BENETEAU 323 Owner's Manual

Sailing boat

Hide thumbs

Table of Contents

Quick Links

HULL IDENTIFICATION NUMBER:

US-BEY _ _ _ _ _ _ _ _ _

OWNER'S MANUAL BENETEAU PART #: 112746

Need help?

Do you have a question about the 323 and is the answer not in the manual?

Questions and answers

steve josey

June 20, 2025

furling inside the mast -lines to pull it from the sail how does it work

Summary of Contents for BENETEAU 323

Page 1: Table Of Contents
OWNER’S MANUAL BENETEAU 323 HULL IDENTIFICATION NUMBER: US-BEY _ _ _ _ _ _ _ _ _ OWNER’S MANUAL BENETEAU PART #: 112746 TABLE OF CONTENTS: INTRODUCTION..........................3 ANTI-FOULING..........................4 III) LIMITED WARRANTY........................5 HULL IDENTIFICATION NUMBERS ....................7 DEALER'S RESPONSIBILITIES .......................7 OWNER'S/OPERATOR'S RESPONSIBILITIES................8 VII) SAFE OPERATION AND WARNING LABELS ................12...
Page 2 (or any piece of boat equipment) must obtain lessons, gain knowledge and seek experienced advice, before proceeding to use a boat (or any piece of boat equipment). Your Beneteau dealer can advise you on the availability of boating courses, sailing lessons and professional instruction in your area.
Page 3: I) Introduction
1313 Highway 76 West Marion, SC 29571 Tel (843)-629-5300 Fax (843)-629-5329 We would like to sincerely thank you for choosing a Beneteau and we wish you good sailing. NOTE: Specifications, dimensions, capacities and descriptions are estimations given for general information purposes, and they are not contractual in nature.
Page 4: Ii) Anti-Fouling
The primary function of your Beneteau is to maximize your boating pleasure. Your new Beneteau was made to last for many years. From the very beginning, care has been taken in building your boat. Your years of pleasurable ownership are dependent upon proper care and preparation.
Page 5: Iii) Limited Warranty
BOATS. Beneteau shall in no event be liable to the Owner or any other person or entity for damages of any kind, including but not limited to direct, indirect, special or consequential damages, arising from the sale or in connection with the use or inability to use the boat for any purpose whatsoever, irrespective of whether the claims or actions for such damages are based upon contract, tort, negligence, strict liability, warranty, or otherwise.
Page 6 For a period of five years from date of manufacture, your new Beneteau has a transferable, limited hull and deck warranty. In the event of selling your Beneteau, the new owner must be registered with Beneteau within 30 days of the date of sale for the warranty to be transferred.
Page 7: Iv) Hull Identification Numbers
Checking of all systems on the boat for fit, proper function and to familiarize you with • the usage of each system. Sea trial of your new Beneteau with you as a final verification that all systems are in • good order.
Page 8: Vi) Owner's/Operator's Responsibilities
US Coast Guard. SAFETY AND MAINTENANCE For maximum enjoyment of your Beneteau, due respect should be given to proper safety and maintenance procedures. Be sure that your boat is operated according to the U.S. Coast Guard Regulations as outlined in the "Federal Requirements for Recreational Boats".
Page 9 • A large capacity bilge pump. • We recommend that you fully outfit your Beneteau with safety equipment that can be obtained through your dealer or marine supply outlets. These items should include but not be limited to: Up to date nautical charts covering your intended cruising area.
