Buggy Kids Ride on Car
Installation and Operation Instructions
Please read this instruction manual carefully. It is important to
read and follow all of the steps during assembly to ensure proper
operation and safety of the child. Please keep this manual for
future reference.
Scan this QR Code
to view the
Assembly Video

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Volkswagen Beetle and is the answer not in the manual?

Questions and answers

Related Manuals for Supertrax Volkswagen Beetle

Summary of Contents for Supertrax Volkswagen Beetle

  • Page 1 Buggy Kids Ride on Car Installation and Operation Instructions Please read this instruction manual carefully. It is important to read and follow all of the steps during assembly to ensure proper operation and safety of the child. Please keep this manual for future reference.

  • Page 2: Specifications

    SPECIFICATIONS: Car Type: Volkswagen Beetle Style Battery Type: 2*6V4.5AH Electric Motor: 12V20W (driving motor) Age Range: 2 – 5 Years Max. Weight: 65 lbs Product Size: 44”L x 25”W x 16”H Avg. Speed: 3 MPH Charging time: 8-12 hrs Avg. Use Time: .75-1.5 Hrs (depending on use)

  • Page 3: Parts List

    PARTS LIST: Car Body Seat Charger Steering Wheel Motor/Gearbox Remote Control Wheel Covers Rear Axle Instruction Manual Wheels Windshield Frame ASSEMBLY INSTRUCTIONS: Installing Rear Wheels & Gearboxes Apply a thin layer of grease (supplied) uniformly onto the axle Remove car from box and plastic. Prop rear of car up so rear axle is off the ground.
  • Page 4 Installing Front Wheels Apply a thin layer of grease (supplied) uniformly onto the axle Place a washer onto the axle shaft. Push the center button on the outside of the wheel and push the wheel onto the axle. Release the center button and make sure that the wheel snaps into place.

  • Page 5: Installing The Seat

    Installing the Seat Remove the two screws. Set the seat in the appropriate position on the car. Insert the two screws and tighten.

  • Page 6: Operating The Remote Control

    Operating the remote control 1. Install batteries 2. Press button on lower right of left/right arrows, the red LED light on the remote will flash. 3. Press the power button on the car to pair the remote to the car. 4.
  • Page 7 Vehicle stops working: First check the fuse to see if it is burnt out or broken. If so, replace with a new fuse. There is a spare fuse located under the seat. WARNING: - Use only the rechargeable battery and charger supplied with your vehicle. NEVER substitute the battery or charger with another brand.

  • Page 8: General Maintenance

    GENERAL MAINTENANCE: It is the parent’s responsibility to check main parts of the toy before using. Regularly examine the car for potential hazard, such as damage to the battery, charger, cable or cord, and plug. Also, check that all screws are tightened throughout the car.

  • Page 9: Troubleshooting Guide

    TROUBLE SHOOTING GUIDE: Problem Possible Cause Possible Solutions Car will not move Battery voltage is low. Charge the battery Battery connector or wires Re-connect the battery are loose. connector to the car Battery is damaged or Replace battery dead. Electrical box or motor is Replace motor damaged The battery will not...
