FLECK
4600-MECH
INSTALLER
MANUAL
WATER PURIFICATION

Advertisement

Table of Contents
loading

Related Manuals for Pentair Fleck 4600-MECH

Summary of Contents for Pentair Fleck 4600-MECH

  • Page 1 FLECK 4600-MECH INSTALLER MANUAL WATER PURIFICATION...

  • Page 2: Table Of Contents

    Installer Manual Fleck 4600 - MECH - Table of contents Table of contents Generalities ......... . 7 1.1.
  • Page 3 Installer Manual Fleck 4600 - MECH - Table of contents System sizing ........24 4.1.
  • Page 4 Installer Manual Fleck 4600 - MECH - Table of contents Programming ........45 6.1.
  • Page 5 Installer Manual Fleck 4600 - MECH - Table of contents Maintenance ......... 57 9.1.
  • Page 6 Installer Manual Fleck 4600 - MECH - Table of contents PAGE INTENTIONALLY LEFT BLANK 6 / 88 Ref. MKT-IM-027 / B - 01.06.2018...

  • Page 7: Generalities

    First edition. Address change, Bleam information and valve on 01.06.2018 BRY/FIM tank assembly. 1.3. Manufacturer identifier, product Manufacturer: Pentair International LLC Avenue de Sevelin 18 1004 Lausanne Switzerland Product: Fleck 4600 - MECH 1.4. Intended use The device is intended to be used for domestic applications only and it is purpose-built for water treatment.

  • Page 8: Abbreviations Used

    Installer Manual Fleck 4600 - MECH - Generalities 1.5. Abbreviations used Assy............Assembly BLFC ............Brine Line Flow Controller BV ............Brine Valve CW............Cold Water DF............Down Flow Distr ............Distribution DLFC ............Drain Line Flow Controller FR............Fast Regeneration HW............

  • Page 9: Available Certificates

    Pentair Quality System EMEA products benefit, under specific conditions, from a manufacturer warranty that may be invoked by Pentair’s direct customers. Users should contact the vendor of this product for applicable conditions and in case of a potential warranty claim.

  • Page 10: Scan & Service Application

    Installer Manual Fleck 4600 - MECH - Generalities 1.10. Scan & Service application Scan & Service mobile application is the ideal support for the maintenance person in his daily business. A simple scan of an identification (ID) label (1) present on the valve with a smartphone gives an instantaneously access to all updated information related to the product, such as: •...

  • Page 11: Safety

    Installer Manual Fleck 4600 - MECH - Safety Safety 2.1. Safety pictograms definition Caution Warning Warns of a risk of minor injury or major Warns against serious personal injury material damage to the device or and damage to health. environment. Danger...

  • Page 12: Hazards

    Installer Manual Fleck 4600 - MECH - Safety 2.3. Hazards All the safety and protection instructions contained in this document must be observed in order to avoid temporary or permanent injury, damage to property or environmental pollution. At the same time, any other legal regulations, accident prevention and environmental protection measures, as well as any recognized technical regulations relating to appropriate and risk-free methods of working which apply in the country and place of use of the device must be adhered to.

  • Page 13: Hygiene Measures

    Installer Manual Fleck 4600 - MECH - Safety Assembly • Assemble only with components which are in accordance with drinking water standards; • after installation and before use, perform one or more manual regenerations in order to clean the media bed. During such operations, do not use the water for human consumption. Perform a disinfection of the system in the case of installations for treatment of drinking water for human use.

  • Page 14: Description

    Installer Manual Fleck 4600 - MECH - Description Description 3.1. Technical specifications Design specifications/ratings Valve body ..........Brass Rubber components ....... EP or EPDM Weight (valve with controller) ....2.5 kg Recommended operating pressure ..1.4 - 8.6 bar Maximum inlet pressure ......8.6 bar Hydrostatic test pressure.......

  • Page 15: Performance Flow Rate Characteristics

    Installer Manual Fleck 4600 - MECH - Description Environmental conditions • Indoor use only; • temperature from 5°C to 40°C; • maximum relative humidity 80% for temperatures up to 31°C decreasing linearly to 50% relative humidity at 40°C; • mains supply voltage fluctuations up to ±10% of the nominal voltage. 3.1.1.

