Step 4
Apply AC power to the Distribution Module by connecting the supplied power cable from the Distribution
Module to the RATH® model RP7700104 or RP7701500 Power Supply.
Step 5
Turn on the Power Supply.

Setting the Date and Time

Step 6
All Distribution Module programming will be done from the Command Center handset.
1. Entering Program Mode
a. Dial 1#91
b. Enter Password: 7284
2. Program the time zone
a. Dial 1002 followed by the appropriate time zone code
Eastern Time Zone = 111
Central Time Zone = 112
Mountain Time Zone = 113
Pacific Time Zone = 114
b. Touch the GREEN button in the middle of the phone when finished
3. Program the date (month-day-year format):
a. Dial 1001 followed by the appropriate date (xx/xx/xxxx)
Example: for February 15, 2011 dial 02152011
b. Touch the GREEN button in the middle of the phone when finished
4. Program the time (military time including hour-minute-second):
a. Dial 1003 followed by the appropriate time (xx/xx/00)
Example: for 2:30 pm dial 143000
b. Touch the GREEN button in the middle of the phone when finished
5. To Exit Program Mode dial 00 followed by the GREEN button

Phone Programming

Step 7
Programming the phone line:
Option 1
Elevator Phone calls a number outside the building:
1. For the Elevator Phone to call a number outside the building, it must be programmed to first dial 9,
Pause, Pause then the phone number
2. Follow the directions that came with the Elevator Phone to program Memory Location 1 to dial 9, Pause,
Pause then the digits of the outside phone number
