  • Page 1 ANTARES 36 OWNER'S MANUAL 197855 RCD-2 Index B...

  • Page 3: Table Of Contents

    5 ......................Introduction 9 ..................Technical specifications 13 ...............Design categories and displacement 17 ..................Stability and buoyancy 23 ....................Manoeuvrability 29 .......................Safety 43 ........Information relating to fire risks and risks of explosion 51 ....................Electrical system 75 ............Liquefied Petroleum Gas system (LPG) 83 ..................Domestic appliances CONTENTS 87 ...................

  • Page 5: Introduction

    The whole BENETEAU team welcomes you aboard. A BENETEAU is made to last, in order to bring you all the pleasure you expect from a vessel over a period of many years. Each boat is subject to the utmost attention to detail from the design stage right through to launching.
  • Page 6 This manual has been produced to help you enjoy using your boat in all safety. It contains the details of the boat and of all the equipment provided and installed on your boat, as well as the instructions for their use. Read it carefully and really get to know your boat before using it. This owner's manual is not in any way a navigation or mariner's training manual.
  • Page 7 Notes on reading this manual The various symbols used throughout the manual for crucial safety information are as follows: DANGER Indicates the existence of a serious inherent danger with a high risk of death or serious injury if the appropriate precautions are not taken. WARNING Indicates the existence of a danger which could lead to injury or death if the appropriate precautions are not taken.

  • Page 9: Technical Specifications

    TECHNICAL SPECIFICATIONS Construction ..................10 General dimensions ................. 10 Engine....................10 Electricity ..................10 Capacities..................11...
  • Page 10 CONSTRUCTION Model..................................................ANTARES 36 Architect / Design .........................................Beneteau Power / Patrice Sarrazin Builder ..................................................SPBI S.A Principal means of propulsion ............................................Motor Hull and deck construction material ..............................Laminated sandwich glass / GRP / Balsa wood Hull and deck backing mould construction material ............................Single skin laminated fibreglass / GRP Application................................................
  • Page 11 CAPACITIES Total mass of the liquid content of fixed tanks when they are full ................................. 1 184 kg : The density of a liquid can vary according to its temperature and quality. The volume masses chosen are: - 0,86 kg/L for diesel fuel, - 1 kg/L for water.

  • Page 13: Design Categories And Displacement

    DESIGN CATEGORIES AND DISPLACEMENT Design categories................16...
  • Page 14 - Some of the data is shown on the manufacturer's plate fixed to the boat. The explanation of the data is given in the appropriate chapters of this manual. EFINITION Design category * CL: Crew Limit Maximum number of people to be allowed onboard (CL)* ** MLC: Mass of the boat in Light Craft Condition Maximum number of people to be allowed on the flybridge includes the weight of the boat in the standard...
  • Page 15 If some of those onboard are children, the total number of people allowed onboard may be increased, provided that: - The total weight of the children does not exceed 37,5 kg; - Do not exceed the recommended maximum number of people onboard. However many and that people are onboard, the total, combined load of people and any gear or equipment must never...
  • Page 16 DESIGN CATEGORIES Category A: A yacht of design category A is considered to be designed for wind that may exceed force 8 (on the Beaufort scale) and waves that can exceed a significant height of 4 metres, but excluding exceptional conditions such as storms, severe storms, tornadoes and extreme sea conditions or huge waves. Category B: A yacht of design category B is considered to be designed for wind that may go up to force 8 inclusive and waves that can reach a significant height up to 4 metres inclusive.

  • Page 17: Stability And Buoyancy

    STABILITY AND BUOYANCY Stability data ..................18 Access to the boat................19...
  • Page 18 STABILITY DATA - Fully laden displacement was used to evaluate the stability and buoyancy of the boat. The value of this displacement - Reduce speed in waves. can be found in paragraph "Technical specifications" at the beginning of this manual. - Always adjust the speed and heading of - Any changes in the distribution of loads onboard (for example by adding a raised structure for fishing, fitting a radar or your boat according to the sea conditions.
  • Page 19 ACCESS TO THE BOAT - It is imperative that both the cockpit and the Access to the cockpit engine compartment are kept closed when at Holding sea. - When at sea close the guardrail side- opening or openings. - Slamming an access hatch may cause injury : always close the hatch gently and carefully.
  • Page 20 Access to the engine compartment Saloon Aft cabin Stability and buoyancy 197855 RCD-2 Index B...
  • Page 21 Access to the flybridge Direct access to cockpit locker 197855 RCD-2 Index B...
  • Page 22 Access to the saloon Stability and buoyancy 197855 RCD-2 Index B...

  • Page 23: Manoeuvrability

    MANOEUVRABILITY Visibility from the steering station..........25...
  • Page 24 - It is important to take additional precautions in very strong winds or in a confused sea or breaking waves. - Do not install an engine in this boat with a higher rated power than that indicated on the manufacturer's plate. - Do not drive the boat at high speed with a negative trim of the propulsion equipment (bow down).
  • Page 25 VISIBILITY FROM THE STEERING STATION The view of the helmsman from the helm station can be obstructed by the boat heeling significantly or because of other - Manoeuvrability is reduced at excessive factors caused by one or several of the following variable conditions: speeds.
  • Page 26 4.1.1 Wiper The windscreen wipers run on DC power. Control: Steering station Engine access: Deckhead (Forward cabin) Location: Manoeuvrability 197855 RCD-2 Index B...
  • Page 27 4.1.2 Windscreen washer Reservoir location: Control: Steering station Saloon (Starboard bench seat) 4.1.3 Horn The foghorn runs on DC power. Control: Steering station Location: 197855 RCD-2 Index B...
  • Page 28 4.1.4 Navigation lights The navigation lights run on DC power. Control: Steering station Mooring light The only function of the samson post is to support the navigation light. Any other use is dangerous and forbidden. Manoeuvrability 197855 RCD-2 Index B...
  • Page 29 SAFETY Preventing man overboard situations and the means of getting someone back onboard ..............30 Storing the life-raft ................33 Securing moveable items ..............34 Information about the risks of flooding and about the boat's stability ....................35 Emergency systems in case of steering gear failure....42...