  • Page 16: Outline Drawing

    Installer Manual Fleck 4600 - MECH - Description 3.2. Outline drawing 16 / 88 Ref. MKT-IM-027 / B - 01.06.2018...

  • Page 17: Description And Components Location

    Installer Manual Fleck 4600 - MECH - Description 3.3. Description and components location Green light Red light 24 hour wheel Brine line Injector block Program wheel *Meter Drain line Mixing device Outlet Inlet Brine cam Motor Brine valve Piston *Not included in case of time clock Ref.

  • Page 18: System Regeneration Cycle

    Installer Manual Fleck 4600 - MECH - Description 3.4. System regeneration cycle Note This valve allows to do down flow regenerations. 3.4.1. Down flow regeneration cycle (5-cycles operation) Service — normal use Untreated water is directed down through the resin bed and up through the riser tube. The hardness ions attach themselves to the resin and are removed from the raw water being exchanged on the resin beads against sodium ions.
  • Page 19 Installer Manual Fleck 4600 - MECH - Description Note For illustration purpose only. Always verify inlet and outlet marking on the valve. SERVICE NORMAL USE BACKWASH Outlet Inlet Outlet Inlet Drain Valve Valve BRINE DRAW & SLOW RINSE SECOND BACKWASH (Double backwash units only) Outlet Inlet...

  • Page 20: Filter Cycle (3-Cycles Operation)

    Installer Manual Fleck 4600 - MECH - Description 3.4.2. Filter cycle (3-cycles operation) Service — normal use Untreated water is directed down through the media and up through the riser tube. The impurities are retained by the media. The water is filtered as it passes through the media. Backwash —...

  • Page 21: Configurations For Volumetric And Time Clock Softeners

    Installer Manual Fleck 4600 - MECH - Description 3.5. Configurations for volumetric and time clock softeners To configure the valve as volumetric or time clock softener, the 24 hour gear, the skipper or program wheel and the meter must be set as shown below. 3.5.1.

  • Page 22: Time Clock

    Installer Manual Fleck 4600 - MECH - Description 3.5.2. Time clock Skipper wheel assy 7 days PN 14860 Skipper wheel assy 12 days PN 24100 24 hour gear PN 13009-21SP 22 / 88 Ref. MKT-IM-027 / B - 01.06.2018...

  • Page 23: Options Available On The Valve

    Installer Manual Fleck 4600 - MECH - Description 3.6. Options available on the valve Mixing device The valve can be equipped with a mixing device (1) whose function is to regulate the hardness of the water at the outlet. The mixing can be set from 0% to 50% of hard water (i.e. 0 turn = 0% of hard water with 100% of treated water and 1-½...

  • Page 24: System Sizing

    Installer Manual Fleck 4600 - MECH - System sizing System sizing 4.1. Recommendations 4.1.1. Injector/DLFC/BLFC-Valve configuration Resin Diameter Injector DLFC BLFC Valve volume type [in] Color Color [gpm] DF [gpm] UF [gpm] 5 - 8 0.125 9 - 14 15 - 21 4600/ 0.25 1600...
  • Page 25 Installer Manual Fleck 4600 - MECH - System sizing The below sizing method can be applied for both residential and industrial softeners. The sizing of a softener must be based upon certain parameters: • inlet water hardness; • peak flow rate and nominal flow rate; •...

  • Page 26: Determining The Required Volume Of Resin

    Installer Manual Fleck 4600 - MECH - System sizing Piping size (internal diameter) Max. flow rate [in] [mm] /h at 3 m/s] 1.25 8.69 13.57 21.20 34.2 49.2 4.2.2. Determining the required volume of resin When sizing a softener, make sure that the volume of resin in the tank (bed volume) will be sufficient so that even when the peak flow rate is reached, the velocity is still between the above values depending on the hardness.

