Bluetooth® Low Energy Custom Service Implementation

Introduction

This document demonstrates how to use the ATBTLC1000 Bluetooth
custom specific profile using the
•
Technical overview of the ATBTLC1000 board from hardware architecture to software design
•
Description of the required process for developing the Bluetooth Low Energy peripheral application
with the ATBTLC1000
•
Handling of Bluetooth Low Energy custom services and characteristics
Note:  The custom service implementation procedure uses the
procedure is also applicable for other supported platforms, as mentioned in
Figure 1. Bluetooth Low Energy System Solution with ATBTLC1000
©
2017 Microchip Technology Inc.
Microchip
BluSDK. This document includes the following topics:
Training Manual
ATBTLC1000
®
Low Energy SoC by building a
ATBTLC1000ZR-XSTK
kit. This
BluSDK Release
Notes.
DS00002599A-page 1
