7.3 LEDs

There are nine LEDs present.
One panel-mount LED indicates the emergency call progress.
One panel-mount optional 2
Seven PCB-mounted LEDs provide the essential diagnostic and status information at a glance:
1. Heartbeat (pulsing green) (located behind the keypad)
2. Power (green)
3. PLM (normal = green; alarm = red; if no mains power = off to conserve battery)
4. Alarm (normal = off; solid red = alarm with power; flashing red = alarm on battery power)
5. Wake Keypad (awake = green)
6. Program mode (green)
7. Line test - test call in progress (green)

8 Ordering

EMC-60 ABC
EC Emergency Hands-free phone
With options:
A = Second call button with 2nd button phone number or
B = Second LED
C = False alarm monitoring (requires input from elevator door curtain contact)
nd
LED available.