  • Page 27: Resin Exchange Capacity And Capacity Of The Unit

    Installer Manual Fleck 4600 - MECH - System sizing 4.2.3. Resin exchange capacity and capacity of the unit The resin exchange capacity and capacity of the unit are two different things that should not be confused. The resin exchange capacity is the amount of Ca and Mg that can be retained by 1 litre of resin, which will depend on the resin type and salt dosage, whereas the capacity of the unit is the...
  • Page 28 Installer Manual Fleck 4600 - MECH - System sizing Salt amount Corresponding resin exchange °f.m °dH.m [g/L capacity in [g/L ] as CaCO [per L [per L resin resin resin resin 58.5 5.85 3.27 62.7 6.27 66.9 6.69 3.74 3.97 75.3 7.53 4.21...

  • Page 29: Valve Configuration

    Installer Manual Fleck 4600 - MECH - System sizing 4.2.4. Valve configuration Knowing the volume of resin, tank size and specifications of the resin, it is possible to determine the required valve configuration. The resin specification will give the backwash velocity, as well as the brine draw and slow rinse velocity that must be respected in order to ensure a proper regeneration of the unit.

  • Page 30: Cycle Time Calculation

    Installer Manual Fleck 4600 - MECH - System sizing 4.2.5. Cycle time calculation Note The mechanical controller uses fixed times. 4.3. Salt amount definition The salt setting is done through the controller programming. 4.4. Injector flow rates The following graphics represent the injectors flow rate as a function of the inlet pressure for the different injector sizes.

  • Page 31: 1600 Injectors

    Installer Manual Fleck 4600 - MECH - System sizing 4.4.1. 1600 Injectors INJECTOR 0 Total Draw Rinse Rinse Draw Inlet pressure [bar] INJECTOR 1 Total Rinse Draw Inlet pressure [bar] INJECTOR 2 Total Rinse Draw Inlet pressure [bar] Ref. MKT-IM-027 / B - 01.06.2018 31 / 88...

  • Page 32: 1650 Injectors

    Installer Manual Fleck 4600 - MECH - System sizing 4.4.2. 1650 Injectors INJECTOR 0 Total Rinse Draw Inlet pressure [bar] INJECTOR 1 Total Rinse Draw Inlet pressure [bar] INJECTOR 2 Total Rinse Draw Inlet pressure [bar] 32 / 88 Ref. MKT-IM-027 / B - 01.06.2018...

  • Page 33: Installation

    Installer Manual Fleck 4600 - MECH - Installation Installation Mandatory It is strictly forbidden for not qualified personal, to accede to system’s internal parts to perform any kind of technical action. Be sure to disconnect the electrical power, close the water inlet and depressurize the system before opening the front cover to access internal parts.

  • Page 34: Water

    Installer Manual Fleck 4600 - MECH - Installation • when installing the water connection (bypass or manifold) first connect to the plumbing system. Allow heated parts to cool and cemented parts to set before installing any plastic parts. Do not get primer or solvent on O-rings, nuts, or the valve.

  • Page 35: Integration Constraints

    Installer Manual Fleck 4600 - MECH - Installation • the riser tube should be cut flush with the top of the tank. Slightly bevel the ridge in order to avoid deterioration of the seal whilst fitting the valve; • the drain line must be a minimum of 12.7 mm (½") in diameter. Use 19 mm (¾") pipe if the backwash flow rate is greater than 26.5 lpm (7 gpm) or the pipe length is greater than 6 m ...

  • Page 36: Top-Mounted Valve Installation

    Installer Manual Fleck 4600 - MECH - Installation 5.5.1. Top-mounted valve installation When pressurized, any composite tank will expand both vertically and circumferential. In order to compensate the vertical expansion, the piping connections to the valve must be flexible enough to avoid overstress on the valve and tank.
  • Page 37 • in any case, any failure caused by improper installation and/or piping connections may void the warranty of Pentair products; • in the same way, using lubricant* on the valve thread is not allowed and will void the warranty for the valve and tank.

  • Page 38: Block Diagram And Configuration Example

    Installer Manual Fleck 4600 - MECH - Installation 5.6. Block diagram and configuration example Block diagram Pressure gauge Main inlet User’s line Check valve to prevent water harm Filter cartridge By-pass Pressure regulator Meter Suggested options Mixing device Can be integrated in the Drain line valve Brine line...

