MAX300 Series 3-Axis Flexure Stages
SMC connectors
Fig. 1.2 MAX302 NanoMax piezo-actuated stage without feedback
The piezo-actuated models deliver 20 microns of travel, each piezo channel has a
coaxial SMC connector (see Fig. 1.1 and Fig. 1.2). In addition, the MAX301 has a 7-
pin LEMO connector for each feedback channel (see Fig. 1.1). A corresponding
number of leads for connection to the Thorlabs piezoelectric controllers are also
supplied.The piezo-actuated models deliver 20 microns of travel, with a coaxial SMC
connector for each piezo channel.
The pin functions for the Lemo connectorare detailed below.
Page 2
6
5
4
Pin
1
2
3
4
5
6
7
Fig. 1.3 Feedback Lemo connector pin functions
1
7
2
3
Description
+15 V
Oscillator +
0 V
Sig Out -
Sig Out +
-15 V
Travel
10997-D02
