4 Oceanis 351 Rev. 00...

  • Page 62: Intake & Discharge Thruhulls

    After hot water has been run through a pipe for the first time, check the tightness of all the clamps. NOTE: These recommendations also apply to the cooling system of the inboard engine, if your boat has one. 13.6.3. Thru Hull Drawing Oceanis 351 Rev. 00...

  • Page 63: Marine Toilet & Holding Tank

    The marine sanitary system consists of a marine toilet (head), a holding tank and a series of thru hull intakes, discharges and valves to control the intake of water into the head to flush the bowl either into the holding tank or overboard. Oceanis 351 Rev. 00...

  • Page 65: Head Operating Procedure

    8:54 AM 13.7.2. Head Operating Procedure. The marine heads on your Beneteau are installed below the water line, all valves must be closed after use and the selection lever on the head must be returned to the dry bowl position. Failure to do so could result on the bowl overflowing and flooding the boat with water.

  • Page 66: Bilge Pumps

    0 0 2 00 2 0 0 2 00 2 0 0 1 00 3 I N T A K E 00 4 00 4 00 7 D I S C H A R G E Oceanis 351 Rev. 00...
  • Page 67 11/6/2006 8:54 AM Oceanis 351 Rev. 00...

  • Page 68: Electric Bilge Pump

    0 0 2 0 0 3 C B 0 0 2 0 0 2 0 0 1 0 0 2 0 0 2 0 1 7 BE CAREFUL NOT TO WASH THE O-RING SEAL OUT OF THE FILTER Oceanis 351 Rev. 00...

  • Page 69: Deck Filler & Discharge Plates

    11/6/2006 8:54 AM 13.9. DECK FILLER & DISCHARGE PLATES Oceanis 351 Rev. 00...

  • Page 70: Self- Draining Cockpit

    Make sure that these drainholes are not blocked. When using the cockpit as a "workshop" plug drainholes with large cork bungs to avoid the loss of any nuts or bolts which you may accidentally drop. Oceanis 351 Rev. 00...

  • Page 71: Propane.cooking System

    13.11.1. Propane System Description. Your Beneteau is equipped with a propane combination stove and oven. This unit is located in the galley and is gimbaled for your safety and comfort in a seaway. The stove is supplied by a storage bottle located in a self draining locker in the cockpit.

  • Page 72: P R O P A N E D R A W I N G

    11/6/2006 8:54 AM 13.11.2. P r o p a n e D r a w i n g Oceanis 351 Rev. 00...

  • Page 73: Operation

    If the odor of gas is detected at any, time turn off all electrical and mechanical systems, extinguish any open flames and immediately check for a propane leak. Propane is a heavy gas and may settle in the bilge which represents an explosion and fire hazard. Oceanis 351 Rev. 00...

  • Page 74: System

    S H O W E R S U M P 10 A 10 A C ABI N SP ARE L TS 10 A 10 A FRESH W A TER SP ARE PUM P 13.12.2. Panel Wiring Schematic Oceanis 351 Rev. 00...
  • Page 75 BUS 2 BUS 1 BLACK #14 AWG (GND) RED #10 AWG (+12V) RED #14 AWG (REFRIG) W A G O W I R I N G B L O C K P L U G S Oceanis 351 Rev. 00...

  • Page 76: Wago Drawing

    Wires are inserted into the block by: Inserting a small screwdriver into the inside hole and pressing down. Insert the wire. Remove the screwdriver Remove wires by inserting the screwdriver and pulling out the wire. Oceanis 351 Rev. 00...

  • Page 77: Light No.'s & Wire No.'s

    #11 Refrigeration +++ Central Aft Cabin Reading #35 Aft cabin Reading #194 Optional Aft Cabin Fan #10 Stern Light (+Brown) #17 Gas Solenoid (+Brown) #60 Cockpit Light #9 Compass Light (+Brown) #18 Spare Table to Lazarette Oceanis 351 Rev. 00...

