Step 2: Assembly of front base and computer
1. Mount the front base (5) on the front frame (4) with two 3/8"
spring washers (94) and two 3/8" caps for nuts (103) (see fig. B1).
Tighten all screws.
2. Mount the computer (32) on the front frame (4) with two
pre-mounted 3/16" X 16L screws (87). Please pay attention
to that the computer (32) is correctly aligned (see fig. B2).
Then tighten the screws.
14
B 1
103
94
4
5
B 1
4
5
B 2
4
87
32
ROW X
B 2
103
94
32
