Installation & Operations Manual
SmartRescue 5 & 10
WITH HARD WIRED TRANSFORMER
N56W24720 N. Corporate Circle
Sussex, WI 53089
RP8500003A
800-451-1460
262-246-4828 (fax)
Made in the USA
Ver. 9
www.rathmicrotech.com
www.area-of-refuge.com
3 Year Warranty
08/17

Advertisement

loading
Need help?

Need help?

Do you have a question about the SmartRescue 5 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Rath SmartRescue 5

  • Page 1 Installation & Operations Manual SmartRescue 5 & 10 WITH HARD WIRED TRANSFORMER N56W24720 N. Corporate Circle Sussex, WI 53089 RP8500003A 800-451-1460 262-246-4828 (fax) Made in the USA Ver. 9 www.rathmicrotech.com www.area-of-refuge.com 3 Year Warranty 08/17...
  • Page 2: Table Of Contents

    Thank you for purchasing Rath’s SmartRescue. We are the largest Emergency Phone Manufacturer in North America and have been in business for over 35 years. We take great pride in our products, service, and support. Our Emergency Phones are of the highest quality.
  • Page 3: Installation

    • Dedicated Analog Telephone Line (POTS, PBX, or Central Office) with RJ11 connector. If you are installing on a Voice Over IP (VoIP) phone system, you must obtain from Rath (Model 2100-VOIP) or the phone system provider a VoIP Interface programmed to provide a disconnect (CPC) signal. It can be used as an intercom system when used with a Rath 2100-LINESIM.
  • Page 4: Power Supply Installation

    SmartRescue 5 & 10 24 Volt Power Supply Installation • Connect the hot wire of the 120vac to the L screw on the power supply. • Connect the neutral wire of the 120vac to the N screw on the power supply.
  • Page 5: Wiring Diagrams

    Wiring Diagram with 2500-PWR24 Power Supply EMERGENCY PHONE SOLID LIGHT: CALLING BLINKING LIGHT: RECEIVED 7 8 9 2 Pair- Twisted SmartRescuePhone 24-22ga Disconnect Call to Rescue Services Submaster 1 Submaster 2 EMERGENCY PHONE SOLID LIGHT: CALLING BLINKING LIGHT: RECEIVED Solid lit LED (Phone, Sub-Master, or Rescue Services 1 Pair indicates Call In Progress Slow blinking LED indicateds Call on Hold...
  • Page 6 Wiring Diagram with Individual Transformers HELP PHONE SOLID LIGHT: CALLING BLINKING LIGHT: RECEIVED GROUND NEUTRAL 120vac HOT 7 8 9 2 Pair- Twisted SmartRescuePhone 24-22ga Disconnect Call to Rescue Services Submaster 1 HELP PHONE Submaster 2 SOLID LIGHT: CALLING BLINKING LIGHT: RECEIVED GROUND NEUTRAL...
  • Page 7 SmartRescue Base Station Typical Wiring Diagram with 120vac Yellow (PIN-1) Green (PIN-2) Red (PIN-3) Black (PIN-4) Phone Push Connector 1 Phone Push Connector 2 Phone Push Connector 3 Phone Push Connector 4 Phone Push Connector 5 7 8 9 Phone Push Connector 6 Phone Push Connector 7 Phone Push Connector 8 Phone Push Connector 9...
  • Page 8: Smartrescue Programming Options

    Programming Options for SmartRescue 1. Program SmartRescue to Allow Emergency Phones to Call it, then Outside Number(s): Programming Steps: a. Apply power and backup battery b. Hold down Red Disconnect and Submaster 1 buttons for 5 seconds c. Release buttons (you will hear a confirmation tone) d.
  • Page 9: Phone Programming Options

    Programming Options for Phone(s) 1. To program phone(s) to dial standard emergency numbers: Programming Steps: a. Press Enter to get into program mode b. Press 1, Enter, (Phone Number), Stop Press 2-5, Enter, (Phone Number), Stop (for each additional phone number) c.
  • Page 10: Operation

    Operation 1. Once all connections are made, the following LEDs should be lit: • Power LED, located on bottom edge of the face plate, will be constantly lit green. • Battery LED, located on bottom edge of the face plate, will be constantly lit: •...
  • Page 11: Sub-Master Phone Installation

    2300-630SM Sub-Master Installation and Operation Installation: • Mount the Sub-Master to the wall in desired location • Run twisted, 24 or 22 gauge, 4 wire cabling (CAT5 rating or greater is preferred) to connect Sub-Master to SmartRescue Operation: • Lift handset •...
  • Page 12: Troubleshooting

    • Battery plug is not connected to circuit board. illuminated: • Battery should be replaced every 2 years (Rath Model #: RP7300109A). No dial tone: • Analog phone line or Voice Over IP (VoIP) with proper VoIP interface is not connected (cannot be a digital phone line).
