Hot Food Holding
Carving Station
Models:
CS-100
CS-200
CS-200 with Breath Guard
CS-100 with Breath Guard
• Installation
• Operation
• Maintenance
W164 N9221 Water Street • P.O. Box 450
Menomonee Falls, Wisconsin 53052-0450 U.S.A.
262.251.3800 • 800.558.8744
PHONE:
U.S.A. / CANADA
262.251.7067 • 800.329.8744
FAX:
U.S.A. ONLY
Consult instructions
www.alto-shaam.com
for operation and use.
MN-29250 (Rev. 6) • 05/18
Printed in U.S.A.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Alto-Shaam CS-100
Summary of Contents for Alto-Shaam CS-100
- Page 1 Hot Food Holding Carving Station Models: CS-100 CS-200 CS-200 with Breath Guard CS-100 with Breath Guard • Installation • Operation • Maintenance W164 N9221 Water Street • P.O. Box 450 Menomonee Falls, Wisconsin 53052-0450 U.S.A. 262.251.3800 • 800.558.8744 PHONE: U.S.A. / CANADA 262.251.7067 •...
-
Page 2: Table Of Contents
Table of Contents Warranty and Service Information . . . . . . . . . . . . . . . . . . . . . . . 3 Delivery . -
Page 3: Warranty And Service Information
Extend Your Manufacturer’s Warranty Register Register your Alto-Shaam appliance online, and you will automatically be entered into a monthly drawing to win an additional year extended warranty! Registering your appliance ensures prompt service in the event of a warranty claim. You will also receive direct notifications of software updates and additional product information. -
Page 4: Delivery
. This manual must be read and understood by all people using or installing the appliance . Contact the Alto-Shaam Tech Team Service Department if you have any questions concerning installation, operation, or maintenance . -
Page 5: Transportation Damage And Claims
. fi led and actively pursued . Alto-Shaam cannot, however, 2 . Do not sign a delivery receipt or a freight bill until fi le any damage claims, assume the responsibility of any a proper count has been made and inspection of all claims, or accept deductions in payment for such claims . -
Page 6: Unpacking
Alto-Shaam of all liability . • Remove all protective plastic fi lm, packaging materials, and accessories from the appliance before connecting electrical power . Store any accessories in a convenient place for future use . -
Page 7: Safety Procedures
. Operating instructions and warnings must WARNING be read and understood by all operators and users . Alto-Shaam recommends regular staff training to avoid Indicates a hazardous situation that, if not avoided, could the risk of accident or damage to the appliance . Operators result in death or serious injury. - Page 8 If your appliance makes an especially loud noise Children should be supervised to ensure that they do not warranty and relieve Alto-Shaam of all liability . when starting up, shut down the appliance and call a play with the appliance.
-
Page 9: Installation
Installation WARNING CAUTION Appliance and accessories may be Improper installation, alteration, adjustment, service, heavy. To prevent serious injury, always cleaning, or maintenance could result in property use a suff icient number of trained and damage, severe injury, or death. experienced workers when moving or Read and understand the installation, operating and leveling appliance and handling accessories. - Page 10 Installation CS-100 Heated product capacity Accessories Weight, maximum 40 lbs (18 kg) Cutting Board - 13-3/4" x 16” x 1/2" BA-28482 (349mm x 406mm x 13mm) Meat size Small steamship round Carving Holder - Prime Rib HL-2635 Carving Holder - Steamship...
- Page 11 Installation CS-200 Heated product capacity Accessories Full-Size Cutting Board - Weight, maximum 70 lbs (31 .7 kg) 21-5/8" x 21-5/8" x 1/2" BA-28066 Meat size Large steamship round (550mm x 550mm x 13mm) Half-Size Cutting Board 10-3/4" x 21-5/8" x 1/2" BA-29244 (273mm x 550mm x 13mm) Carving Holder - Prime Rib...