  • Page 78: Bulbs

    This should be done when the battery is cold and has not been recharged or used for several hours beforehand. A reading of less than 11,5 V means that recharging is necessary. 13.12.7. 12V Charging System The batteries must be recharged by one of the following systems: Oceanis 351 Rev. 00...
  • Page 79 1 2 V P AN EL N E GA T IV E HO US E + E NG IN E + B AT #1 B A T # 2 B A TT ER Y C HA R GE R Oceanis 351 Rev. 00...
  • Page 80 The battery charger is completely automatic, refer to the charger's manual for complete details. To charge the batteries using the charger: plug in the shore power cord and turn the charger breaker on at the 110V shore power panel. Oceanis 351 Rev. 00...
  • Page 82 T H E R M O S T A T F A N L O W T F + C C - B A T T H E R M O S T A T F R E E Z E R Oceanis 351 Rev. 00...
  • Page 83 13.12.10. Windlass Operation The windlass is used to raise and lower your ground tackle (anchors, chains and rodes), refer to the windlass owners manuals for proper operation. As a general guide please observe the following procedures. Oceanis 351 Rev. 00...
  • Page 84 (turn the switch on before starting the engine). Push the gypsy pawl (P) forward and downwards to allow the gypsy to rotate counterclockwise. Oceanis 351 Rev. 00...
  • Page 85 Oceanis 351 Rev. 00...

  • Page 86: Shore Power System

    SYSTEM, INSTALL A SEPARATE SERVICE AND PANEL The 110V panel consists of breaker switches which protect and turn the individual circuits on and off. The charger, hot water heater and the 110V outlet circuit are on separate breakers. 13.13.1. 110V Layout Oceanis 351 Rev. 00...

  • Page 87: Conduit Layout

    11/6/2006 9:02 AM 13.13.2. Conduit Layout Oceanis 351 Rev. 00...

  • Page 88: Schematic

    11/6/2006 9:02 AM 13.13.3. 110V Schematic Oceanis 351 Rev. 00...
  • Page 89 Switch the dock outlet breaker off. Plug the shore power cord into the boat and dock outlet. Switch the dock breaker on. Switch the panel breakers on as needed. DO NOT OPERATE THE 110V WATER HEATER DRY Oceanis 351 Rev. 00...

  • Page 90: Optional 110V Air Conditioning Schematic

    11/6/2006 9:02 AM 13.13.4. Optional 110V Air Conditioning Schematic Oceanis 351 Rev. 00...
  • Page 91 11/6/2006 9:02 AM Oceanis 351 Rev. 00...

  • Page 92: Optional 110V Air Conditioning Layout

    11/6/2006 9:02 AM 13.13.5. Optional 110V Air Conditioning Layout Oceanis 351 Rev. 00...

  • Page 93: Optional 110V Air Conditioning Plumbing

    11/6/2006 9:02 AM 13.13.6. Optional 110V Air Conditioning Plumbing Oceanis 351 Rev. 00...

  • Page 94: Optional 110V Inverter Schematic

    11/6/2006 9:02 AM 13.13.7. Optional 110V Inverter Schematic Oceanis 351 Rev. 00...

  • Page 95: Rigging

    6. Lower Cap Shroud (V1) 7..Aft Lowers Shroud (D1) 8. Fwd Lowers Shroud (D1 9. Chainplate & Turnbuckles 10. Masthead 11. Genoa Furling Tubes 12. Upper Spreaders 13. Lower Spreaders 14. Furling Drum & Forestay Cainplate Below Deck Oceanis 351 Rev. 00...

  • Page 96: Spreader Tip Detail

    11/6/2006 9:02 AM 13.14.2. SPREADER TIP DETAIL 13.14.3. MAST HEAD DETAIL Oceanis 351 Rev. 00...

  • Page 97: Tuning

    To achieve the best performance from your boat the mast and rigging needs to be tuned correctly, the initial tuning of your boat should be completed by your Beneteau Dealer. The tuning of your Beneteau takes a little bit of time and care, but if the mast is correctly setup initially it will require very little adjustment in the future.

  • Page 98: Roller Furling Mast Deck Layout

    11/6/2006 9:02 AM 13.14.5. ROLLER FURLING MAST DECK LAYOUT Oceanis 351 Rev. 00...
  • Page 99 11/6/2006 9:02 AM Oceanis 351 Rev. 00...