  • Page 30: Preventing Man Overboard Situations And The Means Of Getting Someone Back Onboard

    PREVENTING MAN OVERBOARD SITUATIONS AND THE MEANS OF GETTING SOMEONE BACK ONBOARD 5.1.1 Prevention of man overboard - The off-limits areas of the working deck when the boat is under way are cross-hatched below - The "working deck" means those areas outside where people stand or walk during normal use of the boat. Use the seats provided.
  • Page 31 Ref 1 & 1’: Fitting a means of climbing back onboard. Ref 2: Mooring cleats. Regularly check the guard-rails: - With metal guard-rails, watch for corrosion particularly at connecting points. - With synthetic guard-rails, change them as soon as they show signs of wear due to chafing or UV. 197855 RCD-2 Index B...

  • Page 32: Safety

    5.1.2 Getting back onboard The means for getting back onboard must be able to be deployed by one person alone in the water, with no other help. - Some types of equipment for getting back onboard have a locking device when folded up: Installation of means to get back on board when swimming: It is important to keep the means for getting back Swimming ladder (Ref 1):...

  • Page 33: Storing The Life-Raft

    STORING THE LIFE-RAFT The life-raft(not supplied) must be stored in the space provided for it (Ref 1). A pictogram helps to locate it easily. - Before putting to sea, carefully read the launching instructions shown on the liferaft. - When at sea, never padlock or lock the stowage locker for the life-raft.

  • Page 34: Securing Moveable Items

    SECURING MOVEABLE ITEMS The technical areas are identified in the boat by the pictogram below: Technical areas may not be used as storage compartments. - Ensure that movable items are firmly secured when the boat is under way. - Don't store anything below the floorboards. The electrical technical areas are identified in the boat by the pictogram below: Safety 197855 RCD-2...

  • Page 35: Information About The Risks Of Flooding And About The Boat's Stability

    INFORMATION ABOUT THE RISKS OF FLOODING AND ABOUT THE BOAT'S STABILITY 5.4.1 Openings in hull The valves, through-hull and other brass accossories last for about 5 years. Have all valves, hull orifices and other brass accessories of the vessel professionally checked every 5 years and replace them as necessary.
  • Page 36 VIEW OF HULL, STARBOARD SIDE Reference Designation Valve Draining of manual bilge pump Port side fuel tank vent Starboard fuel tank vent Port engine exhaust Air conditioning condensation drain Cabin compressor drain Chain locker scupper VIEW OF HULL, PORT SIDE Reference Designation Valve...
  • Page 37 5.4.2 Drainage system General points - The inner moulding of the hull has channelling: the drainage channels. The drainage channels allow the water to drain down to the lowest point in the boat, where it can be discharged. So it is important to allow the water to flow freely down to this lowest point of the boat, which includes. - Regularly cleaning the lowest point of the boat and the drainage channels.
  • Page 38 DIAGRAM OF THE LAYOUT - BILGE PUMPS Reference Designation Rate Manual bilge pump 32 L/minute (*) Manual bilge pump lever Electric bilge pump 20 L/minute 3’ Electric bilge pump 129 L/minute Electric bilge pump switch (*) 45 strokes/minute Safety 197855 RCD-2 Index B...
  • Page 39 Secondary drainage system Manual bilge pump The manual bilge pump is in the cockpit (Ref 1). The bilge pump lever is located close to it (Ref 2). Operation: I- Put the lever on the manual bilge pump. II- Repeatedly work the lever up and down to its fullest extent. The manual bilge pump lever must remain accessible at all times.
  • Page 40 Main drainage system Electric bilge pumps - The bilge pumps are powered by DC. - Location of the electric bilge pumps: Ref 3 Ref 3’ - The electric bilge pump switch is located at the helm station (Ref 4). - The electric bilge pump must only be used to discharge stagnant water at the bottom of the bilge. It must not be used to pump out any oil-based products (petrol, oil) or inflammable liquids.
  • Page 41 Bilge pump maintenance Please refer to the manufacturer's notes on the instructions for checking and maintaining the bilge pumps. - The drainage system is not designed to control water coming from breaches in the hull. DIAGRAM OF THE LAYOUT - DRYING OUT THE BILGE - Keep the water level in the bilges to the minimum.

  • Page 42: Emergency Systems In Case Of Steering Gear Failure

    EMERGENCY SYSTEMS IN CASE OF STEERING GEAR FAILURE NSTRUCTIONS IN THE EVENT OF STEERING GEAR FAILURE On a twin-engined vessel the emergency tiller system works on the difference in drive between the port and starboard engines (difference in throttle and/or forward/aft). Safety 197855 RCD-2 Index B...
  • Page 43 INFORMATION RELATING TO FIRE RISKS AND RISKS OF EXPLOSION Propulsion engines and other fuel-burning equipment....44 Electrical system ................44 Gas system ..................44 Fire-prevention and fire-fighting equipment........45 Emergency exits in case of fire............49...

