Taurus Ultra Trainer TF-UT-2 Assembly And Operating Instructions Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Assembly and Operating Instructions
max. 150 kg
~ 60 Min.
105.5 kg
L 166 | B 88 | H 178
TFUT.02.02
TF-
Ultra Trainer
TF
TF-UT-2

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ultra Trainer TF-UT-2 and is the answer not in the manual?

Questions and answers

Related Manuals for Taurus Ultra Trainer TF-UT-2

Summary of Contents for Taurus Ultra Trainer TF-UT-2

  • Page 1 Assembly and Operating Instructions max. 150 kg ~ 60 Min. 105.5 kg L 166 | B 88 | H 178 TFUT.02.02 Ultra Trainer TF-UT-2...
  • Page 2 Ultra Trainer...

  • Page 3: Table Of Contents

    Content GENERAL INFORMATION Technical Data Personal Safety Electrical Safety Set-Up Place ASSEMBLY General Instructions Scope of Delivery Assembly OPERATING INSTRUCTIONS Console Display Button Functions Switching on the Device Standby Mode Programmes 3.5.1 Quick Start Programme 3.5.2 Manual Programme (M) 3.5.3 Pre-Set Profile Programmes (P) 3.5.4 User-Defined Programmes (U) 3.5.5 Heart Rate Controlled Programmes (♥) 3.5.6 Watt Controlled Programme (W)
  • Page 4 ORDERING SPARE PARTS Serial Number and Model Name Parts List Exploded Drawing WARRANTY CONTACT Ultra Trainer...
  • Page 5 With Taurus® fitness equipment, the focus is on what sport is all about: maximum performance! Therefore, the equipment is developed in close consultation with athletes and sports scientists.
  • Page 6 ABOUT THIS MANUAL Please carefully read the entire manual before installation and first use. The manual will help you to quickly set up the system and explains how to safely use it. Make sure that all persons exercising with the equipment (especially children and persons with physical, sensory, mental or motor disabilities) are informed about this manual and its contents in advance.

  • Page 7: General Information

    GENERAL INFORMATION Technical Data LED - Display of: Training time in min. Speed in km/h Training distance in km Calories in kcal Heart rate (when using hand pulse sensors or chest strap) Watt RPM (Rotations per Minute) Resistance Level User memory: Programmes in total: Quick-Start programmes: Manual programmes:...

  • Page 8: Personal Safety

    Personal Safety DANGER ⚠ Before you start using the equipment, you should consult your physician that this type of exercise is suitable for you from a health perspective. Particularly affected are persons who: have a hereditary disposition to high blood pressure or heart disease, are over the age of 45, smoke, have high cholesterol values, are overweight and/or have not exercised regularly in the past year.

  • Page 9: Electrical Safety

    Electrical Safety DANGER ⚠ In order to reduce the risk of an electric shock, always unplug the equipment from the mains socket immediately after your workout, before assembly or dismantling, and before maintenance or cleaning. Do not pull on the cable. ⚠...

  • Page 10: Assembly

    ASSEMBLY General Instructions ⚠ DANGER Do not leave any tools, packaging materials such as foils or small parts lying around, as otherwise there is a danger of suffocation for children. Keep children away from the equipment during assembly. ⚠ WARNING Pay attention to the instructions attached to the equipment in order to reduce the risk of injuries.

  • Page 11: Scope Of Delivery

    Scope of Delivery The scope of delivery consist of the following parts. At the beginning, check whether all parts and tools belonging to the device are included in the scope of delivery and whether damage has occurred. In the event of complaints, the contractual partner must be contacted directly. CAUTION ⚠...
  • Page 12 Name Name Main frame Handlebar Base frame Console Left pedal connection leg Tablet holder Right pedal connection leg Tube cap (x2) Left upper swing arm Position stopper (x2) Right upper swing arm Ultra Trainer...

  • Page 13: Assembly

    Assembly Before assembly, take a close look at the individual assembly steps shown and carry out the assembly in the order given. NOTICE First loosely screw all parts together and check that they fit properly. Tighten the screws using the tool only when you are instructed to do so. Step1: Assemble the frame Place the main frame (1) on the base...
  • Page 14 Step 2: Mounting the pedal connection legs ࣑ ATTENTION Before mounting the pedal connection legs, apply some lubricant to the axles on the main frame. Mount the left pedal connection leg (3) to the axle of the main frame (1) with one flat washer (28), one spring washer (27) and one Allen bolt (26).
  • Page 15 Step 4: Mounting the upper swing arms Mount the left upper swing arm (7) to the main frame (1) with three spring washers (31) and three Allen bolts (30). Repeat the step for the other side. Tighten the bolts. Step 5: Mounting the handlebar Guide the hand pulse cable (15) through the opening on the main...
  • Page 16 Step 6: Mounting the console Connect hand pulse cables (15) with the hand pulse cables on the console (16). Conntect the communication cables (14 & 36) with the communication cables on the console (17 & 37). ࣑ ATTENTION Pay attention to not pinch the cable during the next step.
  • Page 17 Step 8: Alignment of the feet If the floor is uneven, you can stabilize the equipment by turning the two setting screws under the main frame. Lift the equipment on the desired side and rotate the setting screws under the main frame.

