probe no more than 1/2 inch into the rectum.
STOP if you meet any resistance. The sensing unit is on the very tip of the probe and there
is no need to insert the probe deep into the rectum. Dispose of the used probe cover and
wash the thermometer as recommended. The peak temperature should be reached in
approximately 25-35 seconds.
Axillary Use: Wipe armpit with a dry towel. Place the probe in the
patient' s armpit (Figure 3) and keep the patient' s arm pressed firmly
against the body. In order to achieve a better axillary reading, a min-
imum measuring time of 90 seconds or longer is recommended,
depending on placement of the probe and closure of the arm
against the body.
Battery Replacement
1. When the symbol "
2. Remove battery compartment lid (Figure 4).
3. Use a pointed object such as a toothpick to pry loose the old
battery. Avoid using any sharp metal object.
4. Place new 1.55V coin-type battery (LR41 or equivalent) in the
chamber with the positive (+) side facing up or towards the
display of the unit.
5. Replace the battery compartment lid.
Cleaning and Disinfecting
Do not use corrosive detergent to clean the unit.
Clean and disinfect the thermometer before and after each use.
Cleaning Process
1. Wipe probe with a cloth dipped in a disinfectant solution such as 70% isopropyl
(rubbing) alcohol or soap and water.
2. Rinse off disinfectant residue.
Care and Storage
• Do NOT drop or crush; this device is not shock proof.
• Do NOT dismantle or modify device other than replacing the battery.
• Do NOT store the device in an extreme environment with direct sunlight or
high temperatures.
• Store the unit in the protective case while not in use.
" appears, the battery needs to be replaced.
5
Figure 3
BATTERY
Figure 4