Page 10 • • Sunscreen first aid/burn cream Insect/bee sting relief ointment/spray • • Sterile pads Cold packs for sprains • • Ace bandages & splints Scissors & tweezers • • BENETEAU 323 Page 10 of 85 Apr. 01, 2004 rev 00...
Page 11: Tool Kit
Lubricating supplies: WD-40 and silicone grease. • Engine: Check engine manual for spare parts, engine oil and transmission fluid • recommendations. Sails: Sail repair kit and sail slides. • BENETEAU 323 Page 11 of 85 Apr. 01, 2004 rev 00...
Page 12: Vii) Safe Operation And Warning Labels
Ensure that the boat operator is not under the influence of drugs and/or alcohol. Do not venture out in weather or sea conditions beyond the skill or experience of the operator. There are "Warning" and "Caution" statements affixed to your Beneteau. These are detailed below with location: FUEL WARNING LABEL •...
Page 13: Propane Labels
PROPANE LABELS • At the propane stove affixed to the bulkhead in the galley Beneteau Part #111353 Beneteau Part #111357 BENETEAU 323 Page 13 of 85 Apr. 01, 2004 rev 00...
Page 14 • In the propane locker affixed under the propane locker lid Beneteau Part #015903 • On or next to the LP Gas Line Beneteau Part #111361 BENETEAU 323 Page 14 of 85 Apr. 01, 2004 rev 00...
Page 15 SWIM LADDER WARNING LABEL • Located on the transom Beneteau Part # 111354 HIGH VOLTAGE WARNING LABEL • Located beside the 110v electric panel. Beneteau Part #111365 TRANSOM DOOR WARNING LABEL • Located on or next to the helmsman’s seat. (Not applicable on all models)
Page 16 • Located at the standard battery switches. Beneteau Part #111363 OPTIONAL INVERTER BATTERY SWITCH LABEL • Located at the battery switches Beneteau Part #112624 (Not applicable on all models) SLING LOCATION ARROWS LABEL • Located at or near the hull to deck joint Beneteau Part #111364 ANTI FREEZE CAUTION TAG •...
Page 17: Viii) Federal/State Regulations
VIII) FEDERAL/STATE REGULATIONS DISCHARGE OF OIL • Located: under the sail locker lid. Beneteau Part #111352 BENETEAU 323 Page 17 of 85 Apr. 01, 2004 rev 00...
Page 18 Beneteau Part #111356 MARINE SANITATION Your Beneteau is equipped with an USCG approved marine head and holding tank. By law you must use a holding tank in all U.S. waters, Check with local authorities for regional laws governing your area before selecting the overboard discharge option.
Page 19 "The owner or operator of a vessel is required by law to render assistance to any individual or vessel in distress, so long as his vessel is not endangered in the process." BENETEAU 323 Page 19 of 85 Apr. 01, 2004...
Page 20: Ix) Commissioning
The first commissioning of a yacht is essentially the start of its life, and the importance of proper commissioning procedures at this time cannot be overstated. The first commissioning procedure must be performed by an authorized Beneteau dealer or those authorized by them. The dealer will also have a commissioning checklist to be signed by the owner and a dealer representative at the time of the first commissioning.
Page 21 _____ No leaks at thru hulls; all hose clamps secure with seacocks open. _____ Fill water tanks, no leaks at fill pipes, overflows or connections. _____ Fill fuel tank. _____ Batteries secured, connected, filled and charged. (NOTE: Beneteau ships batteries dry) _____ Check all cabin lights. _____ Check all navigation lights.
Page 22 _____ All cotter pins in place on turnbuckles and opened. _____ Run main sheets and attach topping lift. _____ Tape chain plates and cotter pins to prevent chafe. _____ Check and double-check all turnbuckles, cotter and clevis pins. BENETEAU 323 Page 22 of 85 Apr. 01, 2004 rev 00...
