  • Page 1 OCEANIS 50 NEW Owner's Manual Code: 135020 Index E...
  • Page 3 The whole BENETEAU team welcomes you aboard. A BENETEAU is made to last, in order to bring you all the pleasure you expect from a vessel over a period of many years. Each boat is subject to the utmost attention to detail from the design stage right through to launching.
  • Page 5 The boat must have on board all the proper safety equipment (lifejackets, The BENETEAU shipyards may not be held responsible for any alterations buoys, harness, flares, liferafts, etc.) depending on the type of vessel, its which they have not approved.
  • Page 6 ARNING So as to be able to continuously improve their product the BENETEAU shipyards reserve the right to make any alterations in Indicates the existence of a danger which could lead to injury or design, layout or equipment which they judge necessary.
  • Page 7 Introduction HISTORY OF UPDATES •Index A................10/2009 •Index B................03/2010 •Index C ................09/2010 •Index D ................12/2010 •Index E................08/2012...

  • Page 9: Table Of Contents

    ............. Introduction 7 ..........General specifications 13 ..............Safety 31 ..............Hull 35 ..............Deck 39 ..........Steering system 43 ........Water and sewage water Contents 49 ...........Electrical equipment 55 ..............Engine 63 ............Launching ............Personal notes...

  • Page 11: General Specifications

    General specifications Technical specifications Certification Design category Your boat...
  • Page 12 Recommended maximum power..........81 kW ECHNICAL SPECIFICATIONS OCEANIS Maximum motorisation mass........... 245 kg L.O.A ..................15,10 m Total mass of liquids (all tanks full) ......... 903 kg Hull length ................. 14,75 m Freshwater capacity ............330 l + 238 l L.W.L..................13,33 m Sewage water capacity - Aft washroom ........73 l Overall width ................
  • Page 13 B - "In open sea" Up to and including 8 Up to and including 4 The sails are the main propulsion means of the OCEANIS 50 NEW. C - "Near to the coast" Up to and including 6 Up to and including 2 D - "In sheltered...
  • Page 14 Category A: At high sea Category D: In sheltered waters This craft is designed to operate in winds that may exceed wind force 8 This craft is designed to operate in winds up to Beaufort force 4 and the (Beaufort scale) and in significant wave heights of 4 m and above. associated wave heights (occasional maximum waves of 0,5 m height).
  • Page 15 Engine type Serial number Engine key number BENETEAU (Establishment of the company SPBI) Z.I. des Mares - BP 66 - 85270 St - Hilaire - de - Riez - FRANCE - Tèl. + 33 (0)2 51 60 50 10 - http://www.beneteau.com...

