Radiator Assembly Group - ODB SKB700 Owner's Manual

4
6
5
ITEM# PART NO.
1 4045.9503
2 4045.2190B
3 4045.2190A
4 AT35158.A
5 R128443
6 G8M8X090
7 JDTH.1
ODB COMPANY

6.6 Radiator Assembly Group

John Deere after August 1996, Cateripillar 2005 and after
7
11
12
13
DESCRIPTION
Radiator
Front Fan Shroud
Rear Fan Shroud
Radiator Fan
Fan Spacer
Spacer Bolts, 4 required
Upper Radiator Hose
8
3
10
11
ITEM# PART NO.
8 10300
9 4045.9681
10 4045.2151G
11 2561.26012
12 4045.2151F
13 ZSB.500.750
800-446-9823
1
10
9
12
13
DESCRIPTION
Radiator Cap
Lower Radiator Hose
Radiator Shim
Radiator Grommet
Radiator Bolt Bracket
Shoulder Bolt
SKB700