Page 23 DELIVERY TO OWNER _____ Walk through the boat with manuals and owner, showing operation of all components. _____ Test sail boat with owner showing all operations. _____ Fill out warranty certificates. BENETEAU 323 Page 23 of 85 Apr. 01, 2004 rev 00...
Page 24: X) Specifications Of The Boat
CE CERTIFICATION Your Beneteau has been manufactured in the United States and has been certified by ICNN to be in compliance with the relevant parts of the Recreational Craft Directive 94/25/EC from the European Parliament. The CE mark means your boat meets or exceeds all current International Organization for Standardization (ISO) standards and directives in effect at the time of manufacture.
Page 25 MAXIMUM LOAD 1300 (2866) 1300 (2866) 1300 (2866) Kg (Lbs.) MAXIMUM LOAD = MAXIMUM LOAD DISPLACEMENT – LIGHT DISPLACEMENT ANY OVERLOADING CARRIES A RISK OF FLOODING OR LOSS OF STABILITY BENETEAU 323 Page 25 of 85 Apr. 01, 2004 rev 00...
Page 26: Xi) Interior Layout
INTERIOR LAYOUT LAYOUT BENETEAU 323 Page 26 of 85 Apr. 01, 2004 rev 00...
Page 27 EXIT IN CASE OF FIRE = Emergency Exit = Recommended Fire Extinguisher Location = Engine Compartment Fire Extinguisher Port BENETEAU 323 Page 27 of 85 Apr. 01, 2004 rev 00...
Page 28: Xii) Deck
- Jack lines can be fastened either to the mooring cleats, or to pad eyes on deck. The Beneteau 323 is fitted with a foldaway swimming ladder. The swimming ladder should be in its folded/upright position as soon as you are on board.
Page 29: Xiii) Sails And Rigging
24.6 m 4.015 m 4.015 m Specifications of the Standing Rigging: V: VERTICAL - D: DIAGONAL CABLE Dia. In. V1D2 D1 AFT (Aft Lower Shroud ) Forestay Double Backstay 3/16 BENETEAU 323 Page 29 of 85 Apr. 01, 2004 rev 00...
Page 30: Standing Rigging
STANDING RIGGING BENETEAU 323 Page 30 of 85 Apr. 01, 2004 rev 00...
Page 31 BENETEAU 323 Page 31 of 85 Apr. 01, 2004 rev 00...
Page 32 2 x 3/8" in black Bag Type: Drawstring type "a' Seam: V-92 Blue / 2 rows 3-step Ditty Bag: Std. NP Ditty Bag Kit Furling System: Ref: Beneteau # 112729 Drawing Information Drawing Name: B323 RFG Drawn By: Date: 11-02 Rev. # 112736 rev0 - 0323 rf genoa.doc...
Page 33 Tack/Clew Detail Black Insignia & Furling Label Beneteau Part #: 112735 Please refer to most recent drawings Specifications subject to change with prior consent from Beneteau Copyright Neil Pryde BENETEAU 323 Page 33 of 85 Apr. 01, 2004 rev 00...
Page 34 Luff Tape: 4" with 6mm rope Luff eyes: 16-#3 eyelets Leech Line: Insignia: 3mm Dacron line Black ‘Beneteau 323” Reef Cleat: 2 x 241 Alum. Bag Type: Drawstring type “a” Reef Hts. % Reef 1 13.8% Reef 2...
Page 35 TECHNICAL SPECIFICATION SHEET Beneteau 323 Classic Lazy Bag Notes: Cover: Forest Green Odysey Side panels form loop by folding 1. Top section folded over to accept a over onto themselves and sewing. Zip-Flap 11mm round batten Top panel is in place and is sewn Zipper half to both sides 2.
Page 36 TECHNICAL SPECIFICATION SHEET Beneteau 323 lazy jack lines Material List for BOTH SIDES 4- 30mm rings 30mts of 5mm line Lines will be tied around round batten 6000mm stock that is exposed in cutouts Note: lengths approximate until fitted. Final Cuts after Annapolis boat show...
Page 37 DESCRIPTION 14323AU20 Tel. (843) 423-4201 - Fax. (843) 423-4912 THIS DOCUMENT IS - PROPRIETARY AND REPRODUCTIONS MUST BE AUTHORIZED BY BENETEAU - DRAWN BY BENETEAU - SPECIFIED AND DESIGNED BY PRODUCT MANUFACTURER. BENETEAU 323 Page 37 of 85 Apr. 01, 2004...
Page 38 DESCRIPTION 14323AU10 Tel. (843) 423-4201 - Fax. (843) 423-4912 THIS DOCUMENT IS - PROPRIETARY AND REPRODUCTIONS MUST BE AUTHORIZED BY BENETEAU - DRAWN BY BENETEAU - SPECIFIED AND DESIGNED BY PRODUCT MANUFACTURER. BENETEAU 323 Page 38 of 85 Apr. 01, 2004...
