Arkon GN032 User Manual

GN032 | Bicycle Handlebar Mount for Garmin® GPS
Fits handlebars up to 33mm diameter. Compatible with most straight, drop, trekking,
touring, and standard (25.4mm and 26mm) size handlebars. Also for use with golf carts,
ATVs, snowmobiles, hang gliders or other apparatus having cylinder-shaped frames or
posts.

Bicycle Handlebar Mounting

Step 1. Choose a safe location on the handlebars of your bicycle in
which to mount the pedestal.
Step 2. Using a screwdriver, remove the two mounting screws (A)
in order to release the 17mm ball plate (B) so the mount
can be placed around the handlebars.
Step 3. Wrap the rubber rings (C) around the handlebar and
reassemble the 17mm ball plate (B) around the rubber rings.
Secure the mount assembly by using the screwdriver to
retighten the two mounting screws.
C

Safety Precautions

!
Do not reposition the pedestal while cycling or driving. Arkon
Resources, Inc. does not promote the adjustment of mobile devices
except when the bicycle or vehicle is safely parked or stopped.
Arkon is not responsible for any damages caused to your bicycle, your
device, or yourself due to the installation or use of this product.
GN032
Bicycle Handlebar Mount
A
B
B

Package Contents:

(1) GN032 - Bicycle handlebar mount with 17mm ball

Compatible with:

• Most Garmin 17mm ball connections (See website for full list)
Precaution: Arkon strongly recommends using a securing
!
strap to provide extra protection for your device. Failure to
do so may result in damage to your device. Do not operate
portable devices while riding. Arkon Resources, Inc. assumes
no liability for safety of bicycle rider or portable device.

Attaching a Garmin Device to Pedestal

Step 1. Attach your Garmin device (not included, sold separately)
to the ball head by fi rmly inserting the ball head (C) into the
cavity (D) in the back of the device.
Garmin brand name and Nüvi and StreetPilot product names are trademarks
or registered trademarks of Garmin International. Arkon Resources, Inc. is
not affi liated with Garmin Intl.
®
The Mobile Mounting Specialists™
Consumer Hotline:
USA (800) 841-0884
INT'L (626) 254-9005
Monday - Friday 9 am - 5 pm, PST
C
D
(Cradle / Device
not included)
www.arkon.com
Arcadia, CA 91006 USA
Designed in USA | Made in China
© Copyright 2010 Arkon Resources, Inc.