  • Page 39: Regeneration Types

    Installer Manual Fleck 4600 - MECH - Installation 5.7. Regeneration types Volumetric The controller monitors the volume of water used. Once it calculates that system capacity is reached, a regeneration cycle will be initiated immediately or at a pre-set time. •...

  • Page 40: Electrical Connections

    Installer Manual Fleck 4600 - MECH - Installation 5.8. Electrical connections With lights N.O. Green lamp (service) Microswitch N.C. Red lamp (regeneration) Valve motor 220 V-50 Hz Without lights Valve motor 220 V-50 Hz 40 / 88 Ref. MKT-IM-027 / B - 01.06.2018...

  • Page 41: By-Passing

    Installer Manual Fleck 4600 - MECH - Installation 5.9. By-passing A bypass valve system should be installed on all water conditioning systems. Bypass valves isolate the softener from the water system and allow unconditioned water to be used. Service or routine maintenance procedures may also require that the system is bypassed.

  • Page 42: Drain Line Connection

    Installer Manual Fleck 4600 - MECH - Installation 5.10. Drain line connection Note Standard commercial practices are expressed here. Local codes may require changes to the following suggestions. Check with local authorities before installing a system. Caution The drain line plastic elbow must always be hand-tighten without using the elbow as a lever. Caution...
  • Page 43 Installer Manual Fleck 4600 - MECH - Installation  Note Waste connections or the drain outlet shall be designed and constructed to provide connection to the sanitary waste system through an air-gap of 2 pipe diameters or 50.8 mm (2"), whichever is larger. Caution...

  • Page 44: Overflow Line Connection

    Installer Manual Fleck 4600 - MECH - Installation 5.11. Overflow line connection In the event of a malfunction, power failure, etc, the brine tank overflow fitting will direct “overflow” to the drain instead of spilling on the floor. This fitting should be on the side of the cabinet or brine tank.

  • Page 45: Programming

    Installer Manual Fleck 4600 - MECH - Programming Programming 6.1. Time of day Operation Press the clutch (1). Turn the hour wheel (2) to display the correct hour in the window (3). Ref. MKT-IM-027 / B - 01.06.2018 45 / 88...

  • Page 46: Volumetric

    Installer Manual Fleck 4600 - MECH - Programming 6.2. Volumetric 1. 24 hour wheel 2. Available capacity → Shows the system remaining capacity. 3. Program wheel → Defines the system capacity in m 4. Time of day → Shows the current time. 5.

  • Page 47: Set The System Capacity

    Installer Manual Fleck 4600 - MECH - Programming 6.2.2. Set the system capacity Operation Lift the transparent disc (1) and display the capacity facing the white dot (2). Note Example for the following drawing, the capacity set is 5.8 m between two regenerations.

  • Page 48: Time Clock

    Installer Manual Fleck 4600 - MECH - Programming 6.3. Time clock 1. 24 hour wheel 2. Program wheel → Defines the number of days between two regenerations. 3. Time of day → Shows the current time. 4. Service position → Service; →...

  • Page 49: Set The Number Of Days Between Two Regenerations

    Installer Manual Fleck 4600 - MECH - Programming 6.3.2. Set the number of days between two regenerations Operation Push the pins (1) out to set up. Note There are two time clock wheels: • 7 days: based on the week, number 1 will refer to Monday, number 7 to Sunday; •...

  • Page 50: Salt Volume Per Regeneration

    Installer Manual Fleck 4600 - MECH - Programming 6.4. Salt volume per regeneration 6.4.1. Salt volume definition Set the weight of salt to be used during regeneration using the following table and formula. Exchange capacity Salt weight Salt weight [g/L [°tH/m [g/°tH/m resin...

  • Page 51: Set The Salt Volume Per Regeneration

    Installer Manual Fleck 4600 - MECH - Programming 6.4.2. Set the salt volume per regeneration Operation Calculate the weight of salt needed per regeneration, see 6.4.1. Salt volume definition, page 50. Remove the screws (2) and the cover (1). Loosen (5). Adjust the segment of the brine cam (4) to the value calculated at point A on the sticker (3).