  • Page 44: Information Relating To Fire Risks And Risks Of Explosion

    6.1 PROPULSION ENGINES AND OTHER FUEL-BURNING EQUIPMENT The risks associated with motorisation are described in the ENGINE chapter. Note concerning the boat's tender: - If the tender is fitted with a more powerful outboard motor than 25 Kw, it must have on board a portable extinguisher with a rating equal to or greater than 8A / 68B. - Place for storing the petrol tank of the tender: on deck.
  • Page 45 FIRE-PREVENTION AND FIRE-FIGHTING EQUIPMENT 6.4.1 Fire-fighting equipment Portable fire-extinguishers and fire blanket (not supplied) - When in use, this boat must be equipped with portable fire extinguishers of the following extinguishing capacity and located in the following places: Location Minimum extinguishing capacity Cockpit locker 5A / 34B Saloon seating...
  • Page 46 Maintenance of the fire-fighting equipment The owner/person operating the boat must: - Get the fire-fighting equipment checked at the frequency shown on the equipment; - Replace portable fire extinguishers, if outdated or discharged, by extinguishing apparatus of equal capacity; - Provide at least one fire bucket with a lanyard, in a readily accessible place, for protection on deck; - Get the fixed fire extinguishing systems filled or replaced if they are discharged or have expired.
  • Page 47 6.4.2 Fixed extinguishing system with manual control - This boat is fitted with a fixed fire extinguishing system protecting the engine compartment. To enable functioning of the fixed fire extinguishers, the safety pins on each - Procedure to follow in the event of fire in the engine compartment: extinguisher must all be removed completely.
  • Page 48 Ref 1: Fixed extinguisher Ref 2: Remote pull switches Location: Engine compartment Location: Steering station The position of the remote control handles is indicated by the pictogram shown below: Information relating to fire risks and risks of explosion 197855 RCD-2 Index B...
  • Page 49 EMERGENCY EXITS IN CASE OF FIRE NEVER: - Obstruct the passages leading to the emergency exits and the hatches; - Obstruct or block safety controls, for instance fuel shut off valves, gas taps, electrical system circuit-breakers; - Obstruct the access to the portable extinguishers stored in lockers;...
  • Page 51 ELECTRICAL SYSTEM General information about the electrical system ......52 DC installation (12V or 24V)............. 53 AC system (110V or 220V) ............... 67 Protection against electrolysis / Earth plate........72...

  • Page 52: Electrical System

    GENERAL INFORMATION ABOUT THE ELECTRICAL SYSTEM The risks of fire or explosion may result from careless use of the DC and AC systems. - The risks of electrocution may result from careless use of the AC system. NEVER: - work on a live electrical system; - modify the elecrical system of the vessel or the relevant diagrams: It is important that the installation, maintenance and any modifications be carried out by...

  • Page 53: Dc Installation (12V Or 24V)

    DC INSTALLATION (12V OR 24V) 7.2.1 Battery use and distribution General points The boat is equipped with a direct current electrical system. The boat's electrical system comprises service batteries and the engine battery or batteries. The service batteries serve as the power supply for all the boat's electrical components.
  • Page 54 Voltmeter Location: Passageway Maintenance - Avoid charging batteries to a voltage greater than 14,6 V. - All work carried out on a battery must only be carried out by someone qualified to do so. - Keep the batteries clean and dry. Whenever working on a battery, wear safety - Regularly check that the terminals and connection cables are clean.
  • Page 55 Maintenance of watertight batteries - This type of battery needs no maintenance and does not produce any gas during normal use. No ventilation is needed. - The optimum temperature for use is between 10 degree C and 30 degrees C. Lower temperatures will reduce the available capacity. Higher temperatures will increase the batteries' self-discharge rate.
  • Page 56 - Electrically controlled battery breakers: In the event of electrical failure, it is possible to press down the button on top of the battery breaker manually to activate it. The electrically-controlled battery breakers use very little electricity when they are on: It is imperative to turn off all the battery breakers during lengthy absences, to prevent the batteries from slowly and irreversibly discharging.
  • Page 57 7.2.3 Power distributor - The electronic charge dividers isolate the battery banks from each other and allow the charge to be directed automatically to the battery with the lowest charge. They give the advantage of preventing a drop in voltage. - The charge divider is electronic.
  • Page 58 7.2.5 Battery charger General points IT IS IMPERATIVE TO DISCONNECT THE BATTERY CHARGER BEFORE - The battery charger runs on AC power. DISCONNECTING THE BATTERY - A breaker protects the electrical circuit. TERMINALS FOR MAINTENANCE. - The battery charger charges all of the batteries onboard, while keeping the service battery bank isolated from the engine's battery bank.
  • Page 59 LAYOUT DIAGRAM - BATTERY CABLES 197855 RCD-2 Index B...
  • Page 60 7.2.6 Layout of the wiring looms in the hull - DC circuit i162 irw jrw chargeur fusible TABLEAU CONNEXION PONT Electrical system 197855 RCD-2 Index B...
  • Page 61 7.2.7 Layout of the deck wiring looms - DC circuit 197855 RCD-2 Index B...
  • Page 62 7.2.8 Layout of the wiring looms in the deck counter-moulding - DC circuit Electrical system 197855 RCD-2 Index B...
  • Page 63 7.2.9 Flybridge backing mould wiring loom plan - DC circuit 197855 RCD-2 Index B...
  • Page 64 7.2.10 Steering station switches Location: Saloon from left to right - Downward: Electronic Horn Windscreen washer Port windscreen wiper Starboard windscreen wiper Navigation lights / Mooring light Water unit Electric bilge pump - Technical locker Electric bilge pump - Passageway Electric windlass Electrical system 197855 RCD-2...
  • Page 65 7.2.11 Fuses - A fuse protects an electrical circuit from a power surge. If it blows, you must replace it with another fuse of the same When replacing fuses/circuit-breakers, always rating. ensure replacements are of the right capacity (see the colour-codes) Aft cabin Location: General fuse 12V - 100A...
  • Page 66 Ref 1 Ref 2 Ref 3 < ; HIFI HIFI A. Windscreen washer 1 & 3. Pump power - Sewage tank 1. Auto pilot B. Port windscreen wiper 2 & 4. Gauge dial - Sewage tank 2. Hifi Steering station C.

  • Page 67: Ac System (110V Or 220V)

    AC SYSTEM (110V OR 220V) Never let the end of the boat/shore supply cable hang in the water: The result may be an electric field liable to hurt or 7.3.1 General points kill the swimmers nearby. - The boat is equipped with an alternating current electrical system. - There may be danger of electrocution if alternating current systems are incorrectly used.
  • Page 68 7.3.2 AC shore socket location of components Ref 1: AC shore socket Ref 2: Breaker (Protection) Ref 3: Breaker (Operation) Operation - First plug the extension cable into the AC socket on the boat, then into the socket onshore. - First unplug the extension cable from the socket onshore, then from the AC socket on the boat. Electrical system 197855 RCD-2 Index B...
  • Page 69 7.3.3 Layout diagram AC ELECTRICAL SYSTEM Reference Designation Socket (16A) T 32A 220 Volts / 50Hz Water heater (220 V) Shore power socket (30A) Breaker (32A) Differential (40A) Electrical panel (220 V) 220V Sockets 220 Volts / 50Hz Battery charger (40A) 197855 RCD-2 Index B...
  • Page 70 7.3.4 Installation of hull wiring harnesses - AC circuit 220 Volts / 50 Hz BENETEAU 371525 220 Volts / 50 Hz BENETEAU 371525 110 Volts / 60 Hz 220 Volts / 50 Hz BENETEAU 371530 BENETEAU 371525 130 180 TABLEAU...
  • Page 71 Reference Designation Socket (16A) Water heater (220 V) Shore power socket (30A) Breaker (32A) Differential (40A) Electrical panel (220 V) 220V Sockets Battery charger (40A) 197855 RCD-2 Index B...