  • Page 18: Operating Instructions

    OPERATING INSTRUCTIONS NOTICE Familiarise yourself with all the functions and setting options of the device before starting training. Have the proper use of this product explained to you by a specialist. Console Display Display Description Display of rotations per minute Display range: 0–999 Display of training time in minutes TIME...

  • Page 19: Button Functions

    Display of the currently selected programme: Manual programme (M) Pre-set profile programmes (P) M/P/U/♥/W User-defined programmes (U) Heart Rate Controlled programmes (♥) Watt controlled programmes (W) Display of training distance in km DISTANCE Display range: 0.0–99.9 km Setting range: 0.0–99.0 km (in increments of 1 km) Display of calories in kcal CALORIES Display range: 0–999...

  • Page 20: Switching On The Device

    Switching on the Device As soon as the console is started, a beep sounds for one second and the display lights up (Figure 1). The display will then show the device settings (Figure 2). You can then select the user. NOTICE By default, U1 is displayed at the beginning (Figure 3).

  • Page 21: Standby Mode

    Standby Mode As soon as the console receives no signal for at least 4 minutes, it goes into standby mode. To exit standby mode, start moving the pedals or make an entry on the console. Programmes The following programmes are available: Quick Start programmes: Manual programme: Pre-set programmes:...

  • Page 22: Manual Programme (M)

    3.5.2 Manual Programme (M) The manual programme can be used based on one or more target values. Use the PROGRAM button or the +/- buttons to select the manual programme (M) and confirm with the MODE button (Figure 4). You can now set the values for time, distance, calories and/or pulse in this order.

  • Page 23: Pre-Set Profile Programmes (P)

    3.5.3 Pre-Set Profile Programmes (P) A total of 12 pre-set profile programmes are available. Use the PROGRAM button or the +/- buttons to select pre-set programmes (P) and confirm with the MODE button (Figure 5). To select one of the preset programmes (P1– P12), use the +/- buttons and confirm with the MODE button.
  • Page 24 Ultra Trainer...

  • Page 25: User-Defined Programmes (U)

    3.5.4 User-Defined Programmes (U) One user-defined programme with 16 segments can be stored per user. Select the user-defined programme (U) with the PROGRAM button or the +/- buttons and confirm with the MODE button (Figure 6). The first LED segment in the display flashes (Figure 7). To set the resistance levels (1–24) for the individual segments, use the +/- buttons and confirm each of the 16 segments with the MODE...

  • Page 26: Heart Rate Controlled Programmes

    3.5.5 Heart Rate Controlled Programmes ( ♥ ⚠ WARNING Your training equipment is not a medical device. The heart rate measurement of this equipment may be inaccurate. Various factors can affect the accuracy of the heart rate measurement. The heart rate measurement serves only as a training aid. Four heart rate programs are available.

  • Page 27: Watt Controlled Programme (W)

    3.5.6 Watt Controlled Programme (W) Use the PROGRAM button or the +/- buttons to select the watt controlled programme (W) and confirm with the MODE button (Figure 10). Set the desired target value with the +/- buttons and confirm with the MODE button. NOTICE The default value is 120 (Figure 11).

  • Page 28: Heart Rate Recovery Test (Recovery)

    Heart Rate Recovery Test (RECOVERY) Use the recovery function after a workout to measure your recovery heart rate. To start the recovery programme, press the RECOVERY button and hold the hand pulse sensors. The display will show a countdown counting down from 00:60 to 00:00 (Figure 12). NOTICE To exit the recovery function prematurely, press the RECOVERY button again.

  • Page 29: Body Fat Test (Body Fat)

    Body Fat Test (BODY FAT) To start the body fat test, press the BODY FAT button and place your hands on the hand pulse sensors. The display shows a loading screen for approx. 8 second (Figure 14 and 15). Figure 15 Figure 14 NOTICE If you do not properly hold the hand pulse sensors, the display will show error code E-1.

  • Page 30: Storage And Transport

    STORAGE AND TRANSPORT General Instructions ⚠ WARNING The storage location should be chosen so that improper use by third parties or children can be prevented. If your equipment does not have transportation wheels, the equipment must be disassembled before transportation. ࣑...

  • Page 31: Troubleshooting, Care And Maintenance

    TROUBLESHOOTING, CARE AND MAINTENANCE General Instructions ⚠ WARNING Do not make any improper changes to the equipment. CAUTION ⚠ Damaged or worn components may affect your safety and the life of the equipment. Therefore, immediately replace damaged or worn components. In such a case, contact the contract partner.