  • Page 52: Commissioning

    Installer Manual Fleck 4600 - MECH - Commissioning Commissioning Note This chapter is available for standard regeneration types. Contact your supplier if the actual regeneration is not standard and if you need assistance. 7.1. Water filling, draining and waterproofness inspection 7.1.1.

  • Page 53: Sanitization

    Installer Manual Fleck 4600 - MECH - Commissioning 7.2. Sanitization 7.2.1. Disinfection of water softeners The materials of construction of the modern water softener will not support bacterial growth, nor will these materials contaminate a water supply. In addition, during normal use, a softener may become polluted with organic matter, or in some cases with bacteria from the water supply.

  • Page 54: Electro Chlorination

    Installer Manual Fleck 4600 - MECH - Commissioning Calcium hypochlorite Calcium hypochlorite, 70% available chlorine, is available in several forms including tablets and granules. These solid materials may be used directly without dissolving before use. Do not let the disinfectant stand for more than 3 hours in the brine tank before the regeneration start. Dosage Measure two grains ~ 0.11 mL for 1 L.

  • Page 55: Operation

    Installer Manual Fleck 4600 - MECH - Operation Operation 8.1. Display during operation 8.1.1. During service Example: • valve in service: 8.1.2. During regeneration During a regeneration the display shows the current cycle step. Examples: • backwash: • brine draw & slow rinse: •...

  • Page 56: Recommendations

    Installer Manual Fleck 4600 - MECH - Operation 8.2. Recommendations • Use only regeneration salts designed for water softening upon regulation EN973; • for optimal system operation, the use of clean salt and impurities free is recommended (for example salt pellets); •...

  • Page 57: Maintenance

    Cleaning and maintenance shall take place at regular intervals in order to guarantee the proper functioning of the complete system, and be documented in the Maintenance chapter in the User Guide document. Mandatory The maintenance must be done by a professional certified by Pentair, otherwise the warranty will void. 9.1. Recommendations 9.1.1.

  • Page 58: Piston And/Or Brine Valve Replacement

    Installer Manual Fleck 4600 - MECH - Maintenance 9.2.2. Piston and/or brine valve replacement Operation Disconnect the meter cable (1), if available. Using a flat screwdriver, unscrew (5) and remove the cover (4). Using a flat screwdriver, unscrew (3) and remove the washer (2). Using a flat screwdriver or a 8 mm wrench, unscrew (7) and remove the power head (6) from the valve body (8).
  • Page 59 Installer Manual Fleck 4600 - MECH - Maintenance Ref. MKT-IM-027 / B - 01.06.2018 59 / 88...

  • Page 60: Seals And Spacers Cartridge Replacement

    Installer Manual Fleck 4600 - MECH - Maintenance 9.2.3. Seals and spacers cartridge replacement Caution Use only approved silicone grease or soapy water. Operation Remove the piston, see“Piston and/or brine valve replacement”, page 58. Using a small hook, remove a seal (3). Using the puller (1), remove a spacer (4).
  • Page 61 Installer Manual Fleck 4600 - MECH - Maintenance Ref. MKT-IM-027 / B - 01.06.2018 61 / 88...

  • Page 62: Controller Motor Replacement

    Installer Manual Fleck 4600 - MECH - Maintenance 9.2.4. Controller motor replacement Operation Using a flat screwdriver, unscrew (4) and remove the cover (3). Disconnect the motor (1). Using a Phillips screwdriver, unscrew (2) and remove the motor (1). Change the motor (1). Reverse above procedure steps to rebuild.

  • Page 63: Micro-Switch Replacement

    Installer Manual Fleck 4600 - MECH - Maintenance 9.2.6. Micro-switch replacement Operation Using a flat screwdriver, unscrew (2) and remove the cover (1). Using a Phillips screwdriver, unscrew (5) and extract the protection plate (4) and the micro-switch (3). Reverse above procedure steps to rebuild. Ref.