  • Page 72: Protection Against Electrolysis / Earth Plate

    PROTECTION AGAINST ELECTROLYSIS / EARTH PLATE - Never cover the anodes in antifoul. 7.4.1 Anodes - During the first few weeks that the boat is in General points the water, check the anodes and if necessary replace them: they erode very rapidly during this - The sacrificial anodes protect the boat's metal components from electrolysis.
  • Page 73 Cleaning anodes - Use sandpaper. Do not use metal brushes or steel tools to clean the boat, it may damage the galvanic protection. Replacing the anodes - The anodes are fastened with screws and nuts. First, remove the screws and nuts that hold the anode, then clean the contact surface. Press the new anode to obtain a good electrical contact.
  • Page 74 7.4.2 Earthing plates - An earthing plate is a shot-peened plate mounted on the hull to recreate an earth neutral point on the electrical circuit Never antifoul over the earthing plates. of the equipment supplying AC power (generator and AC/DC convertor). The earthing plate earths this equipment. The earthing plate is not an anode: it must not be allowed to deteriorate.

  • Page 75: Liquefied Petroleum Gas System (Lpg)

    LIQUEFIED PETROLEUM GAS SYSTEM (LPG) General points .................. 76 Operation of the LPG system ............78 Verification of the LPG system ............78 Layout diagram................. 81...

  • Page 76: General Points

    GENERAL POINTS - The working pressure of the LPG unit is 28 millibars. - Recommended cylinder capacity: Europe Version: 2,75 kg of butane. US Version: 5 lb of propane. - Have the hoses, the entire LPG system and the flue pipes in the LPG system inspected professionally and regularly (or at intervals determined by the national requirements of the country in which the boat sails), and have them replaced if damage is detected.
  • Page 77 location of components Reference Designation Gas bottle locker Gas supply Gas bottle connection kit Gas locker drain Regulator valve Gas supply valve Hob / Oven 197855 RCD-2 Index B...

  • Page 78: Operation Of The Lpg System

    OPERATION OF THE LPG SYSTEM - Valves for supply lines and cylinder valves must be closed when appliances are not in use, before changing a cylinder and immediately in case of emergency. - Appliance valves must be closed before opening the cylinder valve. - It is necessary to ventilate when appliances that consume oxygen from inside the boat are used.
  • Page 79 - If an LPG leak is detected or suspected, immediately take the following measures: - Do not use LPG appliances; When the cooker is on, ventilate well to prevent any risk of asphyxiation. - Disconnect the LPG supply from the supply valve(s); - Do not use the cooker as a means of heating.
  • Page 80 LAYOUT OF COMPONENTS Gas cylinder locker Hob / Oven Gas supply valve System Piezzo Liquefied Petroleum Gas system (LPG) 197855 RCD-2 Index B...

  • Page 81: Layout Diagram

    LAYOUT DIAGRAM Europe Version Reference Designation Regulator valve Gas cylinder Drain Gas bottle connection kit Bubble tester kit Rubber washers PVC girdled sleeve Copper gas connection kit Label Gas appliance connection kit Thru-wall fitting US Version Reference Designation Regulator valve Gas cylinder Drain Electromagnetic valve (12V)

  • Page 83: Domestic Appliances

    DOMESTIC APPLIANCES Fridge / Cooler .................. 84 Hot plate .................... 86...
  • Page 84 FRIDGE / COOLER General points - Refer to the manufacturer's instructions for use and maintenance. - The fridge is composed of 3 components: the compressor, the evaporator and the condenser. These components are connected by a closed circuit refrigerant gas circuit. The fridge is air-cooled. - Never heat or use tools to defrost the inside of the fridge more quickly (risk of damaging the - The fridge is DC powered.
  • Page 85 Control / Thermostat Fridge (Galley) located in the unit Thermostat Fridge (Flying bridge) located in the unit 197855 RCD-2 Index B...
  • Page 86 HOT PLATE General points - The hob runs on an AC power supply. - A breaker protects the electrical circuit. Starting up - On the switch select the chosen source of current (shore power or generator). - Turn the hob circuit breaker to ON. Domestic appliances 197855 RCD-2 Index B...
  • Page 87 AUDIO-VISUAL EQUIPMENT Television ..................88 Hifi...................... 89...
  • Page 88 10.1 TELEVISION General points - The television is powered by AC provided by the DC/AC invertor which is powered by the service batteries. The inverter has an ON / OFF button. - A circuit-breaker protects the circuit. - Pre-cabling for the aerial is already installed on the boat. Starting up - First turn on the circuit breaker, then switch on the TV.
  • Page 89 10.2 HIFI - The sound system is DC powered. Refer to the manufacturer's instructions for use and maintenance. - The sound from the TV or from the DVD player is amplified by the boom box and the speakers. - The sound from the TV comes out of the integral speakers. - The sound from the TV can come from the speakers if AUX is selected on the DVD player.

