05.04.2019
engineering and production center
OPERATING MANUAL
Technical description.Installation manual.Certificate.
ПШБА.304268.303 РЭ
PATENT FOR INVENTION
No.2615712
1. PURPOSE
The electromechanical locks series Promix-SM306 with a hook-shaped locking mechanism
(below called the locks) are intended to be use as actuating devices in an access control system
(ACS) for locking doors of offices and administrative rooms with a door frame ledge wider than 25
mm.
2. LABELING
The label stuck to the lock body contains
the following information:
1.
Lock model.
2.
Patent number.
3.
Nominal supply voltage.
4.
Nominal consumed current.
5.
Date of manufacture and QCD mark
6.
Identification number.
Manufacturer's website.
7.
For the list of lock modifications that can be ordered, see 5.2.
The color of the product is shown on the sticker stuck to the box, after the product name. Series
colors: Silver, White, Brown.
Other colors are provided optionally.
Supply voltage:
0 - 12V.
Version:
0 - normally opened, 1 - normally closed
ELECTROMECHANICAL LOCK
Promix-SM306
1
ELECTROMECHANICAL LOCK
2
Patent No. 2474661
12 V=0.1 A
3.4
Made in Russia
No. 100 001008
6.7
An example of information
layout on the label.
5
1
Advertisement
Table of Contents
Related Manuals for PROMIX Promix-SM306
Summary of Contents for PROMIX Promix-SM306
- Page 1 No.2615712 1. PURPOSE The electromechanical locks series Promix-SM306 with a hook-shaped locking mechanism (below called the locks) are intended to be use as actuating devices in an access control system (ACS) for locking doors of offices and administrative rooms with a door frame ledge wider than 25 2.
-
Page 2: Design And Principle Of Operation
Promix-SM306 3. SET OF DELIVERY 1 – Lock 1 pc. Base 2 – Latch edge 1 pc. 3 –Adjustment plate 1 pc. (in the as-delivered condition, screwed to the lock with screws 4) 4 – Screw М4х16 (countersunk) 4 pcs. -
Page 3: Technical Data
Promix-SM306 5. TECHNICAL DATA OPERATING CONDITIONS The lock operation environment must be explosion-safe, free of current-conducting dust or gases that cause metal corrosion and destroying insulation of current conductors and electric elements, free of current-carrying dust or water vapor, and preventing ingress of water, steam, fuel and lubricants. -
Page 4: Installation And Connection
Promix-SM306 Lock and latch overall and mounting dimensions. 6. INSTALLATION AND CONNECTION 6.1 LOCK AND LATCH MOUNTING 1. Apply the lock1 with inserted latch 2 and fitted over angular template 10 to the planned mounting place so that: a) The required clearances are ensured between the latch and the lock, the clearances being provided by the angulartemplate10 (see Fig. - Page 5 Promix-SM306 and the opening for the lock power wire. 4. Drill holes Ø2mm (Ø5mm for the power wire) and fix the plate with self-tapping screws 6. 5. Pull the latch out of the lock.Mount the lock 1 on the adjustment plate 3 using screws 4.
-
Page 6: Troubleshooting
Promix-SM306 See operating voltage range in 5.2. Avoid supply of overvoltage. Example of the lock connection to the remote control system Promix-RDS. ~220 V Lock Controller Promix-CR.RX Remote control Promix-CR.TX Provide a reliable electric contact. To prevent short-circuit, insulate places of connection. -
Page 7: Maintenance
13. WARRANTY LIABILITIES The manufacturer, ETC PROMIX LLC, warrants conformity of Promix-SM306 locks to requirements of current Technical Specifications provided that transportation, storage, installation and operation rules established in this Manual are followed. - Page 8 Promix-SM306 Within the period of warranty, ETC PROMIX LLC undertakes to repair defective products free of charge. Expenses for transporting the product to the place of repair and back will be borne by the Buyer. Warranty liabilities do not cover any defects and damages caused by: ...
