  • Page 1 Digital Power Plug-In Module (PIM) User’s Guide  2019 Microchip Technology Inc. DS50002853A...
  • Page 2 WiperLock, Wireless DNA, and ZENA are trademarks of Microchip Technology Incorporated in the U.S.A. and other countries. SQTP is a service mark of Microchip Technology Incorporated in Microchip received ISO/TS-16949:2009 certification for its worldwide headquarters, design and wafer fabrication facilities in Chandler and the U.S.A.

  • Page 3: Table Of Contents

    1.2.1 Test Points ....................10 1.2.2 Electrical Characteristics ................10 1.2.3 Analog and Digital Signals ................ 11 1.2.4 dsPIC33CH512MP506 DP PIM – PCB Edge Connector ......11 1.3 UART Communication .................. 12 1.4 Low-Frequency Bode Plot Measurements ........... 12 Appendix A. Board Layout and Schematics A.1 Pinout ......................
  • Page 4 Digital Power PIM User’s Guide NOTES:  2019 Microchip Technology Inc. DS50002853A-page 4...

  • Page 5: Preface

    • Document Revision History DOCUMENT LAYOUT This document provides an overview of the dsPIC33CH512MP506 Digital Power PIM. The document is organized as follows: • Chapter 1. “Overview” — This chapter introduces the dsPIC33CH512MP506 Digital Power PIM and provides a brief overview of its various features.
  • Page 6 Digital Power PIM User’s Guide CONVENTIONS USED IN THIS GUIDE This manual uses the following documentation conventions: DOCUMENTATION CONVENTIONS Description Represents Examples Arial font: ® Italic characters Referenced books MPLAB IDE User’s Guide Emphasized text ...is the only compiler...
  • Page 7 Preface RECOMMENDED READING This user’s guide describes how to use the dsPIC33CH512MP506 Digital Power PIM. Other useful document(s) are listed below. The following Microchip document is available and recommended as a supplemental reference resource: • “dsPIC33CH128MP508 Family Data Sheet” (DS70005319) Refer to this document for detailed information on the dsPIC33CH Dual Core Digital Signal Controllers (DSCs).
  • Page 8 Digital Power PIM User’s Guide CUSTOMER SUPPORT Users of Microchip products can receive assistance through several channels: • Distributor or Representative • Local Sales Office • Corporate Application Engineer (CAE) • Embedded Solutions Engineer (ESE) Customers should contact their distributor, representative or Embedded Solutions Engineer (ESE) for support.

  • Page 9: Chapter 1. Overview

    POWER PIM USER’S GUIDE Chapter 1. Overview INTRODUCTION The dsPIC33CH512MP506 Digital Power Plug-In Module (DP PIM) is a demonstration board that, in conjunction with different power boards, showcases the Microchip dsPIC33CH512MP506 16-Bit Digital Signal Controller (DSC) features. The DP PIM...

  • Page 10: Test Points

    17. Op amp buffers for medium speed ADC inputs. 18. MEMS oscillator. Board dimensions are: 51 mm (length) x 38.5 mm (width). 1.2.1 Test Points Table 1-1 lists the test points available on the dsPIC33CH512MP506 DP PIM. TABLE 1-1: TEST POINTS Test Point Name Function/Description TP1, TP2...

  • Page 11: Analog And Digital Signals

    Overview 1.2.3 Analog and Digital Signals The dsPIC33CH512MP506 DP PIM ensures good signal integrity and provides all signals needed to control a power train. These signals are divided into two main sections: Analog and Digital. 1. Analog Section The analog section is located at the short segment of the edge connector.

  • Page 12: Uart Communication

    (www.microchip.com). LOW-FREQUENCY BODE PLOT MEASUREMENTS The dsPIC33CH512MP506 device, along with an additional on-board circuitry, allows Bode plot measurements to be performed without the need for an isolation transformer. The transformer might still be required if the injected signal tends to be at a very low frequency (for instance, in case of Power Factor Correction (PFC) applications).
  • Page 13 FIGURE 1-3: SCHEME OF CLOSED-LOOP MEASUREMENT Power Stage Output Bode 100 Signal Min/Max Injec Clamp DAC1 Output BODE Bode 100 Generator Compensator – S1AN13 /2 + 2 x V Remove O set Reference  2019 Microchip Technology Inc. DS50002853A-page 13...
  • Page 14 Digital Power PIM User’s Guide NOTES:  2019 Microchip Technology Inc. DS50002853A-page 14...

  • Page 15: Appendix A. Board Layout And Schematics

    Slot — — — — RC8_RP56_ASDA1 Digital General Purpose 75R Series Resistance RB12_RP44 Digital General Purpose 270R Series Resistance RD14 Digital General Purpose 270R Series Resistance RB13_RP45 Digital General Purpose 270R Series Resistance  2019 Microchip Technology Inc. DS50002853A-page 15...
  • Page 16 Digital Power PIM User’s Guide TABLE A-1: PINOUT AND ELECTRICAL PARAMETERS (CONTINUED) Edge Device Name Connector Function/Description Remarks Digital General Purpose 270R Series Resistance — — — — — — — — RD6_S1PWM6H PWM Output 75R Series Resistance RC9_ASCL1...

  • Page 17: Board Schematics

    BOARD SCHEMATICS Figure A-1 Figure A-2 show the board schematics. FIGURE A-1: dsPIC33CH512MP506 DIGITAL POWER PIM SCHEMATIC REV. 1.0 (PAGE 1 OF 2) 270R -> RES2134 +3.3V_OPA +3.3V_OPA +3.3V MCLR RA0_AN0 RA0_AN0_IN MCLR OPA_1 RB5_SDA2 RA1_AN1 SDA2 150R RA2_S1AN16 560 pF...
  • Page 18 FIGURE A-2: dsPIC33CH512MP506 DIGITAL POWER PIM SCHEMATIC REV. 1.0 (PAGE 2 OF 2) USB Port USB/UART-I C Interface +5V_USB USB2.0 MICRO-B FEMALE +3.3V +3.3V Micro-AB Receptacle 0.1 μF 1 μF 0402 4.7k 4.7k 1 2 3 4 5 0402 0402...