  • Page 100: Roller Furling Mast Drawing

    0 0 0 6 0 C O R E C A B L E F O R C O M B I N A T I O N L I G H T 0 0 0 0 0 Oceanis 351 Rev. 00...

  • Page 101: Roller Furling Mast

    11/6/2006 9:02 AM 13.14.7. ROLLER FURLING MAST Main Swivel Hoist Car Furling Tubes Access Plate Main Sail Furling Drum Main Sail Furling Line Oceanis 351 Rev. 00...
  • Page 102 NEVER TAKE IN ONE LINE WITHOUT KEEPING A LITTLE TENSION ON OPPOSITE LINE The main may be reefed by turning the boat into the wind and furling the main up to the marked reef points on the sail. Oceanis 351 Rev. 00...

  • Page 103: Classic Mast Deck Layout

    11/6/2006 9:02 AM 13.14.8. CLASSIC MAST DECK LAYOUT Oceanis 351 Rev. 00...

  • Page 104: Classic Mast

    0 0 0 6 0 C O R E C A B L E F O R C O M B IN A T I ON L I G H T 0 0 0 0 0 Oceanis 351 Rev. 00...

  • Page 105: Genoa Furling System

    2. Halyard Swivel Shackle 8. Furling Line 3. Swivel Car 9. Anchor Locker Block 4. Upper Sail Shackle 10. Furling Drum 5. Furling Tubes 11. Lower Forestay Link Plate 6. Genoa Tack Shackle 12. Forestay Chainplate 13.14.11. RIGGING SPECIFICATIONS Oceanis 351 Rev. 00...

  • Page 106: Oceanis

    CEANIS 351 Appendix A (6/26/97) odification pdates Appendix 1...
  • Page 107 MAKE PROFURL (PROENGIN) MODEL LC32-14M INSTALLED ABOVE DECK NUMBER 13641 EXTRUSIONS X L2000 & 1 X FORESTAY DIAMETER (9/32") 13506 13506 13486 PLAY 13475 PLASTIC MULTITOP 11mm 13469 HALYARD RESTRAINER 1346 HALYARD SWIVEL WITH ADJUSTABLE STRAP mm STAINLESS STEEL RING mm ID HEAD SHACKLE mm LONG D...
  • Page 108 STEMBALL FORES BACKSTAY WITH WASHER 14060 DOUBLE 1/2" DELTA PLATE DOUBLE WITH 3 CLEVIS PINS TOGGLE AND SPLIT SUPPLIED PINS WITH MAST 14175 50 m LONG MARINE EYE MARINE 1/4" 9/32" 1x19 1x19 SS WIRE SS WIRE 1/2" STUD SWAGE TOGGLE FORK TURNBUCKLE GIBB G67416...
  • Page 109 Appendix 4...
  • Page 110 Appendix 5...
  • Page 111 Appendix 6...
  • Page 112 FRONT SPEAKER RF= GRY / BLK WH/BLK L1 WHITE L COM- R COM- GRAY GRN/BLK L2+ R2+ VIO/ BLK REAR SPEAKER YELLOW TO ANTENNA - NEG BLACK F LTER & FUSE CD SH UT TLE CONTROL SC C HEAD 92. 3 TRE BL E BASS JENSEN...
  • Page 113 FRONT SPEAKER RF= GRY / BLK WH/BLK L1 WHITE L COM- R COM- GRAY GRN/BLK L2+ R2+ VIO/ BLK REAR SPEAKER 12-00 SH U ANTENNA REMOTE CONTROL FUSE MODULATOR + 12V YELLOW 89-1 / 88-7 FILTER 5A FUSE YELLOW BLACK - NEG BLACK CD SH UT TLE CONTROL...
  • Page 114 11/06/06 9:03 AM PICTURE 8 AFT STBD COCKPIT LOCKER PICTURE 9 UNDER MID SALON SETTEE Revision Hull #205 onwards Oceanis 351 Rev. 02...