Page 39 MAINSHEET LAYOUT BENETEAU 323 Page 39 of 85 Apr. 01, 2004 rev 00...
Page 40 Vang is pinned on the top hole of the toggle of the vang bracket. • A single swivel block is shackled to the lowest hole of the toggle on the bracket. BENETEAU 323 Page 40 of 85 Apr. 01, 2004...
Page 41 LINE - classic mast TASMANIA ZSPAR 253 SINGLE+BECKET BLOCK REEF 1 - GLEISTEIN BURNT BURNT 10mm 19600 classic mast TASMANIA REEF 2 - GLEISTEIN BLUE BURNT BURNT 10mm 27400 classic mast TASMANIA BENETEAU 323 Page 41 of 85 Apr. 01, 2004 rev 00...
Page 42: Xiv) Fresh Water System
• Do not force hosepipe nozzle down the fill pipe as a high back pressure could occur. Check the vent/overflow fitting to avoid over filling. BENETEAU 323 Page 42 of 85 Apr. 01, 2004 rev 00...
Page 43 160L = 42 US gal. TRANSOM SHOWER WASHBASIN / WATER HEATER SHOWER FRESH WATER 23L = 6 US gal. PUMP & FILTER PUMP STATION BEHIND STBD SETTEE FRESH WATER PUMP AND FILTER BENETEAU 323 Page 43 of 85 Apr. 01, 2004 rev 00...
Page 44: Xv) Bilge Pump System
Locate the switch of the electric bilge pump. (See the lay out drawing of the system - next page) PUMP STATION BILGE / SHOWER PUMP AND FILTER BEHIND STBD SETTEE BENETEAU 323 Page 44 of 85 Apr. 01, 2004 rev 00...
Page 45 + FILTER MANUAL BILGE PUMP INTAKE HOSE BILGE / SHOWER 3-WAY VALVE SHOWER DRAIN INTAKE HOSE ELECTRIC BILGE PUMP DISCHARGE HOSE MANUAL BILGE PUMP DISCHARGE HOSE MANUAL BILGE PUMP BENETEAU 323 Page 45 of 85 Apr. 01, 2004 rev 00...
Page 46 BENETEAU 323 Page 46 of 85 Apr. 01, 2004 rev 00...
Page 47: Xvi) Seacocks And Thru-Hulls
Galley Sink Discharge Engine Cooling Water Intake Ice Box Draining Stern Tube Cooling Intake Valve Speed/Log, Depth Sounder Thruhulls Electric Bilge Drain Manual Bilge Drain Exhaust LPG Locker Drain (on transom) BENETEAU 323 Page 47 of 85 Apr. 01, 2004 rev 00...
Page 48 SEACOCK AND THRU-HULL LAY OUT BENETEAU 323 Page 48 of 85 Apr. 01, 2004 rev 00...
Page 49: Xvii) Marine Toilet & Holding Tank
Head Operating Procedure The marine heads on your Beneteau are installed below the water line, all valves must be closed after use and the selection lever on the head must be returned to the dry bowl position. Failure to do so could result on the bowl overflowing and flooding the boat with water.
Page 50 WASTE TANK LOCATION WASTE TANK 50L = 13 US gal. BENETEAU 323 Page 50 of 85 Apr. 01, 2004 rev 00...
Page 51 Marion, SC 29571 Part No. Macerator 12v (803) 423-4201 THIS DOCUMENT IS - PROPRIETARY AND REPRODUCTIONS MUST BE AUTHORIZED BY BENETEAU - DRAWN BY BENETEAU - SPECIFIED AND DESIGNED BY PRODUCT MANUFACTURER. BENETEAU 323 Page 51 of 85 Apr. 01, 2004...
Page 52 BENETEAU 323 Page 52 of 85 Apr. 01, 2004 rev 00...
Page 53: Xviii) Electric Systems
(has not been recharged or used for several hours beforehand). A reading of less than 11.5 V means that recharging is necessary. WARNING! NEVER OPERATE ISOLATING SWITCHES WHILE THE ENGINE IS RUNNING - DOING SO COULD DAMAGE THE ALTERNATOR DIODES AND REGULATOR BEYOND REPAIR. BENETEAU 323 Page 53 of 85 Apr. 01, 2004 rev 00...
Page 54 Harness black Big Red BATTERY Main pwr SWITCHES Negative Engine House Fuel tank Use rubber boots to cover wire connections. Alternator ENGINE 300A FUSE House BATTERY Engine BATTERY BENETEAU 323 Page 54 of 85 Apr. 01, 2004 rev 00...
Page 55 12v Panel BREAKER AMPERAGE BENETEAU 323 Page 55 of 85 Apr. 01, 2004 rev 00...
Page 56 P.O. Drawer 1218 Marion, SC 29571 111386 (803) 423-4201 0000 THIS DOCUMENT IS - PROPRIETARY AND REPRODUCTIONS MUST BE AUTHORIZED BY BENETEAU 0000 DRAWN BY BENETEAU - SPECIFIED AND DESIGNED BY PRODUCT MANUFACTURER. BENETEAU 323 Page 56 of 85 Apr. 01, 2004...