  • Page 91: Onboard Comfort

    11 11 ONBOARD COMFORT Air conditioning ................92 Electronic equipment ............... 97 Equipment other than for propulsion, which burns fuel (Generator, Heating) ..................... 99...
  • Page 92 11.1 AIR CONDITIONING General points - The air-conditioning is powered by alternating current. - The air-conditioning cools the air temperature inside the boat (only when the boat is floating in water). - The cooling circuit consists of one or more compressors that operate independently. A compressor is called "reversible" because it can heat the boat if the sea water temperature exceeds 13°C.
  • Page 93 DIAGRAMMATIC VIEW - AIR CONDITIONING - Refer to the manufacturer's instructions for use and maintenance. - When the air-conditioning is running, check visually that the sea water has been fully 1. Insulated pipe drained. 2. Ambiant air intake - Never start the generator when the climate 3.
  • Page 94 Air-conditioning controls Please refer to the key on the following page Onboard comfort 197855 RCD-2 Index B...
  • Page 95 Manual control of the air-conditioning NOTES 1. Data display - When the system is programmed in Screen which displays the desired temperature, the programmed values and the error messages. dehumidifying mode, the system's safety 2. MODE devices remain active: if there is an interruption Enables you to navigate between the different operating modes.
  • Page 96 OCKING METHOD - It is possible to lock the control buttons to avoid any accidental handling: Press the three buttons at once: MODE, UP (arrow pointing up), FAN. LC appears on the screen, which signifies "LOCK". - To unlock and resume use of the buttons, press the three buttons at the same time: MODE, UP (arrow pointing up), FAN. UL appears on the screen, which signifies "UNLOCK".
  • Page 97 11.2 ELECTRONIC EQUIPMENT The onboard electronics are powered by direct current. Control: Steering station 11 11 LEAD LINES - Do not store material on top of the sensors. - Do not cover the sensors in antifoul when antifouling the hull. - Regularly clean the sensors.
  • Page 98 Auto pilot - To ensure optimum perfomance, keep all metallic objects away from the gyrocompass. - Do not store material close to the calculator and electrical connections. Control: Steering station Gyrocompass installation: Aft cabin Autopilot ram - Place the protective covers on the repeaters Layout of components: when unused for long periods.
  • Page 99 11.3 EQUIPMENT OTHER THAN FOR PROPULSION, WHICH BURNS FUEL (GENERATOR, HEATING) - Never store fuel tanks or tanks containing 11.3.1 General points petrol in any area not specifically designed for - Make sure that the ventilation openings in the engine (and generator, if installed) compartment are well cleared. storing petrol.
  • Page 100 11.3.2 Generator LAYOUT DIAGRAM Reference Designation Fuel filter Sea water filter Water trap Anti-siphon valve Differential circuit breaker Generator Water - Gas separator Seawater inlet Seawater discharge Outlet Onboard comfort 197855 RCD-2 Index B...
  • Page 101 General points - The generator is a machine which can produce AC electrical power using mechanical power (fuel). The generator will fed the onboard equipment operating at 220V or 110V, moored or sailing. - The generator starts with its own battery (12 V circuit). - Make sure that there is enough fuel in the fuel tank before using the generator.
  • Page 102 In the event of the generator catching fire - Don't open it. - Please refer to the manufacturer's instructions for using the generator. - Cut the supply (electrical and fuel) to the boat's engines, to the generator and to the ventilators. - Never start the generator when the climate - Use the extinguisher access port on the generator to discharge the contents of the portable extinguisher.
  • Page 103 11.3.3 Warm air heating system General points - The heating is powered by DC supply. The electrical supply is provided by the onboard battery bank. - A fuse potects the circuit. - You are advised to run the heating system for about 15 minutes every month (to prevent the operating components from becoming blocked/to refresh the fuel in the pipeline). - The warm air heating system, installed at the back of the boat draws in the air outside via an integrated ventilator.
  • Page 104 Manual control Location: Saloon - Please refer to the manufacturer's instructions for the use and maintenance of the heating system. - A sudden cut in the electrical supply risks damaging the heater: REMEMBER TO SWITCH OFF THE HEATER BEFORE ISOLATING THE BATTERIES.
  • Page 105 DESCRIPTION OF PICTOGRAMS Timer menu Ventilation menu Heating menu Settings menu Normal heating mode Eco heating mode Boost heating mode Ventilation speed (speeds 1 to 4) Add the time programmer Activate the time programmer 11 11 Deactivate the time programmer Delete the time programmer Delete all time programmers Time programmer activated...
  • Page 106 LAYOUT DIAGRAM - The heater must be switched off when refilling the fuel tank. - The heater's exhaust gases are very hot: they risk burning the shock mounts or the cables running too close to the exhaust outlet skin fitting. Reference Designation Diesel tank...
  • Page 107 LAYOUT OF COMPONENTS Heater Fuel supply valve Sensor Location: Engine compartment (Starboard tank) 11 11 197855 RCD-2 Index B...
  • Page 109 WATER SYSTEMS General points ................110 Using a valve................... 111 Fresh water filling system ............. 112 Fresh water distribution system ........... 114 Main plumbing equipment ............. 115 Black water system (WC)............... 119 Waste water system ............... 124...

  • Page 110: Water Systems

    12.1 GENERAL POINTS - It is essential to rinse the entire on-board water system the first time the boat is used (The water system is protected in - Regularly check water-tightness of joints in the factory by a dietary anti-freeze). the water system installations.

  • Page 111: Using A Valve

    12.2 USING A VALVE The valve is shut when the valve handle is at right angles to the pipe, the valve is open when the valve handle is in line The valves, through-hull and other brass with the pipe. accossories last for about 5 years. Have all valves, hull orifices and other brass accessories of the vessel professionally checked every 5 years and replace them as necessary.

  • Page 112: Fresh Water Filling System

    12.3 FRESH WATER FILLING SYSTEM Reference Designation Reference Designation Water tank filler Tank filling Water tank vent Vent hole Water tank Hot water/cold water distribution bundle Gauge electrical unit Fresh water filter Water unit Water systems 197855 RCD-2 Index B...
  • Page 113 Water tank Gauge Location: Aft cabin Location: Passageway 197855 RCD-2 Index B...

  • Page 114: Fresh Water Distribution System

    12.4 FRESH WATER DISTRIBUTION SYSTEM Reference Designation Reference Designation Water unit Hot water/cold water distribution bundle Water heater Washbasin mixer tap Mixer shower Sink mixer tap Cockpit shower Cockpit shower mixer tap Water systems 197855 RCD-2 Index B...

