- Page 1 SD700SP VARIABLE SPEED DRIVE FOR SOLAR PUMPING HARDWARE AND INSTALLATION MANUAL www.power-electronics.com...
- Page 3 Variable Speed Drive for Solar Pumping Hardware and Installation Manual Edition: December 2017 SD7SPMTHW02AI Rev. A...
- Page 4 First Edition The equipment and technical documentation are periodically updated. Power Electronics reserves the right to modify all or part of the contents of this manual without previous notice. To consult the most updated information of this product, you may access our website www.power-electronics.com, where the latest version of this manual can be downloaded.
-
Page 5: Table Of Contents
POWER ELECTRONICS SD700SP TABLE OF CONTENTS SAFETY SYMBOLS ............................. 5 SAFETY INSTRUCTIONS ..........................6 INTRODUCTION ........................... 10 Hybrid System ............................ 11 Isolated System ..........................12 CONFIGURATION TABLE AND STANDARD RATINGS ..............13 Configuration Table ..........................13 Standard Ratings ..........................13 TECHNICAL CHARACTERISTICS ...................... - Page 6 SD700SP POWER ELECTRONICS MAINTENANCE ............................ 54 Warnings ............................54 Routine Inspection ..........................54 CE MARKING ............................56 EMC Directive............................. 56 Low Voltage Directive ......................... 56 TABLE OF CONTENTS...
-
Page 7: Safety Symbols
POWER ELECTRONICS SD700SP SAFETY SYMBOLS Always follow safety instructions to prevent accidents and potential hazards from occurring. In this manual, safety messages are classified as follows: Identifies potentially hazardous situations where dangerous voltage may be present which if not avoided could result in minor personal injury, serious... -
Page 8: Safety Instructions
Read this manual carefully to maximize the performance of this product and to ensure its safe use and installation. Power Electronics accepts no responsibility or liability for any damage resulting from inappropriate use of the equipment. In this manual, safety messages are classified as follows: WARNING Do not remove the metal cover while the power is applied or the unit is in operation. - Page 9 The SD700SP are carefully tested and perfectly packed before delivering. ▪ In the event of transport damage, please ensure that you notify the transport agency and POWER ELECTRONICS: 902 40 20 70 (International +34 96 136 65 57) or your nearest agent, within 24hrs from receiving the goods. UNPACKING ▪...
- Page 10 • Do not disconnect motor cables if input power supply remains connected. • The internal circuits of the SD700SP Series will be damaged if the incoming power is connected and applied to output terminals (U, V, W).
- Page 11 Otherwise, it may lead to injury to people. • Do not modify or alter internal wiring and spare parts without Power Electronics supervision. • Before programming or operating the SD700SP Series, initialise all parameters back to factory default values.
-
Page 12: Introduction
POWER ELECTRONICS INTRODUCTION Power Electronics has a strong commitment to reduce the levelized cost of water (LCoW) by offering upgraded energy saving solutions. Synergies between our Industrial and Solar Divisions have come together in the SD700 SOLAR POWER – SD700SP. This unique product takes advantage of the outstanding features of the SD700 variable speed drive to power pumping systems from either the solar PV panels (off-grid) or simultaneously from the PV panels and grid supply (PV solar assisted). -
Page 13: Hybrid System
PV panels connected in series. The number of strings in parallel will be determined according to the pump power. Power Electronics has developed a system, which is able to use all DC energy available and it takes only power from the AC supply when it is needed. This system connects/disconnects the AC input to the mains therefore avoids the need of having a "stand by"... -
Page 14: Isolated System
30Hz to 45Hz), which generates a minimum pump flow. At the same time, the frequency range determines the minimum power threshold and therefore PV sizing. With the MPPt dynamic search algorithm developed by Power Electronics, the SD700SP searches for the Maximum Power Point automatically, therefore the PV field will always supply the maximum power available. -
Page 15: Configuration Table And Standard Ratings
SD7SP00385 18,5 SD7SP00485 SD7SP00605 SD7SP0075 5 SD7SP00905 SD7SP0115 5 SD7SP0150 5 SD7SP0170 5 SD7SP0210 5 SD7SP02505 SD7SP0275 5 SD7SP03305 SD7SP03705 SD7SP04605 SD7SP05805 SD7SP06505 SD7SP072 05 1080 SD7SP08405 1260 Higher power drives available. Consult Power Electronics. CONFIGURATION TABLE AND STANDARD RATINGS... -