  • Page 64: Injector Cleaning

    Installer Manual Fleck 4600 - MECH - Maintenance 9.2.7. Injector cleaning Operation Using a flat screwdriver or a 8 mm wrench, remove the screws (6). Remove the cap injector (5). Remove the seal (4). Remove the filter (2). Using a flat screwdriver, remove the injector nozzle (3). Using a flat screwdriver, remove the injector throat (1).

  • Page 65: Blfc Cleaning

    Installer Manual Fleck 4600 - MECH - Maintenance 9.2.8. BLFC cleaning Operation Using a wrench, remove the BLFC holder (1). Using pliers, remove the cage (4) form the BLCF holder (1). Remove the BLFC washer (3) from the BLFC holder (1). Clean the BLFC washer (3) with a terry cloth.

  • Page 66: Valve On Tank Assembly

    Installer Manual Fleck 4600 - MECH - Maintenance 9.2.9. Valve on tank assembly Operation Lubricate the seals with approved silicone grease. Spin the valve (1) onto the tank (2), ensuring the threads are not cross-threaded. Rotate the valve (1) clockwise and freely, without using force until it comes to a stop. Note...

  • Page 67: Troubleshooting

    Installer Manual Fleck 4600 - MECH - Troubleshooting Troubleshooting Problem Cause Solution Interrupted power or switched off Restore the controller and connect to power source. constant power source. Check connections in the power head Disconnected/faulty meter cable. and on the meter cover. Change the cable.
  • Page 68 Installer Manual Fleck 4600 - MECH - Troubleshooting Problem Cause Solution Iron deposit in the valve inlet. Clean the inlet. Water pressure Iron deposit in the valve. Clean the valve and resin. drop Valve inlet obstructed by foreign Remove piston and clean the valve. elements.
  • Page 69 Installer Manual Fleck 4600 - MECH - Troubleshooting Problem Cause Solution Plugged drain line flow control. Clean drain line flow control. Plugged injector and/or filter. Clean or replace injector and/or filter. Raise inlet pressure to 1.8 bar Low water pressure. minimum.

  • Page 70: Spare Parts

    Installer Manual Fleck 4600 - MECH - Spare parts Spare parts 11.1. Power head parts list Assembly Min. order Item Part number Description quantity quantity 40422SP Wire nut 11545 Power cord European black 13547SP Strain relief 24121-0.12 Brine cam assy 4600/5600 DF 24121-0.25 Brine cam assy 4600/5600 DF 24121-0.50...
  • Page 71 Installer Manual Fleck 4600 - MECH - Spare parts Assembly Min. order Item Part number Description quantity quantity 26070-0.12 Brine cam assy 4600/5600 DF imm 26070-0.25 Brine cam assy 4600/5600 DF imm 26070-0.50 Brine cam assy 4600/5600 DF imm 26070-1 Brine cam assy 4600/5600 DF imm 26116-0.12 Brine cam assy 4600/5600 DF FR imm...

  • Page 72: Time Clock Power Head Specific Parts And Assembly List

    Installer Manual Fleck 4600 - MECH - Spare parts Assembly Min. order Item Part number Description quantity quantity 24378SP Green light 4600/5600 230V 26722SP Green light 4600/5600 24V 24377SP Red light 4600/5600 230V 26723SP Red light 4600/5600 24V 24119 Program wheel assy 8 m 24120 Program wheel assy 40 m 13802SP...
  • Page 73 Installer Manual Fleck 4600 - MECH - Spare parts Assembly Min. order Item Part number Description quantity quantity 13011 ARM cycle actuator 13296SP Screw 13014 Pointer regen 24100 Skipper wheel assy 12 days 14860 Skipper wheel assy 7 days BU26968 Front label TC picto with lights 27165 Front label 5600 TC picto without light...

  • Page 74: Valve Parts List

    Installer Manual Fleck 4600 - MECH - Spare parts 11.3. Valve parts list 74 / 88 Ref. MKT-IM-027 / B - 01.06.2018...
  • Page 75 Installer Manual Fleck 4600 - MECH - Spare parts Assembly Min. order Item Part number Description quantity quantity BU28518-01 VB assy 4600 filter BU28518-02 VB assy 4600 with mixing BU28518-03 VB assy 4600 LWU with mixing BU28518-04 VB assy 4600 FR with mixing BU28518-05 VB assy 4600 HW with mixing BU28518-06...

