Using Combination Buttons; Operating Guide; Replacement Of Batteries In The Remote Control - Innova IGPCX-27-1 Owner's Manual

ENG

Using combination buttons

Child lock function
Pressing the "+" and "-" buttons simultaneously will turn the child lock function on or off.
When the child lock function is activated, the " " icon will be displayed on the remote control.
If the remote control is operated, the " " icon will flash three times and the remote control will
not send a signal.
Switchover function for temperature display
After turning off the unit using the remote control, press the "-" button and the "MODE" button
simultaneously to switch between °C and °F.

Operating guide

1. After connecting to the power, press the "
air conditioner.
2. Press the "
" button to select your required mode: AUTO, COOL, DRY, FAN.
3. Press the "+" or "-" button to set your required temperature. (The temperature cannot be
adjusted in auto mode).
4. Press the "

Replacement of batteries in the remote control

1. Press the reverse of the remote control marked "
", as illustrated, and then push out the cover of
battery box in the direction of the arrow.
2. Replace the two 7# (AAA 1.5V) dry batteries, and
make sure that the "+" and "-" poles are in the
correct positions.
3. Replace the cover of the battery compartment.
• During operation, point the remote control signal sender at the receiving window on the unit.
• The distance between signal sender and receiving window should be no more than 8 m, and
there should be no obstacles between them.
• The signal is easily disrupted in a room with fluorescent lights or a wireless phone; the remote
control should be close to the unit during operation.
• Insert new batteries of the same model when replacement is required.
• If you will not be using the remote control for a long time, please take out the batteries.
• If the display on the remote control is fuzzy or there is no display, please replace the batteries.
" button to set your required fan speed: auto, low, medium or high speed.
NOTICE
" button on the remote control to turn on the
signal sender
Battery box cover
14
battery
reinstall
remove
