- Page 1 Jet fans IV Smart AC, IV Smart EC, IV Smart EC CO Installation and Operating Instructions Document in original language | · 003...
- Page 2 © Copyright Systemair AB All rights reserved E&OE Systemair AB reserves the rights to alter their products without notice. This also applies to products already ordered, as long as it does not affect the previously agreed specifications. | 003...
-
Page 3: Table Of Contents
Contents General information .........1 Connection ...........7 8.3.1 Wiring diagram IV Smart Notice symbols ........1 AC ..........8 1.1.1 Instruction symbols.....1 8.3.2 Wiring diagram IV Smart Important safety information ......1 EC ...........9 Personnel ..........1 8.3.3 Wiring IV Smart EC-CO ....10 Personal protective equipment....2 Protective grounding wire ...... - Page 4 Contents 15 Commissioning Report........17 16 EU Declaration of conformity......18 | 003...
-
Page 5: General Information
General information | General information Notice symbols Danger Caution Hazard with a low risk Direct hazard Failure to comply with this warning may lead to Failure to comply with this warning will lead moderate injuries. directly to death or to serious injury. Important Warning Hazard with risk of damage to objects... -
Page 6: Personal Protective Equipment
Further prerequisites are a completed maintenance plan with no gaps and a commissioning re- port. Systemair will require these in the case of a warranty claim. The commissioning report is a component of this document. The maintenance plan must be created by the operator, see section 11.4 Maintenance, page 15. -
Page 7: Transport
Description IV Smart | Warning When opening the transport packaging, there is a risk of damage from sharp edges, nails, staples, splinters etc. ♦ Unpack the fan carefully. ♦ Check the fan for obvious transport damage. ♦ Only remove the packaging shortly before assembly. ♦... -
Page 8: Information On The Effects Of Co On Humans
| Description IV Smart 5.3.2 Information on the effects of CO on humans Warning This CO control unit is designed to protect people from the acute effects of carbon monoxide. It cannot prevent the chronic effects of carbon monoxide exposure. The CO control unit can not fully protect people at special risk, such as those with particular medical conditions. -
Page 9: Technical Data Of The Fan
Description IV Smart | Technical data of the fan • IV Smart AC: Temperature range [°C] of transported air = -25 to 55 • IV Smart EC: Temperature range [°C] of transported air = -25 to 55 • IV Smart EC CO: Temperature range [°C] of transported air = -20 to 40 •... -
Page 10: Name Plate And Type Key
| Name plate and type key Name plate and type key IV Smart EC 230 V~ 2,6 A 50 Hz 0,35 kW IP54 2510 min ¹ 17kg INS.CL.B Serial.no: 84543/1002773290-001/20170131 Made in GERMANY Type designation Insulation class Voltage/current/frequency Article number/production number/manufacturing date Input power... -
Page 11: Installation On The Ceiling
Electrical connection | Installation on the ceiling Installation IV Smart Electrical connection Safety information / Preconditions Warning: Danger from electrical voltage! ♦ Observe the 5 rules of electrical safety, see 2.3 5 rules of electrical safety, page 2. ♦ Prevent the ingress of water into the connection box. ♦... -
Page 12: Wiring Diagram Iv Smart Ac
| Electrical connection ♦ Use all of the locking screws. ♦ Insert the screws by hand to avoid damaging the thread. ♦ Tighten all glands well in order to guarantee protection class IP. ♦ Screw the lid of the terminal box/inspection switch evenly tight. ♦... -
Page 13: Wiring Diagram Iv Smart Ec
Electrical connection | 8.3.2 Wiring diagram IV Smart EC The connection cables of the two motors of the IV Smart are carried out in the terminal boxes. Terminal assignment terminal boxes (Client side) schwarz / black / noir blau / blue / bleu grün/gelb / green/yellow vert/jaune Terminal box —... -
Page 14: Wiring Iv Smart Ec-Co
| Electrical connection 8.3.3 Wiring IV Smart EC-CO The wiring diagram of the IV Smart EC-CO fan is not included in this document, but within this delivery. Table 5 Electrical connections Name Occupancy Designation Description 1. L Supply connection to the control unit 2. -
Page 15: Protective Grounding Wire
Commissioning | raised CO concentrations in the air. The following table provides information about the control unit's speed specifica- tions to the fans. Table 6 Fan speed specification Comment CO concentration Speed specification values CO < 15 ppm Switch-off hysteresis 10 Fan standstill CO = 15 ppm Speed depending on set value... -
Page 16: Tests
| Commissioning Tests ♦ Before switching the fan on, check for externally visible damage and ensure that the protective equipment functions properly. AC motor EC motor When the mains are switched on, the motor starts an 1. Switch the fan on. initialization (a few seconds). -
Page 17: Operation
Problem Possible causes Remedy Fan does not run Impeller imbalance Rebalancing by a specialist company if possible, smoothly otherwise contact Systemair. Soiling on the impeller Clean carefully, rebalance Contact Systemair Material decomposition on the impeller due to aggressive material conveyed. -
Page 18: Alarm And Fault Handling Carbon Monoxide Control Unit
Check if the correct fan is used for your application. Note: For all other damage/defects, please contact Systemair. Defective safety-relevant fans (for Ex and smoke extraction applications) must be replaced completely. 11.3 Alarm and fault handling Carbon monoxide control unit The control unit continuously monitors the sensor's function, as well as the function of the fans. -
Page 19: Maintenance
1-2 and call the emergency gas services (please check you have their number now) and if necessary notify the relevant gas fitter. - Fan failure Contact Systemair Fault - Sensor fault 11.4 Maintenance Warranty claims can only be made if maintenance work is carried out correctly and written evidence thereof is provided. -
Page 20: Spare Parts
Check the flexible connectors for damage. See normal operating conditions Note: For all other damage/defects, please contact Systemair. Defective safety-relevant fans (for Ex and smoke extraction applications) must be replaced completely. 11.5 Spare parts ♦ Use original spare parts from Systemair only. - Page 21 Commissioning Report | Commissioning Report Warranty claims can only be made if commissioning work is carried out correctly and written evidence thereof is provided. Description: Article no.: Manufacturing order no.: Installer Company: Contact person: Company address: Tel. no.: Email: Operator (Place of installation) Company: Contact person: Company address:...
- Page 22 Grille measurement acc. to VDI 2044 □ □ Commissioning of the fan successful? Date, installer's signature Date, operator's signature EU Declaration of conformity The manufacturer: Systemair GmbH Seehöfer Straße 45 DE-97944 Boxberg Germany +49 (7930) 9272 - 553 Product designation: Jet fans Type designation: AJR;...
- Page 23 | 003...
- Page 24 Systemair GmbH Seehöfer Str. 45 97944 Boxberg Germany Tel.: +49 (0)7930/9272-0 Fax: +49 (0)7930/9273-92 info@systemair.de www.systemair.de...
