- Page 1 nXLi INSTRUCTION MANUAL Publication Number: A770-10-880 Issue: A Original Instructions edwardsvacuum.com...
-
Page 2: Copyright Notice
A770-10-880A - Copyright notice Copyright notice © Edwards Limited 2017. All rights reserved. Trademark credits Edwards and the Edwards logo are trademarks of Edwards Limited. Page 2... -
Page 5: Table Of Contents
A770-10-880A - Contents Contents Copyright notice..................... 2 Trademark credits....................2 List of Figures......................7 List of Tables......................8 Safety and compliance Definition of Warnings and Cautions................9 Safety symbols........................ 9 General description Overview........................10 Pump controller......................11 User interface control panel..................12 Logic interface...................... - Page 6 A770-10-880A - Contents Maintenance and service General maintenance....................27 Service.......................... 27 Returning a pump for service................27 Storage Disposal Fault finding The pump has failed to start or has stopped..............30 The pump has failed to achieve the required performance......... 30 The pump is noisy......................
-
Page 7: List Of Figures
Figure 3: Valve connector showing pin numbers..............13 Figure 4: Logic interface connection..................23 Figure 5: Digital operator screen view..................25 Figure 6: Dimensions - nXL110i....................33 Figure 7: Dimensions - nXL200i....................34 Figure 8: nXL110i performance graph..................35 Figure 9: nXL200i performance graph..................36 Figure 10: HS1 Form........................ -
Page 8: List Of Tables
A770-10-880A - List of Tables List of Tables Table 1: Auxiliary load currents....................13 Table 2: Recommended mating plugs..................13 Table 3: Checklist of items....................... 16 Table 4: Displayed parameters....................25 Table 5: Digital operator......................32 Table 6: Recommended cord sets....................32 Table 7: Operating and storage conditions................33 Table 8: Mechanical data...................... -
Page 9: Safety And Compliance
A770-10-880A - Safety and compliance Safety and compliance Definition of Warnings and Cautions Important safety information is highlighted as WARNING and CAUTION instructions; these instructions must be obeyed. The use of WARNINGs and CAUTIONs is defined below. WARNING: Warnings are given where failure to observe the instruction could result in injury or death to people. -
Page 10: General Description
A770-10-880A - General description General description Overview WARNING: Improper use of the equipment could cause damage to it or injury to people. The user is responsible for the safe operation, installation and monitoring of the system. The pump is a cord connected system rated 200 - 230 V, 50/60 Hz, 8.5 A. The pumping system is intended for use on clean duty applications only. -
Page 11: Pump Controller
A770-10-880A - General description If pumping a gas not listed, contact the supplier for advice. Failure to contact the supplier may invalidate the warranty on the pump. The pump is not suitable for pumping aggressive or corrosive gases. Figure 1 nXLi 1. -
Page 12: User Interface Control Panel
A770-10-880A - General description The pump controller provides the user interface control panel. The pump may be operated in these modes: • Manually, using the buttons on the user interface panel control panel. Refer to Figure 1 on page 11, item (1) and Figure 2 on page 12. -
Page 13: Figure 3 Valve Connector Showing Pin Numbers
A770-10-880A - General description parallel with the pump NORMAL output signal, that is, the (normally closed) valve opens when the normal signal becomes active (pump at speed) and closes when stop is selected or there is a fault condition. Reaction time will be in line with valve selection. The output signal is 24 V d.c. -
Page 14: Pump Controller Configuration
A770-10-880A - General description Description Data Mating connector plug; screw Phoenix part number SACC-M 8MR-4CON-M-SW connection, right angle Mating connector plug; solder Phoenix part number SACC-M 8MR-4CON-M connection, right angle Pump controller configuration All the configuration settings stored within the pump controller are retained when power to the pump is removed so that it is possible to use a separate system to configure the pump controller before fitting the pump to the application. -
Page 15: Installation
This publication is available on request by contacting Edwards. • Contact the local service centre or Edwards for more information regarding advice or assistance on installation. • Do not remove the temporary covers from the system inlet and exhaust until ready to connect to the vacuum or exhaust extraction system. -
Page 16: Mechanical Installation
A770-10-880A - Installation The pump is supplied fixed by metal brackets to a wooden pallet with a cardboard surround. These metal brackets should be removed and retained. • Take care when unpacking the pump to avoid excessive shocks which could damage the bearings and reduce the life of the pump. - Page 17 A770-10-880A - Installation WARNING: Install the pump in the vacuum system before connecting the pump to the power supply. This will ensure that the pump cannot operate and injure people during installation. WARNING: Topple hazard. Do not exceed the topple angle when moving the pump or the pump may fall over and injure people.
