Stamina Precision Series Owner's Manual
  1. Manuals
  2. Brands
  3. Stamina Manuals
  4. Fitness Equipment
  5. Precision Series
  6. Owner's manual
Stamina Precision Series Owner's Manual

Stamina Precision Series Owner's Manual

Cadillac studio tower
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Product May Vary Slightly From Pictured.
CAUTION:
Weight on this product should not exceed 300 lbs.
This Product is Distributed Exclusively by
2040 N Alliance Ave, Springfield, MO 65803
www.staminaproducts.com
Customer Care
1 (800) 375-7520
Owner's
Manual
WARNING
!
Exercise can present a
h e a l t h r i s k . C o n s u l t a
physician before beginning
any exercise program with
this equipment. If you feel
faint or dizzy, immediately
d i s c o n t i n u e u s e o f t h i s
equipment. Serious bodily
i n j u r y c a n o c c u r i f t h i s
equipment is not assembled
and used correctly. Serious
bodily injury can also occur
if all instructions are not
followed. Keep others and
pets away from equipment
when in use. Always make
sure all bolts and nuts are
securely tightened prior to
each use. Follow all safety
instructions in this manual.
When calling for parts or
service, please specify
the following numbers :
Model#: 55-5604
S/N: _____________
STAMINA PRODUCTS
MADE IN CHINA
© 2019 Stamina Products, Inc.
2019, 06

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Precision Series and is the answer not in the manual?

Questions and answers

Related Manuals for Stamina Precision Series

Summary of Contents for Stamina Precision Series

  • Page 1 Weight on this product should not exceed 300 lbs. This Product is Distributed Exclusively by STAMINA PRODUCTS MADE IN CHINA 2040 N Alliance Ave, Springfield, MO 65803 Customer Care © 2019 Stamina Products, Inc. 1 (800) 375-7520 2019, 06 www.staminaproducts.com...

  • Page 3: Table Of Contents

    16. The AeroPilates® Precision Series Cadillac Studio Tower should be used by only one person at a time. 17. The AeroPilates® Precision Series Cadillac Studio Tower is for consumer use only. It is not for use in public or semipublic facilities.
  • Page 4 1 (800) 375-7520 customer.care@staminaproducts.com Hi! From all of us here at Stamina Products, thank you for your purchase. We know that you have big fitness goals in mind and we are here to help you along. Call us, email us, or send us a message on Facebook. Be sure to contact us if you have any questions on your new product.

  • Page 5: Before You Begin

    BEFORE YOU BEGIN Thank you for choosing the AeroPilates® Read this manual carefully before using the Precision Series Cadillac Studio Tower. We take AeroPilates® Precision Series Cadillac Studio great pride in this quality product and hope it will Tower. provide many hours of quality exercise to make you Providing you with a quality product is Stamina's feel better, look better, and enjoy life to its fullest.

  • Page 6: Equipment Warning, Caution & Notice Labels

    EQUIPMENT WARNING, CAUTION & NOTICE LABELS This chart is provided to help identify the warning, caution, and notice labels on the AeroPilates® Precision Series Cadillac Studio Tower. Please take a moment to familiarize yourself with all of the warning, caution, and notice labels.

  • Page 7: Hardware Identification Chart

    HARDWARE IDENTIFICATION CHART This chart is provided to help identify the hardware used in the assembly process. Place the washers or the ends of the bolts or screws on the circles to check for the correct diameter. Use the small scale to check the length of the bolts and screws.

  • Page 8: Assembly Instructions

    ASSEMBLY INSTRUCTIONS Place all parts from the box in a cleared area and position them on the floor in front of you. Remove all packing materials from your area and place them back into the box. Do not dispose of the packing materials until assembly is completed.
  • Page 9 ASSEMBLY INSTRUCTIONS STEP 2 Make the EYEHOOKS(21) point to the front. Insert the UPRIGHTS(9) onto the LOWER UPRIGHTS(7) and secure with BUTTON HEAD BOLTS(M6x1x15mm)(41) and ARC WASHERS(M6)(45). STEP 3 Make the EYEHOOKS(21) point to the front. Insert the TOP CROSS BAR(8) onto the UPRIGHTS(9) and secure with BUTTON HEAD BOLTS(M6x1x15mm)(41) and ARC WASHERS(M6)(45).
  • Page 10 ASSEMBLY INSTRUCTIONS STEP 4 NOTE: 1. There are four adjustment holes in each UPRIGHT(9) that allow you to attach the PUSH-THRU BAR(27) to four different heights. 2. Refer to the inset drawing. Push in the button on the “T” end of the LOCKING PIN(17) to release the Steel Ball on the other end of the pin.
  • Page 11 ASSEMBLY INSTRUCTIONS STEP 6 Attach the STANDS(11) to the FRONT CUSHION FRAME(1) and the REAR CUSHION FRAME(2) with BUTTON HEAD BOLTS(M6x1x20mm)(46). STEP 7 Insert the FRONT CUSHION FRAME(1) into the REAR CUSHION FRAME(2) and secure with BUTTON HEAD BOLTS(M8x1.25x10mm)(36) and WASHERS(M8)(44).
  • Page 12 ASSEMBLY INSTRUCTIONS STEP 8 Refer to illustration B. Put a WASHER(M10)(40) onto each of the BUTTON HEAD BOLT(M10x1.5x60mm) (38). Attach the REAR CUSHION FRAME(2) to the BASE FRAME(6) by inserting the BUTTON HEAD BOLTS(M10x1.5x60mm)(38) with WASHERS(M10)(40) through the two brackets on the BASE FRAME(6) and the REAR CUSHION FRAME(2).

