Installation - Bosch OMNEO OM-1 Manual

en | Installation
6
2

Installation

1.
2.
3.
4.
5.
6.
7.
8.
17-Jun-2015 | 03 | F01U308252
Turn off the power of the unit and pull the mains plug
Remove the cover plate (6 screws on the sides, 3 screws on
top, 4 screws on the rear)
Remove the blind on the rear panel (2 screws)
Install the OM-1 module (see picture); first, secure it with 2
screws on the rear panel Ⓐ, then with 2 screws on the bolt
Ⓑ, tighten the screws
Make the following cable connections: Left connector on
OM-1 module with CN28 on main board 80500 (65 mm flat
wire cable) Ⓒ. Right connector on OM-1 module with CN5
on DSP-Board 80496 (190 mm flat wire cable) Ⓓ.
Re-install the cover plate
Plug in the mains cord and turn the unit's power on
Configure OM-1 module parameter in IRIS-Net according to
application needs
OMNEO module