- Page 12 Installation CS-100 over 500 18-3/8" (466mm) CS-200 over 750 25-7/8" (657mm) MN-29250 • Rev 6 • 05/18 • Carving Station...
-
Page 13: Electrical Connection
Read and understand the installation, operating and maintenance instructions thoroughly before installing, servicing, or operating this equipment. 1 . An identification tag is permanently mounted on the Electrical - CS-100 carving station . 2 . If necessary, a proper receptacle or outlet NEMA 5-15P 4 .2... -
Page 14: Operation
Operation Operating procedures WARNING 1. Set rocker switches To prevent serious injury, death, or property Set rocker switch for heated surface to the On ( ) damage, always disconnect the appliance position . Set 3-way rocker switch to the desired holding from the power source before cleaning temperature (low/medium/high) . -
Page 15: Cleaning And Preventative Maintenance
Cleaning and Preventative Maintenance Protecting Stainless Steel Surfaces Cleaning Agents It is important to guard against corrosion Use non-abrasive cleaning products designed for in the care of stainless steel use on stainless steel surfaces . Cleaning agents must surfaces . Harsh, corrosive, be chloride-free compounds and must not contain or inappropriate chemicals quaternary salts . - Page 16 Cleaning and Preventative Maintenance Equipment Care WARNING The cleanliness and appearance of this equipment will contribute To prevent serious personal injury, death, or considerably to operating property damage: efficiency and savory, appetizing Do not steam clean, hose down or flood the food .
-
Page 17: Food Safety
Food Safety Food fl avor and aroma are usually so closely related that it Internal Food Product Temperatures is diffi cult, if not impossible, to separate them . There is also Hot Foods an important, inseparable relationship between cleanliness Danger Zone 40°F to 140°F 4°C to 60°C and food fl avor . -
Page 18: Service
Service CS-100 201401/201402 DETAIL A DETAIL C DETAIL D DETAIL B Part numbers and drawings are subject to change without notice . MN-29250 • Rev 6 • 05/18 • Carving Station... - Page 19 Service CS-100 201401/201402 Item Description Part No. L-Bracket 1008529 — — — Relay Attachment L-Bracket 1011286 Breath Guard Bracket 1011870 — — — Top Base Panel Spot 5008801 Base Housing Cover Panel 5008802 — — — Cutting Board BA-28482 Block, Modular, 5 Pole...
- Page 20 Service CS-200 201301/201302 Part numbers and drawings are subject to change without notice . MN-29250 • Rev 6 • 05/18 • Carving Station...
- Page 21 Service CS-200 201301/201302 Item Description Part No. L-Bracket 1008529 Insulation IN-22265 Breath Guard Bracket 1011870 Top Base Panel Spot 5007406 Bottom Cover Panel Hex Insert 5007447 Cutting Board BA-28066 Block, Modular, 5 Pole BK-25567 Bumper 3/8-16 Male Thread BM-22606 Bushing, 3/4" White, Snap BU-3008 Bushing, Strain Relief, 90°, Black BU-34898...
- Page 22 Service Breath Guard Kits CS-100 - 5012582 Item Description Part No. Quantity Bracket 1011870 Frame FR-28484 Glass, tempered, 5mm, Upper GL-29240 Glass, tempered, 5mm, Lower GL-29241 Screw, .8-32x3/8, 1/2 dia . head SC-2816 CS-200 - 5009074 Item Description Part No.
-
Page 23: Wiring Diagrams
Wiring Diagrams MN-29250 • Rev 6 • 05/18 • Carving Station... - Page 24 Wiring Diagrams MN-29250 • Rev 6 • 05/18 • Carving Station...
-
Page 25: Limited Warranty
This warranty is exclusive and is in lieu of all other warranties, express or implied, including the implied warranties of merchantability and fi tness for a particular purpose . In no event shall Alto-Shaam be liable for loss of use, loss of revenue or profi t, or loss of product, or for any indirect, special, incidental, or consequential damages .