  • Page 115: Main Plumbing Equipment

    12.5 MAIN PLUMBING EQUIPMENT 12.5.1 Water unit - The water unit is supplied by direct current. - It serves to feed all the boat's plumbing equipment with fresh water. It is fitted with a pressure switch that activates the flow when the pressure in the water system falls. - The water unit must only be used with the fresh water supply.
  • Page 116 12.5.2 Cockpit shower - The cockpit shower allows the use of fresh water for rinsing off. - The shower is fitted with a mixer tap. - The tap has a dual function: - It allows the water to be turned on/off, - It allows a choice of water temperature (hot water / Cold water).
  • Page 117 12.5.3 Deck wash pump - The deck wash pump is supplied by direct current. - The deck wash pump allows the deck or the boat's tender to be washed. - The deck wash pump is switched on at the helm station. Control: Steering station Operation - Open the sea water intake valve.
  • Page 118 12.5.4 Water heater - The water heater allows the use of hot water on board the boat. - The water heater operates by recovering heat from the port/starboard engine cooling system or via the onboard AC electrical system. - The water heater thermostat regulates the water temperature only when it is operating with electrical resistance. The thermostat is pre-set in the factory. - The mixer tap allows the temperature leaving the water heater to be adjusted.

  • Page 119: Black Water System (Wc)

    12.6 BLACK WATER SYSTEM (WC) General points - Black water is human waste including the flushing water from the toilets. - Close the valves after each use and above all when the boat is unattended. - Regularly check the valves and thru-hull seacocks for proper operation and watertightness. - Regularly check the tightness of the flexible pipe clamps and connections.
  • Page 120 Maintenance of black water tank - The risk of unpleasant odours forming increases when the waste water remains in the tank for a long time. Never use automobile anti-freeze in the black water system: risk of poisoning. - Whenever possible empty the tank regularly even before it is full. - Every time the tank is emptied put in about 5 litres of fresh water and add an appropriate detergent additive (available from chandleries).
  • Page 121 Layout diagram of black water system Drainage by electric pump DC (Masher) Reference Designation Vent hole Seawater intake valve Black water tank Masher (WC drainage pump) Gauge "WASTE" deck connection Sea discharge valve 197855 RCD-2 Index B...
  • Page 122 Using a marine toilet with a tank drain by macerator I. Open the sea water intake valve (Ref 2). Refer to the manufacturer's instructions for II. Fill the bowl by using the manual toilet pump. use and maintenance. III. Using the toilet (Ref 5). IV.a.
  • Page 123 LAYOUT OF COMPONENTS Black water tank Black water tank gauge Masher (WC drainage pump) Masher control Location: Aft cabin Location: Head located directly on the tank NOTE: It is essential to open the toilet discharge valve at sea BEFORE activating the discharge pump.

  • Page 124: Waste Water System

    12.7 WASTE WATER SYSTEM General points Observe local regulations regarding the emptying of grey water tanks. - The waste water system is the water coming from the sink, showers, air conditioning drains and washbasins. - Close the valves after each use and above all when the boat is unattended. - Regularly check the valves and thru-hull seacocks for proper operation and watertightness.
  • Page 125 12.7.1 Diagram of waste water circuit installation   Reference Designation Reference Designation Washbasin drain plug Sink drain to through-hull Washbasin drain valve Shower tray draining (Electric pump) Shower plug hole Shower pump drain to Y Shower pump Through-hull washbasin drain Sink plug hole Sink drainage valve 197855 RCD-2...
  • Page 126 12.7.2 Waste water tank installation diagram    Reference Designation Reference Designation Water tank filler Plunger Water tank vent Vent hole Water tank Inspection hatch Gauge electrical unit Water level loom - 5 points Fresh water filter Tank filling Water unit Vent hole Water heater...
  • Page 127 LAYOUT OF COMPONENTS Shower pump Shower plug hole The shower pump control Location: Aft cabin Shower screen NOTE: Must be secured while sailing. 197855 RCD-2 Index B...

  • Page 129: Engine

    ENGINE Information about the risks of fire and of explosion of engines 130 Danger from moving mechanical parts ........131 General points ................131 Starting the engine ................. 134 Engine water intake valve.............. 135 Fuel filter ..................136 Engine installation................137 Engine control ................

  • Page 130: Information About The Risks Of Fire And Of Explosion Of Engines

    13.1 INFORMATION ABOUT THE RISKS OF FIRE AND OF EXPLOSION OF ENGINES - Make sure that the coolant is circulating properly. - Ensure that the engine compartment ventilation air inlets are kept clear. - Stop the engine and refrain from smoking during fuel tank filling. - Get your fuel circuit checked regularly by a professional engineer.

  • Page 131: Danger From Moving Mechanical Parts

    13.2 DANGER FROM MOVING MECHANICAL PARTS - Keep away from the moving parts of the engine (belts and moving parts or hot components) and the drive shafts etc.. - Regularly check that the O ring on the filler cap is in good condition, to prevent any water - Be careful if you have long hair, bulky clothing, rings etc (at risk of being caught).
  • Page 132 Type of motorisation Your boat is fitted with two in-board diesel engines. The transmission is of a shaftline type. Filling up with fuel - Fill the fuel tank using the "PETROL"/"DIESEL" deck filler provided for this. - Regularly check that the O ring on the filler cap is in good condition, to prevent any water ingress. - Each fuel supply valve supplies one engine.
  • Page 133 Gauge - The fuel level is given by the gauge to the indicator on the steering station. The tanks' nominal capacity cannot be fully used due to the load and the need to maintain - Some of the gauges must be calibrated when you first fill the tanks: please consult your dealer. the correct trim.

  • Page 134: Starting The Engine

    13.4 STARTING THE ENGINE Before starting the engine, it is imperative: Before using the engine, make sure you carefully read the handbook provided by the - to open the fuel supply valve; engine manufacturer. - to open the sea water intake valve of the engine; - to open the sea water intake seacock for the stern gland;...

  • Page 135: Engine Water Intake Valve

    13.5 ENGINE WATER INTAKE VALVE The sea water intake valve plays a crucial role in ensuring that the engine runs well. - Keep the strainer under the hull as clean as possible; - brush the strainer whenever the boat is lifted out. This valve must absolutely always be opened before starting the engine.