  • Page 19: Pcb Layout

    Board Layout and Schematics PCB LAYOUT The dsPIC33CH512MP506 DP PIM is a four-layer FR4, 1.55 mm, Plated-Through-Hole (PTH) PCB construction. Figure A-3 through Figure A-5 illustrate the PCB layers and Figure A-6 shows the assembly drawings of the dsPIC33CH512MP506 DP PIM.
  • Page 20 Digital Power PIM User’s Guide FIGURE A-4: dsPIC33CH512MP506 DIGITAL POWER PIM MID1 AND MID2 INNER COPPER (BOTTOM VIEW) Mid1 Inner Copper Mid2 Inner Copper  2019 Microchip Technology Inc. DS50002853A-page 20...
  • Page 21 Board Layout and Schematics FIGURE A-5: dsPIC33CH512MP506 DIGITAL POWER PIM BOTTOM COPPER AND BOTTOM SILKSCREEN (BOTTOM VIEW) Bottom Copper Bottom Silkscreen  2019 Microchip Technology Inc. DS50002853A-page 21...
  • Page 22 Digital Power PIM User’s Guide FIGURE A-6: dsPIC33CH512MP506 DIGITAL POWER PIM TOP AND BOTTOM ASSEMBLY Top Assembly 30 29 28 26 25 24 22 21 20 18 17 Bottom Assembly  2019 Microchip Technology Inc. DS50002853A-page 22...

  • Page 23: Appendix B. Bill Of Materials (Bom)

    DIGITAL POWER PIM USER’S GUIDE Appendix B. Bill of Materials (BOM) This appendix contains the Bill of Materials (BOM) for the dsPIC33CH512MP506 Digital Power PIM. • Bill of Materials BILL OF MATERIALS Table B-1 shows the Bill of Materials for the dsPIC33CH512MP506.
  • Page 24 Digital Power PIM User’s Guide TABLE B-1: dsPIC33CH512MP506 DIGITAL POWER PIM BILL OF MATERIALS (BOM) (CONTINUED) Designator Description Manufacturer Manufacturer Part Number Common-mode Choke, 90R, Wurth Elektronik 744230900 100 MHz, 0.145R, 550 mA, SMD, 0603 ® Diode LED Green, 2V, 30 mA, Lite-On , Inc.
  • Page 25 Bill of Materials (BOM) TABLE B-1: dsPIC33CH512MP506 DIGITAL POWER PIM BILL OF MATERIALS (BOM) (CONTINUED) Designator Description Manufacturer Manufacturer Part Number TP4, TP5 Misc. Test Point, PC, Mini, Keystone Electronics 5004 0.040", D, Yellow Corp. Microchip Interface, USB, Microchip MCP2221A-I/ML C/UART, MCP2221A-I/ML, Technology Inc.
  • Page 26 Digital Power PIM User’s Guide NOTES:  2019 Microchip Technology Inc. DS50002853A-page 26...

  • Page 27: Appendix C. Characterization Data

    To allow a more accurate analysis of the tracking error, with regards to the transient frequency, we need to look at the total gain characteristic over frequency.  2019 Microchip Technology Inc. DS50002853A-page 27...
  • Page 28 Digital Power PIM User’s Guide The transfer function of a first-order RC low-pass filter is defined by Equation C-2 through Equation C-4. EQUATION C-2: H s   --------------- ----- -  EQUATION C-3:  2f ---------------------- Filt Filt EQUATION C-4: H s ...

  • Page 29: Example

    When this phase delay is not properly considered, the ADC trigger may be displaced from the desired average point of the oversampled signal, resulting in a significant measurement error. FIGURE C-2: UNFILTERED AND FILTERED TRIANGULAR WAVEFORMS  2019 Microchip Technology Inc. DS50002853A-page 29...
  • Page 30 Digital Power PIM User’s Guide Depending on the application, in order to obtain the average value with the required accuracy, a time delay in the sampling trigger of the ADC might need to be introduced. In our specific case, in order to take the sample with the best accuracy, the trigger...
  • Page 31 C-6). EQUATION C-7: t   V t   –  t    ---------------------------------------- t   EQUATION C-8: t –    t    100 e  2019 Microchip Technology Inc. DS50002853A-page 31...
  • Page 32 Digital Power PIM User’s Guide Figure C-5 depicts the remaining percentage error with respect to the sampling time. FIGURE C-5: NORMALIZED OUTPUT ERROR On the other hand, if a maximum tolerable percentage error,  , is defined in advance, the earliest time the sample should be taken can be calculated by using...
  • Page 33 = Leakage Current at the Pin LEAKAGE due to Various Junctions Note 1: The C value depends on the device package and is not tested. The effect of 5 k. the C is negligible if R  2019 Microchip Technology Inc. DS50002853A-page 33...

  • Page 34: Worldwide Sales And Service

    New York, NY Tel: 46-31-704-60-40 Tel: 631-435-6000 Sweden - Stockholm San Jose, CA Tel: 46-8-5090-4654 Tel: 408-735-9110 UK - Wokingham Tel: 408-436-4270 Tel: 44-118-921-5800 Canada - Toronto Fax: 44-118-921-5820 Tel: 905-695-1980 Fax: 905-695-2078  2019 Microchip Technology Inc. DS50002853A-page 34 08/15/18...