  • Page 76: Meters Parts List

    Installer Manual Fleck 4600 - MECH - Spare parts 11.4. Meters parts list 76 / 88 Ref. MKT-IM-027 / B - 01.06.2018...
  • Page 77 Installer Manual Fleck 4600 - MECH - Spare parts Assembly Min. order Item Part number Description quantity quantity 24107 Meter assy ¾” 8 m³ plastic 12473SP Screw hex washer 10-24x. 18-8SS BR14038 Cover meter assy plastic 13509SP Impeller meter except 2” & 3” 24102 Meter body assy ¾”...

  • Page 78: Safety Brine Valve Parts List

    Installer Manual Fleck 4600 - MECH - Spare parts 11.5. Safety brine valve parts list Assembly Min. order Item Part number Description quantity quantity 60014SP Safety brine assy, 2310 PWG19647 Elbow assy, SBV 11183-01SP O-ring 19625SP BV 1650 plastic nut assy PWG19649 Flow disperser PWG19652-01 Poppet assy, SBV, with o-ring...

  • Page 79: Safety Brine Valves List

    Installer Manual Fleck 4600 - MECH - Spare parts Assembly Min. order Item Part number Description quantity quantity 19804 Screw, sckt hd, set, 10-24 x 0.75" 60068-30SP New float assy 2310 10150SP Grommet pass rod 2300/2310/2350 18168 Air check 500 (0,915 m) 26773 Air check 500 (1,25 m) 23473...

  • Page 80: Bypass And Coupling Parts Lists

    Installer Manual Fleck 4600 - MECH - Spare parts 11.7. Bypass and coupling parts lists 11.7.1. Bypass stainless Steel 1" BSP 80 / 88 Ref. MKT-IM-027 / B - 01.06.2018...
  • Page 81 Installer Manual Fleck 4600 - MECH - Spare parts Assembly Min. order Item Part number Description quantity quantity BU28502 Bypass stainless steel 1" BSP 13386SP Screw hex hd mach 1/4-20 X 1 or slot hex 24419-10SP Bypass handle red 15727 Screw, hex washer head 10-24 x 0.5"...

  • Page 82: Bypass Stainless Steel 1" Bsp With Mixing

    Installer Manual Fleck 4600 - MECH - Spare parts 11.7.2. Bypass stainless Steel 1" BSP with mixing 82 / 88 Ref. MKT-IM-027 / B - 01.06.2018...
  • Page 83 Installer Manual Fleck 4600 - MECH - Spare parts Assembly Min. order Item Part number Description quantity quantity 24734-10 Bypass 1” BSP female brass with mixing BU28642 Screw TC, slotted, M6x30 24419-10SP Bypass handle red 11737SP Screw TH M5x12 21134 Bypass label BU11978 Cover bypass, top...

  • Page 84: Plastic Residential Bypass And Coupling Parts List

    Installer Manual Fleck 4600 - MECH - Spare parts 11.7.3. Plastic residential bypass and coupling parts list Assembly Min. order Item Part number Description quantity quantity BU26054 Plastic residential bypass 13314SP Screw adapt clip 13255SP Mounting clip 13305-01SP O-ring 2 - 4 18706-10 Yoke, 1", BSP, male, plastic 18706-12...

  • Page 85: Ce Compliance Components List

    Installer Manual Fleck 4600 - MECH - Spare parts 11.8. CE compliance components list Assembly Min. order Item Part number Description quantity quantity 18280SP Collector top 1”x 0.011 grey bayonet 13308SP Drain hose barb ½” Ref. MKT-IM-027 / B - 01.06.2018 85 / 88...

  • Page 86: Disposal

    This will help to reduce the impact on the environment, health, safety and help to promote recycling. Pentair does not collect used product for recycling. Contact your local recycling center for more information.