  • Page 136: Fuel Filter

    13.6 FUEL FILTER Engine running problems may have different origins, including dirty fuel. The injection pump may wear out if there is water in the system. The water results either from the condensation resulting from an insufficiently filled tank, or from a filler cap either not closed properly or with a damaged seal. In order to prevent any water infiltration, the fuel runs through two filters: - One filter is an integral part of the engine, its role is to filter fuel very finely.

  • Page 137: Engine Installation

    13.7 ENGINE INSTALLATION 197855 RCD-2 Index B...
  • Page 138 Engine 197855 RCD-2 Index B...
  • Page 139 Reference Designation Engine control lever - Flying bridge steering station Box Electronics Engine - Flying bridge steering station Flying bridge steering station Interior steering station Engine control lever - Interior steering station Extinguisher remote control + Remote control - Supply valve: Fuel Box Electronics Engine - Interior steering station Filler cap...

  • Page 140: Engine Control

    INSTALLATION OF SHAFT ENGINE WITH BRACKET 13.8 ENGINE CONTROL - The engine manufacturer's notes provide detailed explanations on how to operate the engine and keep it running well. - Read the manufacturer's notes on use and maintenance of the engine. Control lever Engine 197855 RCD-2...

  • Page 141: Access To The Engine

    13.9 ACCESS TO THE ENGINE The access to the engine is via: - The cockpit, - Side hatches. All access hatches to the engine absolutely must be kept shut when at sea. 13.10 FLAPS General points - Refer to the manufacturer's instructions for - The flaps (trim control system) allow the pilot to adjust the boat's trim under way and thus to reduce fuel consumption.
  • Page 142 DIAGRAM OF THE LAYOUT Engine 197855 RCD-2 Index B...
  • Page 143 Description of elements A. The control unit represents the system's brain. It is located in the engine compartment. B. The control panel for the flaps is located in the wheelhouse. C. Interception units. Each interception unit includes an integral watertight joint. D.

  • Page 144: Propeller Shaft

    13.11 PROPELLER SHAFT - The shaft is stainless steel. - The shaft is aligned in the factory. When the boat is launched, its re-adjustment must be carried out by a professional. - A hydrolube bush holds the shaft in the bracket. This is a wearing ring.

  • Page 145: 13.12 Stuffing Box

    13.12 STUFFING BOX - The stern gland keeps the propeller shaft watertight. - The stern gland is accessible through the engine compartment. - Grease the watertight joint every 200 engine hours (or at least once a year). Apply grease as recommended by the mechanic.

  • Page 147: Steering System

    STEERING SYSTEM General points ................148 Layout diagram................149 Hydraulic steering ................151 Bow thruster ................... 152...

  • Page 148: General Points

    14.1 GENERAL POINTS - The steering is hydraulic. - The steering system is an important safety feature. For this reason, the annual inspection of the whole system must be carried out by a professional engineer. Two helm stations are fitted on the boat: - main helm station in the saloon, - secondary helm station on the flying bridge.

  • Page 149: Layout Diagram

    14.2 LAYOUT DIAGRAM 197855 RCD-2 Index B...
  • Page 150 Reference Designation Quantity Rudder stainless steel Black flanged bush Rudder port tube White flanged bush Balance bush Steering connecting rod Rocker bar pin Ball yoke Tie bar Piston + 2 Bleeds Hydraulic transmission kit Hydraulic transmission kit - Auto pilot Reversible unit - Pilot Hydraulic pump Bleed caps...

  • Page 151: Hydraulic Steering

    14.3 HYDRAULIC STEERING General points Refer to the manufacturer's instructions for use and maintenance. - The hydraulic pump allows the boat's steering to be controlled. - It is essential that dismantling the wheel should be carried out with the aid of a 'hub puller' type tool. Never tap or lever the wheel to access the pump.

  • Page 152: Bow Thruster

    14.4 BOW THRUSTER General points - The bow-thruster's motor is DC powered. - The bow-thruster assists with steering the boat when manoeuvering at low speed (picking up a mooring buoy or berthing on a pontoon for instance). - An operating relay is installed in the circuit. - A fuse protects the electrical circuit.
  • Page 153 During lift-out - Check that the propellers turn properly, with neither play nor stiffness. - Refer to the manufacturer's instructions for use and maintenance. - Clean the blades carefully. - Remove the propeller, clean the shaft support, smear the shaft with silicone-based grease before refitting the propeller. - Never run the motor when the propeller is out of the water.
  • Page 155 DECK FITTINGS General points ................156 Equipment ..................158 Berthing, anchoring, towing............160 Main elements of the chain locker ..........162 Electric windlass ................163...

  • Page 156: Deck Fittings

    15.1 GENERAL POINTS Alcohol, solvent or acetone based solutions to clean / maintain the outer surfaces of the boat are not to be used. A warm soapy water based solution is preferred. 15.1.1 GRP - Regularly brush the deck using a gentle de-greasing agent then rinse the deck with fresh water. - Use as few cleaning agents as possible.
  • Page 157 15.1.4 Solid wood on exterior wooden panelling - Wood exposed to harsh conditions, such as salty air and UV rays tends to become whiter and to lose its natural colour. Never use detergents, acetone or other harsh This phenomenon has no effect on the intrinsic qualities of the wood, but can spoil its aesthetic appeal. products on the wood.

  • Page 158: Deck Fittings

    15.2 EQUIPMENT - Do not use the gangway when at sea. 15.2.1 Gangway - Never manoeuvre the gangway with anyone Description on it, below it or within its arc of movement. - The gangway allows you to embark/disembark easily when the boat is moored stern on to the pontoon. - Do not use the gangway as a diving board.
  • Page 159 Hydraulic unit Location: Cockpit locker 1. Motor 2. Manual emergency lever 3. Oil filler cap Emergency procedure - A key allows the user to open the electronics box to put the emergency switch to ON. - Operate the manual lever to stow the gangway. - Put the switch back into its original position after the manoeuvre.

