Product Change Notification /
Date:
09-Mar-2021
Product Category:
Bluetooth Module
PCN Type:
Document Change
Notification Subject:
Data Sheet - BM78 Bluetooth Dual-Mode Data Sheet
Affected CPNs:
SYST-08ESNT900_Affected_CPN_03092021.pdf
SYST-08ESNT900_Affected_CPN_03092021.csv
Notification Text:
SYST-08ESNT900
Microchip has released a new Product Documents for the BM78 Bluetooth Dual-Mode Data Sheet of devices. If you are using one of
these devices please read the document located at
Notification Status: Final
Description of Change:
1. Updated Table 1-1.
2. Updated A.2.1 "Labeling and User Information Requirements" and A.3 "Europe".
3. Added A.4.1 "Labeling and User Information Requirements" and A.2.3 "Approved Antennas".
4. Updated with the new terminologies. For more details, see the following note.
Note: Microchip is aware that some terminologies used in the technical documents and existing software codes
of this product are outdated and unsuitable. This document may use these new terminologies, which may or may
not reflect on the source codes, software GUIs and the documents referenced within this document. The
following table shows the relevant terminology changes made in this document.
Table D-1: TERMINOLOG RELATES CHANGES
SYST-08ESNT900
BM78 Bluetooth Dual-Mode Data Sheet
.
Page 1 of 2
