H e a t e d D i s p l a y C a s e s
F u l l S e r v i c e o r S e l f S e r v i c e
Models:
ED2sys-48
ED2-48; ED2SYS-48
ED2-48/P; ED2SYS-48/P
EU2SYS-48; EU2SYS-48/P
ED2-72; ED2SYS-72
ED2-48
ED2-72/P; ED2SYS-72/P
ED2-72/PL; ED2SYS-72/PL
ED2-72/PR; ED2SYS-72/PR
ED2sys-72
EU2SYS-72; EU2SYS-72/P
EU2SYS-72/PL
EU2SYS-72/PR
ED2-96; ED2SYS-96
ED2-96/PL; ED2SYS-96/PL
ED2-72
ED2-96/PR; ED2SYS-96/PR
EU2SYS-96; EU2SYS-96/P
EU2SYS-96/PL
EU2SYS-96/PR
ED2sys-96
• InstallatIon
• operatIon
• MaIntenance
ED2-96
W164 N9221 Water Street • P.O. Box 450 • Menomonee Falls, Wisconsin 53052-0450 USA
PHONE: 262.251.3800 • 800.558.8744
/
FAX: 262.251.7067 • 800.329.8744
.
.
.
USA
CANADA
U
S
A
ONLY
www.alto-shaam.com
M N - 2 8 8 2 0 • 0 3 / 1 1
.
.
.
p r i n t e d i n u
s
a