  • Page 160: Berthing, Anchoring, Towing

    15.3 BERTHING, ANCHORING, TOWING The anchoring points or those showing visible 15.3.1 Anchor points signs of deterioration must be replaced. Responsibility It is the responsibility of the owner/user of the boat to ensure that the berthing lines, towing cables, chains and mooring lines and the anchors are adequate for the intended use of the boat, i.e.
  • Page 161 15.3.2 Towing Responsibility: It is important that the owner thinks through the actions required when securing a towing cable onboard. - Generally the breaking strength of lines/ chains must not exceed 80% of the breaking Location of attachment points strength of the anchor points. - Always tow or be towed at low speed.

  • Page 162: Main Elements Of The Chain Locker

    15.4 MAIN ELEMENTS OF THE CHAIN LOCKER - Refer to the manufacturer's instructions for use and maintenance. - Windlass operations are dangerous: 1. Bow fitting - Always keep the anchor chain or rode free 2. Electric windlass (Chain rim - and unfouled;...

  • Page 163: Electric Windlass

    15.5 ELECTRIC WINDLASS General points - The windlass is DC powered. - The windlass is designed for anchoring purposes: Any other use is dangerous and forbidden. - An operation relay is fitted to the electrical circuit. - A circuit-breaker protects the power supply to the windlass. - The windlass operation is activated by an operational interlock relay which is powered by the engine's alternator: the windlass only works when the boat's engine is running.
  • Page 164 Maintenance - once a year, dismantle, carefully wash and grease all the moving parts of the windlass. The handle serves only to release the chain grab in order to lower the anchor manually - Regularly grease the supply terminals of the electric motor of the windlass and of the relay control box. should the electric windlass break down.
  • Page 165 LAYOUT DIAGRAM - CHAIN METER Reference Designation Remote control for the windlass Service batteries Operation relay Windlass Breaker Chain meter 197855 RCD-2 Index B...

  • Page 167: Hull Fittings

    HULL FITTINGS Upholstery..................168 Interior woodwork ................171 Interior maintenance ..............171...
  • Page 168 16.1 UPHOLSTERY - Test the product on a small hidden area of LEATHER the surface before cleaning. Maintenance - Avoid excessive moisture. Leather must be regularly cleaned and waxed. - Do not scrub on leather surfaces. To do so, clean the leather surface with a damp rag. This operation will remove dust. - If you notice leather colour on the rag, Every 6 months to a year depending on use, apply a leather shampoo on the leather then use a hydrating cream which immediately stop cleaning.
  • Page 169 ALCANTARA (microfibre) Stain removal The fabric must be free from dust before removing. To do so, use a vacuum cleaner to achieve optimal cleanness. Rub with a duster soaked in a solution containing ammonia diluted by 10%. Dilute to the strength appropriate for this fabric. Try it out first on a hidden corner, the hem for instance, if the appearance of the fabric changes, dilute accordingly.
  • Page 170 COATED FABRIC (PVC) Maintenance - The PVC must be regularly cleaned with soapy water to maintain its appearance and avoid accumulation of debris. Try to avoid using the following products: lacqeurs, aggressive cleaning products, detergents, xylene or acetone-based products which can cause permanent damage or make the fabric deteriorate. The use of such products is at the owner's risk.
  • Page 171 16.2 INTERIOR WOODWORK - Clean the interior varnish using a de-greasing shampoo on a damp cloth. - If the stains persist or if in doubt, consult a cleaning specialist. - Polish the interior varnishing with a chamois leather. - When winterising the boat, make sure the - If there are any stains or light scratches, it is possible to polish the varnish.

  • Page 173: Handling, Transport

    HANDLING, TRANSPORT Lifting plan ..................174 Lifting....................175 Upper limit of antifoul ..............175 Launch/Lift out................176 Winter Storage ................177 Transport..................178...

  • Page 174: Lifting Plan

    17.1 LIFTING PLAN 3300 1900 Note: Measurements are expressed in mm. The position of the lifting slings is shown in the pictogram below: Handling, transport 197855 RCD-2 Index B...

  • Page 175: Lifting

    17.2 LIFTING - Before the first application of antifouling to the hull, you can lightly sand the hull using 400 µm or more wet and dry - Follow the manufacturer's sandpaper. recommendations scrupulously when applying antifouling. - The lower hull of your boat should be covered with an anti-fouling paint which will prevent the adhesion of marine growth.

  • Page 176: Launch/Lift Out

    17.4 LAUNCH/LIFT OUT The initial commissioning of your boat will require a lot of skill and care. The proper working of all your boat's equipment Do not remain onboard or beneath the boat is the result of the quality of the commissioning operations. This is why the initial launch must be overseen by your dealer. during the handling operations.

  • Page 177: Winter Storage

    17.5 WINTER STORAGE - Take advantage of laying up the boat to carry out a full inventory of the equipment. - The winterisation of the engine requires the skills of a professional engineer: please consult - Check the expiry dates of the safety equipment. your dealer.

  • Page 178: Transport

    17.6 TRANSPORT PACKING PLAN 1 0 5 0 1 5 0 0 2 8 0 0 3 8 5 0 Note: Measurements are expressed in mm. Handling, transport 197855 RCD-2 Index B...

  • Page 179: Environment

    ENVIRONMENT Waste management................ 180...
  • Page 180 18.1 WASTE MANAGEMENT - Throw all packaging in the recycling containers provided for this. - Make sure you know the local enviromental regulations and follow the codes of best - Once a piece of equipment has completely stopped working, find out about the relevant recycling regulations from your practice.

  • Page 181: Appendixe

    APPENDIXE Meaning of the labels ..............182...
  • Page 182 MEANING OF THE LABELS General electrical Engine group Plumbing group Colour - WC group Comfort group Drainage group equipment Valve location label Closed valve Open valve Meaning of the symbols Motor Shower Electric pump Port engine Washbasin Manual pump Starboard engine Icemaker Toilet Propeller shaft...
  • Page 183 Shore power socket Fuel tank Fuel filter Service Holding tank Inverter Generator Battery stock Heating Breaker Thruster Air conditioning 157559 Label code (Element) ATTERY Each label is defined by: (Function) ENERATOR - a functional group (specific colour); example: - a component. (Colour: ENERAL ELECTRICAL EQUIPMENT Yellow)

Table of Contents

Save PDF