  • Page 32: Error Codes And Troubleshooting

    Eliminate sources of interference (e.g. Sources of interference in mobile phone, WLAN, lawn mower the room and vacuum cleaner robot, etc..) unsuitable chest strap Use a suitable chest strap (see RECOMMENDED ACCESSORIES). Wrong position of chest No pulse display strap Reposition chest...

  • Page 33: Maintenance And Inspection Calendar

    Maintenance and Inspection Calendar To avoid damage from body sweat, the equipment must be cleaned with a damp towel (no solvents!) after each training session. The following routine tasks must be performed at the specified intervals: Part Weekly Monthly Quarterly Display console Slide rails Lubrication of slide rails and moving parts...

  • Page 34: Recommended Accessories

    RECOMMENDED ACCESSORIES To make your training experience even more efficient and pleasant, we recommend that you add suiting accessories to your fitness equipment. This could be a floor mat, for example, which makes your fitness equipment stand more securely and also protects the floor from falling sweat, but it could also be additional handrails on some treadmills or silicone spray to keep moving parts in good shape.
  • Page 35 The serial number of your equipment is unique. It's located on a white sticker. The exact position of this sticker is shown in the following illustration. Enter the serial number in the appropriate field. Serial number: Brand / Category: Taurus / Crosstrainer Model Name: Ultra Trainer Article Number: TF-UT-2...
  • Page 36 Parts List Name Specification Qty. Main frame Basic frame Left pedal connection leg Right pedal connection leg Left pedal Right pedal Left upper swing arm Right upper swing arm Handlebar Console I-Pad holder Tube cap Φ55 Roll wheel position stopper Φ17×Φ8.5×47 Communication line A L-650mm...
  • Page 37 Flat washer Φ8.5×Φ20×t1.5 Philips C.K.S. full thread bolt M5×15 Philips C.K.S. self-tapping screw ST4×16 Communication line B L-650mm Communication line B of console Deep groove ball bearing 6004-ZZ Swing arm Allen C.K.S. full thread bolt M8×15 Spring washer Φ42 Self-aligning ball bearing 2203-2RS Lower swing arm Crank cover...
  • Page 38 Magnet sensor fixer Philips self-tapping screw ST4×12 Magnet control motor Flywheel weight stack Flywheel Flywheel Φ450×62 Allen cylinder head half thread bolt M10×45×20 Incline motor Hex self-locking nut Allen cylinder head full thread bolt M10×15 Powder case Φ32×Φ16×12. 7 Sliding rail Axle Φ16×145.5 Tube cap Φ38×17.5...
  • Page 39 Out cover decoration strip Philips C.K.S. self-tapping screw ST4×10 Mp3 wire L-400mm Brake line Sliding rail group Philips C.K.S. full thread bolt M4×10 Wheel cover-left Wheel cover-right Wheels Φ79×37.8 Tube sets Φ25×Φ21×6.5 Tube cap Φ32×t1.5 Power line with computer tail Allen C.K.S.
  • Page 40 Exploded Drawing 1 1 2 1 2 2 1 0 6 1 2 2 1 0 7 1 2 3 Ultra Trainer...
  • Page 41 1 0 2 1 0 0 1 0  1 0  1 0 3 1 0 0 1 0  1 2 1 1 0 5 1 0  1 1 6 1 0  1 1 5 1 0 3 1 0  1 0 1 1 0 8...
  • Page 42 WARRANTY Training equipment from Taurus® is subject to strict quality control. However, if a fitness equipment purchased from us does not work perfectly, we take it very seriously and ask you to contact our customer service as indicated. We are happy to help you by phone via our service hotline.
  • Page 43 Warranty Conditions For the warranty to be valid, the following steps must be taken: Please contact our customer service by email or phone. If the product under warranty has to be sent in for repair, the seller bears costs. After expiry of the warranty, the buyer bears the costs of transport and insurance.
  • Page 44 CONTACT TECHNICAL SUPPORT TECHNICAL SUPPORT & SERVICE TECHNICAL SUPPORT & SERVICE �� �� �� +49 4621 4210-900 80 90 16 50 +33 (0) 172 770033 +49 4621 4210-945 +49 4621 4210-933 �� +49 4621 4210-698 �� �� info@fitshop.dk service-france@fitshop.fr �� technik@sport-tiedje.de ��...
  • Page 45 LIVE FITNESS WEBSHOP AND SOCIAL MEDIA Sport-Tiedje is Europe’s largest specialist store www.sport-tiedje.co.uk for home fitness equipment with currently over www.sport-tiedje.de/blog 70 stores and one of the world’s most renowned online mail order companies for fitness equipment. Private customers order via the 25 www.facebook.com/SportTiedje web shops in the respective national language or have their desired equpiment assembled on...
  • Page 46 Notes Ultra Trainer...
  • Page 47 Notes...
  • Page 48 Ultra Trainer...
  • Page 49 Ultra Trainer...