-
Page 18: Leak Test The System
Ensure that the sealing surfaces are clean and scratch-free. • Edwards recommends the use of an exhaust extraction system suitable for use with all process gases being pumped. Ensure that the exhaust extraction system cannot become blocked or obstructed when the pump is operating. -
Page 19: Electrical Installation
A770-10-880A - Installation Note: Ensure that the nitrogen supply conforms to the requirements given in Table 11 page 36 section. If it does not, the gas pipelines may become blocked or the dry pumping system may be damaged. Refer to Figure 1 on page 11, item (12) for location of the nitrogen purge port. -
Page 20: Connection For Remote Control And Monitoring
Parallel and serial control mode on page 22 for more information. To control the pump using the serial interface, please contact Edwards for further information. Additional safety equipment Install suitable measurement equipment in the nitrogen supply pipeline if the process tool/ control system needs to know the total flow rate of nitrogen to the pump for safety reasons. -
Page 21: Operation
A770-10-880A - Operation Operation Operation safety WARNING: Do not operate the pump with any parts of the enclosures removed or damaged as there may be a risk of an electric shock. WARNING: Do not expose any part of the human body to the vacuum as this could result in injury to or death of people. -
Page 22: Operational Modes
A770-10-880A - Operation CAUTION: This is an industrial (Class A, Group 1) product as defined by EN55011 and EN61325. To ensure compliance with European Electromagnetic Compatibility (EMC) requirements for EMC emissions, please note that it is not intended for use in domestic buildings or in properties directly connected to an electrical supply network which also supplies domestic buildings. -
Page 23: Autorun
A770-10-880A - Operation The available controls are: • Run/Stop • Normal/OK signal • Standby Figure 4 on page 23 shows which connections to make to enable the functions. The "AUTORUN" switch (Figure 1 on page 11, item 7) should be in the 'OFF' position for remote operation. -
Page 24: Start The Pump
The parameters shown in Table 4 on page 25 are visible on the display screen whilst the pump is running: To view other parameters please refer to the digital operator user manual or by contacting Edwards. Page 24... -
Page 25: Transient Overload Protection
A770-10-880A - Operation Figure 5 Digital operator screen view Table 4 Displayed parameters Parameter code Parameter description U1-01 Reference frequency (set to 450 Hz) U1-02 Actual frequency (Hz) U1-03 Output current (A) Transient overload protection The pump operates an overload protection condition such that if the load exceeds the pumps capacity, the pump will momentarily stop before restarting automatically to attempt pump down again. -
Page 26: Restart The Pump
Note: If the pump has automatically shut down because of high pump power, check that the pump is free to rotate before restarting: contact Edwards. If the pump has been automatically shut down because of an alarm condition, the alarm condition must be rectified before restarting the pump. -
Page 27: Maintenance And Service
A770-10-880A - Maintenance and service Maintenance and service General maintenance The system requires no user maintenance. Maintenance must be carried out by Edwards service centres (refer to Service on page 27). The frequency of maintenance operations depends on the process. Adjust the frequency of maintenance operations according to user experience. -
Page 28: Storage
Do not drain oil from the pump whether dangerous substances have been pumped or not. Blanking plates must be fitted to seal vacuum inlet and outlet ports to prevent possible oil leakage. Ensure the pump is correctly labelled. If in doubt, contact Edwards. To store the pump: 1. -
Page 29: Disposal
Dispose of the pump and any components and accessories safely and in accordance with all local and national safety and environmental requirements. Edwards products are supported by a world-wide network of Edwards Service Centres. Each Service Centre offers a wide range of options including disposal. Refer to... -
Page 30: Fault Finding
Remedy Ensure that the vacuum measurement equipment is calibrated and is in date and that the correct gauge range has been selected for the application. Contact Edwards for further assistance on gauge selection, if required. Cause The vacuum fittings are dirty or damaged. -
Page 31: The Pumping Speed Is Poor Or If Pump Down Time Is Too Long
Table 8 on page 33. Alarm indicator If the red alarm indicator LED (Figure 2 on page 12, item 9) is illuminated, contact Edwards for further information. Before performing any fault finding, lockout/tagout the electrical and nitrogen supplies. Page 31... -
Page 32: Accessories
A770-10-880A - Accessories Accessories The following accessories are available to support the pump. Please contact an Edwards representative for more information. Digital operator Allows connection to the pump controller via the XLR connection socket on the interface control panel. Electrical cables Recommended cord sets for regional requirements. -
Page 33: Technical Reference
704 x 308 x 343 mm Maximum tilt angle 25 ° Nominal rotational speed 9000 rpm Mass 75 kg 81 kg Inlet connection NW40/NW50 Outlet connection NW25 Figure 6 Dimensions - nXL110i All measurements indicated are shown in mm (inches) Page 33... -
Page 34: Performance
A770-10-880A - Technical Reference Figure 7 Dimensions - nXL200i All measurements indicated are shown in mm (inches) Performance Table 9 Performance data nXL110i nXL200i Maximum pumping speed (m /hr) Maximum continuous inlet pressure at 40° ambient (mbar) Maximum continuous inlet pressure at 30°... -
Page 35: Figure 8 Nxl110I Performance Graph
1 m from the pump in free space dB(A) Uncertainty, K dB(A) Values determined in accordance with ISO 3744: 2010 Figure 8 nXL110i performance graph 1. nXL110i 3. Supply power (kW) 2. nXL110i in transient overload protection... -
Page 36: Materials Exposed To Gases Pumped
A770-10-880A - Technical Reference Figure 9 nXL200i performance graph 1. nXL200i 3. Supply power (kW) 2. nXL200i in transient overload protection Materials exposed to gases pumped The following materials and component types are exposed to the gases pumped: • SG iron •... -
Page 37: Electrical Data
A770-10-880A - Technical Reference Electrical data Table 12 Electrical rating for continuous operation Supply Phase Frequency (Hz) Input current (V a.c. rms) (A rms) 200 - 230 Single 50/60 Note: In a transient overload condition the maximum overload current drawn by the pump is 10 amps. -
Page 38: Figure 10 Hs1 Form
Complete the Declaration (HS2) and send it to Edwards before you dispatch the equipment. It is important to note that this declaration is for Edwards internal use only, and has no relationship to local, national or international transportation safety or environmental requirements. -
Page 39: Figure 11 Hs2 Form
Read the Return of Edwards Equipment – Procedure (HS1) before you complete this Declaration • Contact Edwards to obtain a Return Authorisation Number and to obtain advice if you have any questions • Send this form to Edwards before you return your equipment as per the procedure in HS1... - Page 40 © Edwards Limited . All rights reserved edwardsvacuum.com Edwards and the Edwards logo are trademarks of Edwards Limited...