Page 16: Technical Characteristics
[2] For operation frequencies higher than 100Hz, consult Power Electronics. [3] Valid for frames 3 to 8, depending on the rated power, the input voltage and under Power Electronics' installation recommendations. For Frames 1 and 2, optional filters are available. -
Page 17: Dc Configuation Limits
POWER ELECTRONICS SD700SP DC CONFIGUATION LIMITS The following definitions are technical characteristics of the photovoltaic panel: • Isc: maximum current obtained by short-circuiting the two terminals (positive and negative) of the module. During the short circuit the voltage between terminals is 0V. -
Page 18: Dimensions & Weight
SD700SP POWER ELECTRONICS DIMENSIONS & WEIGHT NOTICE The dimensions and weight described in this manual are for the SD700SP without solar kit. DIMENSIONS [mm] FRAME WEIGHT [kg] Height (H) Width (W) Depth (D) 67,5 1245 1712 1712 1712 1132 1712... -
Page 19: Reception, Handling And Transportation
The SD700SP are carefully tested and perfectly packed before delivering. In the event of transport damage, please ensure that you notify the transport agency and Power Electronics: 902 40 20 70 (International +34 96 136 65 57) or your nearest agent, within 24hrs from receipt of the goods. - Page 20 SD700SP POWER ELECTRONICS Unpack the drive carefully. Do not use edge tool to protect the product from damage. After open the package, please check the goods contained. Verify the item numbers contained within the package with the packing inventory list. Please set aside and reserve, if contained, the case of spare parts shipped with the product.
- Page 21 POWER ELECTRONICS SD700SP the drive on the floor, stop lowering it just before reaching the floor and then slowly lower it on the floor to avoid any shock. During handling and transportation, the goods should not be exposed to moisture, overturned, inverted, tilted or impacted.
-
Page 22: Mechanical Installation
SD700SP POWER ELECTRONICS MECHANICAL INSTALLATION CAUTION The installation must be done by qualified personal. Otherwise, the equipment can get damaged and lead to injury to people. NOTICE The mechanical installation described in this manual is for the SD700SP without solar kit. -
Page 23: Drive Mounting
SD700SP without solar kit. Wall mounting drives The variable speed drives of the SD700SP series from frame 1 to 4 are wall-mounting drives. Additionally frame 4 has available an optional plinth that converts it into a stand-alone cabinet. -
Page 24: Clearances
The heat sources inside the equipment correspond with the inverter bridge (IGBTs), rectifier bridge, the input filter and the output dV/dt filter. SD700SP series present an overall efficiency higher than 98% at rated power, so the heat dissipation approximately corresponds to 2% of the input power. - Page 25 POWER ELECTRONICS SD700SP Cooling airflow for SD700SP (Protection Grade IP54). Area - Electronics: IP20 cabinets are equipped with fans on the top of the cabinet that evacuates the internal heat generated in the area. IP54 cabinets have totally sealed electronics. The internal heat generated is evacuated through the metallic doors by an internal forced convection system.
- Page 26 SD700SP POWER ELECTRONICS SD700SP gratings and fans FRAMES OPERATION FLOW (m /h) (*) 64-77 239-287 306-367 342-410 396-475 486-583 720-864 AREA 2 INLET GRATING NET SECTION (m 0.081 0.016 0.025 0.031 0.034 0.064 0.101 OUTLET GRATING NET SECTION (m 0.003 0.013 0.017...
-
Page 27: Power Connection
POWER ELECTRONICS SD700SP POWER CONNECTION CAUTION Read carefully the following installation instructions for a correct electrical installation. Otherwise, it could cause damage to the equipment and lead to injury to people. In solar pumping installations the solar field must be with floating earth, without connecting any pole to ground. -
Page 28: Dc Configuration
Blocking diode: To prevent the current from the grid flowing back the photovoltaic panels. DC protections, solar kit components Customer is responsible for installing the solar kit. For other options consult Power Electronics. Topology SD700SP drive operates according to the principle of pulse-width modulation (PWM). Varying the power... - Page 29 The inverter bridge generates the PWM wave that controls the motor performance (voltage, current, torque, etc...). SD700SP Series by Power Electronics, integrate as standard output dV/dt filters and a CLAMP system that reduces significantly the dV/dt rise time below 500V/μs - 800V/μs, therefore, it reduces the voltages peaks at the motor windings, the common mode currents and the EMC emissions.
