Summary of Contents for Ingersoll-Rand EL 115V AC Series
Page 1
45530110 Edition 1 July 2008 Electric Screwdrivers EL, EP and ET 115V AC Series Maintenance Information Save These Instructions...
Page 2
WARNING Always wear eye protection when operating or performing maintenance on this tool. Always turn off the air supply and disconnect the air supply hose before installing, removing or adjusting any accessory on this tool or before performing any maintenance on this tool. Note: When reading the instructions, refer to exploded diagrams in parts Information Manuals when applicable (see under Related Documentation for form numbers).
Page 3
Disassembly of the Electrical Components 20. If the Reverse Switch (70) is damaged, desolder and replace. 21. Using an Ohm meter, check the Resistor (72) on the Reverse Remove the Reverse Switch Circuit Board (69) from the Housing. Switch Circuit Board. Reading should be 20 Ohm for 115 V Tools and 80 Ohm for 230 V Tools.
Page 4
14. Install the two Switch Base Screws and tighten to 1.6 KG-cm. Brake 15. Install the Controller Assembly into its groove in the Housing. Switch Place the ground wire into the notch in the Controller Assembly Pilot Rod Screws and align this notch with the tab in the Housing. Brake Switch Assembly 16.
Page 5
Insert a .80 mm gauge and push the Bit Holder. The Shut-off NOTICE Switch should click. Adjust the Pilot Rod Adjusting Screw if necessary using the two This is a left-hand thread. adjusting spanner wrenches. For Throttle Lever Start Models, there is no need to push the Bit At the middle of the Clutch Housing threads, apply Loctite Holder, Slide the gauges between the Pilot Rod Adjusting Screw Threadlocker 3 Bond 1406®...
Troubleshooting Guide Trouble Probable Cause Solution Starting microswitch is defective; replace the microswitch. Pilot Rod “H” is binding; clear obstruction or replace Rod. Pilot Rod “G” or Pilot Rod “H” is defective; repair or replace Rod. Does the microswitch “click” when the bit is Bit Holder is binding;...
Page 7
Trouble Probable Cause Solution Bit Holder is defective; repair or replace the Bit Holder. Bit Holder cannot be depressed Retaining Ring on Bit Holder has been lost or is out of position. Screws are loose; tighten all Screws Is there looseness at the assembled points. Clutch Housing is loose;...