  • Page 17: Safety

    Safety Safety Equipment General information Gas system Recommendations for gas Fight against fire Bilge pump system Emergency tiller...
  • Page 18 AFETY QUIPMENT Designation Position of swimming ladder (means of coming back onboard) Location of liferaft locker Swimming ladder Storage locker for liferaft Fastener - Swimming ladder (means of coming back onboard) (not supplied) Safety...
  • Page 19 Safety ENERAL INFORMATION ANGER DANGERS The major hazards concern: - Fuel leaks or vapour represent a danger of fire and explosion. - The gas system. - Leave the engine compartment ventilated for a long time before starting the engine. - The electrical system. - There may be danger of fire or explosion if direct current systems are incorrectly used.
  • Page 20 AS SYSTEM OCATION Designation Gas cylinder locker Regulator valve Supply - Gas Connector - gas copper Supply valve - Gas Drain Valve Supply valve Gas 6 - Open position Gas cylinder locker 7 - Closed position Safety...
  • Page 21 Safety ECOMMENDATIONS FOR GAS ARNING Type of cylinder: butane, service pressure 10 kg/cm or according to current standards of your country). Close the valves on the system and on the cylinder when the appliances are not used. Close the valves before -Don't use a solution containing ammonia.
  • Page 22 CHEMA ERSION UROPE Designation Regulator valve Gas cylinder Drain Connection kit gas bottle Rubber washers Pictogram Connection kit gas copper PVC girdled sleeve Gas appliance connection kit Safety...
  • Page 23 Safety Regularly check and replace the rubber tubings that link the cylinder to one end of the circuit and the stove to the other one, depending on the norms and regulations in force in your country. ARNING Pay particular attention to keep in good condition the screw thread of the cylinder on which the regulator is. Check the condition of the regulator every year and change it if necessary.
  • Page 24 CHEMA ERSION US Designation Regulator valve 12V Gas cylinder Drain Stuffing box PVC girdled sleeve Electromagnetic valve for gas 12V Pipe Propane Plastic Safety...
  • Page 25 Safety MERGENCY EVACUATION AND LOCATION OF EXTINGUISHERS Emergency exits in case of fire - Deck hatch of the fore cabin - Companionway...
  • Page 26 Position of portable extinguishers (not supplied) - Cockpit locker - Hanging locker - Forward cabin - Hanging locker - Port aft cabin - Port saloon Note: Same position for the other layouts. Safety...
  • Page 27 Extinguisher, per unit, minimum capacity 5A/34B. emergency exits. -Do not obstruct the safety controls (fuel oil For the OCEANIS 50 NEW: 20A/136B(equivalent 4 extinguishers of this minimum capacity). valves, gas valves, power switches). -Do not block the extinguishers placed on shelves.
  • Page 28 OSITION OF FUEL VALVE AND ENGINE COMPARTMENT EXTINGUISHER APERTURE Extinguisher hole located under A pictogram helps to locate it Supply valve Fuel the companionway step easily Safety...
  • Page 29 Safety The engine compartment has a port that makes it possible to inject the extinguishing product inside without opening the usual access hatches. NSTRUCTIONS TO FOLLOW IN CASE OF A FIRE IN THE ENGINE COMPARTMENT BILGE - Stop the engine. - Switch off power and stop fuel supply.
  • Page 30 SE OF THE MANUAL BILGE PUMP Operation Location Capacity: 40,5 litre / minute Safety...
  • Page 31 Safety ILGE PUMP SYSTEM ARNING ROCEDURE TO BE FOLLOWED - Switch on power to the electric bilge pumps. -The bilge pump system is not designed to - If necessary activate the manual pump. provide buoyancy to the boat in case of damage.
  • Page 32 SE STEERS FRANK OF HELP Sector access port Tiller in position Safety...
  • Page 33 Safety MERGENCY TILLER DVICE ECOMMENDATION The emergency tiller is in an aft locker and shall be easy to get to. To operate the tiller: -The emergency tiller is designed only to - Use a winch handle and unscrew the tiller cover situated at the back of the cockpit. be able to continue underway at a reduced speed in case of steering gear - Insert the tiller into the rudder stock and make sure it is fully secure in the square.

  • Page 35: Hull

    Hull Maintenance of the Hull Lifting...
  • Page 36 IFTING Wetted area : 48 m² Hull...
  • Page 37 Hull AINTENANCE OF THE RECAUTION The materials and equipments of your boat have been selected because of their high quality and performance and ease of maintenance. However you shall carry out a minimum maintenance in order to protect your boat -Consult the harbourmaster's office to find from outside attacks (salt, sun, electrolysis ...).

  • Page 39: Deck

    Deck Navigation - Deck Layout Stability Prevention of man overboard Mooring lines...
  • Page 40 NAVIGATION - DECK LAYOUT A. Mooring cleats Jack-lines to be fixed to the mooring cleats B. Towing: - at the bow, to be towed - at the stern, to tow C. Swimming ladder (means of coming back onboard) D. Mount Outboard (not supplied) E.
  • Page 41 Deck TABILITY Breaking waves represent a serious danger for stability and for taking in water. Close the companionway doors ANGER and hatches in heavy seas. During sailing keep all the portholes, windows and doors closed. -Wear your life jacket. - The stability is reduced when you add weight in the upper parts. -In heavy weather, wear your safety - Stability may be reduced when towing a boat or when heavy weights are lifted with the davits.