- Page 30 SD700SP POWER ELECTRONICS SD700SP frames 1 and 2 power electronics SD700SP frames 3 and 4 power electronics SD700SP frames 5 to 8 power electronics POWER CONNECTION...
-
Page 31: Power Connection And Wiring
The following installation recommendations are suitable for TN and TT grids. For IT grids consult Power Electronics. Otherwise, it could cause damage to the equipment and lead to injury to people. Wiring and periodic inspections should be performed at least 10 minutes after disconnecting the input power. - Page 32 SD700SP POWER ELECTRONICS AC TERMINALS (L1-L2-L3) DC TERMINALS ( HVDC+ ,HVDC-) • • It is recommended to use Ø11 tin plated It is recommended to use Ø9 tin plated aluminium aluminium or coper terminal lugs. or copper terminal lugs. •...
- Page 33 POWER ELECTRONICS SD700SP CAUTION Line voltage (input supply) must never be connected to U, V and W terminals. Otherwise, the drive will be damaged. It is necessary that installer guarantee the correct observance of the law and the regulations that are in force in those countries or areas where this device is going to be installed.
- Page 34 SD700SP POWER ELECTRONICS It is recommended to route in separately cable racks, trays or ducts, the following cable types: ▪ Single-wire signal or data cables with V< 60V ▪ Single wire cable with 60V<V< 230V ▪ Input power cables with low level of interferences 230V<V<1000V ▪...
-
Page 35: Ground Connection
In hybrid solar pumping system, the diesel generator must be grounded for a TT configuration. For other configurations consult with Power Electronics. For safety reasons, it is determinant to measure the grounding resistance of the plant itself. This must be established before the first start up of the plant and with the drive disconnected. -
Page 36: Emc Installation Requirements
SD700SP POWER ELECTRONICS EMC Installation Requirements Introduction The European EMC Directive defines electromagnetic compatibility as follows: the capability of an apparatus, an industrial plant, or a system to work satisfactorily in the electromagnetic environment without at the same time causing electromagnetic disturbance, which would be unacceptable to apparatus, industrial plant, or systems present in this environment. - Page 37 POWER ELECTRONICS SD700SP The two environments are divided in four categories C1 to C4 that are summarized in the following table. FIRST ENVIRONMENT SECOND ENVIRONMENT Restricted Installation [1] YES [2] Notes [1]. “Restricted Installation” means that the installation and commissioning must be carried out by specialist personnel.
- Page 38 SD700SP POWER ELECTRONICS Correct output motor cables shield bonding It is recommended for control signals to use shielded cable and to follow recommendations included in section ” Wiring recommendations”. CAUTION Select communication and control system according to the drive EMC environment. Otherwise, systems could suffer from interferences due to a low EMS level.
-
Page 39: Ac Protections
POWER ELECTRONICS SD700SP AC Protections Short circuit SD700SP includes from frame 5 to 8 ultra fast fuses as standard. Frame 5 includes one fuse per phase with a rated current that depends on the drive’s nominal current. Frames 6 on are constructed through the parallel connection of frame 5 so the fuses per phase in those frames correspond with the number of parallel drive modules (frame 5) interconnected. -
Page 40: Dc Protections
To protect the photovoltaic field and the grounding equipment. On-load Breaker. To be able to open the circuit while the load on the system is connected. Power Electronics recommends the equipment being off before opening the breaker in order not to damage the variable speed drive capacitors. -
Page 41: Power Terminals
POWER ELECTRONICS SD700SP Power terminals Connections for Frame 1 Connections for Frame 2 POWER CONNECTION... - Page 42 SD700SP POWER ELECTRONICS Connections for Frame 3 Connections for Frame 4 POWER CONNECTION...
- Page 43 POWER ELECTRONICS SD700SP Connections for Frame 5 POWER CONNECTION...
- Page 44 SD700SP POWER ELECTRONICS Connections for Frame 6 POWER CONNECTION...