  • Page 13: Operational Instructions

    OPERATIONAL INSTRUCTIONS TO USE THE ACCESSORIES: NOTE: Prior to adding the PUSH-THRU SPRING(19) to the PUSH-THRU BAR(27) make sure the SAFETY CHAIN(25) is at a length that allows enough clearance to get under the PUSH-THRU BAR(27). PUSH-THRU BAR When doing exercises that require the spring resistance to come from above the bar, attach the PUSH-THRU SPRING(19) to the hook on the upper side of the PUSH-THRU BAR(27) with the DOUBLE ENDED CLIP (23).
  • Page 14 OPERATIONAL INSTRUCTIONS SAFETY CHAIN The SAFETY CHAIN(25) must be used as follows: When using the PUSH-THRU BAR(27) with spring attached from below to do arm or leg exercises, the chain must be attached to the hook on the upper side of the bar on the same side as the spring and to an EYEHOOK(21).

  • Page 15: Storage

    STORAGE 1. To store the AeroPilates® Precision Series Cadillac Studio Tower, simply keep it in a clean dry place. 2. It is recommended that two people be available to move the AeroPilates® Precision Series Cadillac Studio Tower. Fold the unit as instructed in the below diagrams, then lift to move.

  • Page 16: Conditioning Guidelines

    CONDITIONING GUIDELINES How you begin your exercise program depends on your physical condition. If you have been inactive for several years or are severely overweight, start slowly and increase your workout time gradually. Increase your workout intensity gradually by monitoring your heart rate while you exercise. Remember to follow these essentials: Have your doctor review your training and diet programs.

  • Page 17: Warm-Up And Cool-Down

    WARM-UP and COOL-DOWN Warm-Up The purpose of warming up is to prepare your body for exercise and to minimize injuries. Warm up for two to five minutes before strength training or aerobic exercising. Perform activities that raise your heart rate and warm the working muscles. Activities may include brisk walking, jogging, jumping jacks, jump rope, and running in place.

  • Page 18: Product Parts Drawing

    PRODUCT PARTS DRAWING BACK FRONT...

  • Page 19: Parts List

    PARTS LIST PART# PART NAME Front Cushion Frame Rear Cushion Frame Cushion Extension Cushion Frame Extension Cushion Base Frame Lower Upright Top Cross Bar Upright Roll-Down Bar Stand Base Stand Round Plug (Ø38.1mm) Securing Strap Hand/Foot Strap Spring Sleeve Locking Pin Leg Spring (Ø2.3 x Ø29.2 x 610mm) Push-Thru Spring (Ø2.67 x Ø29 x 500mm) Arm Spring (Ø2.0 x Ø23 x 477mm)

  • Page 20: Warranty

    To implement this limited warranty, send a written notice stating your name, date, and place of purchase and a brief description of the defect along with your receipt to Stamina Products, Inc. 2040 N Alliance Ave, Springfield, Missouri, USA, MO 65803, or email us at customer.care@staminaproducts.com, or call us at 1-800-375-7520.

  • Page 21: Notes

    NOTES...

  • Page 22: Fax/Mail Ordering Form

    2040 N Alliance Ave, Springfield, MO 65803 Would you like to recieve email information or special offers from Stamina Products? Register at contact.staminaproducts.com TO REGISTER YOUR PRODUCT To enact your warranty, please register your product by going to register.staminaproducts.com. Please have your product model number (printed on the cover of this owner’s manual) and the serial number (printed on the black and white sticker on your...

This manual is also suitable for:

Aeropilates 55-5604