Page 57 12/17/03 P.O. Drawer 1218 Add 18/181 12/03 Marion, SC 29571 N° : 062779 (803) 423-4201 MODIFICATIONS DATES This document is proprietary an d reproduction must be authorized by Beneteau- BENETEAU 323 Page 57 of 85 Apr. 01, 2004 rev 00...
Page 58 (803) 423-4201 MODIFICATIONS DATES (803) 423-4201 This document is proprietary and reproduction must be authorized by Benetea u- This document is proprietary and reproduction must be au thorized by Beneteau- BENETEAU 323 Page 58 of 85 Apr. 01, 2004 rev 00...
Page 59 BENETEAU 323 Page 59 of 85 Apr. 01, 2004 rev 00...
Page 60 WARNING! DO NOT OPERATE THE 110V WATER HEATER DRY. 110V Panel AC MAIN SHORE REVERSED POLARITY WATER HEATER BATTERY CHARGER OUTLETS Ultra panel marine, MIAMI,FL, USA BENETEAU 323 Page 60 of 85 Apr. 01, 2004 rev 00...
Page 61 Location of 110V Outlets and Appliances DESCRIPTION Shore Power Inlet Main Breaker Battery Charger 110V Outlet Water Heater 110V Panel IN DECK IN HULL 2 CABIN 3 CABIN BENETEAU 323 Page 61 of 85 Apr. 01, 2004 rev 00...
Page 62 LAY OUT OF THE CONDUITS IN HULL IN DECK BENETEAU 323 Page 62 of 85 Apr. 01, 2004 rev 00...
Page 63: Xx) Lp Gas System
GAS STOVE Your Beneteau is equipped with a propane stove and oven combination. This unit is located in the galley and is gimbaled for your safety and comfort in a seaway. The stove is supplied by a storage bottle located in a self draining locker in the cockpit.
Page 64 Note: If the odor of gas is detected at any, time turn off all electrical and mechanical systems, extinguish any open flames and immediately check for a propane leak. Propane is a heavy gas and may settle in the bilge which represents an explosion and fire hazard. BENETEAU 323 Page 64 of 85 Apr. 01, 2004...
Page 65 LAY OUT OF THE GAS SYSTEM Hose from stove Conduit Conduit to regulating kit LPG TANK PIG TAIL HOSE PRESSURE GAUGE REGULATOR SOLENOID HOSE TO STOVE PROPANE LOCKER REGULATING KIT AND LPG TANK BENETEAU 323 Page 65 of 85 Apr. 01, 2004 rev 00...
Page 66: Xxi) Steering System
UNIT PIVOTED OUT OF THE NORMAL OPERATING POSITION. Emergency Tiller As a safety precaution on your Beneteau, an emergency tiller has been provided as a backup to the wheel steering system. NOTE: PRACTICE USING THE EMERGENCY TILLER AND BE SURE ALL CREW MEMBERS KNOW THE LOCATION AND OPERATION OF THE EMERGENCY TILLER Check at least once a year that the steering cables are properly tightened and lubricated.
Page 67 Steering Cable Lower Rudder Shaft Bearing Idler Sheave Box Rudder Tube Steering Chain Upper Rudder Shaft Bearing Steerer Retaining Ring Wheel Brake Quadrant Steering Wheel Rudder stop Emergency Tiller BENETEAU 323 Page 67 of 85 Apr. 01, 2004 rev 00...
Page 68: Engine
Move the lever to neutral, and open the throttle a little (the mechanism will differ depending on the control box fitted). Turn on the black negative battery handle and the red handled engine battery switch. BENETEAU 323 Page 68 of 85 Apr. 01, 2004...
Page 69 While employment of a diesel engine results in a greatly reduced fire hazard when compared to gasoline, it should be remembered that diesel fuel is flammable, and that the employment of good fueling practices are necessary. The following steps are provided as guidelines. BENETEAU 323 Page 69 of 85 Apr. 01, 2004...
Page 70 BENETEAU 323 Page 70 of 85 Apr.
Page 71 Various brands of this product are available at marine supply stores. As with all products of this nature, the directions on the container should be carefully followed. BENETEAU 323 Page 71 of 85 Apr. 01, 2004...