- Page 45 POWER ELECTRONICS SD700SP Connections for Frame 7 POWER CONNECTION...
- Page 46 SD700SP POWER ELECTRONICS Connections for Frame 8 POWER CONNECTION...
-
Page 47: Control Connection
POWER ELECTRONICS SD700SP CONTROL CONNECTION Wiring recommendations Before planning the installation, follow the next recommendations. The parallel cable routing should be minimized and the distance between the control wiring and the power wiring should be maximized. It is recommended to route control cables with different voltages in separately cable racks, trays or ducts. -
Page 48: Control Board Terminals Description
SD700SP POWER ELECTRONICS Control board terminals description CAUTION Changes of control wiring or bridges should be performed at least 10 minutes after disconnecting the input power and after checking the DC Link voltage is discharged with a meter (below 30VDC). - Page 49 POWER ELECTRONICS SD700SP The control terminals X1 and X2 for the solar pumping drive SD700SP are: • Terminals 1 and 2 (DI1): Start / Stop. • Terminals 1 and 3 (DI2): Manual / Automatic (Only with pressure control). • Terminals 1 and 5 (DI4): Diesel generator group state.
- Page 50 SD700SP POWER ELECTRONICS The following figure provides an overview of the standard wiring of control terminals through the X1 and X2 user connectors for the standard SD700: CONTROL CONNECTION...
-
Page 51: Modbus Communication
POWER ELECTRONICS SD700SP MODBUS COMMUNICATION Introduction To guarantee a correct operation of the drive, peripheral elements should be selected correctly and should be connected properly. A wrong installation and/or application could cause a wrong operation of the system or a reduction of the long life of the equipment, and its parts may be damaged. This manual should be read carefully and understood before proceeding. -
Page 52: Hardware Technical Specifications
SD700SP POWER ELECTRONICS Hardware technical specifications Physical level 3 cables, optically insulated, half duplex, RS232 single ending Terminals 23 RS Common (0VDC) 24 RS232 Rx (receiving line) 25 RS232 Tx (transmitting line) Output signal level '1' logical ≤ 6.5V regarding to 0V '0' logical ≥... -
Page 53: Rs232 Connections
POWER ELECTRONICS SD700SP RS232 Connections The following diagram shows a common wiring for a RS232 connection: RS485 Connections The following diagram shows a common wiring for a RS232 connection RS485: MODBUS COMMUNICATION... -
Page 54: Commissioning
SD700SP POWER ELECTRONICS COMMISSIONING CAUTION Only qualified personnel are allowed to commission the drive. Read and follow the safety instructions on the first pages of this manual. Neglecting the safety instructions can cause injury or death. Ensure that there is no voltage present in the input power terminals and no voltage can be connected to the drive inadvertently. - Page 55 POWER ELECTRONICS SD700SP Check that the drive protective covers are mounted and doors are properly closed. Check control, and analogue and digital signals cables, functions. Voltage free. Check that the drive follows the remote and local speed commands. Connect input power supply.
- Page 56 SD700SP POWER ELECTRONICS MAINTENANCE SD700SP drives consist of advanced semiconductor devices. Temperature, humidity, vibration and deteriorated components can reduce their efficiency. To avoid any possible irregularity, we recommend making periodic inspections. Warnings • Make sure to remove the input power while performing maintenance.
- Page 57 POWER ELECTRONICS SD700SP Period Inspection Instrument of Inspection Inspection method Criterion element Measurement Is the conductor Conductor/ corroded? Visual check. No anomaly. Cable Is the sheathing of the cable damaged? Terminal Is any damage visible? Visual check. No anomaly. Disconnect the cables of the...
- Page 58 EMC Directive The EMC Directive defines the requirements for immunity and emissions of electrical equipment used within the European Union. SD700SP Series drives are in accordance with the directive IEC 61800- 3:2004 about adjustable speed electrical power drive systems. Low Voltage Directive The low voltage directive defines the security requirements of low voltage electrical equipment in order to circulate freely within the European Economic Area.
- Page 59 DECLARATION OF CONFORMITY CE DECLARACIÓN DE CONFORMIDAD CE References of the harmonized technical norms applied under the Machinery Directive:...
- Page 60 24h Technical Assistance 365 days a year Find your nearest delegation: http://power-electronics.com/contact/ Follow us on:...