  • Page 43: Steering System

    Steering system Steering Gear...
  • Page 45 Steering system TEERING ARNING ABLE ADJUSTMENT TEERING SYSTEM -The steering system is a feature of sailing The steering gear is assembled and pre-adjusted at the factory, however, only actual use at sea will enable the safety and for this reason must be verified steering cable to find its definitive postion around the wheel drum.

  • Page 47: Water And Sewage Water

    Water and sewage water Water system - Distribution...
  • Page 48 ATER SYSTEM ISTRIBUTION ARNING SE OF THE WASHBASINS AND SHOWERS - Close the valves and turn off the taps after use. -Turn off the shore freshwater supply valve before leaving the vessel. EA WATER FOOT PUMP RESH WATER The footpump makes either seawater or freshwater available at the sink. RECAUTION Manipulate the valve (choice of water) and push down on the pump pedal.
  • Page 49 Water and sewage water OCKPIT SHOWER SPRAY Location HORE FRESHWATER SUPPLY Selection valve - Location Shore fresh water / On board water circuit Location: Seating - Port saloon...
  • Page 50 Black water circuit - Schematic diagram Deck or sea evacuation Deck only evacuation 1. WC 2. Seawater inlet 1. Deck filler - Suction and Rinsing 4. Sewage tank 2. Tank vent hole 5. Closing cap 3. Thru-hull seacock 6. Vent hole 7.
  • Page 51 Water and sewage water SE OF MARINE S FITTED WITH BLACK WATER TANK Open the water intake valve (valve handle parallel to the pipe). ARNING In the case of a direct discharge into the sea: Open the draining valve. -The tanks' nominal capacity cannot be In case you store the waste waters in the tank: Make sure the draining valve is closed (valve handle fully used due to the load and the need to perpendicular to the pipe).

  • Page 53: Electrical Equipment

    Electrical equipment General information 12 V DC system 110-220 V AC system...
  • Page 54 Schematic diagram Electrical equipment...
  • Page 55 Electrical equipment ENERAL INFORMATION ANGER LECTRICAL PANEL The electrical switchboard does not require any routine maintenance . In case an electric appliance is not -There may be danger of fire or explosion if energized, check: direct current systems are incorrectly used.
  • Page 56 HORE POWER SOCKET Bipolar circuit breaker 32A Differential switch 40A - Shore power socket 220V - 30A Cockpit locker - Starboard Chart table unit (Ref 1) (Ref 2) Electrical equipment...
  • Page 57 Electrical equipment , 110-220 V LECTRICAL CIRCUIT ANGER ENERAL RECOMMENDATIONS -Never let the end of the boat/shore supply Certain vessels are equipped (as either standard or optional features depending on the model)with a 110 V or cable hang in the water: The result may be an electric field liable to hurt or kill the 230 V circuit.

  • Page 59: Engine

    Engine General information Engine fitting...
  • Page 60 ENERAL INFORMATION ANGER YPE OF MOTORISATION Your vessel is fitted with an in-board diesel engine. -Stop the engine and refrain from smoking during fuel tank filling. Transmission type is Sail Drive. -Make sure that the ventilation openings in the engine (and generator, if installed) RECAUTIONS OF USE OPERATING ADVICE compartment are well cleared.
  • Page 61 Engine NGINE FITTING...
  • Page 62 IAGRAM OCATION Engine...
  • Page 63 Engine...
  • Page 64 Designation Sail-drive engine Fuel tank Engine battery Battery isolation switch set diesel filter Sea water filter Anti-siphon valve Water heater Engine control lever Water trap Outlet Accumulator tank Engine panel Fuel filler Engine...
  • Page 65 Engine The instrument panel has all the testing functions of the engine and it does not require any special precaution (refer to engine leaflet). DVICE ECOMMENDATION Check the clutch and accelerator cables (lubricate the end fittings and forks). -When the engine is running, avoid making ISIBILITY FROM THE STEERING STATION noise and chops near the other users.

  • Page 67: Launching

    Launching Launching recommendations Stepping the mast...
  • Page 68 OSITION OF HOISTING CRADLE AND STRAPS Note: Measurements are expressed in mm. Launching...

  • Page 70: Personal Notes
