Cybernet IPC-R1ix User Manual page 43

CN5 Mini PCIe Connector Pin-Out
Pin Signal
No. Name
51 Reserved
49 Reserved
47 Reserved
45 Reserved
43 Status
41 +3.3Vaux
39 +3.3Vaux
37 GND
35 GND
15 GND
13 REFCLK+
11 REFCLK-
9 GND
Pin Signal
No. Name
52 +3.3Vaux
50 GND
48 +1.5V
46 Reserved
44 Reserved
42 Reserved
40 GND
38 USB_D+
36 USB_D-
Mechanical Key
16 Reserved
14 Reserved
12 Reserved
10 Reserved
Pin Signal
No. Name
33 PETp0
31 PETn0
29 GND
27 GND
25 PERp0
23 PERn0
21 GND
19 Reserved
17 Reserved
7 CLKREQ#
5 Reserved
3 Reserved
1 WAKE#
GETTING TO KNOW YOUR IPC-R1ix
Pin Signal
No. Name
34 GND
32 SMB_DATA
30 SMB_CLK
28 +1.5V
26 GND
24 +3.3Vaux
22 PERST#
20 reserved
18 GND
8 Reserved
6 1.5V
4 GND
2 3.3Vaux