Page 72 Throttle/Shift Cables Fuel tank Antisyphon Valve Engine Engine Battery Raw Water Filter Exhaust Engine Control Thruhull Waterlock Panel Fuel Tank Fuel Tank Water Muffler in cockpit Vent Fill Heater BENETEAU 323 Page 72 of 85 Apr. 01, 2004 rev 00...
Page 73: Xxiii) Handling
XXIII) HANDLING Contact your BENETEAU dealer for maintenance and repair of your boat. The dealer will advise properly, or will supply you with the spare parts you need or the materials that are suited to your boat. Have your boat hauled & serviced once a year.
Page 74: Xxiv) Maintenance Of Your Boat
After a few years, the gel coat may be re-polished, either with a lambs wool buffer and polish, or by hand using a polish or similar product. Your yard will also be able to supply you with special cleaning products for getting rid of stubborn stains. BENETEAU 323 Page 74 of 85 Apr. 01, 2004...
Page 75 MINOR GEL COAT REPAIRS To fill in a scratch or small nick, order a Beneteau Gel coat Repair Kit with instructions for use, from your dealer or obtain a small quantity of gel coat and catalyst. Clean the affected area and rub it down with wet-and-dry sandpaper, then dry it off thoroughly (use a hair-dryer if necessary).
Page 76 Should the woodwork become damaged, gently rub it down with very fine sandpaper and touch it with several coats of the varnish. Your dealer should be able to order a Beneteau touch up kit. When this is dry, rub it down with a very fine wet-and-dry sandpaper (grade 800 or 1000) and finish off with polish (or a silicone spray) or wax.
Page 77 Maintenance consists of regularly pumping the system out with fresh water and leaving the holding tank empty whenever possible. Check the thru-hulls, seacocks, connectors and hose clamps regularly. Make sure the seacocks turn freely. BENETEAU 323 Page 77 of 85 Apr. 01, 2004 rev 00...
Page 78 Water temperature, salinity, the presence of neighboring boats, the nature of the bottom and the materials in the dock will all affect the life of your boat's anodes. Order your spare anodes thru your dealer or from Beneteau Customer Service. CALIFORNIA...
Page 79 (preferably on a lawn) to dry. Never dry a sail by hoisting it and letting it flog in the wind; this will very quickly cause the sail to deteriorate. Never fold and store a damp sail. BENETEAU 323 Page 79 of 85 Apr. 01, 2004...
Page 80: Xxv) Winterizing Procedures
The following sections are oriented towards hauling your boat for winter storage in a cold climate, but they are also a good guideline as a lay-up procedure for your Beneteau in any climate.
Page 81 If possible, allow this to sit in the tank overnight, then completely pump out and drain the entire system. If antifreeze is used in the system, check in the manufacturer's literature for the recommended type. BENETEAU 323 Page 81 of 85 Apr. 01, 2004...
Page 82 Completely pump out bilge of any water and clean out any debris present. Bilge pumps should be pumped dry and hoses disconnected, to ensure that no water is left in the system. BENETEAU 323 Page 82 of 85 Apr. 01, 2004...
Page 83 SHRINK-WRAP THE BOAT BY TAPING TO THE HULL. ALWAYS ASSURE GOOD VENTILATION. SAILS Remove the sails, clean following the sail makers recommendations and store in a clean dry space. BENETEAU 323 Page 83 of 85 Apr. 01, 2004 rev 00...
Page 84 Check all hardware on mast carefully for signs of corrosion, and check the tightness of the fastenings. Masthead sheaves should show no signs of wear and should move freely. Lubricate if necessary. BENETEAU 323 Page 84 of 85 Apr. 01, 2004...
Page 85: Xxvi) Environment
Do not throw plastic bags overboard. You love the sea, just as we do; therefore, help us to protect it and do not pollute it. BENETEAU 323 Page 85 of 85 Apr. 01, 2004...
